A listagem está confusa com o texto da segunda coluna

Eu tenho a seguinte lista longa. Usei um adjustboxpara ajustar as linhas e adicionei [float=*]às propriedades da listagem para encaixá-la em duas colunas. estou usandoessemodelo que é um artigo baseado em duas colunas. O problema é mostrado na foto abaixo. Como evitar que isso aconteça?

MWE

   \documentclass{comjnl}

    \usepackage{lipsum}
\usepackage{listings}
\usepackage{adjustbox}
\usepackage{url}
\usepackage{amsmath}
\usepackage{cuted}
\usepackage{hyperref}

\shortauthors{jd}

\begin{document}

\lipsum[50]
\lstset{
frame = single}
\begin{lstlisting}[caption={Regular expression used to extract links within HTML code of Web pages},label=Pattern,linewidth=12cm]

"https?://(?:www\\.)?[^\\n<>\"]+(?:\"[^<]*>([^<]*))?"

\end{lstlisting}
\lipsum[50]
       \begin{strip}
    \centering
\centering
          \adjustbox{width=\textwidth, frame}{

    \begin{lstlisting}[caption={A demonstration of a hierarchical XML file used in this experiment to evaluate our framework.},label=Layers,linewidth=20cm][float=*]
    <?xml version="1.0" encoding="UTF-8"?>
    <crawledURLs>
       <URL adr="http://www.cs.tsinghua.edu.cn/publish/csen/index.html" id="0" info="">
         <URL adr="http://www.tsinghua.edu.cn title=" id="1" info=""/>
        -<URL adr="http://ss.cs.tsinghua.edu.cn" id="2" info="2017 Deep Learning Summer School">
          <url ADR="http://fonts.googleapis.com/css?family=Source+Sans+Pro:300,400,700,300italic,400italic,700italic" ID="0" INFO=""/>
          <url ADR="http://fontawesome.io/examples/ --" ID="1" INFO=""/>
          <url ADR="http://www.cs.tsinghua.edu.cn/publish/csen/index.html" ID="2" INFO=""/>
          <url ADR="http://www.tsinghua.edu.cn/publish/newthuen/newthuen_cnt/about-th/about-1.html" ID="3" INFO=""/>
        </URL>
        -<URL adr="http://thu-cmu.cs.tsinghua.edu.cn" id="3" info="Tsinghua-CMU Double Master Degree Progra...">
          <url ADR="http://tv.tsinghua.edu.cn/folder1/folder20/2011/04/2011-04-215.html" ID="1" INFO=""/>
          <url ADR="http://tv.tsinghua.edu.cn/folder1/folder20/2011/04/2011-04-215.html" ID="2" INFO="Tsinghua University Introduction"/>
          <url ADR="http://www.tudou.com/programs/view/guyM0hdQNi4/?phd=99" ID="3" INFO=""/>
          <url ADR="http://tv.tsinghua.edu.cn/folder1/folder20/2011/04/2011-04-215.html" ID="4" INFO="Campus Tour"/>
          <url ADR="http://www.cs.tsinghua.edu.cn/" ID="5" INFO="DCST"/>
          <url ADR="http://www.cmu.edu/index.shtml" ID="6" INFO="Carnegie Mellon University"/>
          <url ADR="http://www.cs.tsinghua.edu.cn/" ID="7" INFO="Tsinghua CS Department"/>
          <url ADR="http://www.cmu.edu/index.shtml" ID="8" INFO="CMU"/>
          <url ADR="http://www.tsinghua.edu.cn/publish/th/index.html" ID="9" INFO="Tsinghua University"/>
         </URL>
        -<URL adr="http://ac.cs.tsinghua.edu.cn" id="4" info="Advanced Computing Master Program">
          <url ADR="https://fonts.googleapis.com/icon?family=Material+Icons" ID="0" INFO=""/>
          <url ADR="http://gradadmission.tsinghua.edu.cn" ID="1" INFO="Apply Now"/>
          <url ADR="http://gradadmission.tsinghua.edu.cn" ID="2" INFO="Apply Now"/>
          <url ADR="http://gradadmission.tsinghua.edu.cn" ID="3" INFO="Apply"/>
          <url ADR="http://clem109.com" ID="4" INFO="clem109"/>
         </URL>
         <URL adr="http://www.csai.tsinghua.edu.cn/homepage.shtm" id="5" info="State Key Lab of Intelligence Techonoly ..."/>
         <URL adr="http://media.cs.tsinghua.edu.cn/en/" id="6" info="Institute of HCI & Media Integration"/>
        -<URL adr="http://soft.cs.tsinghua.edu.cn/English/index.html" id="7" info="Institute of Computer Software">
          <url ADR="http://dbgroup.cs.tsinghua.edu.cn" ID="1" INFO="Data Engineering"/>
          <url ADR="http://keg.cs.tsinghua.edu.cn" ID="2" INFO="Knowledge Engineering"/>
          <url ADR="http://166.111.68.91" ID="3" INFO="Design Automation of Computer and VLSI Circuits"/>
          <url ADR="http://vis.cs.tsinghua.edu.cn" ID="4" INFO="Visualization and Computer Graphics"/>
          <url ADR="http://soft.cs.tsinghua.edu.cn/soft/" ID="5" INFO="Software Engineering and System Software"/>
          <url ADR="http://dbgroup.cs.tsinghua.edu.cn" ID="6" INFO="Data Engineering"/>
          <url ADR="http://keg.cs.tsinghua.edu.cn" ID="7" INFO="Knowledge Engineering"/>
          <url ADR="http://166.111.68.91" ID="8" INFO="Design Automation of Computer and VLSI Circuit"/>
          <url ADR="http://vis.cs.tsinghua.edu.cn" ID="9" INFO="Visualization Technology and Computer Graphics"/>
        </URL>
        <URL adr="http://network.cs.tsinghua.edu.cn" id="8" info="Institute of Computer Networks"/>
       </URL>
     </crawledURLs>
    \end{lstlisting}
     }
\end{strip}

