내 KVM 게스트에 들어오거나 나가는 네트워크 트래픽이 없는 문제가 발생했습니다. 많은 시간 동안 디버깅을 한 후에는 필수적인 것이 빠졌다고 확신합니다.
장애 조치에 결합된 2개의 10Gbit 인터페이스가 있는 서버가 있습니다. 관련 구성 및 출력:
기본 인터페이스:
# Autogenerated by /usr/sbin/iface-genconf on 2020-01-09 13:08:26
# backup file moved into /etc/sysconfig/network-scripts/.ens1f0-1578575306
DEVICE=ens1f0
ONBOOT=yes
TYPE=Ethernet
MASTER=bond0
SLAVE='yes'
BOOTPROTO=none
MTU=9000
NM_CONTROLLED=no
보조 인터페이스:
# Autogenerated by /usr/sbin/iface-genconf on 2020-01-09 13:08:26
# backup file moved into /etc/sysconfig/network-scripts/.ens1f1-1578575306
DEVICE=ens1f1
ONBOOT=yes
TYPE=Ethernet
MASTER=bond0
SLAVE='yes'
BOOTPROTO=none
MTU=9000
NM_CONTROLLED=no
채권 상태:
Ethernet Channel Bonding Driver: v3.7.1 (April 27, 2011)
Bonding Mode: fault-tolerance (active-backup)
Primary Slave: None
Currently Active Slave: ens1f0
MII Status: up
MII Polling Interval (ms): 0
Up Delay (ms): 0
Down Delay (ms): 0
ARP Polling Interval (ms): 500
ARP IP target/s (n.n.n.n form): 10.29.55.102, 10.29.55.103, 10.29.55.104
Slave Interface: dummy0
MII Status: down
Speed: Unknown
Duplex: Unknown
Link Failure Count: 1
Permanent HW addr: 32:15:f6:14:3b:18
Slave queue ID: 0
Slave Interface: ens1f0
MII Status: up
Speed: 10000 Mbps
Duplex: full
Link Failure Count: 0
Permanent HW addr: 0c:c4:7a:bd:3d:cc
Slave queue ID: 0
Slave Interface: ens1f1
MII Status: up
Speed: 10000 Mbps
Duplex: full
Link Failure Count: 0
Permanent HW addr: 0c:c4:7a:bd:3d:cd
Slave queue ID: 0
이 본드 위에는 관리 트래픽용 VLAN 302와 공용 트래픽용 VLAN 101 등 2개의 VLAN 인터페이스가 실행됩니다.
구성 VLAN 302:
DEVICE=bond0.302
ONBOOT=yes
TYPE=Ethernet
BOOTPROTO=none
VLAN=yes
USERCTL=no
BRIDGE=manbr0
구성 VLAN 101:
DEVICE=bond0.101
ONBOOT=yes
TYPE=Ethernet
BOOTPROTO=none
VLAN=yes
USERCTL=no
BRIDGE=cloudbr0
보시다시피 각 VLAN 인터페이스는 브리지에 연결되어 있습니다. 관리용 manbr0, 공용 트래픽용 cloudbr0.
manbr0 구성:
DEVICE=manbr0
BOOTPROTO=none
ONBOOT=yes
TYPE=Bridge
USERCTL=no
NAME=manbr0
IPADDR=10.29.55.106
PREFIX=24
GATEWAY=10.29.55.1
cloudbr0 구성:
DEVICE=cloudbr0
BOOTPROTO=none
ONBOOT=yes
TYPE=Bridge
USERCTL=no
DELAY=0
MTU=1500```
brctl show output:
```[root@hv2 ~]# brctl show
bridge name bridge id STP enabled interfaces
manbr0 8000.da7b71f50c30 no bond0.302
cloudbr0 8000.da7b71f50c30 no bond0.101
여태까지는 그런대로 잘됐다. 관리 네트워크는 매력적으로 작동합니다. cloudbr0에서 공용 IP를 구성하면 모두 예상대로 작동합니다. 구성된 인터페이스:
cloudbr0: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 9000
inet 185.x.x.222 netmask 255.255.255.0 broadcast 185.x.x.255
inet6 fe80::d87b:71ff:fef5:c30 prefixlen 64 scopeid 0x20<link>
ether da:7b:71:f5:0c:30 txqueuelen 1000 (Ethernet)
RX packets 37448 bytes 1751235 (1.6 MiB)
RX errors 0 dropped 0 overruns 0 frame 0
TX packets 8 bytes 656 (656.0 B)
TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0
원격 호스트에서 핑:
PING 185.X.X.222 (185.X.X.222) 56(84) bytes of data.
