Eu estava tentando controlar o Ubuntu 20.04 remotamente através do Windows 10.
Eu instalei o xrdp com os scripts dehttps://c-nergy.be/.
Depois de fazer login no Windows, a tela foi atualizada, mas o mouse e o teclado não responderam.
O sistema Ubuntu está instalado em um laptop e o teclado e o mouse estão normais.
Aqui está o arquivo de log.
[20210624-20:53:08] [DEBUG] Closed socket 12 (AF_INET6 ::ffff:192.168.1.112 port 3389)
[20210624-20:53:08] [DEBUG] Closed socket 11 (AF_INET6 :: port 3389)
[20210624-20:53:08] [INFO ] Using default X.509 certificate: /etc/xrdp/cert.pem
[20210624-20:53:08] [INFO ] Using default X.509 key file: /etc/xrdp/key.pem
[20210624-20:53:08] [DEBUG] TLSv1.3 enabled
[20210624-20:53:08] [DEBUG] TLSv1.2 enabled
[20210624-20:53:08] [DEBUG] Security layer: requested 11, selected 1
[20210624-20:53:08] [INFO ] connected client computer name: HUSKY-K610C
[20210624-20:53:08] [INFO ] adding channel item name rdpdr chan_id 1004 flags 0x80800000
[20210624-20:53:08] [INFO ] adding channel item name rdpsnd chan_id 1005 flags 0xc0000000
[20210624-20:53:08] [INFO ] adding channel item name cliprdr chan_id 1006 flags 0xc0a00000
[20210624-20:53:08] [INFO ] adding channel item name drdynvc chan_id 1007 flags 0xc0800000
[20210624-20:53:08] [INFO ] TLS connection established from ::ffff:: TLSv1.2 with cipher ECDHE-RSA-AES256-GCM-SHA384
[20210624-20:53:08] [DEBUG] xrdp_00000dc2_wm_login_mode_event_00000001
[20210624-20:53:08] [INFO ] Cannot find keymap file /etc/xrdp/km-00000804.ini
[20210624-20:53:08] [INFO ] Cannot find keymap file /etc/xrdp/km-00000804.ini
[20210624-20:53:08] [INFO ] Loading keymap file /etc/xrdp/km-00000409.ini
[20210624-20:53:08] [WARN ] local keymap file for 0x00000804 found and doesn't match built in keymap, using local keymap file
[20210624-20:53:08] [DEBUG] xrdp_wm_log_msg: connecting to sesman ip 127.0.0.1 port 3350
[20210624-20:53:08] [INFO ] xrdp_wm_log_msg: sesman connect ok
[20210624-20:53:08] [DEBUG] xrdp_wm_log_msg: sending login info to session manager, please wait...
[20210624-20:53:08] [DEBUG] return value from xrdp_mm_connect 0
[20210624-20:53:10] [INFO ] xrdp_wm_log_msg: login failed for display 0
[20210624-20:53:10] [DEBUG] xrdp_mm_module_cleanup
[20210624-20:53:10] [DEBUG] Closed socket 18 (AF_INET6 ::1 port 47924)
[20210624-20:53:25] [DEBUG] xrdp_wm_log_msg: connecting to sesman ip 127.0.0.1 port 3350
[20210624-20:53:25] [INFO ] xrdp_wm_log_msg: sesman connect ok
[20210624-20:53:25] [DEBUG] xrdp_wm_log_msg: sending login info to session manager, please wait...
