Como evitar que o texto \newenvironment seja colocado em uma única página

Como evitar que o texto \newenvironment seja colocado em uma única página

Estou usando o \newenvironmentcomando pela primeira vez e está causando problemas. Estou usando-o para criar um novo theoremambiente


\documentclass{article}
\usepackage{amsmath, amssymb}
\usepackage{amsthm , amsfonts, latexsym}
\usepackage{tikz}
\usepackage{shadethm}
\usepackage[mathscr]{euscript}
\usepackage{graphics,graphicx}
\usepackage{enumerate}
\usepackage{color}

\theoremstyle{definition} \newshadetheorem{lems}{Lemma}[section]

\newenvironment{lem}[1][]{ \definecolor{shadethmcolor}{HTML}{00FFFF} \begin{lems}[#1]\hspace*{1mm} }{\end{lems}}

Usando este novo theoremambiente estou fazendo uma prova de um lema que precisa de algumas páginas de espaço.


\begin{document}
\begin{lem}
Let $H$ be a connected S-thin hypergraph, and $A \boxtimes B$ and $C \boxtimes D$ be two
decompositions of $H$ with respect to the strong product. Then there exists a decomposition
$$ A_C \boxtimes A_D \boxtimes B_C \boxtimes B_D $$
of $H$ such that $A =  A_C \boxtimes A_D, B= B_C \boxtimes B_D , C= A_C \boxtimes B_C,
D=A_D \boxtimes B_D$.
\begin{proof}
The idea of the proof is by using the PFD of the cartesian skeleton $H^{\Box}$ of $H$  to define four proper factors, such that
each factor has as vertex set the set of one of our desired factors, e.g. $A_C$. Then we define the desired factors of $H$ by defining projections on $H$ where the vertex set is given by the composed factors of the cartesian skeleton and such that the
edges obey the definition of the strong product. Finally via those projections it is shown that $A=A_C \boxtimes A_D$.\

Let $ H_1 \Box H_2 \Box ... \Box H_n $ be the unique PFD of a cartesian skeleton $H^{\Box}$ of $H$ . Let $I_A$ be the subset of the index set $ {1,2,...,n}$ with $V(A)=V(\Box_{i \in I_A} H_i)$ and $I_B, I_C$ and $I_D$ be defined analogously. Furthermore set $$ H_{A,C} = \Box_{i \in I_A \cap I_C} H_i$$ and define $H_{A,D}, H_{B,C}$ and $H_{B,D}$ similarly. Then $$ H^{\Box} = H_{A,C} \Box H_{A,D} \Box H_{B,C} \Box H_{B,D} . $$ It will be convenient to use only four coordinates $(x_1,x_2,x_3,x_4)$ for every vertex $x \in V(G)$ henceforth. Of course it is possible that not all of the intersections $I_A \cap I_C, I_A \cap I_D, I_D \cap I_C$ and $I_B \cap I_D$ are nonempty. Suppose that $I_B \cap I_C = \emptyset$ then $I_A \cap I_D \neq \emptyset$. If in addition $I_A \cap I_C$ were empty, then $I_A = I_D$ and thus $I_B=I_C$, but then would be nothing to prove. \ We can thus assume that all but possibly $I_B \cap I_D$ are nonempty and at least three of the four coordinates are nontrivial, that is to say, there are at least two vertices that differ in the first, second and third coordinates, but it is possible that all vertices have the same fourth coordinate. \ Clearly, for $y=(y_1,y_2,y_3,y_4),$ $$V(A^y) = { (x_1,x_2,y_3,y_4) | x_1 \in V(H_{A,C}), x_2 \in V(H_{A,D}) } $$ $$V(B^y) = { (y_1,y_2,x_3,x_4) | x_3 \in V(H_{B,C}), x_4 \in V(H_{B,D}) } $$ $$V(C^y) = { (x_1,y_2,x_3,y_4) | x_1 \in V(H_{A,C}), x_3 \in V(H_{B,C}) } $$ $$V(D^y) = { (y_1,x_2,y_3,x_4) | x_2 \in V(H_{A,D}), x_4 \in V(H_{B,D}) } $$ are the vertex sets of the $A-,B-,C-$ and $D-$ layers of $H$. \

We now define $A_C$ as $p_1(H)$, namely $V(A_C) = V(H_{A,C})$ and $${x_1^1,...,x_k^1 } \in E(A_C)$$ if and only if there are vertices $ \tilde x_1=(x_1^1,x_1^2,x_1^3,x_1^4),..., \tilde x_k =(x_k^1,x_k^2,x_k^3,x_k^4) \in H \text { such that} $ $$ \exists e \in E(H) : \exists S \subseteq I={2,3,4} : p_1(e) = { x_1^1,...,x_k^1} $$ \begin{itemize}

\item[(i)] $ p_s(e) \subseteq e_s \in E_s , \forall s \in S$ \item[(ii)]$ |e| = |p_s(e)|, \forall s \in S$ \item[(iii)] $|p_i(e)|=1, \forall i \in I \setminus S$ \end{itemize}

