우리는 지난 몇 달 동안 우리에게 고통을 주는 문제를 경험해 왔습니다.
문제는 Kubernetes 실행기를 통해 포드를 요청할 때 포드 생성에 실패하는 경우가 있는 것 같습니다.
예를 들어 다음 오류로 인해 Spark Pod가 실패할 수 있습니다.
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Warning FailedCreatePodSandBox 20m (x3 over 32m) kubelet, k8s-agentpool1-123456789-vmss00000q (combined from similar events): Failed create pod sandbox: rpc error: code = Unknown desc = failed to create a sandbox for pod "spark-worker-cc1d28bf3de8428a826c04471e58487c-8577d5d654-2jg89": operation timeout: context deadline exceeded
Normal SandboxChanged 16m (x150 over 159m) kubelet, k8s-agentpool1-123456789-vmss00000q Pod sandbox changed, it will be killed and re-created.
Warning FailedCreatePodSandBox 5m7s (x14 over 161m) kubelet, k8s-agentpool1-123456789-vmss00000q Failed create pod sandbox: rpc error: code = Unknown desc = failed to create a sandbox for pod "spark-worker-cc1d28bf3de8428a826c04471e58487c-8577d5d654-2jg89": operation timeout: context deadline exceeded
로그를 보면 kubelet에서 새 포드를 요청하는 "SyncLoop"가 표시됩니다.
Jul 16 16:33:58 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: I0716 16:33:58.001997 4797 kubelet.go:1908] SyncLoop (ADD, "api"): "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)
볼륨이 마운트되었음을 나타내는 일부 로그도 있습니다.
Jul 16 16:34:29 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: I0716 16:33:58.175573 4797 reconciler.go:252] operationExecutor.MountVolume started for volume "default-shared" (UniqueName: "kubernetes.io/glusterfs/8272d74f-a7e7-11e9-8f1c-000d3a7b202b-default-shared") pod "d9b3911585c4461c9728aefa39716c44" (UID: "8272d74f-a7e7-11e9-8f1c-000d3a7b202b")
포드 Sandbox가 생성되는 것을 볼 수 있습니다.
Jul 16 16:34:29 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: I0716 16:34:29.627374 4797 kuberuntime_manager.go:397] No sandbox for pod "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" can be found. Need to start a new one
다음이 기록되기 전까지는 아무것도 볼 수 없는 것 같습니다.
Jul 16 16:36:29 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: E0716 16:36:29.629252 4797 kuberuntime_manager.go:662] createPodSandbox for pod "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" failed: rpc error: code = Unknown desc = failed to create a sandbox for pod "d9b3911585c4461c9728aefa39716c44": operation timeout: context deadline exceeded
Jul 16 16:36:29 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: E0716 16:36:29.629301 4797 pod_workers.go:190] Error syncing pod 8272d74f-a7e7-11e9-8f1c-000d3a7b202b ("d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)"), skipping: failed to "CreatePodSandbox" for "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" with CreatePodSandboxError: "CreatePodSandbox for pod \"d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)\" failed: rpc error: code = Unknown desc = failed to create a sandbox for pod \"d9b3911585c4461c9728aefa39716c44\": operation timeout: context deadline exceeded"
Jul 16 16:36:43 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: I0716 16:36:43.937085 4797 kuberuntime_manager.go:397] No sandbox for pod "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" can be found. Need to start a new one
Jul 16 16:36:43 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: E0716 16:36:43.940691 4797 remote_runtime.go:96] RunPodSandbox from runtime service failed: rpc error: code = Unknown desc = failed to create a sandbox for pod "d9b3911585c4461c9728aefa39716c44": Error response from daemon: Conflict. The container name "/k8s_POD_d9b3911585c4461c9728aefa39716c44_default_8272d74f-a7e7-11e9-8f1c-000d3a7b202b_0" is already in use by container "2a7ecfd3725bbe6604b3006abf6c59a36eb8a5d7142e71a3791f5f7378bf5e27". You have to remove (or rename) that container to be able to reuse that name.
