Atualmente estou usando o arch no meu laptop Asus UX51VZ há quase um mês. Eu tenho uma configuração fakeraid com dois SSDs de 256 GB usando mdadm. Eu estava usando essa configuração sem problemas. No entanto, depois de reinstalar acidentalmente o pacote linux-4.1.6 e reiniciar, fui recebido com uma mensagem dizendo unable to find root device UUID: .... (este UUID está na saída fstab e lsblk -f).
Inicializei um formulário USB ativo onde posso montar com êxito o dispositivo RAID e ver todos os meus dados (o chroot também está funcionando). Verifiquei /etc/mkinitcpio.conf (mdadm_udev está em seu lugar) e executei mkinitcpio -p linux (que é executado sem erros). Também tentei reinstalar o grub, mas também sem sucesso. Mais tarde reinstalei o mdadm, o dmraid e também atualizei para o linux-4.2, mas nada mudou.
Alguém pode ver o que pode estar errado? Qualquer ajuda será muito apreciada.
Meu mdadmd.conf:
# mdadm configuration file
#
# mdadm will function properly without the use of a configuration file,
# but this file is useful for keeping track of arrays and member disks.
# In general, a mdadm.conf file is created, and updated, after arrays
# are created. This is the opposite behavior of /etc/raidtab which is
# created prior to array construction.
#
#
# the config file takes two types of lines:
#
# DEVICE lines specify a list of devices of where to look for
# potential member disks
#
# ARRAY lines specify information about how to identify arrays so
# so that they can be activated
#
# You can have more than one device line and use wild cards. The first
# example includes SCSI the first partition of SCSI disks /dev/sdb,
# /dev/sdc, /dev/sdd, /dev/sdj, /dev/sdk, and /dev/sdl. The second
# line looks for array slices on IDE disks.
#
#DEVICE /dev/sd[bcdjkl]1
#DEVICE /dev/hda1 /dev/hdb1
#
# If you mount devfs on /dev, then a suitable way to list all devices is:
#DEVICE /dev/discs/*/*
#
#
# The AUTO line can control which arrays get assembled by auto-assembly,
# meaing either "mdadm -As" when there are no 'ARRAY' lines in this file,
# or "mdadm --incremental" when the array found is not listed in this file.
# By default, all arrays that are found are assembled.
# If you want to ignore all DDF arrays (maybe they are managed by dmraid),
# and only assemble 1.x arrays if which are marked for 'this' homehost,
# but assemble all others, then use
#AUTO -ddf homehost -1.x +all
#
# ARRAY lines specify an array to assemble and a method of identification.
# Arrays can currently be identified by using a UUID, superblock minor number,
# or a listing of devices.
#
# super-minor is usually the minor number of the metadevice
# UUID is the Universally Unique Identifier for the array
# Each can be obtained using
#
# mdadm -D <md>
#
#ARRAY /dev/md0 UUID=3aaa0122:29827cfa:5331ad66:ca767371
#ARRAY /dev/md1 super-minor=1
#ARRAY /dev/md2 devices=/dev/hda1,/dev/hdb1
#
# ARRAY lines can also specify a "spare-group" for each array. mdadm --monitor
# will then move a spare between arrays in a spare-group if one array has a failed
# drive but no spare
#ARRAY /dev/md4 uuid=b23f3c6d:aec43a9f:fd65db85:369432df spare-group=group1
#ARRAY /dev/md5 uuid=19464854:03f71b1b:e0df2edd:246cc977 spare-group=group1
#
# When used in --follow (aka --monitor) mode, mdadm needs a
# mail address and/or a program. This can be given with "mailaddr"
# and "program" lines to that monitoring can be started using
# mdadm --follow --scan & echo $! > /run/mdadm/mon.pid
# If the lines are not found, mdadm will exit quietly
#MAILADDR [email protected]
#PROGRAM /usr/sbin/handle-mdadm-events
ARRAY /dev/md/imsm0 metadata=imsm UUID=4f9f485d:ad8c1ad3:0f95a3c8:35e49dc6
ARRAY /dev/md/RAID0SYS_0 container=/dev/md/imsm0 member=0 UUID=a703574c:86157ccd:2f213f57:810ea8e5
Meu mkinitcpio.conf:
# vim:set ft=sh
# MODULES
# The following modules are loaded before any boot hooks are
# run. Advanced users may wish to specify all system modules
# in this array. For instance:
# MODULES="piix ide_disk reiserfs"
MODULES=""
# BINARIES
# This setting includes any additional binaries a given user may
# wish into the CPIO image. This is run last, so it may be used to
# override the actual binaries included by a given hook
# BINARIES are dependency parsed, so you may safely ignore libraries
BINARIES="mdmon"
