jsxc/xmpp-cloud-auth와 함께 ejabberd 서버를 사용하여 nextcloud용 외부 xmpp 서버를 설정하는 데 문제가 있습니다.
nextcloud 외부 서버 구성에서 XMPP 도메인 오류가 표시되었습니다.https://cloud.XXX.com:5280 BOSH URL: /http-bind/ 잘못된 XML이 수신되었습니다. 아마도https://cloud.XXX.com/http-bind/리디렉션되었습니다. 절대 URL을 사용해야 합니다.
브라우저를 사용하여 탐색하면 /http-bind에서 404 Not Found가 표시되고, 내 관리 패널도 약간 이상하게 표시되고 모든 것이 표시되지는 않습니다(사진에서 볼 수 있듯이).
나는 다음을 사용하고 있습니다: ubuntu 20.04.1 Apache2 2.4.41 ejabberd 20.12 Nextcloud JavaScript XMPP Chat 4.2.0 xmpp-cloud-auth v2.0.4
이 기사를 사용하여 시스템을 설정했습니다.https://github.com/jsxc/xmpp-cloud-auth/wiki/raspberry-pi-en
왜 이런 일이 발생하는지 아는 사람이 있나요? 404 오류의 원인은 무엇일까요? 누가 http-bind에 답변을 요청합니까? 그리고 원하는 출력은 무엇입니까?
방화벽 설정은 괜찮은 것 같습니다. 로컬에서만 실행되기 때문에 현재 DNS 설정이 설정되어 있지 않습니다. 서버에 호스트 이름 cloud.XXX.com을 제공하는 Windows DNS 서버가 네트워크에서 실행되고 있습니다.
동작을 재현하는 단계
- 타자https://cloud.XXX.com:5280/http-bind브라우저에서
- 404 오류가 발생함
환경
- JSXC 버전: JavaScript XMPP 채팅 4.2.0 xmpp-cloud-auth v2.0.4
- 호스트 시스템 및 버전: Nextcloud 20.0.4 우분투 20.04.1 Apache2 2.4.41
- 브라우저 공급업체 및 버전: 파이어폭스 84.0.1
- 브라우저 플러그인이 활성화되어 있나요? 아니요
- XMPP 서버 공급업체 및 버전: 20.12에 재버드
- XMPP 서버가 예상대로 다른 클라이언트와 작동하고 있습니까?
아니요...
apache2 가상 호스트는 다음과 같이 사용자 정의됩니다.
<VirtualHost *:80>
ServerAdmin webmaster@localhost
DocumentRoot /var/www
<FilesMatch ".php$">
<If "-f %{SCRIPT_FILENAME}">
SetHandler "proxy:unix:/run/php/php7.4-fpm.nextcloud.sock|fcgi://localhost"
</If>
</FilesMatch>
ErrorLog ${APACHE_LOG_DIR}/error.log
CustomLog ${APACHE_LOG_DIR}/access.log combined
ProxyPass /http-bind/ http://localhost:5280/http-bind/
ProxyPassReverse /http-bind/ http://localhost:5280/http-bind/
ProxyPreserveHost On
RewriteEngine on
RewriteCond %{SERVER_NAME} =cloud.XXX.com
RewriteRule ^ https://%{SERVER_NAME}%{REQUEST_URI} [END,NE,R=permanent]
</VirtualHost>
내 ejabberd.yml:
---
loglevel: 4
log_rotate_count: 0
log_rotate_date: ""
hosts:
- "cloud.spacyal.com"
certfiles:
- "/etc/ejabberd/ejabberd.pem"
## TLS configuration
define_macro:
'TLS_CIPHERS': "HIGH:!aNULL:!eNULL:!3DES:@STRENGTH"
'TLS_OPTIONS':
- "no_sslv3"
- "no_tlsv1"
- "no_tlsv1_1"
- "cipher_server_preference"
- "no_compression"
## 'DH_FILE': "/path/to/dhparams.pem"
## generated with: openssl dhparam -out dhparams.pem 2048
c2s_ciphers: 'TLS_CIPHERS'
s2s_ciphers: 'TLS_CIPHERS'
c2s_protocol_options: 'TLS_OPTIONS'
s2s_protocol_options: 'TLS_OPTIONS'
## c2s_dhfile: 'DH_FILE'
## s2s_dhfile: 'DH_FILE'
listen:
-
port: 5222
ip: "::"
module: ejabberd_c2s
max_stanza_size: 262144
shaper: c2s_shaper
access: c2s
starttls_required: true
protocol_options: 'TLS_OPTIONS'
-
port: 5223
ip: "::"
module: ejabberd_c2s
max_stanza_size: 262144
shaper: c2s_shaper
access: c2s
tls: true
protocol_options: 'TLS_OPTIONS'
-
port: 5269
ip: "::"
module: ejabberd_s2s_in
max_stanza_size: 524288
-
port: 5443
ip: "::"
module: ejabberd_http
tls: true
protocol_options: 'TLS_OPTIONS'
request_handlers:
/api: mod_http_api
/bosh: mod_bosh
## /captcha: ejabberd_captcha
## /upload: mod_http_upload
/ws: ejabberd_http_ws
-
port: 5280
ip: "::"
module: ejabberd_http
tls: true
protocol_options: 'TLS_OPTIONS'
request_handlers:
/admin: ejabberd_web_admin
/.well-known/acme-challenge: ejabberd_acme
-
port: 1883
ip: "::"
