IPv6을 사용하여 개시자를 응답자에 연결하려고 합니다.
둘 다 켜져 있고 Ubuntu 20.04초기 strongswan 5.9.0
자는 내 ISP 네트워크에 연결된 상자 뒤에 있는 개인용 컴퓨터의 가상 머신(VMware 사용)에 있습니다. VM은 호스트 컴퓨터와 함께 NAT 네트워크를 사용합니다. 응답자는 온라인 VPS입니다.
개시자는 ipv6(그의 호스트의 것)을 얻었고 응답자 ipv6에 ping을 보낼 수 있습니다. ipv6입니다. <initiator_ipv6>
응답자 ipv6이 올바르게 구성된 것 같습니다. 이를 사용하여 ping 및 ssh를 실행할 수 있습니다. IPv6 입니다<responder_ipv6>
IPv6는 다음 conf를 사용하여 활성화되었습니다(내 VPS 공급자가 제공한 대로).
/etc/netplan/51-ipv6.yaml
network:
version: 2
ethernets:
<responder_interface>:
dhcp4: true
dhcp6: false
match:
name: <responder_interface>
addresses:
- <responder_ipv6>/128
gateway6: <responder_ipv6_gateway>
routes:
- to: <responder_ipv6_gateway>
scope: link
두 Strongswan 모두 다음 명령으로 구성을 사용하여 개시자에 구축되었습니다.
./configure --prefix=<custom_dir> --with-piddir=<custom_dir>/var/run
make
make install
그들은 동일한 Strongswan.conf를 가지고 있는데, 이는 더 쉬운 디버그를 위해 filelog 옵션이 있는 대부분의 기본 파일입니다.
charon {
load_modular = yes
plugins {
include strongswan.d/charon/*.conf
}
filelog {
logger {
path = <custom_dir>/swanctl.log
time_format = %b %e %T
ike_name = yes
default = 1
flush_line = yes
}
}
}
include strongswan.d/*.conf
응답자에는 다음 swanctl.conf가 있습니다.
connections {
# Seems to change nothing
local_addrs = <responder_ipv6>
pubkey-vm {
pools = primary-pool-ipv4, primary-pool-ipv6
local {
auth = pubkey
certs = <responder_cert>
id = <responder_id>
}
remote {
auth = pubkey
id = <initiator_id>
}
children {
client {
}
}
}
}
pools {
primary-pool-ipv4 {
# Totally arbitrary value
addrs = 10.0.0.0/24
}
primary-pool-ipv6 {
# Totally arbitrary value
addrs = 2620:0:2d0:200::7/97
}
}
개시자는 다음과 같은 conf를 가지고 있습니다
connections {
initiator-to-host {
remote_addrs = <responder_ip>
# Any value works, at long as vips got a value (but assigned ip will be in the respodner pool)
vips = 1.2.3.4
local {
auth = pubkey
certs = <initator_cert>
id = <initiator_id>
}
remote {
auth = pubkey
id = <responder_id>
}
children {
to-host {
start_action = none
}
}
}
}
응답자 ipv4를 사용하여 연결을 시도하면 작동하고 시작이 성공적으로 완료됩니다. IP를 ipv6 IP로 전환하면 작동하지 않고 응답자에 다음 로그가 표시됩니다.
<pubkey-vm|4> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (80 bytes)
<pubkey-vm|4> parsed INFORMATIONAL request 2 [ D ]
<pubkey-vm|4> received DELETE for IKE_SA pubkey-vm[4]
<pubkey-vm|4> deleting IKE_SA pubkey-vm[4] between <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|4> IKE_SA deleted
<pubkey-vm|4> generating INFORMATIONAL response 2 [ ]
<pubkey-vm|4> sending packet: from <responder_ipv6>[4500] to <initiator_ipv6>[53870] (80 bytes)
<pubkey-vm|4> lease 10.0.0.1 by '<initiator_id>' went offline
<5> received packet: from <initiator_ipv6>[1016] to <responder_ipv6>[500] (392 bytes)
<5> parsed IKE_SA_INIT request 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) N(FRAG_SUP) N(HASH_ALG) N(REDIR_SUP) ]
<5> <initiator_ipv6> is initiating an IKE_SA
<5> selected proposal: IKE:AES_CBC_128/HMAC_SHA2_256_128/PRF_AES128_XCBC/CURVE_25519
<5> remote host is behind NAT
<5> sending cert request for "C=FR, O=Test, CN=Test CA"
<5> generating IKE_SA_INIT response 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) CERTREQ N(FRAG_SUP) N(HASH_ALG) N(CHDLESS_SUP) N(MULT_AUTH) ]
<5> sending packet: from <responder_ipv6>[500] to <initiator_ipv6>[1016] (273 bytes)
<5> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (356 bytes)
<5> parsed IKE_AUTH request 1 [ EF(2/2) ]
<5> received fragment #2 of 2, waiting for complete IKE message
<5> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (1220 bytes)
<5> parsed IKE_AUTH request 1 [ EF(1/2) ]
<5> received fragment #1 of 2, reassembled fragmented IKE message (1504 bytes)