Jul 16 16:36:43 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: E0716 16:36:43.940731 4797 kuberuntime_sandbox.go:68] CreatePodSandbox for pod "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" failed: rpc error: code = Unknown desc = failed to create a sandbox for pod "d9b3911585c4461c9728aefa39716c44": Error response from daemon: Conflict. The container name "/k8s_POD_d9b3911585c4461c9728aefa39716c44_default_8272d74f-a7e7-11e9-8f1c-000d3a7b202b_0" is already in use by container "2a7ecfd3725bbe6604b3006abf6c59a36eb8a5d7142e71a3791f5f7378bf5e27". You have to remove (or rename) that container to be able to reuse that name.
Jul 16 16:36:43 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: E0716 16:36:43.940747 4797 kuberuntime_manager.go:662] createPodSandbox for pod "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" failed: rpc error: code = Unknown desc = failed to create a sandbox for pod "d9b3911585c4461c9728aefa39716c44": Error response from daemon: Conflict. The container name "/k8s_POD_d9b3911585c4461c9728aefa39716c44_default_8272d74f-a7e7-11e9-8f1c-000d3a7b202b_0" is already in use by container "2a7ecfd3725bbe6604b3006abf6c59a36eb8a5d7142e71a3791f5f7378bf5e27". You have to remove (or rename) that container to be able to reuse that name.
Jul 16 16:36:43 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: E0716 16:36:43.940805 4797 pod_workers.go:190] Error syncing pod 8272d74f-a7e7-11e9-8f1c-000d3a7b202b ("d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)"), skipping: failed to "CreatePodSandbox" for "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" with CreatePodSandboxError: "CreatePodSandbox for pod \"d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)\" failed: rpc error: code = Unknown desc = failed to create a sandbox for pod \"d9b3911585c4461c9728aefa39716c44\": Error response from daemon: Conflict. The container name \"/k8s_POD_d9b3911585c4461c9728aefa39716c44_default_8272d74f-a7e7-11e9-8f1c-000d3a7b202b_0\" is already in use by container \"2a7ecfd3725bbe6604b3006abf6c59a36eb8a5d7142e71a3791f5f7378bf5e27\". You have to remove (or rename) that container to be able to reuse that name."
Jul 16 16:36:44 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: W0716 16:36:44.221607 4797 docker_sandbox.go:384] failed to read pod IP from plugin/docker: NetworkPlugin cni failed on the status hook for pod "d9b3911585c4461c9728aefa39716c44_default": CNI failed to retrieve network namespace path: cannot find network namespace for the terminated container "2a7ecfd3725bbe6604b3006abf6c59a36eb8a5d7142e71a3791f5f7378bf5e27"
Jul 16 16:36:44 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: I0716 16:36:44.222749 4797 kubelet.go:1953] SyncLoop (PLEG): "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)", event: &pleg.PodLifecycleEvent{ID:"8272d74f-a7e7-11e9-8f1c-000d3a7b202b", Type:"ContainerDied", Data:"2a7ecfd3725bbe6604b3006abf6c59a36eb8a5d7142e71a3791f5f7378bf5e27"}
Jul 16 16:36:44 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: I0716 16:36:44.739387 4797 kuberuntime_manager.go:415] No ready sandbox for pod "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" can be found. Need to start a new one
CNI 오류일 수 있다고 생각했지만 Azure CNI 로그를 검토한 결과 IP 요청을 시작하는 부분에도 도달하지 못하고 DEL 명령이 err로 완료되었다는 오류만 표시되는 것 같습니다.
2019/07/16 16:23:06 [net] Deleting veth pair azv4ea5d9d9527 eth0.
2019/07/16 16:23:06 [net] Deleted endpoint &{Id:8e963d34-eth0 HnsId: SandboxKey: IfName:eth0 HostIfName:azv4ea5d9d9527 MacAddress:ce:93:bf:4d:e9:19 InfraVnetIP:{IP:<nil> Mask:<nil>} IPAddresses:[{IP:10.250.18.22
5 Mask:fffff800}] Gateways:[10.250.16.1] DNS:{Suffix: Servers:[168.63.129.16]} Routes:[{Dst:{IP:0.0.0.0 Mask:00000000} Src:<nil> Gw:10.250.16.1 Protocol:0 DevName: Scope:0}] VlanID:0 EnableSnatOnHost:false Enabl
eInfraVnet:false EnableMultitenancy:false NetworkNameSpace:/proc/10781/ns/net ContainerID:8e963d340597f1c9f789b93a7784e8d44ffb00687086de8ee6561338aab7c72d PODName:jupyter-some-person-10 PODNameSpace:defaul
t InfraVnetAddressSpace:}.
