우리는 terraform kubernetes 공급자를 사용하여 kubernetes 배포를 수행하는 동시에 클러스터 eks 자체를 생성했습니다.
그 후 우리가 파괴하려고 할 때, 아직 제품을 사용하지 않고 파괴 테스트만 했습니다. Terraform destroy에서 아래 오류가 발생했습니다.
kubernetes_persistent_volume_claim.prometheus-pvc: Still destroying... [id=default/prometheus-pvc, 19m30s elapsed]
kubernetes_persistent_volume_claim.register-pvc[0]: Still destroying... [id=default/register-pvc, 19m30s elapsed]
kubernetes_persistent_volume_claim.register-pvc[0]: Still destroying... [id=default/register-pvc, 19m40s elapsed]
kubernetes_persistent_volume_claim.prometheus-pvc: Still destroying... [id=default/prometheus-pvc, 19m40s elapsed]
kubernetes_persistent_volume_claim.prometheus-pvc: Still destroying... [id=default/prometheus-pvc, 19m50s elapsed]
kubernetes_persistent_volume_claim.register-pvc[0]: Still destroying... [id=default/register-pvc, 19m50s elapsed]
╷
│ Error: Persistent volume claim prometheus-pvc still exists with finalizers: [kubernetes.io/pvc-protection]
│
│
╵
╷
│ Error: Persistent volume claim register-pvc still exists with finalizers: [kubernetes.io/pvc-protection]
│
│
╵
time=2022-06-17T19:38:38Z level=error msg=1 error occurred:
* exit status 1
Error destroying Terraform
영구 볼륨:
kubectl get pv
NAME CAPACITY ACCESS MODES RECLAIM POLICY STATUS CLAIM STORAGECLASS REASON AGE
pvc-51256bfd-4e32-4a4f-a24b-c0f47f9e1d63 100Gi RWO Delete Bound default/db-persistent-storage-db-0 ssd 171m
pvc-9453236c-ffc3-4161-a205-e057c3e1ba77 20Gi RWO Delete Bound default/prometheus-pvc hdd 171m
pvc-ddfef2b9-9723-4651-916b-2cb75baf0f22 20Gi RWO Delete Bound default/register-pvc ssd 171m
지속성 볼륨 요구:
kubectl get pvc
NAME STATUS VOLUME CAPACITY ACCESS MODES STORAGECLASS AGE
db-persistent-storage-db-0 Bound pvc-51256bfd-4e32-4a4f-a24b-c0f47f9e1d63 100Gi RWO ssd 173m
prometheus-pvc Terminating pvc-9453236c-ffc3-4161-a205-e057c3e1ba77 20Gi RWO hdd 173m
register-pvc Terminating pvc-ddfef2b9-9723-4651-916b-2cb75baf0f22 20Gi RWO ssd 173m
이벤트는 다음과 같습니다.
45m Normal VolumeDelete persistentvolume/pvc-0e5c621a-529c-4458-b224-39ea22a783fc error deleting EBS volume "vol-0e36ca327609ae963" since volume is currently attached to "i-0bff735f4c0871705"
46m Warning NodeNotReady pod/quicksilver-pg2wb Node is not ready
46m Normal Killing pod/reducer-0 Stopping container reducer
46m Normal Killing pod/reducer-0 Stopping container checkup-buddy
45m Warning Unhealthy pod/reducer-0 Readiness probe failed: Get "http://10.0.130.242:9001/": dial tcp 10.0.130.242:9001: connect: connection refused
46m Warning NodeNotReady pod/register-0 Node is not ready
44m Normal TaintManagerEviction pod/register-0 Cancelling deletion of Pod default/register-0
그리고 해당 인스턴스는 쿠버네티스 자동 확장 그룹의 일부인 것 같습니다.