--- 185.X.X.222 ping statistics ---
10 packets transmitted, 10 received, 0% packet loss, time 9004ms
rtt min/avg/max/mdev = 0.119/0.211/0.793/0.195 ms
지금까지는 모든 것이 괜찮아 보입니다. 물론 cloudbr0에서 IP를 제거한 후 이제 동일한 IP를 사용하여 VM을 배포하고 있습니다.
cloudbr0: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 9000
inet6 fe80::d87b:71ff:fef5:c30 prefixlen 64 scopeid 0x20<link>
ether da:7b:71:f5:0c:30 txqueuelen 1000 (Ethernet)
RX packets 80714 bytes 3802772 (3.6 MiB)
RX errors 0 dropped 0 overruns 0 frame 0
TX packets 22 bytes 1916 (1.8 KiB)
TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0
이제 이전에 테스트했던 것과 동일한 IP에서 이 VM이 실행되고 있습니다. 그러나 도달할 수 없습니다. VM 내에서 원격 상자로 ping을 시작하고 원격 서버에서 tcpdump를 실행하면 요청이 들어오는 것을 볼 수 있습니다.
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on bond0, link-type EN10MB (Ethernet), capture size 262144 bytes
09:53:24.074319 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:25.075022 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:25.465094 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 0, length 64
09:53:25.465146 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 1, length 64
09:53:26.074392 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 2, length 64
09:53:27.074432 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 3, length 64
09:53:28.074464 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 4, length 64
09:53:29.074502 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 5, length 64
09:53:30.074540 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 6, length 64
09:53:31.074610 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 7, length 64
09:53:32.074651 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 8, length 64
09:53:33.074688 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 9, length 64
09:53:34.074730 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:35.074841 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:36.078219 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:38.074966 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:39.078221 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:40.081571 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:42.075139 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:43.078240 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:44.081570 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:46.075282 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:47.078253 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:48.081594 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:50.075420 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:51.078295 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:52.081614 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:54.075748 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:55.078285 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:53:55.465183 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 30, length 64
09:53:55.465223 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 31, length 64
09:53:56.075960 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 32, length 64
09:53:57.076013 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 33, length 64
09:53:58.076086 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 34, length 64
09:53:59.076122 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 35, length 64
09:54:00.076168 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 36, length 64
09:54:01.076178 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 37, length 64
09:54:02.076215 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 38, length 64
09:54:03.076286 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 12035, seq 39, length 64
09:54:04.076339 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:05.078322 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:06.081631 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:08.076504 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:09.078345 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:10.081670 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:12.076686 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:13.078363 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:14.081681 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:16.076836 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:17.078402 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:18.081705 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:20.077154 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:21.078355 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:22.081734 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:24.077303 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
09:54:25.078430 ARP, Request who-has 185.X.X.1 tell 185.X.X.222, length 46
위의 스니펫은 패턴입니다. ICMP 요청의 순서를 확인하세요. 따라서 10개의 ICMP 요청을 보낼 수 있으며 그 중 20개가 실패합니다. 10개의 요청이 전송되고 20개가 실패합니다. 등등.
cloudbr0 브리지 인터페이스에서 tcpdumping을 할 때 동일한 패턴이 표시됩니다. 10개 응답, 20개 누락, 10개 응답, 20개 누락, 다시 seq를 확인하세요.