2019/07/16 16:23:06 [net] Save succeeded.
2019/07/16 16:23:06 [cni] Calling plugin azure-vnet-ipam DEL nwCfg:&{CNIVersion:0.3.0 Name:azure Type:azure-vnet Mode:bridge Master: Bridge:azure0 LogLevel: LogTarget: InfraVnetAddressSpace: PodNamespaceForDualN
etwork:[] MultiTenancy:false EnableSnatOnHost:false EnableExactMatchForPodName:false CNSUrl: Ipam:{Type:azure-vnet-ipam Environment: AddrSpace: Subnet:10.250.16.0/21 Address:10.250.18.225 QueryInterval:} DNS:{Na
meservers:[] Domain: Search:[] Options:[]} RuntimeConfig:{PortMappings:[] DNS:{Servers:[] Searches:[] Options:[]}} AdditionalArgs:[]}.
2019/07/16 16:23:06 [cni] Plugin azure-vnet-ipam returned err:<nil>.
2019/07/16 16:23:06 Get number of endpoints for ifname eth0 network azure
2019/07/16 16:23:06 [cni-net] DEL command completed with err:<nil>.
2019/07/16 16:23:06 [cni-net] Plugin stopped.
2019/07/16 16:36:38 [cni-net] Plugin azure-vnet version v1.0.18.
2019/07/16 16:36:38 [cni-net] Running on Linux version 4.15.0-1040-azure (buildd@lgw01-amd64-030) (gcc version 5.4.0 20160609 (Ubuntu 5.4.0-6ubuntu1~16.04.10)) #44-Ubuntu SMP Thu Feb 21 14:24:01 UTC 2019
Client:
Version: 3.0.3
API version: 1.40
Go version: go1.11.4
Git commit: 48bd4c6d
Built: Wed Jan 23 16:17:56 2019
OS/Arch: linux/amd64
Experimental: false
Server:
Engine:
Version: 3.0.4
API version: 1.40 (minimum version 1.12)
Go version: go1.11.4
Git commit: 8ecd530
Built: Fri Jan 25 01:45:38 2019
OS/Arch: linux/amd64
Experimental: false
containerd:
Version: v1.2.2
GitCommit: 9754871865f7fe2f4e74d43e2fc7ccd237edcbce
runc:
Version: 1.0.0-rc6+dev
GitCommit: 96ec2177ae841256168fcf76954f7177af9446eb
docker-init:
Version: 0.18.0
GitCommit: fec3683
k8s 버전 정보는 다음과 같습니다.
Server Version: version.Info{Major:"1", Minor:"13", GitVersion:"v1.13.5", GitCommit:"2166946f41b36dea2c4626f90a77706f426cdea2", GitTreeState:"clean", BuildDate:"2019-03-25T15:19:22Z", GoVersion:"go1.11.5", Compiler:"gc", Platform:"linux/amd64"}
다음은 노드 정보입니다. AKS 엔진을 사용하여 Azure VMSS 노드를 사용하는 Kubernetes 클러스터를 생성하고 있습니다.
Kernel Version: 4.15.0-1050-azure
OS Image: Ubuntu 16.04.6 LTS
Operating System: linux
Architecture: amd64
Container Runtime Version: docker://3.0.4
Kubelet Version: v1.13.5
Kube-Proxy Version: v1.13.5
이 문제를 재현할 수도 없기 때문에 이 문제를 추가로 해결하기 위해 무엇을 할 수 있는지에 대한 아이디어가 없습니다.
이 "컨텍스트 기한 초과" 경고는 일반적인 gRPC 시간 초과라는 것을 이해하지만 어떤 gRPC 트랜잭션이 중단되는지 잘 모르겠습니다.
답변1
문제는 여기에서 논의된 Kubernetes/Linux 커널의 버그로, cgroup이 기하급수적으로 증가하고 높은 CPU/메모리 사용량을 비롯한 문제를 일으키는 것과 관련이 있습니다.
문제가 설명되어 있습니다.여기:
해결 방법/수정 사항은 여기에 설명되어 있습니다. cgroup 누출 수정
해결책은 매시간 정리를 실행하는 데몬셋입니다.
