Ubuntu 18.04에서 Tomcat 9.0.26을 실행 중입니다. 갑자기 Tomcat이 다운된 것을 발견했습니다. 내가 종료하지 않고서는 결코 그런 일이 일어나지 않았습니다. 추적을 보고 다음을 확인했습니다(이로 인해 종료 프로세스가 시작되는 것 같습니다).
29-Jan-2020 07:18:27.927 INFO [Thread-4] org.apache.coyote.AbstractProtocol.pause Pausing ProtocolHandler ["https-jsse-nio2-8443"]
29-Jan-2020 07:18:27.936 INFO [Thread-4] org.apache.coyote.AbstractProtocol.pause Pausing ProtocolHandler ["http-nio-8009"]
29-Jan-2020 07:18:27.946 INFO [Thread-4] org.apache.catalina.core.StandardService.stopInternal Stopping service [Catalina]
여기부터 시작하면 종료 프로세스 자체의 일부이지 원인은 아니지만 관련이 있을 수 있습니다.
29-Jan-2020 07:18:28.145 WARNING [Thread-4] org.apache.catalina.loader.WebappClassLoaderBase.clearReferencesThreads The web application [app] appears to have started a thread named [grpc-default-worker-ELG-1-1] but has failed to stop it. This is very likely to create a memory leak. Stack trace of thread:
위의 부분은 appears to have started a thread named [grpc-default-worker-ELG-1-1]예외 사이에서 변경됩니다. grpc-default-worker-ELG-1-2 Gax-2 Gax-3등등...
그 후 다음과 같은 여러 줄이 표시됩니다.
29-Jan-2020 07:18:28.154 SEVERE [Thread-4] org.apache.catalina.loader.WebappClassLoaderBase.checkThreadLocalMapForLeaks The web application [app] created a ThreadLocal with key of type [java.lang.ThreadLocal] (value [java.lang.ThreadLocal@117138f9]) and a value of type [io.grpc.netty.shaded.io.netty.util.internal.InternalThreadLocalMap] (value [io.grpc.netty.shaded.io.netty.util.internal.InternalThreadLocalMap@2b40bbea]) but failed to remove it when the web application was stopped. Threads are going to be renewed over time to try and avoid a probable memory leak.
그리고 마지막으로:
29-Jan-2020 07:18:28.262 INFO [Thread-4] org.apache.coyote.AbstractProtocol.stop Stopping ProtocolHandler ["https-jsse-nio2-8443"]
29-Jan-2020 07:18:28.305 INFO [Thread-4] org.apache.coyote.AbstractProtocol.stop Stopping ProtocolHandler ["http-nio-8009"]
29-Jan-2020 07:18:28.316 INFO [Thread-4] org.apache.coyote.AbstractProtocol.destroy Destroying ProtocolHandler ["https-jsse-nio2-8443"]
29-Jan-2020 07:18:28.323 INFO [Thread-4] org.apache.coyote.AbstractProtocol.destroy Destroying ProtocolHandler ["http-nio-8009"]
NOTE: Picked up JDK_JAVA_OPTIONS: --add-opens=java.base/java.lang=ALL-UNNAMED --add-opens=java.base/java.io=ALL-UNNAMED --add-opens=java.rmi/sun.rmi.transport=ALL-UNNAMED
어디서, 무엇을 찾아야 할지에 대한 힌트를 주시면 감사하겠습니다. 사전 예고 없이 폐쇄되면서 그곳에서 무슨 일이 일어났는지 궁금해진다. 감사해요
업데이트: 종료와 동시에 /var/log/apache2 로그에서 이것을 발견했습니다.
[Wed Jan 29 07:18:29.141852 2020] [mpm_prefork:notice] [pid 568] AH00169: caught SIGTERM, shutting down
[Wed Jan 29 07:38:12.843389 2020] [suexec:notice] [pid 513] AH01232: suEXEC mechanism enabled (wrapper: /usr/lib/apache2/suexec)
[Wed Jan 29 07:38:13.060250 2020] [mpm_prefork:notice] [pid 539] AH00163: Apache/2.4.29 (Ubuntu) mod_fcgid/2.3.9 OpenSSL/1.1.1 configured -- resuming normal operations
[Wed Jan 29 07:38:13.060350 2020] [core:notice] [pid 539] AH00094: Command line: '/usr/sbin/apache2'
mail.log에서 다음을 볼 수 있습니다(마지막 줄의 날짜 시간이 의심스럽습니다). postfix는 의도적으로 다운되었습니다.