<5> parsed IKE_AUTH request 1 [ IDi CERT N(INIT_CONTACT) CERTREQ IDr AUTH CPRQ(ADDR DNS) SA TSi TSr N(MOBIKE_SUP) N(ADD_4_ADDR) N(MULT_AUTH) N(EAP_ONLY) N(MSG_ID_SYN_SUP) ]
<5> received cert request for "C=FR, O=Test, CN=Test CA"
<5> received end entity cert "C=FR, O=Test, CN=<initiator_id>"
<5> looking for peer configs matching <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|5> selected peer config 'pubkey-vm'
<pubkey-vm|5> using trusted ca certificate "C=FR, O=Test, CN=Test CA"
<pubkey-vm|5> checking certificate status of "C=FR, O=Test, CN=<initiator_id>"
<pubkey-vm|5> certificate status is not available
<pubkey-vm|5> reached self-signed root ca with a path length of 0
<pubkey-vm|5> using trusted certificate "C=FR, O=Test, CN=<initiator_id>"
<pubkey-vm|5> authentication of '<initiator_id>' with RSA_EMSA_PKCS1_SHA2_256 successful
<pubkey-vm|5> peer supports MOBIKE
<pubkey-vm|5> authentication of '<responder_id>' (myself) with RSA_EMSA_PKCS1_SHA2_256 successful
<pubkey-vm|5> IKE_SA pubkey-vm[5] established between <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|5> scheduling rekeying in 14286s
<pubkey-vm|5> maximum IKE_SA lifetime 15726s
<pubkey-vm|5> sending end entity cert "C=FR, O=Test, CN=<responder_id>"
<pubkey-vm|5> peer requested virtual IP 1.2.3.4
<pubkey-vm|5> reassigning offline lease to '<initiator_id>'
<pubkey-vm|5> assigning virtual IP 10.0.0.1 to peer '<initiator_id>'
<pubkey-vm|5> selected proposal: ESP:AES_GCM_16_128
<pubkey-vm|5> received netlink error: Invalid argument (22)
<pubkey-vm|5> unable to add SAD entry with SPI cffdef3f (FAILED)
<pubkey-vm|5> received netlink error: Invalid argument (22)
<pubkey-vm|5> unable to add SAD entry with SPI c028512b (FAILED)
<pubkey-vm|5> unable to install inbound and outbound IPsec SA (SAD) in kernel
<pubkey-vm|5> failed to establish CHILD_SA, keeping IKE_SA
<pubkey-vm|5> generating IKE_AUTH response 1 [ IDr CERT AUTH CPRP(ADDR) N(MOBIKE_SUP) N(ADD_4_ADDR) N(NO_PROP) ]
<pubkey-vm|5> sending packet: from <responder_ipv6>[4500] to <initiator_ipv6>[53870] (1216 bytes)
클라이언트측 로그는 여기에 있습니다.
Starting IKE charon daemon (strongSwan 5.9.0, Linux 5.4.0-56-generic, x86_64)
loading ca certificates from '<custom_path>/etc/ipsec.d/cacerts'
loading aa certificates from '<custom_path>/etc/ipsec.d/aacerts'
loading ocsp signer certificates from '<custom_path>/etc/ipsec.d/ocspcerts'
loading attribute certificates from '<custom_path>/etc/ipsec.d/acerts'
loading crls from '<custom_path>/etc/ipsec.d/crls'
loading secrets from '<custom_path>/etc/ipsec.secrets'
loaded plugins: charon aes eap-aka eap-dynamic eap-identity eap-sim eap-tls des rc2 sha2 sha1 md5 mgf1 random nonce x509 revocation constraints pubkey pkcs1 pkcs7 pkcs8 pkcs12 pgp dnskey sshkey pem fips-prf gmp curve25519 xcbc cmac hmac drbg attr kernel-netlink resolve socket-default stroke vici updown xauth-generic counters
spawning 16 worker threads
loaded certificate 'C=FR, O=Test, CN=<responder_id>'
loaded certificate 'C=FR, O=Test, CN=<initiator_id>'
loaded certificate 'C=FR, O=Test, CN=Test CA'
loaded RSA private key
loaded RSA private key
added vici connection: host-host
vici initiate CHILD_SA 'to-host'
<host-host|1> initiating IKE_SA host-host[1] to <responder_ipv6>
<host-host|1> generating IKE_SA_INIT request 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) N(FRAG_SUP) N(HASH_ALG) N(REDIR_SUP) ]
<host-host|1> sending packet: from <initiator_ipv6>[500] to <responder_ipv6>[500] (392 bytes)