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on cloudbr0, link-type EN10MB (Ethernet), capture size 262144 bytes
09:57:55.464992 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 270, length 64
09:57:55.465005 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 271, length 64
09:57:56.086069 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 272, length 64
09:57:57.086122 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 273, length 64
09:57:58.086181 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 274, length 64
09:57:59.086215 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 275, length 64
09:58:00.086272 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 276, length 64
09:58:01.086238 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 277, length 64
09:58:02.086288 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 278, length 64
09:58:03.086362 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 279, length 64
09:58:25.465128 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 300, length 64
09:58:25.465138 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 301, length 64
09:58:26.087363 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 302, length 64
09:58:27.087421 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 303, length 64
09:58:28.087463 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 304, length 64
09:58:29.087485 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 305, length 64
09:58:30.087799 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 306, length 64
09:58:31.087577 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 307, length 64
09:58:32.087616 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 308, length 64
09:58:33.087610 IP 185.X.X.25 > 185.X.X.222: ICMP echo reply, id 12035, seq 309, length 64
가상 인터페이스에서 tcpdump를 실행하면 동일한 패턴이 표시됩니다. 요청 10개는 보낼 수 있지만 20개는 보낼 수 없습니다. 헹구고 반복하십시오. 게다가 가상 인터페이스로 응답이 돌아오는 것을 본 적이 없습니다.
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on one-79-0, link-type EN10MB (Ethernet), capture size 262144 bytes
11:12:25.494959 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 12, length 64
11:12:25.494970 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 13, length 64
11:12:25.600742 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 14, length 64
11:12:26.600781 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 15, length 64
11:12:27.600832 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 16, length 64
11:12:28.600875 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 17, length 64
11:12:29.600914 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 18, length 64
11:12:30.600950 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 19, length 64
11:12:31.600986 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 20, length 64
11:12:32.601023 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 21, length 64
11:12:55.494978 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 42, length 64
11:12:55.494987 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 43, length 64
11:12:55.601972 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 44, length 64
11:12:56.602010 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 45, length 64
11:12:57.602051 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 46, length 64
11:12:58.602091 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 47, length 64
11:12:59.602128 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 48, length 64
11:13:00.602163 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 49, length 64