Jan 29 07:38:08 app postgrey[271]: Process Backgrounded
Jan 29 07:38:08 app postgrey[271]: 2020/01/29-07:38:08 postgrey (type Net::Server::Multiplex) starting! pid(271)
Jan 29 07:38:08 app postgrey[271]: Resolved [localhost]:10023 to [::1]:10023, IPv6
Jan 29 07:38:08 app postgrey[271]: Resolved [localhost]:10023 to [127.0.0.1]:10023, IPv4
Jan 29 07:38:08 app postgrey[271]: Binding to TCP port 10023 on host ::1 with IPv6
Jan 29 07:38:08 app postgrey[271]: Binding to TCP port 10023 on host 127.0.0.1 with IPv4
Jan 29 07:38:08 app postgrey[271]: Setting gid to "122 122"
Jan 29 07:38:09 app postgrey[271]: Setting uid to "118"
Jan 29 07:38:11 app dovecot: master: Dovecot v2.2.33.2 (d6601f4ec) starting up for imap, pop3 (core dumps disabled)
Jan 29 07:38:12 app opendkim[502]: OpenDKIM Filter v2.11.0 starting (args: -P /var/run/opendkim/opendkim.pid -p inet:[email protected])
이것은 Postgrey에 대한 언급을 볼 수 있는 유일한 시간과 장소이며 그것이 무엇인지 전혀 모릅니다.
업데이트 2:여기서부터 상황이 무너지기 시작했습니다.
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#37793 (wWW.MUARaPeNimBunGiLiR.DeSA.Id): query (cache) 'wWW.MUARaPeNimBunGiLiR.DeSA.Id/A/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#43632 (WWW.mUarapEnImbunGIlIr.dEsA.iD): query (cache) 'WWW.mUarapEnImbunGIlIr.dEsA.iD/A/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#50618 (www.MuarAPEnImBUNgIliR.DEsA.id): query (cache) 'www.MuarAPEnImBUNgIliR.DEsA.id/A/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#40648 (WWW.muAraPeniMbungiLir.desA.iD): query (cache) 'WWW.muAraPeniMbungiLir.desA.iD/A/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#59108 (Www.mUARaPeniMbuNGiLIR.deSA.iD): query (cache) 'Www.mUARaPeniMbuNGiLIR.deSA.iD/A/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#42231 (wWW.mUARapenIMBUNgIlIr.DESA.ID): query (cache) 'wWW.mUARapenIMBUNgIlIr.DESA.ID/A/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#43692 (www.MUarAPeNimbUNGIliR.DeSA.ID): query (cache) 'www.MUarAPeNimbUNGIliR.DeSA.ID/A/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#47881 (Www.mUAraPeNIMBungiLiR.dESA.id): query (cache) 'Www.mUAraPeNIMBungiLiR.dESA.id/A/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#36046 (www.mUaraPeNimBungIliR.Desa.id): query (cache) 'www.mUaraPeNimBungIliR.Desa.id/AAAA/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#49623 (wWw.MuArapenimbUNgILIR.dESA.iD): query (cache) 'wWw.MuArapenimbUNgILIR.dESA.iD/AAAA/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#42436 (Www.muARaPeniMBuNGIliR.DeSa.id): query (cache) 'Www.muARaPeniMBuNGIliR.DeSa.id/AAAA/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#41600 (WWw.mUARAPeNiMbunGiLIr.DEsA.iD): query (cache) 'WWw.mUARAPeNiMbunGiLIr.DEsA.iD/AAAA/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#40947 (WWW.mUAraPeNIMbUNgiLir.DeSA.iD): query (cache) 'WWW.mUAraPeNIMbUNgiLir.DeSA.iD/AAAA/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#47416 (WWW.MUARApENiMBunGilIR.dESA.Id): query (cache) 'WWW.MUARApENiMBunGilIR.dESA.Id/AAAA/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#50269 (Www.mUarAPENImBuNgilir.dESA.id): query (cache) 'Www.mUarAPENImBuNgilir.dESA.id/AAAA/IN' denied
Jan 29 07:13:56 app named[461]: client @0x7f6cec025fa0 35.172.217.55#34727 (WWw.MUArApEniMBUngIliR.DesA.id): query (cache) 'WWw.MUArApEniMBUngIliR.DesA.id/AAAA/IN' denied
then a lot of logs similar to this: Jan 29 07:17:14 app systemd[1]: Started Session c5470 of user app.
