Envie (e empilhe) \marginpar para o topo ou para o final da página

Question 1

Esta solução trata da rotina de saída assíncrona:

As páginas são identificadas por números de páginas absolutos e os números de páginas corretos estão disponíveis na segunda execução do LaTeX usando rótulos.
Cada página recebe duas caixas coletoras que coletam as notas marginais de cima e de baixo. No momento do envio, o número absoluto da página é conhecido e as caixas coletoras da página são exibidas na área "marginpar" da página.
Os registradores de caixa são alocados dinamicamente e gerenciados em um pool. Após o envio da página, seus registros da caixa coletora são liberados e recolocados no pool.
\topskipe \maxdepthsão respeitados pela área “marginpar”.
Muitas notas marginais em uma página são relatadas como \vboxavisos excessivamente completos.
LaTeX \marginparnão é suportado, as notas marginais de diferentes tipos não se conhecem e ficarão felizmente sobrepostas umas às outras.

O documento de exemplo:

\documentclass{article}

\usepackage{atbegshi}
\usepackage{zref-abspage}
\usepackage{picture}

\makeatletter
\providecommand*{\c@zabspage}{\c@abspage}

% * User macros for configuring
%
% \tbmparItemSep is inserted between marginal notes
% \tbmparMiddleSep is inserted between top and bottom marginal notes.

\newcommand*{\tbmparItemSep}{%
  \vspace{1ex minus .5ex}%
  \hrule
  \vspace{1ex minus .5ex}%
}
\newcommand*{\tbmparMiddleSep}{%
  \vspace*{0pt plus 1fil}%
}

% * Debug messages
%
\newcommand*{\tbmparDebug}[1]{%
  \typeout{[tbmpar] #1}%
}

% * Label management to remember absolute page number
%
% \tbmpar@PageByLabel stores and loads absolute page number from
% label and defines \tbmpar@page with absolute page number or
% zero if the label is not yet available.

\newcount\c@tbmpar@item
\c@tbmpar@item\z@

\newcommand*{\tbmpar@PageByLabel}{%
  \global\advance\c@tbmpar@item\@ne
  \zref@labelbyprops{tbmpar\the\c@tbmpar@item}{abspage}%
  \edef\tbmpar@page{%
    \zref@extractdefault{tbmpar\the\c@tbmpar@item}{abspage}{0}%
  }%
  \zref@refused{tbmpar\the\c@tbmpar@item}%
  \tbmparDebug{Item \the\c@tbmpar@item\space on page \tbmpar@page}%
}

% * Box register management

\newcount\c@tbmpar@box
\c@tbmpar@box\z@

\let\tbmpar@boxfreelist\@empty

% Get a new free box register either from the free list or,
% if the free list is empty, allocate a new box register.
\newcommand*{\tbmpar@NextBox}[1]{%
  \@next#1\tbmpar@boxfreelist{%
    \tbmparDebug{Reused box: #1}%
  }{%
    \global\advance\c@tbmpar@box\@ne
    \expandafter\newbox\csname tbmpar@box\the\c@tbmpar@box\endcsname
    \edef#1{\csname tbmpar@box\the\c@tbmpar@box\endcsname}%
    \tbmparDebug{New box: #1}%
  }%
}
% Put free box in free list.
\newcommand*{\tbmpar@FreeBox}[1]{%
  \begingroup
    \let\@elt\relax
    \xdef\tbmpar@boxfreelist{%
      \tbmpar@boxfreelist
      \@elt#1%
    }%
    \tbmparDebug{Free box: #1}%
  \endgroup
}

\newsavebox{\tbmpar@box}

% Each marginpar is put in a box that is initialized as
% parbox/minipage.
\newcommand*{\tbmparBoxSetup}{}
\newcommand{\tbmpar@VBox}[1]{%
  \vbox{%
    \color@begingroup
    \hsize\marginparwidth
    \edef\tbmpar@restore@ifminipage{%
      \if@minipage
        \noexpand\@minipagetrue
      \else
        \noexpand\@minipagefalse
      \fi
    }%
    \@parboxrestore
    \@marginparreset
    \tbmparBoxSetup
    #1%
    \tbmpar@restore@ifminipage
    \color@endgroup
  }%
}

