Estou escrevendo um artigo no formato de Avisos Mensais da Royal Astronomical Society (MNRAS). Tenho várias mesas que preciso de paisagismo, pois são muito largas. Eu usei o comando de tabela lateral e, embora a tabela seja paisagística, ela está fortemente voltada para a esquerda, com metade da tabela não visível.
O preâmbulo do meu artigo é este
\documentclass[useAMS,usenatbib]{mn2e}
%\documentclass[a4paper,11pt,twoside]{article} %showframe
% set up sensible margins (same as for cssethesis)
%\usepackage[paper=a4paper,left=30mm,width=150mm,top=25mm,bottom=25mm] {geometry}
%\usepackage{setspace} % Word spacing
%\singlespacing %(or \doublespacing \onehalfspacing)
\usepackage{txfonts}
\usepackage{mathtools} % can add [fleqn]: fleqn argument shifts equations to the left rather than centred
\usepackage{amssymb} % adds math symbols easily
\usepackage[load-configurations=astronomy]{siunitx} % astro symbols made easy. eg: \num{2e-4} \si{\kilo\metre} \SI{2e-4}{\kilo\metre\per\second}
\DeclareSIUnit\parsec{pc}
\DeclareSIUnit\kilo{K}
\DeclareSIUnit\ergs{ergs}
\usepackage[version=3]{mhchem} % chem symbols made easy eg: \ce{H20}
%\numberwithin{equation}{section} %gives eqns as 1.1 in section 1 and 2.1 in section 2 and so on.
\usepackage{graphicx} % Helps with graphics and tables
%\usepackage[width=0.8\textwidth]{caption} % justification=centering,Captions on figures labelfont=bf,font=it,
\usepackage{float}
\usepackage{subfigure}
\usepackage{subcaption} %subcaptions on figures
%\numberwithin{figure}{section}
\usepackage{titlesec}
\titlespacing\section{0pt}{12pt plus 4pt minus 2pt}{6pt plus 2pt minus 2pt}
\titlespacing\subsection{0pt}{12pt plus 4pt minus 2pt}{6pt plus 2pt minus 2pt}
\titlespacing\subsubsection{0pt}{12pt plus 4pt minus 2pt}{6pt plus 2pt minus 2pt}
\usepackage{morefloats}
\usepackage{lscape}
\usepackage{pdflscape}
%\usepackage{afterpage}
%\newcommand\blankpage{%
%\null
%\thispagestyle{empty}%
%\addtocounter{page}{-1}%
%\newpage}
\usepackage{color}
%\usepackage{pdfpages}
\usepackage{perpage} %the perpage package
\MakePerPage{footnote} %the perpage package command
\usepackage [author year, colon, round]{natbib}
%\usepackage{bibtex} % Use the natbib bibliography and citation package (author, year style, with round brackets)
\usepackage{hyperref} % hyperlinks to reference
\usepackage{booktabs}
\usepackage{multirow}
\usepackage{array}
\usepackage{longtable}
\usepackage{tabu}
\usepackage{threeparttable} %table with notes
\usepackage{threeparttablex} %longtable with notes
\usepackage{rotating}
\usepackage{xtab}
\usepackage{multicol}
\usepackage[title,titletoc,toc]{appendix} % \appendix
%\newcommand{\sol}[1]{\odot{#1}} % short code for sun symbol
% {$\mathrm{}$} = Math mode in non-italized form
\newcommand{\textsubscript}[1]{$_\textrm{#1}$} %short code for subscripting
\newcommand{\Ha}{H${\alpha}$} % short code for H-alpha
\newcommand{\HB}{H$\beta$} % short code for H-beta
\newcommand{\EHaHB}{E(H$\alpha$-H$\beta$)} % short code for E(Ha-HB)
\newcommand{\CHa} {C$_{{\textrm{H}\alpha}}$} % short code for CHa
\newcommand{\CHB}{C$_{{\textrm{H}\beta}}$} % short code for CH-beta
\newcommand{\AV}{$\textrm{A}_{\textrm{V}}$} % short code for Av
\newcommand{\Av}{$\textrm{A}_{\textrm{V}}$} % short code for Av
\newcommand{\AvCHB}{A_{\textrm{V}}(\textrm{C}$_{{\textrm{H}\beta}}$)} % short code for Av(CH-beta)
\newcommand{\AvCHa}{A_{\textrm{V}}(\textrm{C}$_{{\textrm{H}\alpha}}$)} % short code for Av(CH-alpha)
\newcommand{\AvE}{A_{\textrm{V}}[\textrm{E}(\textrm{H}$\alpha$-\textrm{H}$\beta$)]} % short code for E(Ha-HB)
\newcommand{\app}[1]{\textup{\textsc{\MakeLowercase{#1}}}}
\newcommand{\comm}[1]{\texttt{#1}}
\title[}
\author[]
\date{Received:}
\begin{document}
\maketitle
\begin{abstract}
.....
