É certo que este é um grande salto do kernel. 2.6 não tinha conceito de árvore de dispositivos e ainda não criei uma árvore de dispositivos para meu produto. Portanto, apenas os arquivos da árvore de dispositivos padrão com formas mais antigas de configurações UART nos arquivos da placa. Kernel surge sem UART, eu acho, porque nada acontece depois de "Iniciar Kernel ...".
Qualquer contribuição é muito apreciada. Obrigado
U-Boot> setenv linux1 'tftpboot 20cfffc0 kernel.latest'
U-Boot>
U-Boot> setenv linux2 'tftpboot 206fffc0 initrd.latest'
U-Boot>
U-Boot> setenv linux3 'bootm 20cfffc0'
U-Boot>
U-Boot> setenv bootlinux 'run linux1 linux2 linux3'
U-Boot>
U-Boot> setenv ipaddr
U-Boot>
U-Boot> setenv serverip
U-Boot>
U-Boot> setenv resetuser
U-Boot>
U-Boot> run bootlinux
BCM5241A PHY Detected
waited 1680 msec
End of Autonegotiation
TFTP from server ; our IP address is
Filename 'kernel.latest'.
Load address: 0x20cfffc0
Loading: #################################################################
########################################################
done
Bytes transferred = 1764880 (1aee10 hex)
TFTP from server ; our IP address is ---
Filename 'initrd.latest'.
Load address: 0x206fffc0
Loading: #################################################################
#################################################################
##################################
done
Bytes transferred = 2405916 (24b61c hex)
## Booting kernel from Legacy Image at 20cfffc0 ...
Image Name: WLNN_9G20_4.99
Image Type: ARM Linux Kernel Image (uncompressed)
Data Size: 1764816 Bytes = 1.7 MB
Load Address: 20d00000
Entry Point: 20d00000
Verifying Checksum ... OK
Loading Kernel Image ... OK
OK
Starting kernel ...
