SO: Linux Mint 18.2 Cinnamon + Windows 10 Pro; Bota dupla.
Acabei de usar este sitehttp://test-ipv6.com/para verificar minha preparação para IPv6.
Resultados no Windows 10 Pro:
Resultados no Linux Mint 18.2 Cinnamon:
Como você pode ver, eu tenhoalgunsproblema com as configurações de DNS no meu Linux Mint. Mas tudo parece estar ativado, como na seção Configurações de rede - IPv6:
Não tenho certeza de onde procurar a configuração de DNS com falha. Ou o Linux Mint 18 ainda não está pronto para o IPv6?
EDITAR1:
$ cat /etc/resolv.conf
nameserver 209.222.18.222
nameserver 209.222.18.218
Mas no gerenciador de rede vejo o DNS do Google como primário + o do meu IPS como secundário, que configurei no DHCP do meu roteador na seção IPv4:
Suponho que sejam os que meu laptop está usando.
$ nmcli dev show | grep DNS
IP4.DNS[1]: 8.8.8.8
IP4.DNS[2]: 10.255.255.10
IP6.DNS[1]: 2a02:768:0:1010::3
IP6.DNS[2]: 2a02:768:0:1010::2
Admito que não entendo nada de IPv6, mas não entendo por que no Windows o teste, portanto o IPv6 está totalmente operacional e no Linux não.
$ cat /etc/gai.conf
# Configuration for getaddrinfo(3).
#
# So far only configuration for the destination address sorting is needed.
# RFC 3484 governs the sorting. But the RFC also says that system
# administrators should be able to overwrite the defaults. This can be
# achieved here.
#
# All lines have an initial identifier specifying the option followed by
# up to two values. Information specified in this file replaces the
# default information. Complete absence of data of one kind causes the
# appropriate default information to be used. The supported commands include:
#
# reload <yes|no>
# If set to yes, each getaddrinfo(3) call will check whether this file
# changed and if necessary reload. This option should not really be
# used. There are possible runtime problems. The default is no.
#
# label <mask> <value>
# Add another rule to the RFC 3484 label table. See section 2.1 in
# RFC 3484. The default is:
#
#label ::1/128 0
#label ::/0 1
#label 2002::/16 2
#label ::/96 3
#label ::ffff:0:0/96 4
#label fec0::/10 5
#label fc00::/7 6
#label 2001:0::/32 7
#
# This default differs from the tables given in RFC 3484 by handling
# (now obsolete) site-local IPv6 addresses and Unique Local Addresses.
# The reason for this difference is that these addresses are never
# NATed while IPv4 site-local addresses most probably are. Given
# the precedence of IPv6 over IPv4 (see below) on machines having only
# site-local IPv4 and IPv6 addresses a lookup for a global address would
# see the IPv6 be preferred. The result is a long delay because the
# site-local IPv6 addresses cannot be used while the IPv4 address is
# (at least for the foreseeable future) NATed. We also treat Teredo
# tunnels special.
#
# precedence <mask> <value>
# Add another rule to the RFC 3484 precedence table. See section 2.1
# and 10.3 in RFC 3484. The default is:
#
#precedence ::1/128 50
#precedence ::/0 40
#precedence 2002::/16 30
#precedence ::/96 20
#precedence ::ffff:0:0/96 10
#
# For sites which prefer IPv4 connections change the last line to
#
precedence ::ffff:0:0/96 100
#
# scopev4 <mask> <value>
# Add another rule to the RFC 6724 scope table for IPv4 addresses.
# By default the scope IDs described in section 3.2 in RFC 6724 are
# used. Changing these defaults should hardly ever be necessary.
# The defaults are equivalent to:
#
#scopev4 ::ffff:169.254.0.0/112 2
#scopev4 ::ffff:127.0.0.0/104 2
#scopev4 ::ffff:0.0.0.0/96 14
Então, tem quase tudo comentado.
Além disso, você perguntou qual cliente DHCP estou usando:
$ dhclient --help
Internet Systems Consortium DHCP Client 4.3.3
...