% Macro \tbmpar@marginpar looks for the page, where the margin note
% belongs to, stores the note in a box and appends the box to the
% note collector register of the page.
% Each page is assigned a box collector registers that collect
% the top notes and a register that collect the bottom notes.
% The name of the box register is \tbmpar@<top|bot>box<page>.
\newcommand{\tbmpar@marginpar}[4]{%
  \ifhmode
    \@bsphack
  \fi
  \tbmpar@PageByLabel
  \ifnum\tbmpar@page>\z@
    \setbox\tbmpar@box\tbmpar@VBox{#4}%
    \@ifundefined{tbmpar@#1box\tbmpar@page}{%
      \tbmpar@NextBox\tbmpar@currbox
      \global\expandafter\let
          \csname tbmpar@#1box\tbmpar@page\endcsname
          \tbmpar@currbox
      \global\setbox\tbmpar@currbox=\vbox{%
        \unvbox\tbmpar@box
      }%
    }{%
      \tbmparDebug{Use box: \tbmpar@currbox}%
      \expandafter\let\expandafter\tbmpar@currbox
          \csname tbmpar@#1box\tbmpar@page\endcsname
      \global\setbox\tbmpar@currbox\tbmpar@VBox{%
        \unvbox#2%
        \par
        \begingroup
          \tbmparItemSep
        \endgroup
        \unvbox#3%
      }%
    }%
  \fi
  \ifhmode
    \@esphack
  \fi
}
\newcommand*{\topmarginpar}{%
  \tbmpar@marginpar{top}\tbmpar@currbox\tbmpar@box
}
\newcommand*{\botmarginpar}{%
  \tbmpar@marginpar{bot}\tbmpar@box\tbmpar@currbox
}

% At shipout time we look for the box collector registers of this
% page and set these boxes in the marginpar box with respecting
% \topskip and \maxdepth.
\AtBeginShipout{%
  \AtBeginShipoutUpperLeft{%
    \put(%
      \dimexpr 1in+\oddsidemargin+\textwidth+\marginparsep\relax,%
      -\dimexpr 1in+\topmargin+\headheight+\headsep+\textheight\relax
    ){%
      \begingroup
        \global\let\tbmpar@inuse=N%
        \setbox\tbmpar@box=\tbmpar@VBox{%
          \penalty-\@M
          \edef\tbmpar@tmp{tbmpar@topbox\the\value{zabspage}}%
          \@ifundefined{\tbmpar@tmp}{%
          }{%
            \expandafter\let\expandafter\tbmpar@currbox
                \csname\tbmpar@tmp\endcsname
            \unvbox\tbmpar@currbox
            \tbmpar@FreeBox\tbmpar@currbox
            \global\let\tbmpar@inuse=Y%
          }%
          \endgraf
          \tbmparMiddleSep
          \edef\tbmpar@tmp{tbmpar@botbox\the\value{zabspage}}%
          \@ifundefined{\tbmpar@tmp}{%
          }{%
            \expandafter\let\expandafter\tbmpar@currbox
                \csname\tbmpar@tmp\endcsname
            \unvbox\tbmpar@currbox
            \tbmpar@FreeBox\tbmpar@currbox
            \global\let\tbmpar@inuse=Y%
          }%
        }%
        \ifx\tbmpar@inuse Y%
          \splittopskip=\topskip
          \setbox0=\vsplit\tbmpar@box to\z@
          \boxmaxdepth=\maxdepth
          \setbox\tbmpar@box=\vbox to\textheight{%
            \unvbox\tbmpar@box
          }%
          \box\tbmpar@box
        \fi
      \endgroup
    }%
  }%
}

\makeatother

% Testing

\usepackage[
  a5paper,
  left=10mm,
  right=10mm,
  marginparwidth=40mm,
  includemp,
]{geometry}
\usepackage{microtype}
\usepackage[T1]{fontenc}
\usepackage{lmodern}

\clubpenalty=10000
\flushbottom
\settodepth\maxdepth{g}
\setlength{\fboxsep}{1ex}
\usepackage{lipsum}
\usepackage{color}

\newcommand*{\shortlipsum}[1]{%
  \begingroup
    \long\def\y##1. ##2\@nil{##1.}%
    \edef\x{\csname lipsum@\romannumeral#1\endcsname}%
    \expandafter\y\x. \@nil
  \endgroup
}

\begin{document}
  \topmarginpar{\color{blue}\shortlipsum{1}}
  \lipsum[1]
  \botmarginpar{%
    Show effect of \texttt{\textbackslash maxdepth}:
    $\displaystyle\sum_{\textstyle i=\frac{a}{g}}^\infty i = x$}
  \lipsum[2]
  \topmarginpar{\shortlipsum{3}}%
  \botmarginpar{Second bottom marginal note}%
  \lipsum[3-4]
  \noindent a\botmarginpar{a} b\botmarginpar{b} c \botmarginpar{c} d\\
  e\\f\par
  \topmarginpar{\fbox{\shortlipsum{5}}}
  \lipsum[5]
  Text with footnote and marginal note\footnote{Marginal note X}.
  \topmarginpar{This is marginal note X}
  \lipsum[6]
  \botmarginpar{\shortlipsum{7}}
  \lipsum[7]
\end{document}
