클러스터에서 포드로 실행되도록 Vault를 구성했습니다. 아래 배포 YAML 파일에는 포드가 처음 나타날 때 발생하는 저장소 초기화 및 잠금 해제가 포함되어 있습니다. 그러나 포드가 다시 시작되면 자격 증명 모음이 다시 초기화되기 때문에 포드는 crashLoopBackOff 상태가 됩니다. 이는 배포 파일의 postStart lifecycle 명령에 초기화 및 봉인 해제 명령을 모두 포함했기 때문입니다. 포드를 한 번만 초기화하고 나중에 포드가 다시 시작될 때 기존 키를 사용하여 저장소의 봉인을 해제할 수 있는 방법이 있습니까?
배포 파일:
apiVersion: extensions/v1beta1
kind: Deployment
metadata:
labels:
app: vault
name: vault
spec:
replicas: 1
template:
metadata:
labels:
app: vault
spec:
containers:
- image: vault
name: vault
imagePullPolicy: Always
ports:
- containerPort: 8200
name: vaultport
protocol: TCP
securityContext:
capabilities:
add:
- IPC_LOCK
env:
- name: VAULT_ADDR
value: "http://0.0.0.0:8200"
command: ["vault", "server"]
args:
- "-config=/vault/config/config.hcl"
volumeMounts:
- name: vault-unseal
mountPath: /vault/file/unseal.sh
subPath: unseal.sh
- name: vault-config
mountPath: /vault/config/config.hcl
subPath: config.hcl
lifecycle:
postStart:
exec:
command: ["/bin/sh", "-c", "vault operator init > /vault/file/keys.txt; sh /vault/file/unseal.sh" ]
volumes:
- name: vault-unseal
configMap:
name: vault-unseal
- name: vault-config
configMap:
name: vault-config
imagePullSecrets:
- name: regcred
kubectl explain pod의 출력:
Name: vault-677bfd9c9c-dwsgv
Namespace: xxx
Priority: 0
Node: xxxxxxx-5b587f98-ljf4/10.0.0.11
Start Time: Thu, 30 Jan 2020 06:26:21 +0000
Labels: app=vault
pod-template-hash=677bfd9c9c
Annotations: <none>
Status: Running
IP: 10.4.2.10
IPs: <none>
Controlled By: ReplicaSet/vault-677bfd9c9c
Containers:
vault:
Container ID: xxxxxxxxxxx
Image: xxxxxxxxxxxxxxxx
Image ID: xxxxxxxxxxxxxxxxxxxxxxxxx
Port: 8200/TCP
Host Port: 0/TCP
Command:
vault
server
Args:
-config=/vault/config/config.hcl
State: Waiting
Reason: CrashLoopBackOff
Last State: Terminated
Reason: Completed
Exit Code: 0
Started: Thu, 30 Jan 2020 06:26:26 +0000
Finished: Thu, 30 Jan 2020 06:26:27 +0000
Ready: False
Restart Count: 1
Environment:
VAULT_ADDR: http://0.0.0.0:8200
Mounts:
/var/run/secrets/kubernetes.io/serviceaccount from default-token-kxfdb (ro)
/vault/config/config.hcl from vault-config (rw,path="config.hcl")
/vault/file from vault-data (rw)
/vault/file/unseal.sh from vault-unseal (rw,path="unseal.sh")
Conditions:
Type Status
Initialized True
Ready False
ContainersReady False
PodScheduled True
Volumes:
vault-unseal:
Type: ConfigMap (a volume populated by a ConfigMap)
Name: vault-unseal
Optional: false
vault-config:
Type: ConfigMap (a volume populated by a ConfigMap)
Name: vault-config
Optional: false
vault-data:
Type: PersistentVolumeClaim (a reference to a PersistentVolumeClaim in the same namespace)
ClaimName: vault-data
ReadOnly: false
default-token-kxfdb:
Type: Secret (a volume populated by a Secret)
SecretName: default-token-kxfdb
Optional: false
QoS Class: BestEffort
Node-Selectors: <none>
Tolerations: node.kubernetes.io/not-ready:NoExecute for 300s
node.kubernetes.io/unreachable:NoExecute for 300s
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Normal Scheduled 18s default-scheduler Successfully assigned xxx/xxxxxxxxxx
Normal Pulling 13s (x2 over 15s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 pulling image "xxxxxxxxx"
Normal Pulled 13s (x2 over 15s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 Successfully pulled image "xxxxxxx"
Normal Created 13s (x2 over 15s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 Created container
Normal Started 13s (x2 over 14s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 Started container
Warning FailedPostStartHook 12s (x2 over 14s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 Exec lifecycle hook ([/bin/sh -c vault operator init > /vault/file/keys.txt; sh /vault/file/unseal.sh]) for Container "vault" in Pod "vault-677bfd9c9c-dwsgv_xxx(6ebdc17a-4329-11ea-9fc1-4201c0a80004)" failed - error: command '/bin/sh -c vault operator init > /vault/file/keys.txt; sh /vault/file/unseal.sh' exited with 2: Error initializing: Error making API request.