module: mod_mqtt
backlog: 1000
## Disabling digest-md5 SASL authentication. digest-md5 requires plain-text
## password storage (see auth_password_format option).
disable_sasl_mechanisms:
- "digest-md5"
- "X-OAUTH2"
s2s_use_starttls: required
## Store the plain passwords or hashed for SCRAM:
auth_password_format: scram
auth_method: external
extauth_program: "/usr/bin/socket localhost 23662"
auth_use_cache: false
## Full path to a script that generates the image.
## captcha_cmd: "/usr/share/ejabberd/captcha.sh"
acl:
admin:
user:
- "admin"
local:
user_regexp: ""
loopback:
ip:
- 127.0.0.0/8
- ::1/128
access_rules:
local:
allow: local
c2s:
deny: blocked
allow: all
announce:
allow: admin
configure:
allow: admin
muc_create:
allow: local
pubsub_createnode:
allow: local
trusted_network:
allow: loopback
api_permissions:
"console commands":
from:
- ejabberd_ctl
who: all
what: "*"
"admin access":
who:
access:
allow:
acl: loopback
acl: admin
oauth:
scope: "ejabberd:admin"
access:
allow:
acl: loopback
acl: admin
what:
- "*"
- "!stop"
- "!start"
"public commands":
who:
ip: 127.0.0.1/8
what:
- status
- connected_users_number
shaper:
normal: 1000
fast: 50000
shaper_rules:
max_user_sessions: 10
max_user_offline_messages:
5000: admin
100: all
c2s_shaper:
none: admin
normal: all
s2s_shaper: fast
modules:
mod_adhoc: {}
mod_admin_extra: {}
mod_announce:
access: announce
mod_avatar: {}
mod_blocking: {}
mod_bosh: {}
mod_caps: {}
mod_carboncopy: {}
mod_client_state: {}
mod_configure: {}
## mod_delegation: {} # for xep0356
mod_disco: {}
mod_echo: {}
mod_fail2ban: {}
mod_http_api: {}
## mod_http_upload:
## put_url: https://@HOST@:5443/upload
mod_last: {}
## mod_mam:
## ## Mnesia is limited to 2GB, better to use an SQL backend
## ## For small servers SQLite is a good fit and is very easy
## ## to configure. Uncomment this when you have SQL configured:
## ## db_type: sql
## assume_mam_usage: true
## default: always
mod_mqtt: {}
mod_muc:
access:
- allow
access_admin:
- allow: admin
access_create: muc_create
access_persistent: muc_create
access_mam:
- allow
default_room_options:
mam: true
mod_muc_admin: {}
mod_offline:
access_max_user_messages: max_user_offline_messages
mod_ping: {}
mod_pres_counter:
count: 5
interval: 60
mod_privacy: {}
mod_private: {}
mod_proxy65:
access: local
max_connections: 5
mod_pubsub:
access_createnode: pubsub_createnode
plugins:
- flat
- pep
force_node_config:
"eu.siacs.conversations.axolotl.*":
access_model: open
## Avoid buggy clients to make their bookmarks public
storage:bookmarks:
