여러 어댑터가 있는 VMWare의 Ubuntu - 외부에서 핑할 수 없음

tag-icon • tag-icon ubuntu iproute2 netplan
여러 어댑터가 있는 VMWare의 Ubuntu - 외부에서 핑할 수 없음

저는 3개의 nic 어댑터를 사용하여 기계를 만들었습니다. 구성된 네트워크 내에서는 모든 것이 작동하지만 라우팅이 올바르게 작동하지 않는 것 같습니다.

ping 8.8.8.8
ping: connect: Network is unreachable

내 구성은 다음과 같습니다.

/etc/netplan/00-installer-config.yaml :

network:
  version: 2
  ethernets:
    ens160:
      addresses:
      - 172.16.1.114/16
      match:
          macaddress: 00:50:56:aa:00:1d
      nameservers:
        addresses:
        - 172.16.1.11
        - 172.16.1.20
        search:
        - domain.com
      set-name: produzione
      routes:
          - to: 0.0.0.0/0
            via: 172.16.1.1
            table: 60
      routing-policy:
          - from: 172.16.1.114
            table: 60
            priority: 300
    ens192:
      addresses:
      - 172.21.2.114/16
      match:
          macaddress: 00:50:56:aa:6f:ed
      nameservers:
        addresses:
        - 172.16.1.11
        - 172.16.1.20
        search:
        - domain.com
      set-name: qa
      routes:
          - to: 0.0.0.0/0
            via: 172.21.1.1
            table: 61
      routing-policy:
          - from: 172.21.2.114
            table: 61
            priority: 300
    ens224:
      addresses:
      - 172.21.1.114/16
      match:
          macaddress: 00:50:56:aa:16:92
      nameservers:
        addresses:
        - 172.16.1.11
        - 172.16.1.20
        search:
        - domain.com
      set-name: sviluppo
      routes:
          - to: 0.0.0.0/0
            via: 172.21.1.1
            table: 62
      routing-policy:
          - from: 172.21.1.114
            table: 62
            priority: 300

/etc/iproute2/rt_tables.d/swarm.conf :

# produzione
60 60
# qa
61 61
# sviluppo
62 62

어떤 도움이라도 대단히 감사하겠습니다.

답변1

0.0.0.0에 도달하기 위해 각 인터페이스에 대한 라우팅 정책을 잊어버렸습니다.

예:

routing-policy:
              - from: 172.16.1.114
                table: 60
              - to: 0.0.0.0/0
                table: 60

내 경우의 전체 구성은 다음과 같습니다.

  network:
    version: 2
    ethernets:
        ens160:
          dhcp4: no
          addresses:
          - 172.16.1.114/16
          match:
              macaddress: 00:50:56:aa:00:1d
          nameservers:
            addresses:
            - 172.16.1.11
            - 172.16.1.20
            search:
            - domain.com
          set-name: produzione
          routes:
              - to: 0.0.0.0/0
                via: 172.16.1.1
                table: 60
          routing-policy:
              - from: 172.16.1.114
                table: 60
              - to: 0.0.0.0/0
                table: 60
        ens192:
          dhcp4: no
          addresses:
          - 172.21.2.114/16
          match:
              macaddress: 00:50:56:aa:6f:ed
          nameservers:
            addresses:
            - 172.16.1.11
            - 172.16.1.20
            search:
            - domain.com
          set-name: qa
          routes:
              - to: 0.0.0.0/0
                via: 172.21.1.1
                table: 61
          routing-policy:
              - from: 172.21.2.114
                table: 61
              - to: 0.0.0.0/0
                table: 61
        ens224:
          dhcp4: no
          addresses:
          - 172.21.1.114/16
          match:
              macaddress: 00:50:56:aa:16:92
          nameservers:
            addresses:
            - 172.16.1.11
            - 172.16.1.20
            search:
            - domain.com
          set-name: sviluppo
          routes:
              - to: 0.0.0.0/0
                via: 172.21.1.1
                table: 62
          routing-policy:
              - from: 172.21.1.114
                table: 62
              - to: 0.0.0.0/0
                table: 62
