검색해 본 것과 비슷한 질문을 여러 개 찾았지만 답변이 없거나 내 경우에는 답변이 작동하지 않는 경우가 많습니다. 추가된 세부정보가 내 문제를 디버깅하는 데 도움이 되기를 바랍니다.
내 Raspberry Pi B+에는 포트 443/TCP에서 실행되는 OpenVPN이 있습니다. UFW가 활성화된 경우에도 성공적으로 연결할 수 있지만 장치가 인터넷에 액세스할 수 없습니다. UFW를 비활성화하면 VPN이 올바르게 작동합니다.
흥미롭게도 UFW를 비활성화하고 재설정한 다음 53, 80, 443 및 10.8.0.0/24의 모든 항목을 허용하도록 규칙을 다시 추가해 보았습니다. 이것은 약간의 효과가 있었습니다(첫 번째 재부팅 후 작동이 멈춘 것 같습니다).
고양이 /var/log/ufw.log
# 100s of near identical lines ommitted
Aug 24 20:14:25 raspberrypib kernel: [ 559.195772] [UFW BLOCK] IN=tun0 OUT=enxb827eb4217d2 MAC= SRC=10.8.0.2 DST=172.217.25.36 LEN=60 TOS=0x00 PREC=0x00 TTL=63 ID=42717 DF PROTO=TCP SPT=50554 DPT=443 WINDOW=65535 RES=0x00 SYN URGP=0
Aug 24 20:14:25 raspberrypib kernel: [ 559.343362] [UFW BLOCK] IN=tun0 OUT=enxb827eb4217d2 MAC= SRC=10.8.0.2 DST=216.58.220.106 LEN=1378 TOS=0x00 PREC=0x00 TTL=63 ID=12146 DF PROTO=UDP SPT=46888 DPT=443 LEN=1358
Aug 24 20:14:46 raspberrypib kernel: [ 580.290379] [UFW BLOCK] IN=tun0 OUT=enxb827eb4217d2 MAC= SRC=10.8.0.2 DST=216.58.200.99 LEN=60 TOS=0x00 PREC=0x00 TTL=63 ID=63518 DF PROTO=TCP SPT=35938 DPT=443 WINDOW=65535 RES=0x00 SYN URGP=0
이는 UFW가 의도적으로 내 트래픽을 차단하고 있음을 암시하는 것 같지만 필요한 규칙이 있다고 믿습니다. 들어오고 나가는 모든 트래픽이 tun0허용되어야 합니다. 10.8.0.0/24의 트래픽이 허용되어야 합니다.
ufw 상태 장황함
Status: active
Logging: on (low)
Default: deny (incoming), allow (outgoing), allow (routed)
New profiles: skip
To Action From
-- ------ ----
22 ALLOW IN Anywhere
443 ALLOW IN Anywhere
80 ALLOW IN Anywhere
443/tcp ALLOW IN Anywhere
Anywhere ALLOW IN 10.8.0.0/24
53 ALLOW IN Anywhere
Anywhere on tun0 ALLOW IN Anywhere
22 (v6) ALLOW IN Anywhere (v6)
443 (v6) ALLOW IN Anywhere (v6)
80 (v6) ALLOW IN Anywhere (v6)
443/tcp (v6) ALLOW IN Anywhere (v6)
53 (v6) ALLOW IN Anywhere (v6)
Anywhere (v6) on tun0 ALLOW IN Anywhere (v6)
Anywhere ALLOW OUT Anywhere on tun0
Anywhere (v6) ALLOW OUT Anywhere (v6) on tun0
IP 경로 | grep 기본값
default via 192.168.1.1 dev enxb827eb4217d2 src 192.168.1.101 metric 202
고양이 /etc/ufw/before.rules
#
# rules.before
#
# Rules that should be run before the ufw command line added rules. Custom
# rules should be added to one of these chains:
# ufw-before-input
# ufw-before-output
# ufw-before-forward
#
# START OPENVPN RULES
# NAT table rules
*nat
:POSTROUTING ACCEPT [0:0]
# Allow traffic from OpenVPN client to masquerade
-A POSTROUTING -s 10.8.0.0/24 -o enxb827eb4217d2 -j MASQUERADE
COMMIT
# END OPENVPN RULES
# Don't delete these required lines, otherwise there will be errors
*filter
:ufw-before-input - [0:0]
:ufw-before-output - [0:0]
:ufw-before-forward - [0:0]
:ufw-not-local - [0:0]
# End required lines
# allow all on loopback
-A ufw-before-input -i lo -j ACCEPT
-A ufw-before-output -o lo -j ACCEPT
# quickly process packets for which we already have a connection
-A ufw-before-input -m conntrack --ctstate RELATED,ESTABLISHED -j ACCEPT
