Eu tenho um microfone de mesa Arozzi Sfera. Ele tem um fone de ouvido na parte traseira, para o que presumo ser um monitor.
Quando o microfone está conectado, posso ver vários dispositivos de saída de áudio listados na guia "Som" da visualização de configurações, incluindo meus fones de ouvido Bluetooth, a conexão HDMI a um monitor e o microfone. Quando seleciono qualquer dispositivo de saída e uso a função "teste", o áudio é direcionado para o fone de ouvido do microfone.
Tentei executar pulseaudio -ke systemctl --user restart pulseaudio.servicequando o problema se manifestou, sem sucesso.
O status do serviço pulseaudio é assim:
● pulseaudio.service - Sound Service
Loaded: loaded (/usr/lib/systemd/user/pulseaudio.service; enabled; vendor preset: enabled)
Active: active (running) since Wed 2022-11-09 17:04:12 EET; 17min ago
TriggeredBy: ● pulseaudio.socket
Main PID: 7052 (pulseaudio)
Tasks: 8 (limit: 19009)
Memory: 9.8M
CPU: 9.083s
CGroup: /user.slice/user-1000.slice/[email protected]/session.slice/pulseaudio.service
└─7052 /usr/bin/pulseaudio --daemonize=no --log-target=journal
marras 09 17:04:12 haem-desktop systemd[2192]: Starting Sound Service...
marras 09 17:04:12 haem-desktop pulseaudio[7052]: Failed to open cookie file '/home/haem/.config/pulse/cookie': Tiedostoa tai hakemistoa ei ole
marras 09 17:04:12 haem-desktop pulseaudio[7052]: Failed to load authentication key '/home/haem/.config/pulse/cookie': Tiedostoa tai hakemistoa ei ole
marras 09 17:04:12 haem-desktop pulseaudio[7052]: Module "module-udev-detect" should be loaded once at most. Refusing to load.
marras 09 17:04:12 haem-desktop systemd[2192]: Started Sound Service.
marras 09 17:04:12 haem-desktop pulseaudio[7052]: Could not find org.bluez.BatteryProviderManager1.RegisterBatteryProvider(), is bluetoothd started with experimental features enabled (-E flag)?
marras 09 17:04:38 haem-desktop pulseaudio[7052]: Transport Acquire() failed for transport /org/bluez/hci0/dev_2C_4D_79_40_C5_3B/sep1/fd2 (Input/output error)
marras 09 17:05:02 haem-desktop pulseaudio[7052]: org.freedesktop.DBus.Properties.Get /org/bluez/hci0/dev_2C_4D_79_40_C5_3B/sep1/fd3 Volume failed: org.freedesktop.DBus.Error.InvalidArgs: No such property 'Vo>
marras 09 17:05:02 haem-desktop pulseaudio[7052]: Battery Level: 100%
marras 09 17:05:02 haem-desktop pulseaudio[7052]: Dock Status: undocked
Desconectar o microfone e conectá-lo novamente parece resolver o problema ocasionalmente. Quando o problema for corrigido, o status será semelhante a
marras 09 17:04:12 haem-desktop pulseaudio[7052]: Failed to load authentication key '/home/haem/.config/pulse/cookie': Tiedostoa tai hakemistoa ei ole
marras 09 17:04:12 haem-desktop pulseaudio[7052]: Module "module-udev-detect" should be loaded once at most. Refusing to load.
marras 09 17:04:12 haem-desktop systemd[2192]: Started Sound Service.
marras 09 17:04:12 haem-desktop pulseaudio[7052]: Could not find org.bluez.BatteryProviderManager1.RegisterBatteryProvider(), is bluetoothd started with experimental features enabled (-E flag)?
marras 09 17:04:38 haem-desktop pulseaudio[7052]: Transport Acquire() failed for transport /org/bluez/hci0/dev_2C_4D_79_40_C5_3B/sep1/fd2 (Input/output error)
marras 09 17:05:02 haem-desktop pulseaudio[7052]: org.freedesktop.DBus.Properties.Get /org/bluez/hci0/dev_2C_4D_79_40_C5_3B/sep1/fd3 Volume failed: org.freedesktop.DBus.Error.InvalidArgs: No such property 'Vo>
marras 09 17:05:02 haem-desktop pulseaudio[7052]: Battery Level: 100%
marras 09 17:05:02 haem-desktop pulseaudio[7052]: Dock Status: undocked
marras 09 17:22:24 haem-desktop pulseaudio[7052]: Got POLLNVAL from ALSA
marras 09 17:22:24 haem-desktop pulseaudio[7052]: Error opening PCM device hw:1: Tiedostoa tai hakemistoa ei ole
"Tiedostoa tai hakemistoa ei ole" significa "nenhum arquivo ou diretório". Eu verifiquei se a pasta /haem/.config/pulse/existe.