[20210624-20:53:25] [DEBUG] return value from xrdp_mm_connect 0
[20210624-20:53:25] [INFO ] xrdp_wm_log_msg: login successful for display 10
[20210624-20:53:25] [DEBUG] xrdp_wm_log_msg: started connecting
[20210624-20:53:25] [INFO ] lib_mod_log_peer: xrdp_pid=3522 connected to X11rdp_pid=3544 X11rdp_uid=1000 X11rdp_gid=1000 client_ip=::ffff
[20210624-20:53:25] [DEBUG] xrdp_wm_log_msg: connected ok
[20210624-20:53:25] [DEBUG] xrdp_mm_connect_chansrv: chansrv connect successful
[20210624-20:53:25] [DEBUG] Closed socket 18 (AF_INET6 ::1 port 47926)
[20210624-20:55:19] [DEBUG] Closed socket 12 (AF_INET6 ::ffff:192.168.1.112 port 3389)
[20210624-20:55:19] [DEBUG] xrdp_mm_module_cleanup
[20210624-20:55:19] [DEBUG] Closed socket 19 (AF_UNIX)
[20210624-20:55:19] [DEBUG] Closed socket 20 (AF_UNIX)
[20210624-20:55:38] [INFO ] Socket 12: AF_INET6 connection received from ::ffff:59.78.0.91 port 7585
[20210624-20:55:38] [DEBUG] Closed socket 12 (AF_INET6 ::ffff:192.168.1.112 port 3389)
[20210624-20:55:38] [DEBUG] Closed socket 11 (AF_INET6 :: port 3389)
[20210624-20:55:38] [INFO ] Using default X.509 certificate: /etc/xrdp/cert.pem
[20210624-20:55:38] [INFO ] Using default X.509 key file: /etc/xrdp/key.pem
[20210624-20:55:38] [DEBUG] TLSv1.3 enabled
[20210624-20:55:38] [DEBUG] TLSv1.2 enabled
[20210624-20:55:38] [DEBUG] Security layer: requested 11, selected 1
[20210624-20:55:38] [DEBUG] Closed socket 12 (AF_INET6 ::ffff:192.168.1.112 port 3389)
[20210624-20:55:38] [INFO ] Socket 12: AF_INET6 connection received from ::ffff:59.78.0.91 port 7586
[20210624-20:55:38] [DEBUG] Closed socket 12 (AF_INET6 ::ffff:192.168.1.112 port 3389)
[20210624-20:55:38] [DEBUG] Closed socket 11 (AF_INET6 :: port 3389)
[20210624-20:55:38] [INFO ] Using default X.509 certificate: /etc/xrdp/cert.pem
[20210624-20:55:38] [INFO ] Using default X.509 key file: /etc/xrdp/key.pem
[20210624-20:55:38] [DEBUG] TLSv1.3 enabled
[20210624-20:55:38] [DEBUG] TLSv1.2 enabled
[20210624-20:55:38] [DEBUG] Security layer: requested 11, selected 1
[20210624-20:55:38] [INFO ] connected client computer name: HUSKY-K610C
[20210624-20:55:38] [INFO ] adding channel item name rdpdr chan_id 1004 flags 0x80800000
[20210624-20:55:38] [INFO ] adding channel item name rdpsnd chan_id 1005 flags 0xc0000000
[20210624-20:55:38] [INFO ] adding channel item name cliprdr chan_id 1006 flags 0xc0a00000
[20210624-20:55:38] [INFO ] adding channel item name drdynvc chan_id 1007 flags 0xc0800000
[20210624-20:55:38] [INFO ] TLS connection established from ::ffff: TLSv1.2 with cipher ECDHE-RSA-AES256-GCM-SHA384
[20210624-20:55:40] [DEBUG] xrdp_000011c0_wm_login_mode_event_00000001
[20210624-20:55:40] [INFO ] Cannot find keymap file /etc/xrdp/km-00000804.ini
[20210624-20:55:40] [INFO ] Cannot find keymap file /etc/xrdp/km-00000804.ini
[20210624-20:55:40] [INFO ] Loading keymap file /etc/xrdp/km-00000409.ini
[20210624-20:55:40] [WARN ] local keymap file for 0x00000804 found and doesn't match built in keymap, using local keymap file
[20210624-20:55:46] [DEBUG] xrdp_wm_log_msg: connecting to sesman ip 127.0.0.1 port 3350
[20210624-20:55:46] [INFO ] xrdp_wm_log_msg: sesman connect ok
[20210624-20:55:46] [DEBUG] xrdp_wm_log_msg: sending login info to session manager, please wait...
