Alinhamento: tcolorbox na enumeração

Como posso alinhar o marcador da enumeração na parte superior do tcolorbox?

insira a descrição da imagem aqui

MWE

\documentclass[parskip=full]{scrartcl}

\usepackage{lipsum}

\usepackage{tikz}
\usepackage[most]{tcolorbox}

\begin{document}

\lipsum[1]

\begin{itemize}
\item Lorem ipsum
\item
  \begin{tikzpicture}[scale=(\linewidth-\baselineskip)/20cm,baseline={([yshift=-1em] current bounding box.north)}]
  \draw[step=1,help lines,black!20] (-0.95,-0.95) grid (8.95,8.95);
  \draw[thick,->] (-1,0) -- (9,0) node[pos=0.97,below] {$x$};
  \draw[thick,->] (0,-1) -- (0,9) node[pos=0.97,left] {$y$};
  \foreach \x/\xtext in {1,2,...,8}
      \draw[shift={(\x,0)}] (0pt,4pt) -- (0pt,-4pt) node[below] {$\xtext$};
  \foreach \y/\ytext in {1,2,...,8}
      \draw[shift={(0,\y)}] (4pt,0pt) -- (-4pt,0pt) node[left] {$\ytext$};
  \node[below right] at (0,0) {0};
  \end{tikzpicture}
\item
  \tcbsidebyside[sidebyside adapt=left, blanker, sidebyside gap=1cm,
                 sidebyside align=top seam]{%
  \begin{tikzpicture}[scale=\linewidth/20cm, baseline=(current bounding box.north)]
    \draw[step=1,help lines,black!20] (-4.95,-3.45) grid (4.95,3.45);
    \draw[thick] (-2.5,0) ellipse [x radius=2.25, y radius=3.4];
    \draw[thick] (2.5,0) ellipse [x radius=2.25, y radius=3.4];
  \end{tikzpicture}%
  }{Stet clita kasd gubergren, no sea takimata sanctus est Lorem ipsum dolor sit amet.
  Stet clita kasd gubergren, no sea takimata sanctus est Lorem ipsum dolor sit amet.}
\end{itemize}

\end{document}

Responder1

Inicialmente tcolorboxos es estão alinhados na parte inferior, ou seja, box align=bottomestá definido, mas aqui, ele deve estar alinhado na parte superior, então use box align=topnas opções do \tcbsidebyside.

\documentclass[parskip=full]{scrartcl}

\usepackage{lipsum}

\usepackage{tikz}
\usepackage[most]{tcolorbox}

\begin{document}

\lipsum[1]

\begin{itemize}
\item Lorem ipsum
\item
  \begin{tikzpicture}[scale=(\linewidth-\baselineskip)/20cm,baseline={([yshift=-1em] current bounding box.north)}]
  \draw[step=1,help lines,black!20] (-0.95,-0.95) grid (8.95,8.95);
  \draw[thick,->] (-1,0) -- (9,0) node[pos=0.97,below] {$x$};
  \draw[thick,->] (0,-1) -- (0,9) node[pos=0.97,left] {$y$};
  \foreach \x/\xtext in {1,2,...,8}
      \draw[shift={(\x,0)}] (0pt,4pt) -- (0pt,-4pt) node[below] {$\xtext$};
  \foreach \y/\ytext in {1,2,...,8}
      \draw[shift={(0,\y)}] (4pt,0pt) -- (-4pt,0pt) node[left] {$\ytext$};
  \node[below right] at (0,0) {0};
  \end{tikzpicture}
\item
  \tcbsidebyside[box align=top,sidebyside adapt=left, blanker, sidebyside gap=1cm,
                 sidebyside align=top seam]{%
  \begin{tikzpicture}[scale=\linewidth/20cm, baseline=(current bounding box.north)]
    \draw[step=1,help lines,black!20] (-4.95,-3.45) grid (4.95,3.45);
    \draw[thick] (-2.5,0) ellipse [x radius=2.25, y radius=3.4];
    \draw[thick] (2.5,0) ellipse [x radius=2.25, y radius=3.4];
  \end{tikzpicture}%
  }{Stet clita kasd gubergren, no sea takimata sanctus est Lorem ipsum dolor sit amet.
  Stet clita kasd gubergren, no sea takimata sanctus est Lorem ipsum dolor sit amet.}
\end{itemize}

\end{document}

insira a descrição da imagem aqui

Atualizar

\documentclass[parskip=full]{scrartcl}

\usepackage{lipsum}

\usepackage{tikz}
\usepackage[most]{tcolorbox}

\begin{document}

\lipsum[1]

\begin{itemize}
\item Lorem ipsum
\item
  \begin{tikzpicture}[scale=(\linewidth-\baselineskip)/20cm,baseline={([yshift=-1em] current bounding box.north)}]
  \draw[step=1,help lines,black!20] (-0.95,-0.95) grid (8.95,8.95);
  \draw[thick,->] (-1,0) -- (9,0) node[pos=0.97,below] {$x$};
  \draw[thick,->] (0,-1) -- (0,9) node[pos=0.97,left] {$y$};
  \foreach \x/\xtext in {1,2,...,8}
      \draw[shift={(\x,0)}] (0pt,4pt) -- (0pt,-4pt) node[below] {$\xtext$};
  \foreach \y/\ytext in {1,2,...,8}
      \draw[shift={(0,\y)}] (4pt,0pt) -- (-4pt,0pt) node[left] {$\ytext$};
  \node[below right] at (0,0) {0};
  \end{tikzpicture}
\item
  \makeatletter
  \tcbsidebyside[baseline={\tcb@height-2\kvtcb@boxsep+\baselineskip-2\lineskip}, sidebyside adapt=left, blanker, sidebyside gap=1cm,
                 sidebyside align=top seam]{%
  \begin{tikzpicture}[scale=\linewidth/20cm, baseline=(current bounding box.north)]
    \draw[step=1,help lines,black!20] (-4.95,-3.45) grid (4.95,3.45);
    \draw[thick] (-2.5,0) ellipse [x radius=2.25, y radius=3.4];
    \draw[thick] (2.5,0) ellipse [x radius=2.25, y radius=3.4];
  \end{tikzpicture}%
  }{Stet clita kasd gubergren, no sea takimata sanctus est Lorem ipsum dolor sit amet.
  Stet clita kasd gubergren, no sea takimata sanctus est Lorem ipsum dolor sit amet.}
\makeatother
\end{itemize}

\end{document}