Jan 29 07:18:26 app systemd[1]: Removed slice system-serial\x2dgetty.slice.
then a lot of logs similar to this: Jan 29 07:18:26 app systemd[1]: Stopped Session c2888 of user app.
Jan 29 07:18:27 app systemd[875]: Closed GnuPG cryptographic agent and passphrase cache.
Jan 29 07:18:27 app systemd[875]: Reached target Shutdown.
Jan 29 07:18:27 app systemd[875]: Starting Exit the Session...
Jan 29 07:18:27 app systemd[1]: Stopped Session c3432 of user app.
Jan 29 07:18:27 app systemd[875]: Received SIGRTMIN+24 from PID 13436 (kill).
Jan 29 07:38:06 app systemd-sysctl[85]: Couldn't write '1' to 'kernel/kptr_restrict', ignoring: Permission denied
Jan 29 07:38:06 app systemd-sysctl[85]: Couldn't write '1' to 'fs/protected_hardlinks', ignoring: Permission denied
Jan 29 07:38:06 app systemd-sysctl[85]: Couldn't write '1' to 'fs/protected_symlinks', ignoring: Permission denied
Jan 29 07:38:06 app systemd-sysctl[85]: Couldn't write '176' to 'kernel/sysrq', ignoring: Permission denied
Jan 29 07:38:06 app systemd-sysctl[85]: Couldn't write '1' to 'net/ipv4/tcp_syncookies', ignoring: No such file or directory
Jan 29 07:38:06 app systemd-sysctl[85]: Couldn't write '1' to 'kernel/yama/ptrace_scope', ignoring: Permission denied
Jan 29 07:38:06 app keyboard-setup.sh[67]: Couldn't get a file descriptor referring to the console
Jan 29 07:38:06 app systemd-sysctl[85]: Couldn't write '65536' to 'vm/mmap_min_addr', ignoring: Operation not permitted
Jan 29 07:38:06 app keyboard-setup.sh[67]: Couldn't get a file descriptor referring to the console
Jan 29 07:38:06 app systemd-sysctl[85]: Couldn't write 'fq_codel' to 'net/core/default_qdisc', ignoring: No such file or directory
Jan 29 07:38:06 app keyboard-setup.sh[67]: Couldn't get a file descriptor referring to the console
Jan 29 07:38:06 app keyboard-setup.sh[67]: message repeated 4 times: [ Couldn't get a file descriptor referring to the console]
Jan 29 07:38:06 app keyboard-setup.sh[67]: setupcon: We are not on the console, the console is left unconfigured.
왜 100개가 표시되나요 Stopped Session <session> of user...? 내 말은 100초라는 뜻이에요! 공개 세션인가요? 그럴 것 같나요? (초과 적재?)
또한 이 라인 Jan 29 07:18:27 app systemd[875]: Received SIGRTMIN+24 from PID 13436 (kill).은 매우 의심스럽습니다. PID 13436이 무엇인지 알 수 있나요?
답변1
댓글에서 언급했듯이, 내 첫 번째 아이디어는 종료 명령( SHUTDOWN)이 Tomcat의 종료 포트(기본적으로 8005인터페이스 포트에서 수신 대기 localhost)에서 전송되었다는 것입니다. 이 방법의 사용은 다음과 같은 경우에 권장됩니다.Tomcat의 문서.
그러나 Ubuntu(Debian 이후)는 기본적으로 종료 포트를 비활성화했습니다.버전 8.5.32-2. 최신 버전의 Tomcat은 JVM이 를 수신하면 완전한 종료를 수행하므로 SIGTERM종료 포트를 활성화하는 것은 보안 위험일 뿐입니다.
따라서 예상치 못한 종료의 주요 후보는 다음과 같습니다.
- 리눅스OutOfMemory 킬러, 커널 로그(
journalctl -k)에 기록됩니다. - 충돌JVM. 가상 머신 자체는 꽤 안정적이지만, 제가 본libtcnative그것을 내려 놓으십시오. Tomcat9의 기본 로그(
/var/log/catalina.<date>.log)를 확인하세요. Ubuntu 아래에도 잘 수집되어 있습니다.systemd-저널(journalctl -u tomcat9)로 보내졌습니다.시스템 로그. - 자바 자체메모리 부족오류, Tomcat9의 기본 로그에도 있어야 합니다.
업데이트: syslog 발췌 내용에 따르면 누군가 사용자에게 액세스 권한을 얻었습니다 app. 사용자에 대한 많은 사용자 세션이 app생성되어 시스템 리소스를 모두 사용하고 많은 서비스가 종료되었습니다.
