단순 Strongswan 설치로 인해 (Open)SSH를 통해 서버에 연결할 수 없습니다.

Question

원격 컴퓨터(Debian 11.7 / Kernel 5.10.0-23-amd64)에서 작업하는 동안 VPN 클라이언트로 구성하기 위해 Strongswan을 설치했습니다.

apt install strongswan

그 후에는 서비스가 strongswan-starter.service시작되고 호스트에 연결할 수 없게 됩니다. 운 좋게도 재부팅을 통해 서비스를 물리적으로 비활성화할 수 있었습니다 systemctl disable strongswan-starter.service.

하지만 ``systemctl start Strongswan-starter.service'를 실행할 때마다 내 openssh 연결이 끊어집니다.

서비스를 시작하면서 느낀 점은 다음과 같습니다.

May 29 21:45:25 machinename charon: 08[KNL] error installing route with policy 192.168.189.1/32 === 192.168.189.1/32 out
May 29 21:45:25 machinename charon: 08[IKE] installed bypass policy for 192.168.189.1/32
May 29 21:45:25 machinename charon: 08[KNL] received netlink error: Permission denied (13)
May 29 21:45:25 machinename charon: 08[KNL] installing route failed: 2a00:6020:4e2a:8000::/64 src 2a00:xxxx:4e2a:xxxx:6a1d:xxxx:xxxx:9579 dev ipsec0
May 29 21:45:25 machinename charon: 08[IKE] installed bypass policy for 2a00:xxxx:xxxx:8000::/64
May 29 21:45:25 machinename charon: 08[KNL] error installing route with policy fe80::/64 === fe80::/64 out

IP는 192.168.189.1라우터 주소입니다. 하지만 로컬 실제 콘솔에서는 Google 등을 핑할 수 있습니다.

libcharon-extra-plugin 패키지가 설치된 경우에만 표시된다는 사실 때문에 나는 처음에 bypass-lan 플러그인에 초점을 맞췄습니다.

업데이트됨

이는 기본 Strongswan 설치이므로 이 시점에서는 구성이 이루어지지 않았습니다. 관련 구성 파일은 다음과 같습니다.

# ipsec.conf - strongSwan IPsec configuration file

# basic configuration

config setup
        # strictcrlpolicy=yes
        # uniqueids = no

# Add connections here.

# Sample VPN connections

#conn sample-self-signed
#      leftsubnet=10.1.0.0/16
#      leftcert=selfCert.der
#      leftsendcert=never
#      right=192.168.0.2
#      rightsubnet=10.2.0.0/16
#      rightcert=peerCert.der
#      auto=start

#conn sample-with-ca-cert
#      leftsubnet=10.1.0.0/16
#      leftcert=myCert.pem
#      right=192.168.0.2
#      rightsubnet=10.2.0.0/16
#      rightid="C=CH, O=Linux strongSwan CN=peer name"
#      auto=start

# strongswan.conf
charon {

    plugins {
        eap_dynamic {
            preferred = eap-mschapv2, eap-tls
        }
    }
}

# /etc/strongswan.d/starter.conf
starter {

    # Location of the ipsec.conf file
    # config_file = ${sysconfdir}/ipsec.conf

    # Disable charon plugin load option warning.
    # load_warning = yes

}

업데이트 2

hostmachine아래는 서비스를 시작하고 원격 연결이 끊어진 후 전체 로그 출력입니다.