\lipsum[50]
\lipsum[50]
\lipsum[50]
\lipsum[50]
\lipsum[50]
    \end{document}

insira a descrição da imagem aqui

EDITAR

Com base na resposta fornecida abaixo, o resultado será assim. Esse é o objetivo de usar o Adjustbox para permitir que a listagem seja ajustada em uma caixa ~!

insira a descrição da imagem aqui

EDITAR 2

Quando substituo a resposta de Zarko pelo código do meu projeto original, a caixa de ajuste parece ser renderizada conforme abaixo:

insira a descrição da imagem aqui

EDITAR 3 Verifiquei meu projeto original e percebi que o problema é causado pelo fato de ter outra listagem antes dele. Editei o MWE e adicionei a primeira listagem a ele. A compilação do novo MWE resultará no seguinte instantâneo:

insira a descrição da imagem aqui

Responder1

Não há necessidade \adjustbox, float=*deveria estar na definição de lstlisting. É um grande float, então o LaTeX o envia para uma página própria. Usei o floatbarrier apenas para mostrar que é um flutuador flutuante.

\documentclass{comjnl}
\usepackage{lipsum}
\usepackage{listings}
\usepackage{placeins}
%\usepackage{adjustbox}
\usepackage{url}
\usepackage{amsmath}
\usepackage{hyperref}

\shortauthors{jd}
\begin{document}

\lipsum

\lipsum[1-3]



\lstset{frame = single,
        language=XML,
        framexleftmargin=10pt,
        basicstyle=\footnotesize\ttfamily,
        breaklines=true}


