저는 Canon LBP-3300을 가지고 있고 설치했는데 cndrvcups-capt_2.70-1_amd64.deb아무런 cndrvcups-common_3.20-1_amd64.deb문제가 없었습니다.
LBP3300이 프린터에 표시됩니다.
하지만 작업을 인쇄하고 싶을 때 처리가 중단됩니다.
에 갔더니 http://localhost:631/printers/보여주네요Processing - "Sending data to printer."
tail -f /var/log/syslog프린터가 켜져 있고 USB가 연결된 경우 의 결과 :
Jan 27 13:26:55 ice-system udev-configure-printer[6276]: remove /devices/pci0000:00/0000:00:1a.7/usb1/1-1
Jan 27 13:26:55 ice-system udev-configure-printer[6276]: URI of detected printer: usb://Canon/LBP3300?serial=00001184PI9N, normalized: canon lbp3300 serial 00001184pi9n
Jan 27 13:26:55 ice-system udev-configure-printer[6276]: URI of print queue: usb://Canon/LBP3300?serial=00001184PI9N, normalized: canon lbp3300 serial 00001184pi9n
Jan 27 13:26:55 ice-system udev-configure-printer[6276]: Queue ipp://localhost/printers/LBP3300 has matching device URI
Jan 27 13:26:55 ice-system udev-configure-printer[6276]: Disabled printer ipp://localhost/printers/LBP3300 as the corresponding device was unplugged or turned off
Jan 27 13:26:55 ice-system systemd[1]: printer.target: Unit not needed anymore. Stopping.
Jan 27 13:26:55 ice-system systemd[1]: Stopped target Printer.
Jan 27 13:26:55 ice-system kernel: [ 2450.174875] [UFW BLOCK] IN=enp5s0 OUT= MAC= SRC=fe80:0000:0000:0000:c327:77e1:783a:4ca2 DST=ff02:0000:0000:0000:0000:0000:0000:0001 LEN=64 TC=0 HOPLIMIT=1 FLOWLBL=958574 PROTO=UDP SPT=8612 DPT=8612 LEN=24
Jan 27 13:26:55 ice-system kernel: [ 2450.174898] [UFW BLOCK] IN=enp5s0 OUT= MAC= SRC=fe80:0000:0000:0000:c327:77e1:783a:4ca2 DST=ff02:0000:0000:0000:0000:0000:0000:0001 LEN=64 TC=0 HOPLIMIT=1 FLOWLBL=39070 PROTO=UDP SPT=8612 DPT=8610 LEN=24
Jan 27 13:26:55 ice-system kernel: [ 2450.185099] [UFW BLOCK] IN=enp5s0 OUT= MAC= SRC=fe80:0000:0000:0000:c327:77e1:783a:4ca2 DST=ff02:0000:0000:0000:0000:0000:0000:0001 LEN=64 TC=0 HOPLIMIT=1 FLOWLBL=958574 PROTO=UDP SPT=8612 DPT=8612 LEN=24
Jan 27 13:27:26 ice-system kernel: [ 2481.527150] usb 1-1: new high-speed USB device number 5 using ehci-pci
Jan 27 13:27:26 ice-system kernel: [ 2481.681297] usb 1-1: New USB device found, idVendor=04a9, idProduct=267e
Jan 27 13:27:26 ice-system kernel: [ 2481.681300] usb 1-1: New USB device strings: Mfr=1, Product=2, SerialNumber=3
Jan 27 13:27:26 ice-system kernel: [ 2481.681302] usb 1-1: Product: Canon CAPT USB Device
Jan 27 13:27:26 ice-system kernel: [ 2481.681304] usb 1-1: Manufacturer: Canon
Jan 27 13:27:26 ice-system kernel: [ 2481.681305] usb 1-1: SerialNumber: 00001184PI9N
Jan 27 13:27:26 ice-system kernel: [ 2481.682776] usblp 1-1:1.0: usblp1: USB Bidirectional printer dev 5 if 0 alt 0 proto 2 vid 0x04A9 pid 0x267E
Jan 27 13:27:26 ice-system mtp-probe: checking bus 1, device 5: "/sys/devices/pci0000:00/0000:00:1a.7/usb1/1-1"
Jan 27 13:27:26 ice-system mtp-probe: bus: 1, device: 5 was not an MTP device
Jan 27 13:27:26 ice-system systemd[1]: Starting Automatic USB/Bluetooth printer setup (-devices-pci0000:00-0000:00:1a.7-usb1-1\x2d1)...
Jan 27 13:27:26 ice-system systemd[1]: Reached target Printer.
