Comprei recentemente uma câmera PhotonFocus e quero usá-la comUbuntu 18.04. Eu tenho vistoaquiisso para isso eu precisoSDK do eBUS6.x. No entanto, a partiraquiSó consigo baixar a versão 5.1.5. Que opções eu tenho?
Quando tento instalar o .deb da versão 5.1.5 recebo a seguinte saída:
(Reading database ... 468606 files and directories currently installed.)
Preparing to unpack eBUS_SDK_Ubuntu-x86_64-5.1.5-4563.deb ...
Removing /etc/ld.so.conf.d/eBUS_SDK.conf.
Reloading library path.
eBUS daemon is running: stopping the service.
Disabling automatic startup of eBUSd.
Removing /etc/init.d/eBUSd.
The /etc/udev/rules.d/80-drivers-eBUSSDK-28b7.rules rule has been removed.
The /etc/udev/rules.d/80-drivers-eBUSSDK-14fb.rules rule has been removed.
Cannot uninstall ebUniversalProForEthernet: it is not installed.
Unpacking ebus_sdk_ubuntu-x86_64 (5.1.5) over (5.1.5) ...
Setting up ebus_sdk_ubuntu-x86_64 (5.1.5) ...
Creating /etc/ld.so.conf.d/eBUS_SDK.conf.
Reloading library path.
*********************************************
Build ebUniversalProForEthernet-x86_64.ko
*********************************************
Using output folder /opt/pleora/ebus_sdk/Ubuntu-x86_64/module
Using kernel from folder /lib/modules/4.15.0-65-generic/build
Invoking makefile to build the ebUniversalProForEthernet-x86_64.ko module
make: Entering directory '/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet'
make[1]: Entering directory '/usr/src/linux-headers-4.15.0-65-generic'
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/LFT_Module.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/NET_KMLRXPacket.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/NET_KMLUtil.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLEvent.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLGCCCompiler.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLInit.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLLock.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLMemory.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLMemoryMap.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLNetwork.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLString.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLSystem.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLRWLock.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLTime.o
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLTimer.o
/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLTimer.c: In function ‘OS_TimerCreate’:
/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLTimer.c:61:5: error: implicit declaration of function ‘init_timer’; did you mean ‘init_timers’? [-Werror=implicit-function-declaration]
init_timer( lTimer );
^~~~~~~~~~
init_timers
/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLTimer.c:64:11: error: ‘struct timer_list’ has no member named ‘data’
lTimer->data = ( unsigned long ) aTimer;
^~
/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLTimer.c:70:26: error: assignment from incompatible pointer type [-Werror=incompatible-pointer-types]
lTimer->function = OS_TimerPeriodicInternalFunc;
^
/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLTimer.c:74:26: error: assignment from incompatible pointer type [-Werror=incompatible-pointer-types]
lTimer->function = OS_TimerInternalFunc;
^
cc1: some warnings being treated as errors
scripts/Makefile.build:330: recipe for target '/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLTimer.o' failed
make[2]: *** [/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/OS_KMLTimer.o] Error 1
Makefile:1571: recipe for target '_module_/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet' failed
make[1]: *** [_module_/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet] Error 2
make[1]: Leaving directory '/usr/src/linux-headers-4.15.0-65-generic'
Makefile:28: recipe for target 'all' failed
make: *** [all] Error 2
make: Leaving directory '/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet'
Error: *** Fail to create the module ebUniversalProForEthernet-x86_64.ko ***
Driver build failed, skipping installation.
Setting rp_filter mode to No source validation.
For more information, read the RHEL knowledge note:
https://access.redhat.com/knowledge/solutions/53031
Restarting network stack.
Configuring eBUSd for automatic startup.
Starting eBUS daemon.
The /etc/udev/rules.d/80-drivers-eBUSSDK-28b7.rules rule has been created.
The /etc/udev/rules.d/80-drivers-eBUSSDK-14fb.rules rule has been created.