# FILES
# This setting is similar to BINARIES above, however, files are added
# as-is and are not parsed in any way. This is useful for config files.
FILES=""
# HOOKS
# This is the most important setting in this file. The HOOKS control the
# modules and scripts added to the image, and what happens at boot time.
# Order is important, and it is recommended that you do not change the
# order in which HOOKS are added. Run 'mkinitcpio -H <hook name>' for
# help on a given hook.
# 'base' is _required_ unless you know precisely what you are doing.
# 'udev' is _required_ in order to automatically load modules
# 'filesystems' is _required_ unless you specify your fs modules in MODULES
# Examples:
## This setup specifies all modules in the MODULES setting above.
## No raid, lvm2, or encrypted root is needed.
# HOOKS="base"
#
## This setup will autodetect all modules for your system and should
## work as a sane default
# HOOKS="base udev autodetect block filesystems"
#
## This setup will generate a 'full' image which supports most systems.
## No autodetection is done.
# HOOKS="base udev block filesystems"
#
## This setup assembles a pata mdadm array with an encrypted root FS.
## Note: See 'mkinitcpio -H mdadm' for more information on raid devices.
# HOOKS="base udev block mdadm encrypt filesystems"
#
## This setup loads an lvm2 volume group on a usb device.
# HOOKS="base udev block lvm2 filesystems"
#
## NOTE: If you have /usr on a separate partition, you MUST include the
# usr, fsck and shutdown hooks.
HOOKS="base udev autodetect block mdadm_udev keyboard fsck resume filesystems shutdown"
# COMPRESSION
# Use this to compress the initramfs image. By default, gzip compression
# is used. Use 'cat' to create an uncompressed image.
#COMPRESSION="gzip"
#COMPRESSION="bzip2"
#COMPRESSION="lzma"
#COMPRESSION="xz"
#COMPRESSION="lzop"
#COMPRESSION="lz4"
# COMPRESSION_OPTIONS
# Additional options for the compressor
#COMPRESSION_OPTIONS=""
Meu fstab: # /dev/md126p3 UUID=41cf124a-3aca-4d61-9b23-5e51cd88445e / ext4 rw,relatime,stripe=64,data=ordered 0 1
# /dev/md126p4
UUID=cbacfa26-0890-46bc-ae68-22d613f0cf5e /home ext4 rw,relatime,stripe=64,data=ordered 0 2
# /dev/md126p1
UUID=22B4-3DED /boot vfat rw,relatime,fmask=0022,dmask=0022,codepage=437,iocharset=iso8859-1,shortname=mixed,errors=remount-ro 0 2
# /dev/md126p2
UUID=34aeb345-fa3a-4dad-bacd-c97fe5a13a3f none swap defaults 0 0
Saída lsblk -f do chroot da unidade USB:
NAME FSTYPE LABEL UUID MOUNTPOINT
sda
└─md126
├─md126p1 /boot
├─md126p2 [SWAP]
├─md126p3 /
└─md126p4 /home
sdb
└─md126
├─md126p1 /boot
├─md126p2 [SWAP]
├─md126p3 /
└─md126p4 /home
sdc
├─sdc1
└─sdc2
loop0
loop1
loop2
loop3
saída blkid:
/dev/sda: TYPE="isw_raid_member"
/dev/sdb: TYPE="isw_raid_member"
/dev/sdc1: UUID="2015-07-13-20-38-48-00" LABEL="MJRO0813" TYPE="iso9660" PTUUID="18247d08" PTTYPE="dos" PARTUUID="18247d08-01"
/dev/sdc2: SEC_TYPE="msdos" LABEL="MISO_EFI" UUID="C8E1-3936" TYPE="vfat" PARTUUID="18247d08-02"
/dev/loop0: TYPE="squashfs"
/dev/loop1: TYPE="squashfs"
/dev/loop2: TYPE="squashfs"
/dev/loop3: TYPE="squashfs"
/dev/md126: PTUUID="bdb2552b-bac3-4691-a6e3-8f11574b11a5" PTTYPE="gpt"
/dev/md126p1: UUID="22B4-3DED" TYPE="vfat" PARTLABEL="EFI System" PARTUUID="938e8f67-7259-4c02-a841-b04f7f6fd1e8"
/dev/md126p2: UUID="34aeb345-fa3a-4dad-bacd-c97fe5a13a3f" TYPE="swap" PARTLABEL="Linux swap" PARTUUID="8dc3fde4-ecba-42a0-ac5f-37b11917755d"
/dev/md126p3: UUID="41cf124a-3aca-4d61-9b23-5e51cd88445e" TYPE="ext4" PARTLABEL="Linux filesystem" PARTUUID="cad3a0ba-365e-49de-a117-c526b1fadd8c"
/dev/md126p4: UUID="cbacfa26-0890-46bc-ae68-22d613f0cf5e" TYPE="ext4" PARTLABEL="Linux /home" PARTUUID="6ae8c946-bdbf-4f0d-aabe-9cc3b291ace4"
Também posso postar qualquer informação adicional que você precisar.