[ec2-user@ip-172-31-16-242 software]$ kubectl get po
NAME READY STATUS RESTARTS AGE
auto-updater-27601140-4gqtw 0/1 Error 0 50m
auto-updater-27601140-hzrnl 0/1 Error 0 49m
auto-updater-27601140-kmspn 0/1 Error 0 50m
auto-updater-27601140-m4ws6 0/1 Error 0 49m
auto-updater-27601140-wsdpm 0/1 Error 0 45m
auto-updater-27601140-z2m7r 0/1 Error 0 48m
estimator-0 3/3 Terminating 0 51m
reducer-0 1/2 Terminating 0 51m
[ec2-user@ip-172-31-16-242 software]$ kubectl get pvc
NAME STATUS VOLUME CAPACITY ACCESS MODES STORAGECLASS AGE
db-persistent-storage-db-0 Bound pvc-ca829a02-9bf5-4540-9900-b6e5ab4624a2 100Gi RWO ssd 52m
estimator Terminating pvc-e028acd5-eeb1-4028-89c2-a42c1d28091e 200Gi RWO hdd 52m
[ec2-user@ip-172-31-16-242 software]$ kubectl get logs estimator-0
error: the server doesn't have a resource type "logs"
[ec2-user@ip-172-31-16-242 software]$ kubectl logs estimator-0
error: a container name must be specified for pod estimator-0, choose one of: [postgres estimator resize-buddy]
[ec2-user@ip-172-31-16-242 software]$ kubectl logs estimator-0 -c estimator
Error from server (InternalError): Internal error occurred: Authorization error (user=kube-apiserver-kubelet-client, verb=get, resource=nodes, subresource=proxy)
[ec2-user@ip-172-31-16-242 software]$ kubectl logs estimator-0 -c postgres
Error from server (InternalError): Internal error occurred: Authorization error (user=kube-apiserver-kubelet-client, verb=get, resource=nodes, subresource=proxy)
[ec2-user@ip-172-31-16-242 software]$ kubectl logs estimator-0 -c resize-buddy
Error from server (InternalError): Internal error occurred: Authorization error (user=kube-apiserver-kubelet-client, verb=get, resource=nodes, subresource=proxy)
[ec2-user@ip-172-31-16-242 software]$
그리고 감속기 포드의 세부 사항입니다.
[ec2-user@ip-172-31-16-242 software]$ kubectl logs reducer-0
Default container name "data-cruncher" not found in pod reducer-0
error: a container name must be specified for pod reducer-0, choose one of: [reducer checkup-buddy] or one of the init containers: [set-resource-owner]
[ec2-user@ip-172-31-16-242 software]$ kubectl logs reducer-0 -c reducer
Error from server (InternalError): Internal error occurred: Authorization error (user=kube-apiserver-kubelet-client, verb=get, resource=nodes, subresource=proxy)
[ec2-user@ip-172-31-16-242 software]$ kubectl logs reducer-0 -c checkup-buddy
Error from server (InternalError): Internal error occurred: Authorization error (user=kube-apiserver-kubelet-client, verb=get, resource=nodes, subresource=proxy)
심지어 자동 업데이트 포드도 확인했습니다. 비슷한 인증 오류도 발생합니다.
kubectl logs auto-updater-27601140-4gqtw
Error from server (InternalError): Internal error occurred: Authorization error (user=kube-apiserver-kubelet-client, verb=get, resource=nodes, subresource=proxy)
그리고 kubectl edit을 사용하여 PVC 내용을 확인하려고 했더니 아래와 같은 정보를 얻었습니다.
Volume.beta.kubernetes.io/storage-provisioner: kubernetes.io/aws-ebs
[ec2-user@ip-172-31-16-242 ~]$ kubectl describe pv pvc-ca829a02-9bf5-4540-9900-b6e5ab4624a2
Name: pvc-ca829a02-9bf5-4540-9900-b6e5ab4624a2
Labels: topology.kubernetes.io/region=us-west-2
topology.kubernetes.io/zone=us-west-2b
Annotations: kubernetes.io/createdby: aws-ebs-dynamic-provisioner
pv.kubernetes.io/bound-by-controller: yes
pv.kubernetes.io/provisioned-by: kubernetes.io/aws-ebs
Finalizers: [kubernetes.io/pv-protection]
StorageClass: ssd
Status: Terminating (lasts 89m)
Claim: default/db-persistent-storage-db-0
Reclaim Policy: Delete
Access Modes: RWO
VolumeMode: Filesystem
Capacity: 100Gi
Node Affinity:
Required Terms:
Term 0: topology.kubernetes.io/zone in [us-west-2b]
topology.kubernetes.io/region in [us-west-2]
Message:
Source:
Type: AWSElasticBlockStore (a Persistent Disk resource in AWS)
VolumeID: aws://us-west-2b/vol-02bc902640cdb406c
FSType: ext4
Partition: 0
ReadOnly: false
Events: <none>
볼륨 첨부 없음
[ec2-user@ip-172-31-16-242 ~]$ kubectl get volumeattachment
No resources found
노드:
kubectl get node
NAME STATUS ROLES AGE VERSION
ip-10-0-134-174.us-west-2.compute.internal NotReady <none> 3h8m v1.21.12-eks-5308cf7
ip-10-0-142-12.us-west-2.compute.internal NotReady <none> 3h5m v1.21.12-eks-5308cf7
그리고 컴퓨팅 섹션에는 노드가 없습니다.
이 문제를 해결하는 방법을 제안해 주세요.
