Estou tentando reproduzir fielmente a primeira seção do padrão da Polícia do Reino UnidoFormulário de declaração de testemunha, conhecido como MG11.
Estou tendo dificuldade em alinhar as caixas da primeira página com a caixa que deveria conter o corpo da declaração.
Mais importante ainda, as caixas permitem que o texto percorra várias páginas, mas isso faz com que não tenham linhas na parte inferior ou superior das páginas onde ele quebra. Isso também se sobrepõe ao cabeçalho da Declaração da Testemunha nas páginas subsequentes.
Aqui está o código LaTeX que gera meu pdf até agora:
\documentclass{article}
\usepackage{dashrule}
\usepackage{listings}
\usepackage{float}
\usepackage{scrpage2}
\usepackage{mdframed}
\usepackage[english]{babel}
\usepackage{blindtext}
\usepackage{helvet}
\renewcommand{\familydefault}{\sfdefault}
\pagestyle{scrheadings}
\clearscrheadfoot
\usepackage{lastpage}
\usepackage[margin=0.5in]{geometry}
\ihead{}
\chead{\\\framebox[1.1\width]{RESTRICTED}\\ \LARGE{Witness Statement}\\ \footnotesize{Criminal Procedure Rules, r 27.2; Criminal Justice Act 1967, s. 9; Magistrate's Courts Act 1980, s. 5B}\\}
\ohead{\\\framebox[1.1\width]{MG11} \vspace*{0.1 in} \\Page \textbf{\pagemark} of \pageref{LastPage}}
\ifoot{Signature: \hdashrule{26em}{1pt}{1.5mm} Signature Witnessed by: \textbf{N/A}}
\cfoot{}
\ofoot{}
\setlength\parindent{0pt} % Removes all indentation from paragraphs
\begin{document}
% URN boxes drawn using table
\begin{table}
\vspace*{0.35 in}
\begin{flushright}
\begin{tabular}{llllll}
\cline{2-5}
URN:& \multicolumn{1}{|@{\hspace{2em}}l|@{\hspace{2em}}}{} & \multicolumn{1}{l|@{\hspace{2em}}}{} & \multicolumn{1}{l|@{\hspace{2em}}}{} & \multicolumn{1}{l|}{} &\\ \cline{2-5}
\end{tabular}
\end{flushright}
\end{table}
% Front page boxes drawn inside fboxes
\fbox{
\parbox{\textwidth}{
Statement of: \textbf{John Smith} \\ \\
Age of witness: \textbf{Over 18} {\hspace{23em}} Occupation: \textbf{Paper-pusher}\\
This statement (consisting of \pageref{LastPage} pages each signed by me) is true to the best of my knowledge and belief and I make it knowing that, if it is tendered in evidence, I shall be liable to prosecution if I have wilfully stated in it, anything which I know to be false, or do not believe to be true.
}
}
\fbox{
\parbox[b][2em]{\textwidth}{
Signature: \hdashrule{29em}{1pt}{1.5mm} Date: \textbf{\today}
}
}
% mdframed box for main textbox
\global\mdfdefinestyle{exampledefault}{%
linecolor=black,linewidth=1pt,%
leftmargin=0cm,rightmargin=0cm
}
\begin{mdframed}[style=exampledefault]
\Blindtext[14]
\end{mdframed}
\end{document}
Alguém poderia aconselhar como consertar as caixas para que copiem as encontradas no link de referência?
Muito obrigado!
Responder1
Um primeiro teste com tcolorbox- O principal problema são as headerconfigurações do rodapé e, levando à sobreposição.
\documentclass{article}
\usepackage{dashrule}
\usepackage[english]{babel}
\usepackage{blindtext}
\usepackage{helvet}
\renewcommand{\familydefault}{\sfdefault}
\usepackage[most]{tcolorbox}
\usepackage{fancyhdr}
\usepackage{lastpage}
\usepackage[margin=0.5in,top=1.25in,headheight=45pt,bottom=1in]{geometry}
\fancyhf{}
\renewcommand{\headrulewidth}{0pt}
\fancyhead[C]{\begin{tabular}[b]{c}\fbox{RESTRICTED}\tabularnewline\tabularnewline\multicolumn{1}{c}{\LARGE Witness Statement}\tabularnewline\multicolumn{1}{c}{\footnotesize Criminal Procedure Rules, r 27.2; Criminal Justice Act 1967, s. 9; Magistrate's Courts Act 1980, s. 5B}\end{tabular}}
\fancyhead[RO]{\begin{tabular}[b]{|p{1.1cm}|}\hline MG11\tabularnewline\hline\multicolumn{1}{c}{}\tabularnewline \multicolumn{1}{l}{Page \textbf{\thepage} of \pageref{LastPage}}\end{tabular}}
\fancyfoot[L]{Signature: \hdashrule{26em}{1pt}{1.5mm} Signature Witnessed by: \textbf{N/A}}
\pagestyle{fancy}
\setlength\parindent{0pt} % Removes all indentation from paragraphs
\newlength{\effectiveboxwidth}
\setlength{\effectiveboxwidth}{\dimexpr\textwidth-2\fboxsep-2\fboxrule}
\begin{document}
\hfill\begin{tabular}{llllll}
\cline{2-5}
URN:& \multicolumn{1}{|@{\hspace{2em}}l|@{\hspace{2em}}}{} & \multicolumn{1}{l|@{\hspace{2em}}}{} & \multicolumn{1}{l|@{\hspace{2em}}}{} & \multicolumn{1}{l|}{} &\\ \cline{2-5}
\end{tabular}
\tcbset{witness/.style={colframe=black,sharp corners,enhanced jigsaw, colback=white}} % Common settings
\begin{tcolorbox}[after={},witness]
Statement of: \textbf{John Smith} \par
\vskip\baselineskip
Age of witness: \textbf{Over 18} \hfill Occupation: \textbf{Paper-pusher}\\
This statement (consisting of \pageref{LastPage} pages each signed by me) is true to the best of my knowledge and belief and I make it knowing that, if it is tendered in evidence, I shall be liable to prosecution if I have wilfully stated in it, anything which I know to be false, or do not believe to be true.
\end{tcolorbox}
\begin{tcolorbox}[nobeforeafter,witness]
Signature: \hdashrule{29em}{1pt}{1.5mm} Date: \textbf{\today}
\end{tcolorbox}
\begin{tcolorbox}[witness,breakable,boxrule=1pt,toprule at break=1pt,extras={toprule at break=1pt} ]
\Blindtext[14]
\end{tcolorbox}
\end{document}
Os espaçamentos individuais devem ser adaptados. Não tenho o formulário original em mãos.