\begin{lstlisting}[caption={A demonstration of a hierarchical XML file used in this experiment to evaluate our framework.},label=Layers,float=*]
   % <?xml version="1.0" encoding="UTF-8"?>
    <crawledURLs>
       <URL adr="http://www.cs.tsinghua.edu.cn/publish/csen/index.html" id="0" info="">
         <URL adr="http://www.tsinghua.edu.cn title=" id="1" info=""/>
        -<URL adr="http://ss.cs.tsinghua.edu.cn" id="2" info="2017 Deep Learning Summer School">
          <url ADR="http://fonts.googleapis.com/css?family=Source+Sans+Pro:300,400,700,300italic,400italic,700italic" ID="0" INFO=""/>
          <url ADR="http://fontawesome.io/examples/ --" ID="1" INFO=""/>
          <url ADR="http://www.cs.tsinghua.edu.cn/publish/csen/index.html" ID="2" INFO=""/>
          <url ADR="http://www.tsinghua.edu.cn/publish/newthuen/newthuen_cnt/about-th/about-1.html" ID="3" INFO=""/>
        </URL>
        -<URL adr="http://thu-cmu.cs.tsinghua.edu.cn" id="3" info="Tsinghua-CMU Double Master Degree Progra...">
          <url ADR="http://tv.tsinghua.edu.cn/folder1/folder20/2011/04/2011-04-215.html" ID="1" INFO=""/>
          <url ADR="http://tv.tsinghua.edu.cn/folder1/folder20/2011/04/2011-04-215.html" ID="2" INFO="Tsinghua University Introduction"/>
          <url ADR="http://www.tudou.com/programs/view/guyM0hdQNi4/?phd=99" ID="3" INFO=""/>
          <url ADR="http://tv.tsinghua.edu.cn/folder1/folder20/2011/04/2011-04-215.html" ID="4" INFO="Campus Tour"/>
          <url ADR="http://www.cs.tsinghua.edu.cn/" ID="5" INFO="DCST"/>
          <url ADR="http://www.cmu.edu/index.shtml" ID="6" INFO="Carnegie Mellon University"/>
          <url ADR="http://www.cs.tsinghua.edu.cn/" ID="7" INFO="Tsinghua CS Department"/>
          <url ADR="http://www.cmu.edu/index.shtml" ID="8" INFO="CMU"/>
          <url ADR="http://www.tsinghua.edu.cn/publish/th/index.html" ID="9" INFO="Tsinghua University"/>
         </URL>
        -<URL adr="http://ac.cs.tsinghua.edu.cn" id="4" info="Advanced Computing Master Program">
          <url ADR="https://fonts.googleapis.com/icon?family=Material+Icons" ID="0" INFO=""/>
          <url ADR="http://gradadmission.tsinghua.edu.cn" ID="1" INFO="Apply Now"/>
          <url ADR="http://gradadmission.tsinghua.edu.cn" ID="2" INFO="Apply Now"/>
          <url ADR="http://gradadmission.tsinghua.edu.cn" ID="3" INFO="Apply"/>
          <url ADR="http://clem109.com" ID="4" INFO="clem109"/>
         </URL>
         <URL adr="http://www.csai.tsinghua.edu.cn/homepage.shtm" id="5" info="State Key Lab of Intelligence Techonoly ..."/>
         <URL adr="http://media.cs.tsinghua.edu.cn/en/" id="6" info="Institute of HCI & Media Integration"/>
        -<URL adr="http://soft.cs.tsinghua.edu.cn/English/index.html" id="7" info="Institute of Computer Software">
          <url ADR="http://dbgroup.cs.tsinghua.edu.cn" ID="1" INFO="Data Engineering"/>
          <url ADR="http://keg.cs.tsinghua.edu.cn" ID="2" INFO="Knowledge Engineering"/>
          <url ADR="http://166.111.68.91" ID="3" INFO="Design Automation of Computer and VLSI Circuits"/>
          <url ADR="http://vis.cs.tsinghua.edu.cn" ID="4" INFO="Visualization and Computer Graphics"/>
          <url ADR="http://soft.cs.tsinghua.edu.cn/soft/" ID="5" INFO="Software Engineering and System Software"/>
          <url ADR="http://dbgroup.cs.tsinghua.edu.cn" ID="6" INFO="Data Engineering"/>
          <url ADR="http://keg.cs.tsinghua.edu.cn" ID="7" INFO="Knowledge Engineering"/>
          <url ADR="http://166.111.68.91" ID="8" INFO="Design Automation of Computer and VLSI Circuit"/>
          <url ADR="http://vis.cs.tsinghua.edu.cn" ID="9" INFO="Visualization Technology and Computer Graphics"/>
        </URL>
        <URL adr="http://network.cs.tsinghua.edu.cn" id="8" info="Institute of Computer Networks"/>
       </URL>
     </crawledURLs>
    \end{lstlisting}




\FloatBarrier

\lipsum[50]

\lipsum[50]

\lipsum[50]

\lipsum[50]

\lipsum[50]
\end{document}

EDITAR:

E O RESULTADO insira a descrição da imagem aqui