\end{abstract}
\begin{keywords}
......
\end{keywords}
\input{./Tables/Table1}
%\include{Appendix}
\bibliographystyle{chicago}
\bibliography{fullbib}
\end{document}
O código da tabela é este:
\begin{sidewaystable*}
\centering
\caption [Table 1]{Table 1}
\label{Table 1}
\begin{threeparttable}
\begin{tabular}{lllllllp{1.5cm}p{1.3cm}p{1.3cm}p{1.3cm}p{1.5cm}l}
\toprule
\textbf{} & \textbf{} & \textbf{} & \textbf{} & \multicolumn{3}{c}{\textbf{CCD Data}} & \multicolumn{4}{c}{\textbf{Aperture Radii}} & \multicolumn{2}{c}{\textbf{Source Intensity}} \\
\cmidrule(lr){5-7}
\cmidrule(lr){8-11}
\cmidrule(lr){12-13}
\textbf{PN Name} & \textbf{RA} & \textbf{Dec} & \textbf{Run} & \textbf{CCD} & \textbf{X} & \textbf{Y} & \textbf{Shape} & \textbf{Centroid} & \textbf{Inner Sky} & \textbf{Outer Sky} & \textbf{intensity (counts)} & \textbf{unc.} \\
(1) & (2) & (3) & (4) & (5) & (6) & (7) & (8) & (9) & (10) & (11) & (12) & (13)\\
\midrule
PN G119.64+03.2 & 00:19:09.79 & +65:53:26.00 & 414 153 & 4 & 539 & 743 & C & 4 & 9 & 14 & 1013.10 & 38.87 \\
& & & 414551 & 2 & 1968 & 1612 & & & & & 1050.30 & 43.22 \\
& & & 414554 & 2 & 1061 & 2513 & & & & & 1075.10 & 38.98 \\
PN G121.68+03.6 & 00:38:54.00 & +66:23:49.00 & 417705 & 3 & 1124 & 795 & C & 41 & 47 & 52 & 128616.00 & 1154.20 \\
& & & 418383 & 2 & 1832 & 99 & & & & & 155089.00 & 930.89 \\
& & & 419386 & 2 & - & - & & & & & 157573.00 & 931.57 \\
PN G126.30+02.9 & 01:24:58.60 & +65:38:36.00 & 367533 & 3 & 1305 & 249 & C & 24 & 27 & 30 & 326749.00 & 1057.60 \\
& & & 703469 & 4 & 354 & 3756 & & & & & 317515.00 & 1069.20 \\
& & & 703472 & 2 & 1562 & 1191 & & & & & 309835.00 & 1017.60 \\
PN G126.60+01.3 & 01:25:07.90 & +63:56:53.00 & 367778 & 4 & 827.00 & 612.00 & E & Maj=60 & 67 & 75 & 292152.00 & 1253.30 \\
& & & 367781 & 4 & 1744.90 & 1521.70 & Rot=+28$\si{\degree}$ & Min=34 & & & 276108.00 & 1770.50 \\
& & & 367894 & 2 & 1098.60 & 2801.60 & Rot=-46$\si{\degree}$ & & 60 & 70 & 288338.00 & 2313.70 \\
& & & 367897 & 2 & 173.80 & 3708.60 & & & & & 289128.00 & 2314.60 \\
\bottomrule
\end{tabular}
\begin{tablenotes}
\footnotesize
\item .......
\end{tablenotes}
\end{threeparttable}
\end{sidewaystable*}
Eu tentei comandos de rotação e \hspace, \vspacemas \newgeometry{margin=1cm}nada parece funcionar. Como faço para corrigir isso?
Responder1
Parece que a mn2eclasse do documento está enfrentando alguns conflitos com o rotatingpacote (que fornece o sidewaystableambiente) ou possivelmente com o graphicxpacote carregado pelo rotatingpacote.
Uma solução alternativa - não uma correção completa, com certeza - consiste em inserir a instrução
\RequirePackage{rotating}
antesa \documentclassinstrução.
Com esta configuração, sua tabela no documento de amostra é posicionada corretamente.
