저는 94GB RAM과 24개의 CPU 코어를 갖춘 서버가 40개의 동시 연결을 처리할 수 없는 문제를 다루고 있습니다. 도구를 사용하여 ab한 번에 40개의 요청을 보냅니다.
ab -n 40 -c 40 http://ip-address/
첫 번째 요청은 빠르게 완료됩니다.
Concurrency Level: 40
Time taken for tests: 1.951 seconds
Complete requests: 40
Failed requests: 0
Non-2xx responses: 40
Total transferred: 20280 bytes
HTML transferred: 0 bytes
Requests per second: 20.50 [#/sec] (mean)
Time per request: 1951.311 [ms] (mean)
Time per request: 48.783 [ms] (mean, across all concurrent requests)
Transfer rate: 10.15 [Kbytes/sec] received
Connection Times (ms)
min mean[+/-sd] median max
Connect: 27 73 28.7 75 120
Processing: 540 1008 129.6 998 1256
Waiting: 536 1007 129.9 998 1255
Total: 575 1081 153.1 1071 1376
Percentage of the requests served within a certain time (ms)
50% 1071
66% 1177
75% 1208
80% 1237
90% 1261
95% 1322
98% 1376
99% 1376
100% 1376 (longest request)
그러나 동일한 명령을 다시 실행하면 연결 시간 초과가 발생합니다. 앞으로 몇 분 동안 서버에 SSH로 연결할 수 없습니다.
제가 요청을 보내는 페이지는 748개의 SELECT쿼리를 포함하는 760개의 쿼리를 실행합니다. MariaDB가 max_connections설정되어 500있으며 이는 PHP-FPM 풀 구성입니다.
listen = 127.0.0.1:9000
listen.allowed_clients = 127.0.0.1
listen.owner = nginx
listen.group = nginx
listen.mode = 0660
user = xxxx ; modified
group = xxxx ; modified
pm = ondemand
pm.max_children = 1000
pm.start_servers = 200
pm.min_spare_servers = 50
pm.max_spare_servers = 100
pm.max_requests = 500
request_terminate_timeout = 100s
pm.process_idle_timeout = 3s
php_admin_value[error_log] = /var/log/php-fpm/pool-error.log
php_admin_flag[log_errors] = on
php_value[session.save_handler] = files
php_value[session.save_path] = /var/lib/php/session
더 이상 적용되지 않을 것 같아서 pm설정 했습니다 .ondemandmax_children
나 또한 SELinux를 사용하면서 힘든 시간을 보냈다. 범인이 아닐까?
업데이트
출력 mysqltuner.pl:
Currently running supported MySQL version 10.4.6-MariaDB
[OK] Operating on 64-bit architecture
-------- Log file Recommendations ------------------------------------------------------------------
[--] Log file: /var/lib/mysql/localhost.localdomain.err(0B)
[!!] Log file /var/lib/mysql/localhost.localdomain.err doesn't exist
[!!] Log file /var/lib/mysql/localhost.localdomain.err isn't readable.
-------- Storage Engine Statistics -----------------------------------------------------------------
[--] Status: +Aria +CSV +InnoDB +MEMORY +MRG_MyISAM +MyISAM +PERFORMANCE_SCHEMA +SEQUENCE
[--] Data in MyISAM tables: 72.0K (Tables: 12)
[--] Data in InnoDB tables: 1.9G (Tables: 449)
[--] Data in MEMORY tables: 0B (Tables: 17)
[OK] Total fragmented tables: 0
-------- Analysis Performance Metrics --------------------------------------------------------------
[--] innodb_stats_on_metadata: OFF
[OK] No stat updates during querying INFORMATION_SCHEMA.
-------- Security Recommendations ------------------------------------------------------------------
[OK] There are no anonymous accounts for any database users
[OK] All database users have passwords assigned
[!!] There is no basic password file list!
-------- CVE Security Recommendations --------------------------------------------------------------
[--] Skipped due to --cvefile option undefined
-------- Performance Metrics -----------------------------------------------------------------------
[--] Up for: 3m 0s (15K q [85.489 qps], 401 conn, TX: 44M, RX: 4M)
[--] Reads / Writes: 99% / 1%
[--] Binary logging is disabled
[--] Physical Memory : 94.2G
[--] Max MySQL memory : 154.1G
[--] Other process memory: 0B
[--] Total buffers: 50.4G global + 52.7M per thread (2000 max threads)
[--] P_S Max memory usage: 867M
[--] Galera GCache Max memory usage: 0B
[OK] Maximum reached memory usage: 69.0G (73.22% of installed RAM)
[!!] Maximum possible memory usage: 154.1G (163.47% of installed RAM)
[!!] Overall possible memory usage with other process exceeded memory
[OK] Slow queries: 0% (0/15K)
[OK] Highest usage of available connections: 17% (346/2000)
[OK] Aborted connections: 0.50% (2/401)
[OK] Query cache is disabled by default due to mutex contention on multiprocessor machines.