EDITAR2:
$ cat /etc/dhcp/dhclient.conf
# Configuration file for /sbin/dhclient.
#
# This is a sample configuration file for dhclient. See dhclient.conf's
# man page for more information about the syntax of this file
# and a more comprehensive list of the parameters understood by
# dhclient.
#
# Normally, if the DHCP server provides reasonable information and does
# not leave anything out (like the domain name, for example), then
# few changes must be made to this file, if any.
#
option rfc3442-classless-static-routes code 121 = array of unsigned integer 8;
send host-name = gethostname();
request subnet-mask, broadcast-address, time-offset, routers,
domain-name, domain-name-servers, domain-search, host-name,
dhcp6.name-servers, dhcp6.domain-search, dhcp6.fqdn, dhcp6.sntp-servers,
netbios-name-servers, netbios-scope, interface-mtu,
rfc3442-classless-static-routes, ntp-servers;
#send dhcp-client-identifier 1:0:a0:24:ab:fb:9c;
#send dhcp-lease-time 3600;
#supersede domain-name "fugue.com home.vix.com";
#prepend domain-name-servers 127.0.0.1;
#require subnet-mask, domain-name-servers;
timeout 300;
#retry 60;
#reboot 10;
#select-timeout 5;
#initial-interval 2;
#script "/sbin/dhclient-script";
#media "-link0 -link1 -link2", "link0 link1";
#reject 192.33.137.209;
#alias {
# interface "eth0";
# fixed-address 192.5.5.213;
# option subnet-mask 255.255.255.255;
#}
#lease {
# interface "eth0";
# fixed-address 192.33.137.200;
# medium "link0 link1";
# option host-name "andare.swiftmedia.com";
# option subnet-mask 255.255.255.0;
# option broadcast-address 192.33.137.255;
# option routers 192.33.137.250;
# option domain-name-servers 127.0.0.1;
# renew 2 2000/1/12 00:00:01;
# rebind 2 2000/1/12 00:00:01;
# expire 2 2000/1/12 00:00:01;
#}
EDITAR3:
Depois de copiar e colar a linha IPv6 uma linha acima:
cat /etc/dhcp/dhclient.conf
# Configuration file for /sbin/dhclient.
#
# This is a sample configuration file for dhclient. See dhclient.conf's
# man page for more information about the syntax of this file
# and a more comprehensive list of the parameters understood by
# dhclient.
#
# Normally, if the DHCP server provides reasonable information and does
# not leave anything out (like the domain name, for example), then
# few changes must be made to this file, if any.
#
option rfc3442-classless-static-routes code 121 = array of unsigned integer 8;
send host-name = gethostname();
request subnet-mask, broadcast-address, time-offset, routers,
dhcp6.name-servers, dhcp6.domain-search, dhcp6.fqdn, dhcp6.sntp-servers,
domain-name, domain-name-servers, domain-search, host-name,
netbios-name-servers, netbios-scope, interface-mtu,
rfc3442-classless-static-routes, ntp-servers;
#send dhcp-client-identifier 1:0:a0:24:ab:fb:9c;
#send dhcp-lease-time 3600;
#supersede domain-name "fugue.com home.vix.com";
#prepend domain-name-servers 127.0.0.1;
#require subnet-mask, domain-name-servers;
timeout 300;
#retry 60;
#reboot 10;
#select-timeout 5;
#initial-interval 2;
#script "/sbin/dhclient-script";
#media "-link0 -link1 -link2", "link0 link1";
#reject 192.33.137.209;
#alias {
# interface "eth0";
# fixed-address 192.5.5.213;
# option subnet-mask 255.255.255.255;
#}
#lease {
# interface "eth0";
# fixed-address 192.33.137.200;
# medium "link0 link1";
# option host-name "andare.swiftmedia.com";
# option subnet-mask 255.255.255.0;
# option broadcast-address 192.33.137.255;
# option routers 192.33.137.250;
# option domain-name-servers 127.0.0.1;
# renew 2 2000/1/12 00:00:01;
# rebind 2 2000/1/12 00:00:01;
# expire 2 2000/1/12 00:00:01;
#}
EDITAR4:
Talvez meu aplicativo de provedor de VPN tenha causado isso, não fiz nenhuma alteração. No momento não estou usando VPN, então queria testar se meu Linux é compatível com IPv6. Os servidores de nomes em resolv.conf pertencem ao provedor VPN: Private Internet Access.