11:13:01.602200 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 50, length 64
11:13:02.602241 IP 185.X.X.222 > 185.X.X.25: ICMP echo request, id 14339, seq 51, length 64
내 가상 인터페이스 "one-74-0"이 브리지에 연결됩니다.
[root@hv2 ~]# brctl show
bridge name bridge id STP enabled interfaces
manbr0 8000.da7b71f50c30 no bond0.302
cloudbr0 8000.da7b71f50c30 no bond0.101
one-74-0
흥미로운 점은 KVM 호스트의 가상 인터페이스에 삭제된 패킷이 꽤 많다는 것입니다.
one-74-0: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 9000
inet6 fe80::fc00:b9ff:fe64:83de prefixlen 64 scopeid 0x20<link>
ether fe:00:b9:64:83:de txqueuelen 1000 (Ethernet)
RX packets 441 bytes 27054 (26.4 KiB)
RX errors 0 dropped 0 overruns 0 frame 0
TX packets 1196384 bytes 288740710 (275.3 MiB)
TX errors 0 dropped 23902 overruns 0 carrier 0 collisions 0
iptables 출력:
[root@hv2 ~]# iptables -L
Chain INPUT (policy ACCEPT)
target prot opt source destination
Chain FORWARD (policy ACCEPT)
target prot opt source destination
Chain OUTPUT (policy ACCEPT)
target prot opt source destination
ebtables 출력:
[root@hv2 ~]# ebtables -L
Bridge table: filter
Bridge chain: INPUT, entries: 0, policy: ACCEPT
Bridge chain: FORWARD, entries: 0, policy: ACCEPT
Bridge chain: OUTPUT, entries: 0, policy: ACCEPT
ip_forward:
[root@hv2 ~]# cat /proc/sys/net/ipv4/ip_forward
1
qemu 프로세스:
[root@hv2 ~]# ps -ef | grep qemu
oneadmin 9198 1 6 10:06 ? 00:02:27 /usr/libexec/qemu-kvm -name guest=one-76,debug-threads=on -S -object secret,id=masterKey0,format=raw,file=/var/lib/libvirt/qemu/domain-4-one-76/master-key.aes -machine pc-i440fx-rhel7.6.0,accel=kvm,usb=off,dump-guest-core=off -m 1024 -realtime mlock=off -smp 1,sockets=1,cores=1,threads=1 -uuid e1660604-09ce-452a-a8d9-5cfe8d7a88a9 -no-user-config -nodefaults -chardev socket,id=charmonitor,fd=26,server,nowait -mon chardev=charmonitor,id=monitor,mode=control -rtc base=utc -no-shutdown -boot strict=on -device piix3-usb-uhci,id=usb,bus=pci.0,addr=0x1.0x2 -device virtio-serial-pci,id=virtio-serial0,bus=pci.0,addr=0x4 -drive file=/var/lib/one//datastores/103/76/disk.0,format=raw,if=none,id=drive-ide0-0-0,readonly=on,cache=none,discard=unmap,aio=native -device ide-cd,bus=ide.0,unit=0,drive=drive-ide0-0-0,id=ide0-0-0,write-cache=on -drive file=/var/lib/one//datastores/103/76/disk.1,format=raw,if=none,id=drive-ide0-0-1,readonly=on -device ide-cd,bus=ide.0,unit=1,drive=drive-ide0-0-1,id=ide0-0-1 -netdev tap,fd=29,id=hostnet0,vhost=on,vhostfd=30 -device virtio-net-pci,netdev=hostnet0,id=net0,mac=02:00:b9:64:83:de,bus=pci.0,addr=0x3 -chardev socket,id=charchannel0,fd=31,server,nowait -device virtserialport,bus=virtio-serial0.0,nr=1,chardev=charchannel0,id=channel0,name=org.qemu.guest_agent.0 -vnc 0.0.0.0:76 -device cirrus-vga,id=video0,bus=pci.0,addr=0x2 -device virtio-balloon-pci,id=balloon0,bus=pci.0,addr=0x5 -sandbox on,obsolete=deny,elevateprivileges=deny,spawn=deny,resourcecontrol=deny -msg timestamp=on
게스트의 virsh XML:
<domain type='kvm'>
<name>one-76</name>
<uuid>e1660604-09ce-452a-a8d9-5cfe8d7a88a9</uuid>
<title>sysrescuecd-76</title>
<metadata>
<one:vm xmlns:one="http://opennebula.org/xmlns/libvirt/1.0">
<one:system_datastore><![CDATA[/var/lib/one//datastores/103/76]]></one:system_datastore>
<one:name><![CDATA[sysrescuecd-76]]></one:name>
<one:uname><![CDATA[oneadmin]]></one:uname>
<one:uid>0</one:uid>
<one:gname><![CDATA[oneadmin]]></one:gname>
<one:gid>0</one:gid>
<one:opennebula_version>5.10.1</one:opennebula_version>
<one:stime>1578992757</one:stime>
<one:deployment_time>1578992777</one:deployment_time>
</one:vm>
</metadata>
<memory unit='KiB'>1048576</memory>