It is clear what is meant by $A_D, B_C$ and $B_D$. For the proof of the lemma it suffices to show that $A = A_C \boxtimes A_D$. Recall that $A$ is obtained by projection of $H$ onto the vertex set of $A$. We call this projection $p_A$ and define $p_B,p_C,p_D$ analogously. With our present coordinatization we thus have $$p_A(x_1,x_2,x_3,x_4) = (x_1,x_2,-,-), $$ $$p_B(x_1,x_2,x_3,x_4) = (-,-,x_3,x_4), $$ $$p_C(x_1,x_2,x_3,x_4) = (x_1,-,x_3,-), $$ $$p_D(x_1,x_2,x_3,x_4) = (-,x_2,-,x_4). $$ In order to show that $A=A_C \boxtimes A_D$, it suffices to prove that for $e={\tilde x_1,..., \tilde x_k } \in H$ holds $$ p_A(e) \in A $$ if and only if $$ p_1(e) \in A_C \text{ and either is } e \text{ an edge in }A_D \text{, hence } p_2(e) \subseteq e \in A_D, |e|=|p_2(e)| $$ $$\text{ or not and thus } |p_2(e)|=1 $$ (wlog. we assume that the edge of $A_C$ is of minimal rank, otherwise we could easily add a case to the above definition where the edge of $A_D$ was the minimal one. But for the sake of clarity we omit this case).

Suppose that $ {p_A \tilde x_1,..., p_A \tilde x_k } \subseteq e \in A$. We can assume, wlog., that $\tilde x_1, ... , \tilde x_k $ are chosen such that ${ \tilde x_1 ,... , \tilde x_k } \in E(H).$ But then $ {p_1 \tilde x_1, ... , p_1 \tilde x_k } \in A_C $ and ${p_2 \tilde x_1, ... , p_2 \tilde x_k } \in A_D$ by the definition of $A_C$ and $A_D$. \ On the other hand, suppose that the edge ${ (x_1^1,-,-,-),(x_2^1,-,-,-),...,(x_k^1,-,-,-}$ is in $A_C$ and ${(_,x_1^2,-,-),...,(-,x_t^2,-,-)} $ is in $A_D , t \leq t $. \ Then there are vertices $\tilde x_1, \tilde x_2, ... , \tilde x_k, ... , \tilde x_t$ of the form $$ \tilde x_i = ( x_i^1, x_i^2, x_i^3, x_i^4) $$ with ${ \tilde x_1 , ... , \tilde x_k } \in E(H)$ and ${ \tilde x_1 , ... ,\tilde x_t } \in E(H)$. \ From this we infer that there are edges $$ { (x_1^1,-,x_1^3,-),...,(x_s^1,-,x_s^3,-) } \in E(C) , k \leq s \leq t $$ $$ {(-,x_1^2,-,x_1^4),...,(-,x_r^2,-,x_r^4) } \in E(D), k \leq r \leq t $$ Since $H = C \boxtimes D$ this implies that $$ {(x_1^1,x_1^2,x_1^3,x_1^4),...,(x_s^1,x_s^2,x_s^3,x_s^4) } \in E(H) \text{ where wlog. } s \leq r$$ and hence ${(x_1^1,x_1^2,-,-),...,(x_s^1,x_s^2,-,-) } \subseteq e \in E(A)$. \end{proof} \end{lem} \end{document}

Não é a prova que me incomoda, portanto ninguém precisa verificar para mim;). O problema é que a prova precisa de várias páginas, mas o LaTeX coloca tudo em uma página, o que é obviamente um pouco desvantajoso.

Portanto, eu ficaria feliz se alguém pudesse me dizer como ajustar o ambiente de forma que o conteúdo flua pelas páginas.

Responder1

O comportamento que você está vendo é por causa do shadethmpacote, que admite que não consegue lidar com quebras de página

captura de tela

O shadethmpacote é bastante antigo - a boa notícia é que desde então o pacote extremamente poderoso e fácil de usarmdframedO pacote foi criado por Marco Daniel.

Você pode criar ambientes emoldurados verdadeiramente bonitos com ele e ele lida com quebras de página. Segue um MWE completo, que você pode ajustar conforme necessário – consulte a documentação para obter mais detalhes.

captura de tela

\documentclass{article}
\usepackage{amsmath}
\usepackage{amssymb}
\usepackage{amsthm}
\usepackage{tikz}
\usepackage[framemethod=tikz]{mdframed}
\usepackage{lipsum}

\newmdtheoremenv[outerlinewidth=3,
        innerlinewidth=2,linecolor=gray,
        backgroundcolor=blue!20,%
        innerlinecolor=blue!50,outerlinecolor=red!50,innertopmargin=0pt,%
        splittopskip=\topskip,skipbelow=0pt,%
        ]{lem}{Lemma}[section]


\begin{document}
\begin{lem}
Let $H$ be a connected S-thin hypergraph, and $A \boxtimes B$ and $C \boxtimes D$ be two
decompositions of $H$ with respect to the strong product. Then there exists a decomposition
$$ A_C \boxtimes A_D \boxtimes B_C \boxtimes B_D $$
of $H$ such that $A =  A_C \boxtimes A_D, B= B_C \boxtimes B_D , C= A_C \boxtimes B_C,
D=A_D \boxtimes B_D$.
\mbox{} % needed because you end your lemma with mathematical content
\begin{proof}
 \lipsum
\end{proof}
\end{lem}
\end{document}

Algumas outras notas:

  • Percebi que você estava usando $$...$$para o conteúdo matemático exibido. Isso está desatualizado e você deve usar \[...\], vejaPor que \[... \] é preferível a $$... $$?para uma boa discussão.
  • Também notei que você tinha alguns ambientes matemáticos exibidos consecutivos. Isso também deve ser evitado, e você deve usar um dos ambientes do amsmathpacote, algo como gathertalvez.