Jan 27 13:27:26 ice-system udev-configure-printer[6301]: add /devices/pci0000:00/0000:00:1a.7/usb1/1-1
Jan 27 13:27:26 ice-system udev-configure-printer[6301]: device devpath is /devices/pci0000:00/0000:00:1a.7/usb1/1-1
Jan 27 13:27:26 ice-system udev-configure-printer[6301]: MFG:Canon MDL:LBP3300 SERN:- serial:00001184PI9N
Jan 27 13:27:26 ice-system kernel: [ 2481.772149] [UFW BLOCK] IN=enp5s0 OUT= MAC= SRC=fe80:0000:0000:0000:c327:77e1:783a:4ca2 DST=ff02:0000:0000:0000:0000:0000:0000:0001 LEN=64 TC=0 HOPLIMIT=1 FLOWLBL=958574 PROTO=UDP SPT=8612 DPT=8612 LEN=24
Jan 27 13:27:26 ice-system kernel: [ 2481.772167] [UFW BLOCK] IN=enp5s0 OUT= MAC= SRC=fe80:0000:0000:0000:c327:77e1:783a:4ca2 DST=ff02:0000:0000:0000:0000:0000:0000:0001 LEN=64 TC=0 HOPLIMIT=1 FLOWLBL=39070 PROTO=UDP SPT=8612 DPT=8610 LEN=24
Jan 27 13:27:31 ice-system kernel: [ 2486.746164] usblp1: removed
Jan 27 13:27:31 ice-system kernel: [ 2486.749422] usblp 1-1:1.0: usblp1: USB Bidirectional printer dev 5 if 0 alt 0 proto 2 vid 0x04A9 pid 0x267E
Jan 27 13:27:31 ice-system udev-configure-printer[6301]: URI contains USB serial number
Jan 27 13:27:31 ice-system udev-configure-printer[6301]: URI match: usb://Canon/LBP3300?serial=00001184PI9N
Jan 27 13:27:31 ice-system udev-configure-printer[6301]: URI of detected printer: usb://Canon/LBP3300?serial=00001184PI9N, normalized: canon lbp3300 serial 00001184pi9n
Jan 27 13:27:31 ice-system udev-configure-printer[6301]: URI of print queue: usb://Canon/LBP3300?serial=00001184PI9N, normalized: canon lbp3300 serial 00001184pi9n
Jan 27 13:27:31 ice-system udev-configure-printer[6301]: Queue ipp://localhost/printers/LBP3300 has matching device URI
Jan 27 13:27:31 ice-system udev-configure-printer[6301]: Re-enabled printer ipp://localhost/printers/LBP3300
Jan 27 13:27:31 ice-system systemd[1]: Started Automatic USB/Bluetooth printer setup (-devices-pci0000:00-0000:00:1a.7-usb1-1\x2d1).
Jan 27 13:27:31 ice-system kernel: [ 2486.909373] usblp1: removed
lpinfo -v프린터가 켜져 있고 USB가 연결된 경우 의 결과 :
network http
network ipp14
network beh
network lpd
network socket
network ipp
network ipps
direct hp
direct ccp
network https
direct usb://Canon/LBP3300?serial=00001184PI9N
direct hpfax
lsusb프린터가 켜져 있고 USB가 연결된 경우 의 결과 :
Bus 002 Device 001: ID 1d6b:0002 Linux Foundation 2.0 root hub
Bus 008 Device 001: ID 1d6b:0001 Linux Foundation 1.1 root hub
Bus 007 Device 001: ID 1d6b:0001 Linux Foundation 1.1 root hub
Bus 006 Device 001: ID 1d6b:0001 Linux Foundation 1.1 root hub
Bus 001 Device 002: ID 04a9:267e Canon, Inc.
Bus 001 Device 001: ID 1d6b:0002 Linux Foundation 2.0 root hub
Bus 005 Device 001: ID 1d6b:0001 Linux Foundation 1.1 root hub
Bus 004 Device 001: ID 1d6b:0001 Linux Foundation 1.1 root hub
Bus 003 Device 001: ID 1d6b:0001 Linux Foundation 1.1 root hub
Bus 009 Device 001: ID 1d6b:0002 Linux Foundation 2.0 root hub
Bus 010 Device 001: ID 1d6b:0003 Linux Foundation 3.0 root hub
문제를 어떻게 해결할 수 있나요?
답변1
Canon은 Linux에서 CAPT 드라이버에 대해 4가지 작업을 수행해야 한다고 말합니다.
1) 드라이버 설치
2) 프린터(PPD)를 인쇄 스풀러에 등록합니다.
3) ccpd 데몬 설정 파일에 프린터를 등록합니다.
4) ccpd 데몬 시작
1) 여기에서 최신 드라이버를 다운로드하세요.http://support-asia.canon-asia.com/contents/ASIA/EN/0100459601.htmllinux-capt-drv-v271-uken.tar.gz를 다운로드하고 저장하려면 클릭하세요.
2) sudo /usr/sbin/lpadmin -p LBP3300 -m CNCUPSLBP3300CAPTK.ppd -v ccp://localhost:59787 –E .....참고로 이것은 모두 한 줄입니다......
3) sudo /usr/sbin/ccpdadmin -p LBP3300 -o /dev/usb/lp0이는 USB 프린터가 하나만 있다고 가정합니다.
4)sudo /etc/init.d/ccpd start
그리고 저에게는 두 개의 별도 16.04 설치 작업을 수행했습니다.