Installation summary:
set_puregev_env script generation [ OK ]
Update libraries path [ OK ]
eBUS Universal Pro driver build [ FAIL ]
eBUS Universal Pro driver installation [ FAIL ]
set_rp_filter.sh configuration [ OK ]
eBUS daemon installation [ OK ]
Installation complete.
eBUS SDK installed in /opt/pleora/ebus_sdk/Ubuntu-x86_64
Processing triggers for libc-bin (2.27-3ubuntu1) ...
Eu também tentei construir o driver:
miguel@miguel-ubuntu:/opt/pleora/ebus_sdk/Ubuntu-x86_64/module$ sudo ./build.sh --kernel=/usr/src/linux-headers-4.15.0-65
mas recebo o seguinte erro:
*********************************************
Build ebUniversalProForEthernet-x86_64.ko
*********************************************
Using output folder /opt/pleora/ebus_sdk/Ubuntu-x86_64/module
Using kernel from folder /usr/src/linux-headers-4.15.0-65
Invoking makefile to build the ebUniversalProForEthernet-x86_64.ko module
make: Entering directory '/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet'
make[1]: Entering directory '/usr/src/linux-headers-4.15.0-65'
ERROR: Kernel configuration is invalid.
include/generated/autoconf.h or include/config/auto.conf are missing.
Run 'make oldconfig && make prepare' on kernel src to fix it.
WARNING: Symbol version dump ./Module.symvers
is missing; modules will have no dependencies and modversions.
CC [M] /opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/LFT_Module.o
In file included from <command-line>:0:0:
././include/linux/kconfig.h:5:10: fatal error: generated/autoconf.h: No such file or directory
#include <generated/autoconf.h>
^~~~~~~~~~~~~~~~~~~~~~
compilation terminated.
scripts/Makefile.build:330: recipe for target '/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/LFT_Module.o' failed
make[2]: *** [/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet/LFT_Module.o] Error 1
Makefile:1571: recipe for target '_module_/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet' failed
make[1]: *** [_module_/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet] Error 2
make[1]: Leaving directory '/usr/src/linux-headers-4.15.0-65'
Makefile:28: recipe for target 'all' failed
make: *** [all] Error 2
make: Leaving directory '/opt/pleora/ebus_sdk/Ubuntu-x86_64/module/ebUniversalProForEthernet'
Error: *** Fail to create the module ebUniversalProForEthernet-x86_64.ko ***
Desde já, obrigado.
Responder1
Estou me deparando com isso também. O Pleora não forneceu suporte ao kernel na versão 5 posterior 4.14. Você está preso pagando pela versão 6 ou tentando corrigir o módulo do kernel sozinho. Tenho tentado corrigir o módulo do kernel, mas são muitas mudanças e ainda não obtive sucesso.
Responder2
Provavelmente é um problema de versão do kernel. Eu tive o mesmo problema com o SDK do barramento e o Ubuntu 16.04. A solução foi baixar o kernel 4.1.0 de https://kernel.ubuntu.com/~kernel-ppa/mainline/
Baixe os seguintes arquivos:
linux-headers-xxxxxx-generic-xxxxxx_amd64.deb
linux-headers-xxxxxx_all.deb
linux-image-xxxxxx-generic-xxxxxx_amd64.deb
Antes de instalar o outro kernel, obtenha module-init-tools: sudo apt install -y module-init-tools
Em seguida, navegue até a pasta com os arquivos do kernel baixados e instale-os (se não funcionar, basta alterar a ordem em que são instalados):
sudo dpkg -i linux-headers-xxxxxx_all.deb
sudo dpkg -i linux-image-xxxxxx-generic-xxxxxx_amd64.deb
sudo dpkg -i linux-headers-xxxxxx-generic-xxxxxx_amd64.deb
Para inicializar no novo kernel, pressione shift durante a inicialização para entrar no GRUB. Escolha o novo kernel em um submenu e continue a inicialização.
Agora tente instalar novamente o eBUS SDK