<host-host|1> received packet: from <responder_ipv6>[500] to <initiator_ipv6>[500] (273 bytes)
<host-host|1> parsed IKE_SA_INIT response 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) CERTREQ N(FRAG_SUP) N(HASH_ALG) N(CHDLESS_SUP) N(MULT_AUTH) ]
<host-host|1> selected proposal: IKE:AES_CBC_128/HMAC_SHA2_256_128/PRF_AES128_XCBC/CURVE_25519
<host-host|1> local host is behind NAT, sending keep alives
<host-host|1> received cert request for "C=FR, O=Test, CN=Test CA"
<host-host|1> sending cert request for "C=FR, O=Test, CN=Test CA"
<host-host|1> authentication of '<initiator_id>' (myself) with RSA_EMSA_PKCS1_SHA2_256 successful
<host-host|1> sending end entity cert "C=FR, O=Test, CN=<initiator_id>"
<host-host|1> establishing CHILD_SA to-host{1}
<host-host|1> generating IKE_AUTH request 1 [ IDi CERT N(INIT_CONTACT) CERTREQ IDr AUTH CPRQ(ADDR DNS) SA TSi TSr N(MOBIKE_SUP) N(ADD_4_ADDR) N(MULT_AUTH) N(EAP_ONLY) N(MSG_ID_SYN_SUP) ]
<host-host|1> splitting IKE message (1504 bytes) into 2 fragments
<host-host|1> generating IKE_AUTH request 1 [ EF(1/2) ]
<host-host|1> generating IKE_AUTH request 1 [ EF(2/2) ]
<host-host|1> sending packet: from <initiator_ipv6>[4500] to <responder_ipv6>[4500] (1220 bytes)
<host-host|1> sending packet: from <initiator_ipv6>[4500] to <responder_ipv6>[4500] (356 bytes)
<host-host|1> received packet: from <responder_ipv6>[4500] to <initiator_ipv6>[4500] (1216 bytes)
<host-host|1> parsed IKE_AUTH response 1 [ IDr CERT AUTH CPRP(ADDR) N(MOBIKE_SUP) N(ADD_4_ADDR) N(NO_PROP) ]
<host-host|1> received end entity cert "C=FR, O=Test, CN=<responder_id>"
<host-host|1> using trusted ca certificate "C=FR, O=Test, CN=Test CA"
<host-host|1> checking certificate status of "C=FR, O=Test, CN=<responder_id>"
<host-host|1> certificate status is not available
<host-host|1> reached self-signed root ca with a path length of 0
<host-host|1> using trusted certificate "C=FR, O=Test, CN=<responder_id>"
<host-host|1> authentication of '<responder_id>' with RSA_EMSA_PKCS1_SHA2_256 successful
<host-host|1> IKE_SA host-host[1] established between <initiator_ipv6>[<initiator_id>]...<responder_ipv6>[<responder_id>]
<host-host|1> scheduling rekeying in 13877s
<host-host|1> maximum IKE_SA lifetime 15317s
<host-host|1> installing new virtual IP 10.0.0.1
<host-host|1> received NO_PROPOSAL_CHOSEN notify, no CHILD_SA built
<host-host|1> failed to establish CHILD_SA, keeping IKE_SA
<host-host|1> peer supports MOBIKE
그 문제를 해결하는 방법에 대한 아이디어가 있습니까?
--enable-kernel-libipsec구성 옵션을 사용하여 솔루션을 시도했습니다 . 그래서 지금 나는 얻었다
./configure --prefix=<custom_dir> --with-piddir=<custom_dir>/var/run --enable-kernel-libipsec
개시자 측 로그는 동일하게 유지되었지만 아래에 새로운 응답자 측 로그가 있습니다.
[CFG] <pubkey-vm|1> selected proposal: ESP:AES_GCM_16_128
[ESP] <pubkey-vm|1> failed to create ESP context: unsupported AEAD algorithm AES_GCM_16
[ESP] <pubkey-vm|1> failed to create SAD entry
[ESP] <pubkey-vm|1> failed to create ESP context: unsupported AEAD algorithm AES_GCM_16
[ESP] <pubkey-vm|1> failed to create SAD entry
[IKE] <pubkey-vm|1> unable to install inbound and outbound IPsec SA (SAD) in kernel
[IKE] <pubkey-vm|1> failed to establish CHILD_SA, keeping IKE_SA
답변1
여기에서 피어가 감지한 대로 호스트 간에 NAT가 있는 경우:
<5> remote host is behind NAT
그리고
<host-host|1> local host is behind NAT, sending keep alives
ESP에 대한 UDP 캡슐화는 IPsec SA(NAT-Traversal)에 대해 활성화됩니다. 그러나 이를 위해서는 Linux가 IPv6용 5.8부터만 제공하는 IPsec 스택의 지원이 필요합니다. 따라서 오래된 커널에서는 이것이 작동하지 않습니다.
최신 커널을 사용하거나, NAT를 제거하거나, IPv4 사용으로 돌아가거나, 대체 IPsec 스택(예: StrongSwan 자체 스택)을 사용해야 합니다.libipsec).