Tentando descobrir por que resolv.confnão está sendo atualizado:
$ lsattr /etc/resolv.conf
-------------e-- /etc/resolv.conf
EDITAR5:
$ sudo tcpdump -i eth0 udp port 53
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on eth0, link-type EN10MB (Ethernet), capture size 262144 bytes
13:28:35.416720 IP 192.168.0.11.46858 > resolver1.privateinternetaccess.com.domain: 22927+ A? imap.gmail.com. (32)
13:28:35.416730 IP 192.168.0.11.46858 > resolver1.privateinternetaccess.com.domain: 8909+ AAAA? imap.gmail.com. (32)
13:28:35.416974 IP 192.168.0.11.39732 > resolver1.privateinternetaccess.com.domain: 35471+ PTR? 222.18.222.209.in-addr.arpa. (45)
13:28:35.436305 IP 192.168.0.11.52326 > resolver1.privateinternetaccess.com.domain: 65414+ A? live.mozillamessaging.com. (43)
13:28:35.436310 IP 192.168.0.11.52326 > resolver1.privateinternetaccess.com.domain: 30886+ AAAA? live.mozillamessaging.com. (43)
13:28:35.478049 IP 192.168.0.11.46175 > resolver1.privateinternetaccess.com.domain: 5292+ A? mx.endora.cz. (30)
13:28:35.478053 IP 192.168.0.11.46175 > resolver1.privateinternetaccess.com.domain: 16624+ AAAA? mx.endora.cz. (30)
13:28:35.815497 IP 192.168.0.11.50734 > resolver1.privateinternetaccess.com.domain: 17117+ A? clients1.google.com. (37)
13:28:35.815508 IP 192.168.0.11.50734 > resolver1.privateinternetaccess.com.domain: 34551+ AAAA? clients1.google.com. (37)
13:28:35.816481 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.46175: 5292 1/0/0 A 88.86.120.212 (46)
13:28:35.818739 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.46175: 16624 0/1/0 (86)
13:28:35.959874 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.50734: 17117 2/0/0 CNAME clients.l.google.com., A 172.217.12.142 (77)
13:28:35.959899 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.50734: 34551 2/0/0 CNAME clients.l.google.com., AAAA 2607:f8b0:4006:819::200e (89)
13:28:35.972396 IP 192.168.0.11.50409 > resolver1.privateinternetaccess.com.domain: 53313+ A? ocsp2.globalsign.com. (38)
13:28:35.972406 IP 192.168.0.11.50409 > resolver1.privateinternetaccess.com.domain: 62184+ AAAA? ocsp2.globalsign.com. (38)
13:28:36.145921 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.50409: 62184 3/0/0 CNAME cdn.globalsigncdn.com., AAAA 2400:cb00:2048:1::681f:4a7c, AAAA 2400:cb00:2048:1::681f:4b7c (126)
13:28:36.153394 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.50409: 53313 3/0/0 CNAME cdn.globalsigncdn.com., A 104.31.75.124, A 104.31.74.124 (102)
13:28:36.345446 IP 192.168.0.11.39036 > resolver1.privateinternetaccess.com.domain: 49155+ A? www.googleapis.com. (36)
13:28:36.345462 IP 192.168.0.11.39036 > resolver1.privateinternetaccess.com.domain: 10791+ AAAA? www.googleapis.com. (36)
13:28:36.483314 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.39036: 49155 13/0/0 CNAME googleapis.l.google.com., A 172.217.6.234, A 172.217.10.234, A 172.217.12.170, A 172.217.12.202, A 172.217.9.234, A 172.217.10.10, A 172.217.10.42, A 172.217.10.74, A 172.217.10.138, A 172.217.3.106, A 172.217.12.138, A 172.217.6.202 (262)
13:28:36.483344 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.39036: 10791 2/0/0 CNAME googleapis.l.google.com., AAAA 2607:f8b0:4006:812::200a (98)
^C
EDITAR6:
sudo dhclient -r
sudo dhclient -v eth0
Internet Systems Consortium DHCP Client 4.3.3
Copyright 2004-2015 Internet Systems Consortium.
All rights reserved.
For info, please visit https://www.isc.org/software/dhcp/
Listening on LPF/eth0/d8:50:e6:05:e1:db
Sending on LPF/eth0/d8:50:e6:05:e1:db
Sending on Socket/fallback
DHCPDISCOVER on eth0 to 255.255.255.255 port 67 interval 3 (xid=0x3ede007c)
DHCPREQUEST of 192.168.0.11 on eth0 to 255.255.255.255 port 67 (xid=0x7c00de3e)
DHCPOFFER of 192.168.0.11 from 192.168.0.1
DHCPACK of 192.168.0.11 from 192.168.0.1
/etc/resolvconf/update.d/libc: Warning: /etc/resolv.conf is not a symbolic link to /run/resolvconf/resolv.conf
bound to 192.168.0.11 -- renewal in 2147483648 seconds.