[20210624-20:55:46] [DEBUG] return value from xrdp_mm_connect 0
[20210624-20:55:46] [INFO ] xrdp_wm_log_msg: login successful for display 10
[20210624-20:55:46] [DEBUG] xrdp_wm_log_msg: started connecting
[20210624-20:55:46] [INFO ] lib_mod_log_peer: xrdp_pid=4544 connected to X11rdp_pid=3544 X11rdp_uid=1000 X11rdp_gid=1000 client_ip=::ffff:
[20210624-20:55:46] [DEBUG] xrdp_wm_log_msg: connected ok
[20210624-20:55:46] [DEBUG] xrdp_mm_connect_chansrv: chansrv connect successful
[20210624-20:55:46] [DEBUG] Closed socket 18 (AF_INET6 ::1 port 47944)
[20210624-20:55:54] [DEBUG] Closed socket 12 (AF_INET6 ::ffff:192.168.1.112 port 3389)
[20210624-20:55:54] [DEBUG] xrdp_mm_module_cleanup
[20210624-20:55:54] [DEBUG] Closed socket 19 (AF_UNIX)
[20210624-20:55:54] [DEBUG] Closed socket 20 (AF_UNIX)
[20210624-20:59:23] [INFO ] Socket 12: AF_INET6 connection received from ::ffff:59.78.0.91 port 11866
[20210624-20:59:23] [DEBUG] Closed socket 12 (AF_INET6 ::ffff:192.168.1.112 port 3389)
[20210624-20:59:23] [DEBUG] Closed socket 11 (AF_INET6 :: port 3389)
[20210624-20:59:23] [INFO ] Using default X.509 certificate: /etc/xrdp/cert.pem
[20210624-20:59:23] [INFO ] Using default X.509 key file: /etc/xrdp/key.pem
[20210624-20:59:23] [DEBUG] TLSv1.3 enabled
[20210624-20:59:23] [DEBUG] TLSv1.2 enabled
[20210624-20:59:23] [DEBUG] Security layer: requested 11, selected 1
[20210624-20:59:23] [DEBUG] Closed socket 12 (AF_INET6 ::ffff:192.168.1.112 port 3389)
[20210624-20:59:23] [INFO ] Socket 12: AF_INET6 connection received from ::ffff:59.78.0.91 port 11867
[20210624-20:59:23] [DEBUG] Closed socket 12 (AF_INET6 ::ffff:192.168.1.112 port 3389)
[20210624-20:59:23] [DEBUG] Closed socket 11 (AF_INET6 :: port 3389)
[20210624-20:59:23] [INFO ] Using default X.509 certificate: /etc/xrdp/cert.pem
[20210624-20:59:23] [INFO ] Using default X.509 key file: /etc/xrdp/key.pem
[20210624-20:59:23] [DEBUG] TLSv1.3 enabled
[20210624-20:59:23] [DEBUG] TLSv1.2 enabled
[20210624-20:59:23] [DEBUG] Security layer: requested 11, selected 1
[20210624-20:59:23] [INFO ] connected client computer name: HUSKY-K610C
[20210624-20:59:23] [INFO ] adding channel item name rdpdr chan_id 1004 flags 0x80800000
[20210624-20:59:23] [INFO ] adding channel item name rdpsnd chan_id 1005 flags 0xc0000000
[20210624-20:59:23] [INFO ] adding channel item name cliprdr chan_id 1006 flags 0xc0a00000
[20210624-20:59:23] [INFO ] adding channel item name drdynvc chan_id 1007 flags 0xc0800000
[20210624-20:59:23] [INFO ] TLS connection established from ::ffff: TLSv1.2 with cipher ECDHE-RSA-AES256-GCM-SHA384
[20210624-20:59:23] [DEBUG] xrdp_00001823_wm_login_mode_event_00000001
[20210624-20:59:23] [INFO ] Cannot find keymap file /etc/xrdp/km-00000804.ini
[20210624-20:59:23] [INFO ] Cannot find keymap file /etc/xrdp/km-00000804.ini
[20210624-20:59:23] [INFO ] Loading keymap file /etc/xrdp/km-00000409.ini
[20210624-20:59:23] [WARN ] local keymap file for 0x00000804 found and doesn't match built in keymap, using local keymap file
[20210624-20:59:27] [DEBUG] xrdp_wm_log_msg: connecting to sesman ip 127.0.0.1 port 3350
[20210624-20:59:27] [INFO ] xrdp_wm_log_msg: sesman connect ok
[20210624-20:59:27] [DEBUG] xrdp_wm_log_msg: sending login info to session manager, please wait...