May 29 23:21:49 hostmachine systemd[1]: Started strongSwan IPsec IKEv1/IKEv2 daemon using ipsec.conf.
May 29 23:21:49 hostmachine ipsec[6423]: Starting strongSwan 5.9.1 IPsec [starter]...
May 29 23:21:49 hostmachine charon: 00[DMN] Starting IKE charon daemon (strongSwan 5.9.1, Linux 5.10.0-23-amd64, x86_64)
May 29 23:21:49 hostmachine kernel: [ 3621.243706] NET: Registered protocol family 38
May 29 23:21:49 hostmachine kernel: [ 3621.282054] AVX or AES-NI instructions are not detected.
May 29 23:21:50 hostmachine kernel: [ 3621.332375] AVX or AES-NI instructions are not detected.
May 29 23:21:50 hostmachine kernel: [ 3621.394450] alg: No test for xcbc(camellia) (xcbc(camellia-asm))
May 29 23:21:50 hostmachine kernel: [ 3621.436211] alg: No test for rfc3686(ctr(camellia)) (rfc3686(ctr-camellia-asm))
May 29 23:21:50 hostmachine kernel: [ 3621.445352] CPU feature 'AVX registers' is not supported.
May 29 23:21:50 hostmachine kernel: [ 3621.559730] CPU feature 'AVX registers' is not supported.
May 29 23:21:50 hostmachine kernel: [ 3621.593517] CPU feature 'AVX registers' is not supported.
May 29 23:21:50 hostmachine kernel: [ 3621.682207] CPU feature 'AVX registers' is not supported.
May 29 23:21:50 hostmachine kernel: [ 3621.750485] tun: Universal TUN/TAP device driver, 1.6
May 29 23:21:50 hostmachine charon: 00[LIB] created TUN device: ipsec0
May 29 23:21:50 hostmachine systemd-networkd[281]: ipsec0: Link UP
May 29 23:21:50 hostmachine systemd-networkd[281]: ipsec0: Gained carrier
May 29 23:21:50 hostmachine systemd-networkd[281]: ipsec0: Gained IPv6LL
May 29 23:21:50 hostmachine systemd-udevd[6556]: ethtool: autonegotiation is unset or enabled, the speed and duplex are not writable.
May 29 23:21:50 hostmachine charon: 00[CFG] loading ca certificates from '/etc/ipsec.d/cacerts'
May 29 23:21:50 hostmachine charon: 00[CFG] loading aa certificates from '/etc/ipsec.d/aacerts'
May 29 23:21:50 hostmachine charon: 00[CFG] loading ocsp signer certificates from '/etc/ipsec.d/ocspcerts'
May 29 23:21:50 hostmachine charon: 00[CFG] loading attribute certificates from '/etc/ipsec.d/acerts'
May 29 23:21:50 hostmachine charon: 00[CFG] loading crls from '/etc/ipsec.d/crls'
May 29 23:21:50 hostmachine charon: 00[CFG] loading secrets from '/etc/ipsec.secrets'
May 29 23:21:50 hostmachine charon: 00[CFG] loaded 0 RADIUS server configurations
May 29 23:21:50 hostmachine charon: 00[CFG] HA config misses local/remote address
May 29 23:21:50 hostmachine charon: 00[LIB] loaded plugins: charon test-vectors ldap pkcs11 tpm aesni aes rc2 sha2 sha1 md5 mgf1 rdrand random nonce x509 revocation constraints pubkey pkcs1 pkcs7 pkcs8 pkcs12 pgp dnskey sshkey pem openssl gcrypt af-alg fips-prf gmp curve25519 agent chapoly xcbc cmac hmac ctr ccm gcm drbg curl attr kernel-libipsec kernel-netlink resolve socket-default bypass-lan connmark farp stroke updown eap-identity eap-aka eap-md5 eap-gtc eap-mschapv2 eap-radius eap-tls eap-ttls eap-tnc xauth-generic xauth-eap xauth-pam tnc-tnccs dhcp lookip error-notify certexpire led addrblock unity counters
May 29 23:21:50 hostmachine charon: 00[LIB] dropped capabilities, running as uid 0, gid 0
May 29 23:21:50 hostmachine charon: 00[JOB] spawning 16 worker threads
May 29 23:21:50 hostmachine charon: 08[IKE] installed bypass policy for 172.17.0.0/16
May 29 23:21:50 hostmachine charon: 08[IKE] installed bypass policy for 172.18.0.0/16
May 29 23:21:50 hostmachine charon: 08[IKE] installed bypass policy for 172.25.0.0/16
May 29 23:21:50 hostmachine charon: 08[IKE] installed bypass policy for 192.168.189.0/24
May 29 23:21:50 hostmachine charon: 08[KNL] error installing route with policy 192.168.189.1/32 === 192.168.189.1/32 out
May 29 23:21:50 hostmachine charon: 08[IKE] installed bypass policy for 192.168.189.1/32
May 29 23:21:50 hostmachine charon: 08[IKE] installed bypass policy for ::1/128
May 29 23:21:50 hostmachine charon: 08[IKE] installed bypass policy for 2a00:xxxx:xxxx:8000::/64
May 29 23:21:50 hostmachine charon: 08[KNL] error installing route with policy fe80::/64 === fe80::/64 out
May 29 23:21:50 hostmachine charon: 08[IKE] installed bypass policy for fe80::/64
May 29 23:21:50 hostmachine charon: 08[IKE] interface change for bypass policy for fe80::/64 (from enp1s0 to ipsec0)