-A ufw-before-output -m conntrack --ctstate RELATED,ESTABLISHED -j ACCEPT
-A ufw-before-forward -m conntrack --ctstate RELATED,ESTABLISHED -j ACCEPT
# drop INVALID packets (logs these in loglevel medium and higher)
-A ufw-before-input -m conntrack --ctstate INVALID -j ufw-logging-deny
-A ufw-before-input -m conntrack --ctstate INVALID -j DROP
# ok icmp codes for INPUT
-A ufw-before-input -p icmp --icmp-type destination-unreachable -j ACCEPT
-A ufw-before-input -p icmp --icmp-type source-quench -j ACCEPT
-A ufw-before-input -p icmp --icmp-type time-exceeded -j ACCEPT
-A ufw-before-input -p icmp --icmp-type parameter-problem -j ACCEPT
-A ufw-before-input -p icmp --icmp-type echo-request -j ACCEPT
# ok icmp code for FORWARD
-A ufw-before-forward -p icmp --icmp-type destination-unreachable -j ACCEPT
-A ufw-before-forward -p icmp --icmp-type source-quench -j ACCEPT
-A ufw-before-forward -p icmp --icmp-type time-exceeded -j ACCEPT
-A ufw-before-forward -p icmp --icmp-type parameter-problem -j ACCEPT
-A ufw-before-forward -p icmp --icmp-type echo-request -j ACCEPT
# allow dhcp client to work
-A ufw-before-input -p udp --sport 67 --dport 68 -j ACCEPT
#
# ufw-not-local
#
-A ufw-before-input -j ufw-not-local
# if LOCAL, RETURN
-A ufw-not-local -m addrtype --dst-type LOCAL -j RETURN
# if MULTICAST, RETURN
-A ufw-not-local -m addrtype --dst-type MULTICAST -j RETURN
# if BROADCAST, RETURN
-A ufw-not-local -m addrtype --dst-type BROADCAST -j RETURN
# all other non-local packets are dropped
-A ufw-not-local -m limit --limit 3/min --limit-burst 10 -j ufw-logging-deny
-A ufw-not-local -j DROP
# allow MULTICAST mDNS for service discovery (be sure the MULTICAST line above
# is uncommented)
-A ufw-before-input -p udp -d 224.0.0.251 --dport 5353 -j ACCEPT
# allow MULTICAST UPnP for service discovery (be sure the MULTICAST line above
# is uncommented)
-A ufw-before-input -p udp -d 239.255.255.250 --dport 1900 -j ACCEPT
# don't delete the 'COMMIT' line or these rules won't be processed
COMMIT
IP 주소 표시 tun0
3: tun0: <POINTOPOINT,MULTICAST,NOARP,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UNKNOWN group default qlen 100
link/none
inet 10.8.0.1/24 brd 10.8.0.255 scope global tun0
valid_lft forever preferred_lft forever
inet6 fe80::b3bb:ee7d:df9e:3f65/64 scope link flags 800
valid_lft forever preferred_lft forever
고양이 /etc/default/ufw
# /etc/default/ufw
#
# Set to yes to apply rules to support IPv6 (no means only IPv6 on loopback
# accepted). You will need to 'disable' and then 'enable' the firewall for
# the changes to take affect.
IPV6=yes
# Set the default input policy to ACCEPT, DROP, or REJECT. Please note that if
# you change this you will most likely want to adjust your rules.
DEFAULT_INPUT_POLICY="DROP"