[20210624-20:59:27] [DEBUG] return value from xrdp_mm_connect 0
[20210624-20:59:27] [INFO ] xrdp_wm_log_msg: login successful for display 10
[20210624-20:59:27] [DEBUG] xrdp_wm_log_msg: started connecting
[20210624-20:59:27] [INFO ] lib_mod_log_peer: xrdp_pid=6179 connected to X11rdp_pid=3544 X11rdp_uid=1000 X11rdp_gid=1000 client_ip=::ffff:59.78.0.91 client_port=11867
[20210624-20:59:27] [DEBUG] xrdp_wm_log_msg: connected ok
[20210624-20:59:27] [DEBUG] xrdp_mm_connect_chansrv: chansrv connect successful
[20210624-20:59:27] [DEBUG] Closed socket 18 (AF_INET6 ::1 port 47982)
[20210624-20:59:34] [DEBUG] Closed socket 12 (AF_INET6 ::ffff:192.168.1.112 port 3389)
[20210624-20:59:34] [DEBUG] xrdp_mm_module_cleanup
[20210624-20:59:34] [DEBUG] Closed socket 19 (AF_UNIX)
[20210624-20:59:34] [DEBUG] Closed socket 20 (AF_UNIX)
[20210624-20:59:37] [DEBUG] Closed socket 11 (AF_INET6 :: port 3389)
[20210624-21:01:19] [INFO ] address [0.0.0.0] port [3389] mode 1
[20210624-21:01:19] [INFO ] listening to port 3389 on 0.0.0.0
[20210624-21:01:19] [INFO ] xrdp_listen_pp done
[20210624-21:01:19] [DEBUG] Closed socket 7 (AF_INET6 :: port 3389)
[20210624-21:01:21] [INFO ] starting xrdp with pid 1016
[20210624-21:01:21] [INFO ] address [0.0.0.0] port [3389] mode 1
[20210624-21:01:21] [INFO ] listening to port 3389 on 0.0.0.0
[20210624-21:01:21] [INFO ] xrdp_listen_pp done
Responder1
Tentei uma solução de outro lugar para executar:
sudo apt-get install xserver-xorg-input-all
Mas isso não pareceu funcionar. Mas seguir esta solução aqui funcionou para mim no Xubuntu 20.04 usando xfce:https://github.com/neutrinolabs/xorgxrdp/issues/164#issuecomment-710594486
A correção para mim foi adicionar a opção "CoreKeyboard" e a opção "CorePointer" aos dispositivos de entrada em/etc/X11/xrdp/xorg.confcomo os dispositivos de entrada na seção serverlayout são aparentemente ignorados, não existe nenhum ponteiro central e teclado, o que leva a dispositivos padrão forçados. Não faço ideia por que isso acontece de repente, funcionou bem no Ubuntu 18.04, mas quebrou para mim em 20.04.
Section "InputDevice"
Identifier "xrdpKeyboard"
Driver "xrdpkeyb"
Option "CoreKeyboard"
EndSection
Section "InputDevice"
Identifier "xrdpMouse"
Driver "xrdpmouse"
Option "CorePointer"
EndSection
Responder2
Caso alguém se depare com esta questão. No Debian 12 eu estava usando o xrdp para conectar do Windows. Quando alterei a configuração "Num Lock na inicialização" em "Dispositivos de entrada > Teclado > Hardware" para "não alterar" de "ativado", o teclado remoto parou de funcionar. Quando mudei de volta para "ativado", o teclado voltou.