<currentMemory unit='KiB'>1048576</currentMemory>
<vcpu placement='static'>1</vcpu>
<cputune>
<shares>1024</shares>
</cputune>
<resource>
<partition>/machine</partition>
</resource>
<os>
<type arch='x86_64' machine='pc-i440fx-rhel7.6.0'>hvm</type>
<boot dev='hd'/>
</os>
<features>
<acpi/>
</features>
<clock offset='utc'/>
<on_poweroff>destroy</on_poweroff>
<on_reboot>restart</on_reboot>
<on_crash>destroy</on_crash>
<devices>
<emulator>/usr/libexec/qemu-kvm</emulator>
<disk type='file' device='cdrom'>
<driver name='qemu' type='raw' cache='none' io='native' discard='unmap'/>
<source file='/var/lib/one//datastores/103/76/disk.0'/>
<target dev='hda' bus='ide'/>
<readonly/>
<alias name='ide0-0-0'/>
<address type='drive' controller='0' bus='0' target='0' unit='0'/>
</disk>
<disk type='file' device='cdrom'>
<driver name='qemu' type='raw'/>
<source file='/var/lib/one//datastores/103/76/disk.1'/>
<target dev='hdb' bus='ide'/>
<readonly/>
<alias name='ide0-0-1'/>
<address type='drive' controller='0' bus='0' target='0' unit='1'/>
</disk>
<controller type='usb' index='0' model='piix3-uhci'>
<alias name='usb'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x2'/>
</controller>
<controller type='pci' index='0' model='pci-root'>
<alias name='pci.0'/>
</controller>
<controller type='ide' index='0'>
<alias name='ide'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/>
</controller>
<controller type='virtio-serial' index='0'>
<alias name='virtio-serial0'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x04' function='0x0'/>
</controller>
<interface type='bridge'>
<mac address='02:00:b9:64:83:de'/>
<source bridge='cloudbr0'/>
<target dev='one-76-0'/>
<model type='virtio'/>
<alias name='net0'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x0'/>
</interface>
<channel type='unix'>
<source mode='bind' path='/var/lib/libvirt/qemu/channel/target/domain-4-one-76/org.qemu.guest_agent.0'/>
<target type='virtio' name='org.qemu.guest_agent.0'/>
<alias name='channel0'/>
<address type='virtio-serial' controller='0' bus='0' port='1'/>
</channel>
<input type='mouse' bus='ps2'>
<alias name='input0'/>
</input>
<input type='keyboard' bus='ps2'>
<alias name='input1'/>
</input>
<graphics type='vnc' port='5976' autoport='no' listen='0.0.0.0'>
<listen type='address' address='0.0.0.0'/>
</graphics>
<video>
<model type='cirrus' vram='16384' heads='1' primary='yes'/>
<alias name='video0'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0'/>
</video>
<memballoon model='virtio'>
<alias name='balloon0'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x05' function='0x0'/>
</memballoon>
<seclabel type='dynamic' model='dac' relabel='yes'>
<label>+9869:+9869</label>
<imagelabel>+9869:+9869</imagelabel>
</seclabel>
</domain>
몇 가지 더 흥미로운 점은 다음과 같습니다.
- VM 외부에서 ping을 시도하는 동안 VM 내에서 tcpdumping을 시도하면 패킷이 전혀 렌더링되지 않습니다. ping을 보내는 IP에서는 아무 것도 들어오지 않습니다. 응답은 VM이 아닌 본드에서 종료됩니다.
- VM 내에서 tcpdumping을 수행하고 src IP를 핑하는 호스트로 제한하지 않으면 이 VLAN 내의 다른 브로드캐스트 트래픽이 표시됩니다.
- 매우 흥미로운 것입니다. 수동으로 "ifconfig cloudbr0 down; ifconfig cloudbr0 up"을 실행하면 때때로 100번 중 1번 정도 VM의 IP를 겨냥한 1개의 핑이 전달됩니다.
브리지와 VM NIC 사이에 문제가 있는 것 같습니다. 말했듯이, 브리지에서 동일한 IP를 직접 구성하면 모든 것이 정상입니다. 따라서 하드웨어/네트워크 측면에서는 모든 것이 작동하는 것 같습니다. 이것을 디버깅하는 데 있어 다음으로 가장 좋은 단계가 무엇인지 아시나요?
답변1
주다fwupd모든 펌웨어가 최신인지 확인해보세요.
# install
dnf install fwupd
# check for compatible devices
fwupdmgr get-devices
# pull in newest update database
fwupdmgr refresh
# Gets the list of updates for connected hardware
fwupdmgr get-updates
# Run the updates
fwupdmgr update
이것이 귀하와 비슷한 문제를 겪고 있는 다른 사람들에게 도움이 되기를 바랍니다.