# Set the default output policy to ACCEPT, DROP, or REJECT. Please note that if
# you change this you will most likely want to adjust your rules.
DEFAULT_OUTPUT_POLICY="ACCEPT"
# Set the default forward policy to ACCEPT, DROP or REJECT. Please note that
# if you change this you will most likely want to adjust your rules
DEFAULT_FORWARD_POLICY="ACCEPT"
# Set the default application policy to ACCEPT, DROP, REJECT or SKIP. Please
# note that setting this to ACCEPT may be a security risk. See 'man ufw' for
# details
DEFAULT_APPLICATION_POLICY="SKIP"
# By default, ufw only touches its own chains. Set this to 'yes' to have ufw
# manage the built-in chains too. Warning: setting this to 'yes' will break
# non-ufw managed firewall rules
MANAGE_BUILTINS=no
#
# IPT backend
#
# only enable if using iptables backend
IPT_SYSCTL=/etc/ufw/sysctl.conf
# Extra connection tracking modules to load. Complete list can be found in
# net/netfilter/Kconfig of your kernel source. Some common modules:
# nf_conntrack_irc, nf_nat_irc: DCC (Direct Client to Client) support
# nf_conntrack_netbios_ns: NetBIOS (samba) client support
# nf_conntrack_pptp, nf_nat_pptp: PPTP over stateful firewall/NAT
# nf_conntrack_ftp, nf_nat_ftp: active FTP support
# nf_conntrack_tftp, nf_nat_tftp: TFTP support (server side)
IPT_MODULES="nf_conntrack_ftp nf_nat_ftp nf_conntrack_netbios_ns"
고양이 /etc/sysctl.conf
#
# /etc/sysctl.conf - Configuration file for setting system variables
# See /etc/sysctl.d/ for additional system variables.
# See sysctl.conf (5) for information.
#
#kernel.domainname = example.com
# Uncomment the following to stop low-level messages on console
#kernel.printk = 3 4 1 3
##############################################################3
# Functions previously found in netbase
#
# Uncomment the next two lines to enable Spoof protection (reverse-path filter)
# Turn on Source Address Verification in all interfaces to
# prevent some spoofing attacks
#net.ipv4.conf.default.rp_filter=1
#net.ipv4.conf.all.rp_filter=1
# Uncomment the next line to enable TCP/IP SYN cookies
# See http://lwn.net/Articles/277146/
# Note: This may impact IPv6 TCP sessions too
#net.ipv4.tcp_syncookies=1
# Uncomment the next line to enable packet forwarding for IPv4
net.ipv4.ip_forward=1
# Uncomment the next line to enable packet forwarding for IPv6
# Enabling this option disables Stateless Address Autoconfiguration
# based on Router Advertisements for this host
#net.ipv6.conf.all.forwarding=1
###################################################################
# Additional settings - these settings can improve the network
# security of the host and prevent against some network attacks
# including spoofing attacks and man in the middle attacks through
# redirection. Some network environments, however, require that these
# settings are disabled so review and enable them as needed.
#
# Do not accept ICMP redirects (prevent MITM attacks)
#net.ipv4.conf.all.accept_redirects = 0
#net.ipv6.conf.all.accept_redirects = 0
# _or_
# Accept ICMP redirects only for gateways listed in our default
# gateway list (enabled by default)
# net.ipv4.conf.all.secure_redirects = 1
#
# Do not send ICMP redirects (we are not a router)
#net.ipv4.conf.all.send_redirects = 0
#
# Do not accept IP source route packets (we are not a router)
#net.ipv4.conf.all.accept_source_route = 0
#net.ipv6.conf.all.accept_source_route = 0
#
# Log Martian Packets
#net.ipv4.conf.all.log_martians = 1
#
###################################################################
# Magic system request Key
# 0=disable, 1=enable all
# Debian kernels have this set to 0 (disable the key)
# See https://www.kernel.org/doc/Documentation/sysrq.txt
# for what other values do
#kernel.sysrq=1
###################################################################
# Protected links
#
# Protects against creating or following links under certain conditions
# Debian kernels have both set to 1 (restricted)
# See https://www.kernel.org/doc/Documentation/sysctl/fs.txt
#fs.protected_hardlinks=0
#fs.protected_symlinks=0
sudo iptables --table nat --list
Chain PREROUTING (policy ACCEPT)
target prot opt source destination
Chain INPUT (policy ACCEPT)
target prot opt source destination
Chain OUTPUT (policy ACCEPT)
target prot opt source destination
Chain POSTROUTING (policy ACCEPT)
target prot opt source destination
MASQUERADE all -- 10.8.0.0/24 anywhere
편집: 서버에 핑을 보내고 SSH를 통해 연결할 수 있습니다.