Pesquisar a saída da pactl listpalavra "Arozzi" me dá o seguinte:
Module #8
Name: module-alsa-card
Argument: device_id="1" name="usb-C-Media_Electronics_Inc._Arozzi_Sfera_Microphone-00" card_name="alsa_card.usb-C-Media_Electronics_Inc._Arozzi_Sfera_Microphone-00" namereg_fail=false tsched=yes fixed_latency_range=no ignore_dB=no deferred_volume=yes use_ucm=yes avoid_resampling=no card_properties="module-udev-detect.discovered=1"
Usage counter: 0
Properties:
module.author = "Lennart Poettering"
module.description = "ALSA Card"
module.version = "15.99.1"
...
Sink #1
State: SUSPENDED
Name: alsa_output.usb-C-Media_Electronics_Inc._Arozzi_Sfera_Microphone-00.iec958-stereo
Description: Audio Adapter (Unitek Y-247A) Digitaalinen stereo (IEC958)
Driver: module-alsa-card.c
Sample Specification: s16le 2ch 48000Hz
Channel Map: front-left,front-right
Owner Module: 8
Mute: no
Volume: front-left: 65536 / 100% / 0,00 dB, front-right: 65536 / 100% / 0,00 dB
balance 0,00
Base Volume: 65536 / 100% / 0,00 dB
Monitor Source: alsa_output.usb-C-Media_Electronics_Inc._Arozzi_Sfera_Microphone-00.iec958-stereo.monitor
Latency: 0 usec, configured 0 usec
Flags: HARDWARE DECIBEL_VOLUME LATENCY SET_FORMATS
Properties:
alsa.resolution_bits = "16"
device.api = "alsa"
device.class = "sound"
alsa.class = "generic"
alsa.subclass = "generic-mix"
alsa.name = "USB Audio"
alsa.id = "USB Audio"
alsa.subdevice = "0"
alsa.subdevice_name = "subdevice #0"
alsa.device = "0"
alsa.card = "1"
alsa.card_name = "Arozzi Sfera Microphone"
alsa.long_card_name = "C-Media Electronics Inc. Arozzi Sfera Microphone at usb-0000:00:14.0-4, full sp"
alsa.driver_name = "snd_usb_audio"
device.bus_path = "pci-0000:00:14.0-usb-0:4:1.0"
sysfs.path = "/devices/pci0000:00/0000:00:14.0/usb1/1-4/1-4:1.0/sound/card1"
udev.id = "usb-C-Media_Electronics_Inc._Arozzi_Sfera_Microphone-00"
device.bus = "usb"
device.vendor.id = "0d8c"
device.vendor.name = "C-Media Electronics, Inc."
