Instalei o Sophos Free Home UTM no Oracle VM VirtualBox Manager e não consigo acessar a GUI do webadmin de fora da máquina virtual. Mudei o adaptador de rede de Nat para adaptador em ponte, mas ele ainda não vê o Sophos Home UTM. Tentei fazer ping no endereço IP correto de 192.168.2.100 e ele não responde e também não vejo o endereço IP listado no ifconfig.
Não sei o que tentar a seguir; Qualquer ajuda seria ótimo.
C:\Users\kwjor_000>ipconfig /all
Windows IP Configuration
Host Name . . . . . . . . . . . . : TheFalcon
Primary Dns Suffix . . . . . . . :
Node Type . . . . . . . . . . . . : Hybrid
IP Routing Enabled. . . . . . . . : No
WINS Proxy Enabled. . . . . . . . : No
DNS Suffix Search List. . . . . . : domain
Ethernet adapter Ethernet:
Media State . . . . . . . . . . . : Media disconnected
Connection-specific DNS Suffix . : domain
Description . . . . . . . . . . . : Realtek PCIe GBE Family Controller
Physical Address. . . . . . . . . : B8-2A-72-B8-24-43
DHCP Enabled. . . . . . . . . . . : Yes
Autoconfiguration Enabled . . . . : Yes
Ethernet adapter VirtualBox Host-Only Network #2:
Connection-specific DNS Suffix . :
Description . . . . . . . . . . . : VirtualBox Host-Only Ethernet Adapter #2
Physical Address. . . . . . . . . : 0A-00-27-00-00-02
DHCP Enabled. . . . . . . . . . . : No
Autoconfiguration Enabled . . . . : Yes
Link-local IPv6 Address . . . . . : fe80::e839:a212:8e40:de73%2(Preferred)
IPv4 Address. . . . . . . . . . . : 192.168.56.1(Preferred)
Subnet Mask . . . . . . . . . . . : 255.255.255.0
Default Gateway . . . . . . . . . :
DHCPv6 IAID . . . . . . . . . . . : 369754151
DHCPv6 Client DUID. . . . . . . . : 00-01-00-01-1B-4C-85-0E-B8-2A-72-B8-24-43
DNS Servers . . . . . . . . . . . : fec0:0:0:ffff::1%1
fec0:0:0:ffff::2%1
fec0:0:0:ffff::3%1
NetBIOS over Tcpip. . . . . . . . : Enabled
Wireless LAN adapter Local Area Connection* 3:
Media State . . . . . . . . . . . : Media disconnected
Connection-specific DNS Suffix . :
Description . . . . . . . . . . . : Microsoft Wi-Fi Direct Virtual Adapter
Physical Address. . . . . . . . . : A0-A8-CD-0C-6D-28
DHCP Enabled. . . . . . . . . . . : Yes
Autoconfiguration Enabled . . . . : Yes
Wireless LAN adapter Local Area Connection* 13:
Media State . . . . . . . . . . . : Media disconnected
Connection-specific DNS Suffix . :
Description . . . . . . . . . . . : Microsoft Wi-Fi Direct Virtual Adapter #3
Physical Address. . . . . . . . . : A2-A8-CD-0C-6D-27
DHCP Enabled. . . . . . . . . . . : Yes
Autoconfiguration Enabled . . . . : Yes
Ethernet adapter VMware Network Adapter VMnet1:
Connection-specific DNS Suffix . :
Description . . . . . . . . . . . : VMware Virtual Ethernet Adapter for VMnet1
Physical Address. . . . . . . . . : 00-50-56-C0-00-01
DHCP Enabled. . . . . . . . . . . : Yes
Autoconfiguration Enabled . . . . : Yes
Link-local IPv6 Address . . . . . : fe80::84ee:2799:e6a1:fe37%11(Preferred)
IPv4 Address. . . . . . . . . . . : 192.168.186.1(Preferred)
Subnet Mask . . . . . . . . . . . : 255.255.255.0
Lease Obtained. . . . . . . . . . : Saturday, September 23, 2017 4:04:46 PM
Lease Expires . . . . . . . . . . : Saturday, September 23, 2017 7:34:47 PM
Default Gateway . . . . . . . . . :
DHCP Server . . . . . . . . . . . : 192.168.186.254
DHCPv6 IAID . . . . . . . . . . . : 553668694
DHCPv6 Client DUID. . . . . . . . : 00-01-00-01-1B-4C-85-0E-B8-2A-72-B8-24-43
