Problema com mesa lateral

Question

Eu tenho essas tabelas laterais, mas o texto não quebra corretamente dentro das células, aqui está o meu código

\documentclass{article}
\usepackage[T1]{fontenc}
\usepackage[utf8]{inputenc}
\usepackage[margin=2.5cm,a4paper]{geometry}

\usepackage[frenchb]{babel}
\usepackage{rotating,multirow}
\begin{document}

\begin{sidewaystable}
  \centering\small
  \renewcommand{\arraystretch}{1.5}

  \begin{tabular}{|c|c|c|c|c|p{5cm}|p{5cm}|p{5.5cm}|}
  \hline
    \multicolumn{8}{|c|}{\textbf{ANALYSE DE RISQUE}}\\
  \hline
    \multicolumn{8}{|c|}{\textbf{Poste de travail ou machine:}}\\
  \hline
    \multicolumn{4}{|c|}{\textbf{Risque}} & \textbf{Indice} &  \textbf{Situation Dangereuse} &  \textbf{Conséquence} &  \textbf{Mesure Corrective}\\
   \hline
%%%%%%%%%%%%%%%%%%% Part to duplicate if needed %%%%%%%%%%%
   \multicolumn{4}{|c|}{Heavy weight of mother roller} & \multirow{ 2}{*}{} &  \multirow{ 2}{5cm}{The heavy mother coil is lifted to a high level and has the possibility of falling.} &  \multirow{ 2}{5cm}{The operator working in the moving range may be hited or crushed by the falling mother coil. } &   \multirow{ 2}{5.5cm}{Install a laser sensor to detect the operator moving around the crane and lower the mother coil if it detects someone is approaching this area.}\\
   \cline{1-4}
   G:1 & F:1 & O:1 & P:1 & & & & \\
   \hline
%%%%%%%%%%%%%%%%%%% Part to duplicate if needed %%%%%%%%%%%
   \multicolumn{4}{|c|}{} & \multirow{ 2}{*}{} &  \multirow{ 2}{*}{} &  \multirow{ 2}{*}{} &   \multirow{ 2}{*}{}\\
   \cline{1-4}
   G: & F: & O: & P: & & & & \\
   \hline
%%%%%%%%%%%%%%%%%%% Part to duplicate if needed %%%%%%%%%%%
   \multicolumn{4}{|c|}{} & \multirow{ 2}{*}{} &  \multirow{ 2}{*}{} &  \multirow{ 2}{*}{} &   \multirow{ 2}{*}{}\\
   \cline{1-4}
   G: & F: & O: & P: & & & & \\
   \hline
%%%%%%%%%%%%%%%%%%% Part to duplicate if needed %%%%%%%%%%%
   \multicolumn{4}{|c|}{} & \multirow{ 2}{*}{} &  \multirow{ 2}{*}{} &  \multirow{ 2}{*}{} &   \multirow{ 2}{*}{}\\
   \cline{1-4}
   G: & F: & O: & P: & & & & \\
   \hline
   %%%%%%%%%%%%%%%%%%% Part to duplicate if needed %%%%%%%%%%%
   \multicolumn{4}{|c|}{} & \multirow{ 2}{*}{} &  \multirow{ 2}{*}{} &  \multirow{ 2}{*}{} &   \multirow{ 2}{*}{}\\
   \cline{1-4}
   G: & F: & O: & P: & & & & \\
   \hline
   %%%%%%%%%%%%%%%%%%% Part to duplicate if needed %%%%%%%%%%%
   \multicolumn{4}{|c|}{} & \multirow{ 2}{*}{} &  \multirow{ 2}{*}{} &  \multirow{ 2}{*}{} &   \multirow{ 2}{*}{}\\
   \cline{1-4}
   G: & F: & O: & P: & & & & \\
   \hline
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
  \end{tabular}

\end{sidewaystable}
\end{document}

E eu entendo isso A largura está boa porque eu a defino em múltiplas linhas, mas por que a altura não muda? Saúde

Answer 1

Eu suspeito que você gostaria de ter a seguinte aparência de mesa:

O problema é que a altura do texto em células com várias linhas é maior do que a correspondente das linhas, que se estendem por multirow. Como uma solução (rude) é aumentar uma desta linha. Com a suposição de que multirowas células terão no máximo 4 linhas de texto, defino dois novos comandos (para configuração conveniente da tabela):

• \newcommand\mch[1]{\multicolumn{4}{@{\rule[-1.2em]{0pt}{3.2em}}|c|}{#1}}, que é usado para a linha superior superior para a quantidade de texto de 4 linhas na multirowcélula (veja o código completo) e

• \newcommand\mrh[2][0ex]{\multirow{2}*[#1]{\begin{minipage}{\hsize}#2\end{minipage}}}, que permitem o ajuste manual do texto no multirowambiente

O código completo para parte relevante da tabela:

\documentclass{article}
\usepackage[T1]{fontenc}
\usepackage[utf8]{inputenc}
\usepackage[margin=2.5cm,a4paper]{geometry}

\usepackage[frenchb]{babel}
\usepackage{makecell,multirow}
\usepackage{rotating}


\newcommand\mch[1]{\multicolumn{4}{@{\rule[-1.2em]{0pt}{3.2em}}|c|}{#1}}
\newcommand\mrh[2][0ex]{\multirow{2}*[#1]{\begin{minipage}{\hsize}#2\end{minipage}}}
\begin{document}

\begin{sidewaystable}
  \centering\small
  \renewcommand{\arraystretch}{1.5}

  \begin{tabular}{|c|c|c|c|c|p{5cm}|p{5cm}|p{5.5cm}|}
  \hline
    \multicolumn{8}{|c|}{\textbf{ANALYSE DE RISQUE}}\\
  \hline
    \multicolumn{8}{|c|}{\textbf{Poste de travail ou machine:}}\\
  \hline
    \multicolumn{4}{|c|}{\textbf{Risque}} & \textbf{Indice} &  \textbf{Situation Dangereuse} &  \textbf{Conséquence} &  \textbf{Mesure Corrective}\\
   \hline
%%%%%%%%%%%%%%%%%%% Part to duplicate if needed %%%%%%%%%%%
\mch{Heavy weight of mother roller}
    &   \mrh{}
        &   \mrh[1.5ex]{The heavy mother coil is lifted to a high level and has the possibility of falling.}
            &   \mrh[1.5ex]{The operator working in the moving range may be hited or crushed by the falling mother coil. }
                &   \mrh[1ex]{
                Install a laser sensor to detect the operator moving around the crane and lower the mother coil if it detects someone is approaching this area.
                         }
                         \\
   \cline{1-4}
   G:1 & F:1 & O:1 & P:1 & & & & \\
   \hline
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
  \end{tabular}