device.product.id = "0014"
device.product.name = "Audio Adapter (Unitek Y-247A)"
device.serial = "C-Media_Electronics_Inc._Arozzi_Sfera_Microphone"
device.form_factor = "microphone"
device.string = "iec958:1"
device.buffering.buffer_size = "352800"
device.buffering.fragment_size = "176400"
device.access_mode = "mmap+timer"
device.profile.name = "iec958-stereo"
device.profile.description = "Digitaalinen stereo (IEC958)"
device.description = "Audio Adapter (Unitek Y-247A) Digitaalinen stereo (IEC958)"
module-udev-detect.discovered = "1"
device.icon_name = "audio-input-microphone-usb"
Ports:
iec958-stereo-output: Digital Output (S/PDIF) (type: SPDIF, priority: 0, availability unknown)
Active Port: iec958-stereo-output
Formats:
pcm
Source #1
State: SUSPENDED
Name: alsa_output.usb-C-Media_Electronics_Inc._Arozzi_Sfera_Microphone-00.iec958-stereo.monitor
Description: Monitor of Audio Adapter (Unitek Y-247A) Digitaalinen stereo (IEC958)
Driver: module-alsa-card.c
Sample Specification: s16le 2ch 48000Hz
Channel Map: front-left,front-right
Owner Module: 8
Mute: no
Volume: front-left: 65536 / 100% / 0,00 dB, front-right: 65536 / 100% / 0,00 dB
balance 0,00
Base Volume: 65536 / 100% / 0,00 dB
Monitor of Sink: alsa_output.usb-C-Media_Electronics_Inc._Arozzi_Sfera_Microphone-00.iec958-stereo
Latency: 0 usec, configured 0 usec
Flags: DECIBEL_VOLUME LATENCY
Properties:
device.description = "Monitor of Audio Adapter (Unitek Y-247A) Digitaalinen stereo (IEC958)"
device.class = "monitor"
alsa.card = "1"
alsa.card_name = "Arozzi Sfera Microphone"
alsa.long_card_name = "C-Media Electronics Inc. Arozzi Sfera Microphone at usb-0000:00:14.0-4, full sp"
alsa.driver_name = "snd_usb_audio"
device.bus_path = "pci-0000:00:14.0-usb-0:4:1.0"
sysfs.path = "/devices/pci0000:00/0000:00:14.0/usb1/1-4/1-4:1.0/sound/card1"
udev.id = "usb-C-Media_Electronics_Inc._Arozzi_Sfera_Microphone-00"
device.bus = "usb"
device.vendor.id = "0d8c"
device.vendor.name = "C-Media Electronics, Inc."
device.product.id = "0014"
device.product.name = "Audio Adapter (Unitek Y-247A)"
device.serial = "C-Media_Electronics_Inc._Arozzi_Sfera_Microphone"
device.form_factor = "microphone"
device.string = "1"
module-udev-detect.discovered = "1"
device.icon_name = "audio-input-microphone-usb"
Formats:
pcm
...
Source #2
State: SUSPENDED
Name: alsa_input.usb-C-Media_Electronics_Inc._Arozzi_Sfera_Microphone-00.mono-fallback
Description: Audio Adapter (Unitek Y-247A) Mono
Driver: module-alsa-card.c
Sample Specification: s16le 1ch 44100Hz
Channel Map: mono
Owner Module: 8
Mute: no
Volume: mono: 48211 / 74% / -8,00 dB
balance 0,00
Base Volume: 27111 / 41% / -23,00 dB
Monitor of Sink: n/a
Latency: 0 usec, configured 0 usec
Flags: HARDWARE HW_MUTE_CTRL HW_VOLUME_CTRL DECIBEL_VOLUME LATENCY
Properties:
alsa.resolution_bits = "16"
device.api = "alsa"
device.class = "sound"
alsa.class = "generic"
alsa.subclass = "generic-mix"
alsa.name = "USB Audio"
alsa.id = "USB Audio"
alsa.subdevice = "0"
alsa.subdevice_name = "subdevice #0"
alsa.device = "0"
alsa.card = "1"
alsa.card_name = "Arozzi Sfera Microphone"
alsa.long_card_name = "C-Media Electronics Inc. Arozzi Sfera Microphone at usb-0000:00:14.0-4, full sp"
alsa.driver_name = "snd_usb_audio"
device.bus_path = "pci-0000:00:14.0-usb-0:4:1.0"
sysfs.path = "/devices/pci0000:00/0000:00:14.0/usb1/1-4/1-4:1.0/sound/card1"
udev.id = "usb-C-Media_Electronics_Inc._Arozzi_Sfera_Microphone-00"
device.bus = "usb"
device.vendor.id = "0d8c"
device.vendor.name = "C-Media Electronics, Inc."
device.product.id = "0014"
device.product.name = "Audio Adapter (Unitek Y-247A)"
device.serial = "C-Media_Electronics_Inc._Arozzi_Sfera_Microphone"
device.form_factor = "microphone"
device.string = "hw:1"
device.buffering.buffer_size = "176400"
device.buffering.fragment_size = "88200"
device.access_mode = "mmap+timer"
device.profile.name = "mono-fallback"
device.profile.description = "Mono"
device.description = "Audio Adapter (Unitek Y-247A) Mono"
module-udev-detect.discovered = "1"
device.icon_name = "audio-input-microphone-usb"
Ports:
analog-input-mic: Microphone (type: Mic, priority: 8700, availability unknown)
Active Port: analog-input-mic
Formats:
pcm
...
