Problema com \renewcommand em LaTeX

Considere o seguinte código:

\documentclass[11pt,twoside,openany]{book}

\usepackage[svgnames,x11names]{xcolor}
\usepackage{wallpaper}
\usepackage{changepage}
\usepackage[explicit]{titlesec}
\usepackage{tikz}
\usetikzlibrary{shapes,positioning}
\usepackage{geometry}
\geometry{
   paperwidth=216mm, paperheight=303mm,
   left=23mm,  %% or inner=23mm
   right=18mm, %% or outer=18mm
   top=23mm, bottom=23mm,
   headheight=\baselineskip,
   headsep=7mm,
   footskip=7mm
}


%% Command to hold chapter illustration image
\newcommand\chapterillustration{}

%% Define how the chapter title is printed
\titleformat{\chapter}{}{}{0pt}{
%% Background image at top of page
\ThisULCornerWallPaper{1}{\chapterillustration}
%% Draw a semi-transparent rectangle across the top
\tikz[overlay,remember picture]
  \fill[LightSalmon1,opacity=.7]
  (current page.north west) rectangle
  ([yshift=-3cm] current page.north east);
  %% Check if on an odd or even page
  \checkoddpage\strictpagecheck
  %% On odd pages, "logo" image at lower right
  %% corner; Chapter number printed near spine
  %% edge (near the left); chapter title printed
  %% near outer edge (near the right).
  \ifoddpage{
    \ThisLRCornerWallPaper{.35}{image3}
    \begin{tikzpicture}[overlay,remember picture]
    \node[anchor=south west,
      xshift=20mm,yshift=-30mm,
      font=\sffamily\bfseries\huge]
      at (current page.north west)
      {\chaptername\ \thechapter};
    \node[fill=Sienna!80!black,text=white,
      font=\Huge\bfseries,
      inner ysep=12pt, inner xsep=20pt,
      rounded rectangle,anchor=east,
      xshift=-20mm,yshift=-30mm]
      at (current page.north east) {#1};
    \end{tikzpicture}
  }
  %% On even pages, "logo" image at lower left
  %% corner; Chapter number printed near outer
  %% edge (near the right); chapter title printed
  %% near spine edge (near the left).
  \else {
    \ThisLLCornerWallPaper{.35}{image3}
    \begin{tikzpicture}[overlay,remember picture]
    \node[anchor=south east,
      xshift=-20mm,yshift=-30mm,
      font=\sffamily\bfseries\huge]
      at (current page.north east)
      {\chaptername\ \thechapter};
    \node[fill=Sienna!80!black,text=white,
      font=\Huge\bfseries,
      inner sep=12pt, inner xsep=20pt,
      rounded rectangle,anchor=west,
      xshift=20mm,yshift=-30mm]
      at ( current page.north west) {#1};
    \end{tikzpicture}
  }
  \fi
}
\titlespacing*{\chapter}{0pt}{0pt}{135mm}


\begin{document}
\renewcommand\chapterillustration{image1}
\chapter{First Chapter}

\renewcommand\chapterillustration{image2}
\chapter{Second Chapter}

\end{document}

Problema: Ao compilar com pdflatex, o PDF de saída contém apenas "image2" - para ambos os títulos de capítulo.

ou seja, a seção de código:

\renewcommand\chapterillustration{image1}
\chapter{First Chapter}

\renewcommand\chapterillustration{image2}
\chapter{Second Chapter}

está produzindo "image2" para ambos os capítulos.

Por favor me ajude com esse problema.

Responder1

Isso é causado pelo comportamento assíncrono do TeX: suas imagens são colocadas quando as páginas são construídas, o que acontece bem após a composição. Se você inserir um \newpagena frente de \renewcommand\chapterillustration{image2}, o problema desaparece.

Responder2

Talvez uma solução mais feia, mas você se livra de \newpage:

Altere as seguintes linhas em seu preâmbulo

%% Command to hold chapter illustration image
\newcommand{\chapterillustration}[1]{%
\expandafter\newcommand\csname chillu\roman{chapter}\endcsname{#1}}

%% Define how the chapter title is printed
\titleformat{\chapter}{}{}{0pt}{
%% Background image at top of page
\ThisULCornerWallPaper{1}{\csname chillu\roman{chapter}\endcsname}

e use-o assim em seu documento:

\chapter{First Chapter}
\chapterillustration{image1}

\chapter{Second Chapter}
\chapterillustration{image2}