access_model: whitelist
mod_push: {}
mod_push_keepalive: {}
## mod_register:
## ## Only accept registration requests from the "trusted"
## ## network (see access_rules section above).
## ## Think twice before enabling registration from any
## ## address. See the Jabber SPAM Manifesto for details:
## ## https://github.com/ge0rg/jabber-spam-fighting-manifesto
## ip_access: trusted_network
mod_roster:
versioning: true
mod_s2s_dialback: {}
mod_shared_roster: {}
mod_sic: {}
mod_stream_mgmt:
resend_on_timeout: if_offline
mod_vcard:
search: false
mod_vcard_xupdate: {}
mod_version: {}
ejabberd.log 내용:
2020-12-25 22:03:38.847 [notice] <0.128.0>@lager_file_backend:154 Changed loghwm of /var/log/ejabberd/error.log to 100
2020-12-25 22:03:38.847 [notice] <0.128.0>@lager_file_backend:154 Changed loghwm of /var/log/ejabberd/ejabberd.log to 100
2020-12-25 22:03:38.908 [info] <0.114.0>@ejabberd_config:load:80 Loading configuration from /etc/ejabberd/ejabberd.yml
2020-12-25 22:03:38.919 [warning] <0.114.0>@ejabberd_config_transformer:warn_removed_module:514 Module mod_echo is deprecated and was automatically removed from the configuration. Please adjust your configuration file accordingly. Hint: run `ejabberdctl dump-config` command to view current configuration as it is seen by ejabberd.
2020-12-25 22:03:39.010 [warning] <0.114.0>@gen_mod:warn_soft_dep_fail:576 Module mod_mam is recommended for module mod_muc but is not found in the config
2020-12-25 22:03:39.023 [info] <0.114.0>@ejabberd_config:load:87 Configuration loaded successfully
2020-12-25 22:03:39.262 [info] <0.359.0>@gen_mod:start_modules:124 Loading modules for cloud.spacyal.com
2020-12-25 22:03:39.431 [info] <0.473.0>@mod_mqtt:init_topic_cache:523 Building MQTT cache for cloud.spacyal.com, this may take a while
2020-12-25 22:03:39.490 [info] <0.114.0>@ejabberd_cluster_mnesia:wait_for_sync:123 Waiting for Mnesia synchronization to complete
2020-12-25 22:03:39.629 [info] <0.114.0>@ejabberd_app:start:62 ejabberd 20.01-1 is started in the node ejabberd@localhost in 0.91s
2020-12-25 22:03:39.629 [info] <0.380.0>@ejabberd_listener:init:151 Start accepting TCP connections at [::]:5222 for ejabberd_c2s
2020-12-25 22:03:39.629 [info] <0.381.0>@ejabberd_listener:init:151 Start accepting TLS connections at [::]:5223 for ejabberd_c2s
2020-12-25 22:03:39.629 [info] <0.382.0>@ejabberd_listener:init:151 Start accepting TCP connections at [::]:5269 for ejabberd_s2s_in
2020-12-25 22:03:39.631 [info] <0.383.0>@ejabberd_listener:init:151 Start accepting TLS connections at [::]:5443 for ejabberd_http
2020-12-25 22:03:39.631 [info] <0.384.0>@ejabberd_listener:init:151 Start accepting TLS connections at [::]:5280 for ejabberd_http
2020-12-25 22:03:39.632 [info] <0.385.0>@ejabberd_listener:init:151 Start accepting TCP connections at [::]:1883 for mod_mqtt
2020-12-25 22:03:39.632 [info] <0.477.0>@ejabberd_listener:init:151 Start accepting TCP connections at 10.0.0.4:7777 for mod_proxy65_stream
2020-12-25 22:03:59.226 [info] <0.384.0>@ejabberd_listener:accept:256 (<0.531.0>) Accepted connection [::ffff:10.0.0.3]:60338 -> [::ffff:10.0.0.4]:5280
어떤 아이디어?? 나는 매우 감사하게 될 것입니다! 이틀째 노력했는데 해결이 안되네요
정말 고마워 !!
그리고 메리 크리스마스 :-)
답변1
구성 방법을 확인하세요. ejabberd에게 path 를 수신하도록 지시하는 경우 /bosh해당 URL을 사용해야 합니다. 예를 들어:
listen:
...
-
port: 5280
ip: "::"
module: ejabberd_http
tls: false
request_handlers:
/bosh: mod_bosh
-
port: 5443
ip: "::"
module: ejabberd_http
tls: true
request_handlers:
/bosh: mod_bosh
이것은 작동합니다:
$ curl http://localhost:5280/bosh/
<?xml version='1.0'?>
<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns='http://www.w3.org/1999/xhtml'><head><title>ejabberd mod_bosh</title><style>body {
...
$ curl -k https://localhost:5443/bosh/
<?xml version='1.0'?>
<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns='http://www.w3.org/1999/xhtml'><head><title>ejabberd mod_bosh</title><style>body {
...