Card #1
Name: alsa_card.usb-C-Media_Electronics_Inc._Arozzi_Sfera_Microphone-00
Driver: module-alsa-card.c
Owner Module: 8
Properties:
alsa.card = "1"
alsa.card_name = "Arozzi Sfera Microphone"
alsa.long_card_name = "C-Media Electronics Inc. Arozzi Sfera Microphone at usb-0000:00:14.0-4, full sp"
alsa.driver_name = "snd_usb_audio"
device.bus_path = "pci-0000:00:14.0-usb-0:4:1.0"
sysfs.path = "/devices/pci0000:00/0000:00:14.0/usb1/1-4/1-4:1.0/sound/card1"
udev.id = "usb-C-Media_Electronics_Inc._Arozzi_Sfera_Microphone-00"
device.bus = "usb"
device.vendor.id = "0d8c"
device.vendor.name = "C-Media Electronics, Inc."
device.product.id = "0014"
device.product.name = "Audio Adapter (Unitek Y-247A)"
device.serial = "C-Media_Electronics_Inc._Arozzi_Sfera_Microphone"
device.form_factor = "microphone"
device.string = "1"
device.description = "Audio Adapter (Unitek Y-247A)"
module-udev-detect.discovered = "1"
device.icon_name = "audio-input-microphone-usb"
Profiles:
input:mono-fallback: Mono Sisääntulo (sinks: 0, sources: 1, priority: 1, available: yes)
output:analog-stereo: Analoginen stereo Ulostulo (sinks: 1, sources: 0, priority: 6500, available: yes)
output:analog-stereo+input:mono-fallback: Analoginen stereo Ulostulo + Mono Sisääntulo (sinks: 1, sources: 1, priority: 6501, available: yes)
output:iec958-stereo: Digitaalinen stereo (IEC958) Ulostulo (sinks: 1, sources: 0, priority: 5500, available: yes)
output:iec958-stereo+input:mono-fallback: Digitaalinen stereo (IEC958) Ulostulo + Mono Sisääntulo (sinks: 1, sources: 1, priority: 5501, available: yes)
off: Poissa (sinks: 0, sources: 0, priority: 0, available: yes)
Active Profile: output:iec958-stereo+input:mono-fallback
Ports:
analog-input-mic: Microphone (type: Mic, priority: 8700, latency offset: 0 usec, availability unknown)
Properties:
device.icon_name = "audio-input-microphone"
Part of profile(s): input:mono-fallback, output:analog-stereo+input:mono-fallback, output:iec958-stereo+input:mono-fallback
analog-output: Analog Output (type: Analogue, priority: 9900, latency offset: 0 usec, availability unknown)
Part of profile(s): output:analog-stereo, output:analog-stereo+input:mono-fallback
iec958-stereo-output: Digital Output (S/PDIF) (type: SPDIF, priority: 0, latency offset: 0 usec, availability unknown)
Part of profile(s): output:iec958-stereo, output:iec958-stereo+input:mono-fallback
Descarregar o módulo alsa-card por número ( pactl unload-module 8neste caso) também desativa o microfone como entrada.
pactl infome diz que o coletor padrão é bluez_sink.2C_4D_79_40_C5_3B.a2dp_sink. Isso muda quando altero a saída de áudio nas configurações.
Um problema possivelmente relacionado é que, quando desconecto e reconecto o microfone, posso ver o microfone como a saída "padrão" nas minhas configurações de áudio.
Outra observação; quando eu defino explicitamente o coletor de áudio nas configurações de um aplicativo, por exemplo, no aplicativo de desktop Discord, isso funciona. Parece que é apenas o coletor e/ou gnome padrão que exibe esse comportamento.
Por volta do final de março deste ano, esse comportamento parece ter se tornado constante. Eu sei que funcionou corretamente no dia 30. A única solução que tenho é desconectar o microfone.
Eu gostaria de saber como consertar isso. Caso contrário, gostaria de saber como diagnosticar isso a ponto de poder fazer um relatório de bug para a parte correta.
Responder1
Acredito que encontrei a solução. Usando pavucontrol, encontrei o perfil de áudio do microfone, e o perfil configurado para ele era "Saída estéreo digital + entrada mono", o que confundia o pulseaudio. Acredito que este seja o iec958-stereo+inputperfil de saída.
Mudar isso para apenas "entrada mono", que acredito ser mono-fallback, resolveu o problema.