EDITAR7:
$ sudo tcpdump -i eth0 -vvv -n port 68
tcpdump: listening on eth0, link-type EN10MB (Ethernet), capture size 262144 bytes
14:30:18.135530 IP (tos 0x10, ttl 128, id 0, offset 0, flags [none], proto UDP (17), length 328)
0.0.0.0.68 > 255.255.255.255.67: [udp sum ok] BOOTP/DHCP, Request from d8:50:e6:05:e1:db, length 300, xid 0x7a30842b, Flags [none] (0x0000)
Client-Ethernet-Address d8:50:e6:05:e1:db
Vendor-rfc1048 Extensions
Magic Cookie 0x63825363
DHCP-Message Option 53, length 1: Request
Requested-IP Option 50, length 4: 192.168.0.11
Hostname Option 12, length 10: "vb-nb-mint"
Parameter-Request Option 55, length 18:
Subnet-Mask, BR, Time-Zone, Default-Gateway
Domain-Name, Domain-Name-Server, Option 119, Hostname
Netbios-Name-Server, Netbios-Scope, MTU, Classless-Static-Route
NTP, Classless-Static-Route, Classless-Static-Route-Microsoft, Static-Route
Option 252, NTP
END Option 255, length 0
PAD Option 0, length 0, occurs 18
14:30:18.136280 IP (tos 0x0, ttl 64, id 15220, offset 0, flags [none], proto UDP (17), length 576)
192.168.0.1.67 > 192.168.0.11.68: [udp sum ok] BOOTP/DHCP, Reply, length 548, xid 0x7a30842b, Flags [none] (0x0000)
Your-IP 192.168.0.11
Client-Ethernet-Address d8:50:e6:05:e1:db
Vendor-rfc1048 Extensions
Magic Cookie 0x63825363
DHCP-Message Option 53, length 1: ACK
Server-ID Option 54, length 4: 192.168.0.1
Lease-Time Option 51, length 4: 4294967295
Subnet-Mask Option 1, length 4: 255.255.255.0
Default-Gateway Option 3, length 4: 192.168.0.1
Domain-Name-Server Option 6, length 8: 8.8.8.8,10.255.255.10
END Option 255, length 0
PAD Option 0, length 0, occurs 270
^C
+
$ cat /run/resolvconf/resolv.conf
# Dynamic resolv.conf(5) file for glibc resolver(3) generated by resolvconf(8)
# DO NOT EDIT THIS FILE BY HAND -- YOUR CHANGES WILL BE OVERWRITTEN
nameserver 8.8.8.8
nameserver 10.255.255.10
nameserver 127.0.1.1
Responder1
Em /etc/gai.conf você precisa comentar a linha dando prioridade ao IPv6 sobre IPv4 como em:
# precedence ::ffff:0:0/96 100
Você também precisa editar /etc/dhclient/dhclient6.conf e talvez passar o parâmetro -6 para dhclient se isso não for suficiente.
Eu também sugeriria corrigir o link resolv.conf.
Eu também poderia jurar que o dhclient usa apenas os dois primeiros servidores DNS passados via DHCP, mas posso estar errado.
EDITAR:
O passo acima está correto, ou seja, é o nosso primeiro passo comentando a linha:
precedence ::ffff:0:0/96 100no seguinte arquivo:
/etc/gai.confExecutando as etapas mencionadasem documentos da Microsoftaplicável ao Linux Mint 18.x, que é baseado no Ubuntu 16.04:
Criando o seguinte arquivo:
/etc/dhcp/dhclient6.confcom conteúdo:
timeout 10;Criando o seguinte arquivo:
/etc/network/interfaces.d/50-cloud-init.cfgcom conteúdo:
iface eth0 inet6 auto up sleep 5 up dhclient -1 -6 -cf /etc/dhcp/dhclient6.conf -lf /var/lib/dhcp/dhclient6.eth0.leases -v eth0 || trueE finalmente criando o link simbólico enquanto sobrescreve o original
resolv.conf:ln -sf /run/resolvconf/resolv.conf /etc/resolv.confReinicie e pronto, o IPv6 do DHCP está funcionando.
Responder2
Você pode dar prioridade ao IPv6 sobre IPv4 adicionando a linha precedence 2001:470::/32 100e comentando precedence ::ffff:0:0/96 100no arquivo /etc/gai.conf