[OK] Sorts requiring temporary tables: 0% (0 temp sorts / 1K sorts)
[!!] Joins performed without indexes: 47
[!!] Temporary tables created on disk: 55% (519 on disk / 927 total)
[!!] Thread cache hit rate: 13% (346 created / 401 connections)
[OK] Table cache hit rate: 98% (589 open / 595 opened)
[OK] Open file limit used: 1% (81/8K)
[OK] Table locks acquired immediately: 100% (552 immediate / 552 locks)
-------- Performance schema ------------------------------------------------------------------------
[--] Memory used by P_S: 867.5M
[--] Sys schema isn't installed.
-------- ThreadPool Metrics ------------------------------------------------------------------------
[--] ThreadPool stat is enabled.
[--] Thread Pool Size: 24 thread(s).
[--] Using default value is good enough for your version (10.4.6-MariaDB)
-------- MyISAM Metrics ----------------------------------------------------------------------------
[!!] Key buffer used: 18.2% (24M used / 134M cache)
[OK] Key buffer size / total MyISAM indexes: 128.0M/23.0K
-------- InnoDB Metrics ----------------------------------------------------------------------------
[--] InnoDB is enabled.
[--] InnoDB Thread Concurrency: 0
[OK] InnoDB File per table is activated
[OK] InnoDB buffer pool / data size: 50.0G/1.9G
[OK] Ratio InnoDB log file size / InnoDB Buffer pool size: 6.0G * 2/50.0G should be equal to 25%
[OK] InnoDB buffer pool instances: 50
[--] Number of InnoDB Buffer Pool Chunk : 400 for 50 Buffer Pool Instance(s)
[OK] Innodb_buffer_pool_size aligned with Innodb_buffer_pool_chunk_size & Innodb_buffer_pool_instances
[OK] InnoDB Read buffer efficiency: 99.92% (31587444 hits/ 31612740 total)
[!!] InnoDB Write Log efficiency: 168.97% (49 hits/ 29 total)
[OK] InnoDB log waits: 0.00% (0 waits / 78 writes)
-------- AriaDB Metrics ----------------------------------------------------------------------------
[--] AriaDB is enabled.
[OK] Aria pagecache size / total Aria indexes: 128.0M/2.5M
[OK] Aria pagecache hit rate: 99.1% (59K cached / 542 reads)
-------- TokuDB Metrics ----------------------------------------------------------------------------
[--] TokuDB is disabled.
-------- XtraDB Metrics ----------------------------------------------------------------------------
[--] XtraDB is disabled.
-------- Galera Metrics ----------------------------------------------------------------------------
[--] Galera is disabled.
-------- Replication Metrics -----------------------------------------------------------------------
[--] Galera Synchronous replication: NO
[--] No replication slave(s) for this server.
[--] Binlog format: MIXED
[--] XA support enabled: ON
[--] Semi synchronous replication Master: OFF
[--] Semi synchronous replication Slave: OFF
[--] This is a standalone server
-------- Recommendations ---------------------------------------------------------------------------
General recommendations:
MySQL was started within the last 24 hours - recommendations may be inaccurate
Reduce your overall MySQL memory footprint for system stability
Dedicate this server to your database for highest performance.
Adjust your join queries to always utilize indexes
When making adjustments, make tmp_table_size/max_heap_table_size equal
Reduce your SELECT DISTINCT queries which have no LIMIT clause
Consider installing Sys schema from https://github.com/mysql/mysql-sys for MySQL
Consider installing Sys schema from https://github.com/good-dba/mariadb-sys for MariaDB
Variables to adjust:
*** MySQL's maximum memory usage is dangerously high ***
*** Add RAM before increasing MySQL buffer variables ***
join_buffer_size (> 50.0M, or always use indexes with JOINs)
tmp_table_size (> 100M)
max_heap_table_size (> 100M)
thread_cache_size (> 2000)
답변1
벤치마킹은 까다로운 작업입니다. 일부 벤치마크는 두 가지 서로 다른 하드웨어/소프트웨어 구성을 비교하는 데 적합하지만 시스템의 절대 성능에 대한 현실적인 추정치를 반환하는 데 적합한 벤치마크는 거의 없습니다.
이 예는 매우 몇 밀리초 내에 40개의 동일한 CPU 바인딩 쿼리로 서버를 강타한 것으로 보입니다. 코어가 24개밖에 없기 때문에 프로세스가 빠르게 서로 겹치기 시작했습니다. 참고 ms 타이밍: 575 1081 1376; 이것은 걸림돌을 확인합니다.
25번째 쿼리가 시작되기 전에 첫 번째 쿼리가 575ms 동안 실행되도록 허용되면 처리가 '영원히' 원활하게 진행될 수 있습니다. 40정도 되네요초당, 40 "한 번에"가 아닙니다.
따라서 ab요청(25ms마다 새로운 요청)을 분산시킬 수 있다면 아마도 "문제 없음"이라고 볼 수 있을 것입니다.
반면 웹페이지의 경우 575ms는 매우 긴 응답 시간입니다. 속도를 높이는 데 관련된 쿼리(queries)를 살펴보겠습니다.
실제 생활에서 http 요청은 "동시"와 "균등한 간격" 사이의 웹 서버에서 발생합니다. 테스트에서 상한값만 제공되었습니다.