URL: PUT http://0.0.0.0:8200/v1/sys/init
Code: 400. Errors:
* Vault is already initialized
An error occurred attempting to ask for an unseal key. The raw error message
is shown below, but usually this is because you attempted to pipe a value
into the unseal command or you are executing outside of a terminal (tty). You
should run the unseal command from a terminal for maximum security. If this
is not an option, the unseal key can be provided as the first argument to the
unseal command. The raw error was: file descriptor 0 is not a terminal
An error occurred attempting to ask for an unseal key. The raw error message
is shown below, but usually this is because you attempted to pipe a value
into the unseal command or you are executing outside of a terminal (tty). You
should run the unseal command from a terminal for maximum security. If this
is not an option, the unseal key can be provided as the first argument to the
unseal command. The raw error was: file descriptor 0 is not a terminal
An error occurred attempting to ask for an unseal key. The raw error message
is shown below, but usually this is because you attempted to pipe a value
into the unseal command or you are executing outside of a terminal (tty). You
should run the unseal command from a terminal for maximum security. If this
is not an option, the unseal key can be provided as the first argument to the
unseal command. The raw error was: file descriptor 0 is not a terminal
Token (will be hidden):
Error authenticating: An error occurred attempting to ask for a token. The raw error message is shown below, but usually this is because you attempted to pipe a value into the command or you are executing outside of a terminal (tty). If you want to pipe the value, pass "-" as the argument to read from stdin. The raw error was: file descriptor 0 is not a terminal
, message: "Unseal Key (will be hidden): \nUnseal Key (will be hidden): \nUnseal Key (will be hidden): \nKey Value\n--- -----\nSeal Type shamir\nInitialized true\nSealed true\nTotal Shares 5\nThreshold 3\nUnseal Progress 0/3\nUnseal Nonce n/a\nVersion 1.3.2\nHA Enabled false\n++++++++++++ Vault Status +++++++++\nKey Value\n--- -----\nSeal Type shamir\nInitialized true\nSealed true\nTotal Shares 5\nThreshold 3\nUnseal Progress 0/3\nUnseal Nonce n/a\nVersion 1.3.2\nHA Enabled false\nError initializing: Error making API request.\n\nURL: PUT http://0.0.0.0:8200/v1/sys/init\nCode: 400. Errors:\n\n* Vault is already initialized\nAn error occurred attempting to ask for an unseal key. The raw error message\nis shown below, but usually this is because you attempted to pipe a value\ninto the unseal command or you are executing outside of a terminal (tty). You\nshould run the unseal command from a terminal for maximum security. If this\nis not an option, the unseal key can be provided as the first argument to the\nunseal command. The raw error was: file descriptor 0 is not a terminal\nAn error occurred attempting to ask for an unseal key. The raw error message\nis shown below, but usually this is because you attempted to pipe a value\ninto the unseal command or you are executing outside of a terminal (tty). You\nshould run the unseal command from a terminal for maximum security. If this\nis not an option, the unseal key can be provided as the first argument to the\nunseal command. The raw error was: file descriptor 0 is not a terminal\nAn error occurred attempting to ask for an unseal key. The raw error message\nis shown below, but usually this is because you attempted to pipe a value\ninto the unseal command or you are executing outside of a terminal (tty). You\nshould run the unseal command from a terminal for maximum security. If this\nis not an option, the unseal key can be provided as the first argument to the\nunseal command. The raw error was: file descriptor 0 is not a terminal\nToken (will be hidden): \nError authenticating: An error occurred attempting to ask for a token. The raw error message is shown below, but usually this is because you attempted to pipe a value into the command or you are executing outside of a terminal (tty). If you want to pipe the value, pass \"-\" as the argument to read from stdin. The raw error was: file descriptor 0 is not a terminal\n"
Normal Killing 12s (x2 over 14s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 Killing container with id docker://vault:FailedPostStartHook
Warning BackOff 10s (x2 over 11s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 Back-off restarting failed container
답변1
예, 이 경우 볼트가 이미 초기화되었는지 먼저 확인하려면 스크립트를 더 스마트하게 만들어야 합니다.다음은 bash 스크립트를 사용한 매우 간단한 예입니다..
또한 이를 달성하기 위한 일반적인 패턴은 사이드카를 사용하는 것입니다(결국 무기한 "휴면" 상태가 됨). 그러나 postStart어떤 경우에는 볼트 이전에 실행될 것이라는 점을 고려하여 스크립트의 탄력성을 충분히 높이는 한 후크도 작동해야 합니다. 컨테이너가 작동 중이고 결국 둘 다 동기화될 때까지 컨테이너를 종료하고 다시 시작하게 됩니다.
나는 강력히 추천하고 싶다Seth Vargo의 강연보다 정교한 Golang 프로그램을 사용하여 자동 초기화가 수행됩니다.