DNS Servers . . . . . . . . . . . : fec0:0:0:ffff::1%1
fec0:0:0:ffff::2%1
fec0:0:0:ffff::3%1
NetBIOS over Tcpip. . . . . . . . : Enabled
Ethernet adapter VMware Network Adapter VMnet8:
Connection-specific DNS Suffix . :
Description . . . . . . . . . . . : VMware Virtual Ethernet Adapter for VMnet8
Physical Address. . . . . . . . . : 00-50-56-C0-00-08
DHCP Enabled. . . . . . . . . . . : Yes
Autoconfiguration Enabled . . . . : Yes
Link-local IPv6 Address . . . . . : fe80::9d3c:e0a:8740:cb13%7(Preferred)
IPv4 Address. . . . . . . . . . . : 192.168.202.1(Preferred)
Subnet Mask . . . . . . . . . . . : 255.255.255.0
Lease Obtained. . . . . . . . . . : Saturday, September 23, 2017 4:04:47 PM
Lease Expires . . . . . . . . . . : Saturday, September 23, 2017 7:34:47 PM
Default Gateway . . . . . . . . . :
DHCP Server . . . . . . . . . . . : 192.168.202.254
DHCPv6 IAID . . . . . . . . . . . : 570445910
DHCPv6 Client DUID. . . . . . . . : 00-01-00-01-1B-4C-85-0E-B8-2A-72-B8-24-43
DNS Servers . . . . . . . . . . . : fec0:0:0:ffff::1%1
fec0:0:0:ffff::2%1
fec0:0:0:ffff::3%1
Primary WINS Server . . . . . . . : 192.168.202.2
NetBIOS over Tcpip. . . . . . . . : Enabled
Wireless LAN adapter Wi-Fi:
Connection-specific DNS Suffix . : domain
Description . . . . . . . . . . . : Intel(R) Wireless-N 7260
Physical Address. . . . . . . . . : A0-A8-CD-0C-6D-27
DHCP Enabled. . . . . . . . . . . : Yes
Autoconfiguration Enabled . . . . : Yes
Link-local IPv6 Address . . . . . : fe80::35f6:6e7c:6fd1:23f4%17(Preferred)
IPv4 Address. . . . . . . . . . . : 192.168.0.41(Preferred)
Subnet Mask . . . . . . . . . . . : 255.255.255.0
Lease Obtained. . . . . . . . . . : Saturday, September 23, 2017 12:46:31 PM
Lease Expires . . . . . . . . . . : Saturday, September 23, 2017 8:04:52 PM
Default Gateway . . . . . . . . . : 192.168.0.1
DHCP Server . . . . . . . . . . . : 192.168.0.1
DHCPv6 IAID . . . . . . . . . . . : 77637837
DHCPv6 Client DUID. . . . . . . . : 00-01-00-01-1B-4C-85-0E-B8-2A-72-B8-24-43
DNS Servers . . . . . . . . . . . : 192.168.0.1
192.168.0.1
NetBIOS over Tcpip. . . . . . . . : Enabled
Tunnel adapter Local Area Connection* 12:
Media State . . . . . . . . . . . : Media disconnected
Connection-specific DNS Suffix . :
Description . . . . . . . . . . . : Microsoft Teredo Tunneling Adapter
Physical Address. . . . . . . . . : 00-00-00-00-00-00-00-E0
DHCP Enabled. . . . . . . . . . . : No
Autoconfiguration Enabled . . . . : Yes
C:\Users\kwjor_000>
Responder1
Perfeito. Agora vemos que seu computador está conectado a wifi com um endereço IP 192.168.0.41.
Especificamente, sua interface está configurada assim:
IP: 192.168.0.41
Subnet mask: 255.255.255.0
Gateway: 192.168.0.1
DNS: 192.168.0.1
Portanto, para fins de teste simples, reconfigure o UTM para estar na mesma rede, usando um endereço IP que não esteja sendo utilizado no momento.
Por exemplo, altere o endereço 192.168.2.100 para uma configuração que corresponda à sua rede. Vamos adivinhar que 192.168.0.250 não é usado:
IP: 192.168.0.250
Subnet mask: 255.255.255.0
Gateway: 192.168.0.1
DNS: 192.168.0.1
Não se preocupe se não tiver opção de gateway ou DNS. Como eu disse, um UTM geralmente tem pelo menos 2 interfaces e se a interface 192.168.2.100 for a interface "LAN" ou "Interna" ela não terá gateway ou configuração de DNS porque geralmente É o UTM.
Faça a alteração acima e acesse seu UTM com o novo IP.