May 29 23:21:50 hostmachine charon: 08[KNL] error installing route with policy fe80::/64 === fe80::/64 out
May 29 23:21:50 hostmachine ipsec[6423]: charon (6427) started after 580 ms
May 29 23:22:04 hostmachine charon: 00[DMN] SIGINT received, shutting down
May 29 23:22:04 hostmachine systemd[1]: Stopping strongSwan IPsec IKEv1/IKEv2 daemon using ipsec.conf...
May 29 23:22:04 hostmachine charon: 00[IKE] uninstalling bypass policy for 172.17.0.0/16
May 29 23:22:04 hostmachine charon: 00[IKE] uninstalling bypass policy for 172.18.0.0/16
May 29 23:22:04 hostmachine charon: 00[IKE] uninstalling bypass policy for 172.25.0.0/16
May 29 23:22:04 hostmachine charon: 00[IKE] uninstalling bypass policy for 192.168.189.0/24
May 29 23:22:04 hostmachine systemd-networkd[281]: ipsec0: Link DOWN
May 29 23:22:04 hostmachine charon: 00[IKE] uninstalling bypass policy for 192.168.189.1/32
May 29 23:22:04 hostmachine systemd-networkd[281]: ipsec0: Lost carrier
May 29 23:22:04 hostmachine charon: 00[IKE] uninstalling bypass policy for ::1/128
May 29 23:22:04 hostmachine charon: 00[IKE] uninstalling bypass policy for 2a00:xxxx:xxxx:8000::/64
May 29 23:22:04 hostmachine charon: 00[IKE] uninstalling bypass policy for fe80::/64
May 29 23:22:04 hostmachine ipsec[6427]: 00[DMN] Starting IKE charon daemon (strongSwan 5.9.1, Linux 5.10.0-23-amd64, x86_64)
May 29 23:22:04 hostmachine ipsec[6427]: 00[LIB] created TUN device: ipsec0
May 29 23:22:04 hostmachine ipsec[6427]: 00[CFG] loading ca certificates from '/etc/ipsec.d/cacerts'
May 29 23:22:04 hostmachine ipsec[6427]: 00[CFG] loading aa certificates from '/etc/ipsec.d/aacerts'
May 29 23:22:04 hostmachine ipsec[6427]: 00[CFG] loading ocsp signer certificates from '/etc/ipsec.d/ocspcerts'
May 29 23:22:04 hostmachine ipsec[6427]: 00[CFG] loading attribute certificates from '/etc/ipsec.d/acerts'
May 29 23:22:04 hostmachine ipsec[6427]: 00[CFG] loading crls from '/etc/ipsec.d/crls'
May 29 23:22:04 hostmachine ipsec[6427]: 00[CFG] loading secrets from '/etc/ipsec.secrets'
May 29 23:22:04 hostmachine ipsec[6427]: 00[CFG] loaded 0 RADIUS server configurations
May 29 23:22:04 hostmachine ipsec[6427]: 00[CFG] HA config misses local/remote address
May 29 23:22:04 hostmachine ipsec[6427]: 00[LIB] loaded plugins: charon test-vectors ldap pkcs11 tpm aesni aes rc2 sha2 sha1 md5 mgf1 rdrand random nonce x509 revocation constraints pubkey pkcs1 pkcs7 pkcs8 pkcs12 pgp dnskey sshkey pem openssl gcrypt af-alg fips-prf gmp curve25519 agent chapoly xcbc cmac hmac ctr ccm gcm drbg curl attr kernel-libipsec kernel-netlink resolve socket-default bypass-lan connmark farp stroke updown eap-identity eap-aka eap-md5 eap-gtc eap-mschapv2 eap-radius eap-tls eap-ttls eap-tnc xauth-generic xauth-eap xauth-pam tnc-tnccs dhcp lookip error-notify certexpire led addrblock unity counters
May 29 23:22:04 hostmachine ipsec[6427]: 00[LIB] dropped capabilities, running as uid 0, gid 0
May 29 23:22:04 hostmachine ipsec[6427]: 00[JOB] spawning 16 worker threads
May 29 23:22:04 hostmachine ipsec[6427]: 08[IKE] installed bypass policy for 172.17.0.0/16
May 29 23:22:04 hostmachine ipsec[6427]: 08[IKE] installed bypass policy for 172.18.0.0/16
May 29 23:22:04 hostmachine ipsec[6427]: 08[IKE] installed bypass policy for 172.25.0.0/16
May 29 23:22:04 hostmachine ipsec[6427]: 08[IKE] installed bypass policy for 192.168.189.0/24
May 29 23:22:04 hostmachine ipsec[6427]: 08[KNL] error installing route with policy 192.168.189.1/32 === 192.168.189.1/32 out
May 29 23:22:04 hostmachine ipsec[6427]: 08[IKE] installed bypass policy for 192.168.189.1/32
May 29 23:22:04 hostmachine ipsec[6427]: 08[IKE] installed bypass policy for ::1/128
May 29 23:22:04 hostmachine ipsec[6427]: 08[IKE] installed bypass policy for 2a00:xxxx:xxxx:8000::/64
May 29 23:22:04 hostmachine ipsec[6427]: 08[KNL] error installing route with policy fe80::/64 === fe80::/64 out
May 29 23:22:04 hostmachine ipsec[6427]: 08[IKE] installed bypass policy for fe80::/64
May 29 23:22:04 hostmachine ipsec[6427]: 08[IKE] interface change for bypass policy for fe80::/64 (from enp1s0 to ipsec0)
May 29 23:22:04 hostmachine ipsec[6427]: 08[KNL] error installing route with policy fe80::/64 === fe80::/64 out

어떤 아이디어라도 높이 평가됩니다.
