Força a quebra de linha, para que cada linha subsequente fique mais longa

Question

Ei pessoal. Nosso instituto tem alguns requisitos especiais de formato, e estou me perguntando se um deles pode ser automatizado por alguma magia inteligente do LaTex:

Uma legenda (também seções e subseções) é definida irregularmente à direita. No entanto, a quebra de linha é feita de tal forma que a linha subsequente é mais longa que a linha anterior (com exceção da última linha, se não for possível mantê-la). No entanto, não se pretende ter a última linha completamente \textwith, mas sim encontrar o primeiro ponto de interrupção que de alguma forma torna a próxima linha um pouco mais longa.

Então aqui estão alguns exemplos:

Esse:

This is an example of a very long caption of a figure which might be too long to stay in one line so that it will automatically jump to a new line.

Deveria ficar assim:

This is an example of a very long caption of a figure which might be too long to stay in one line so that it will automatically jump to a new line instead.

This is an example of a very long caption of a figure which might be too long to stay in one line so that it will automatically jump to a new line instead but now it is even more text.

Estou realmente curioso para saber se esse tipo de formatação pode ser automatizado.

Tudo de bom, Bernté

Answer 1

isso começa com a primeira linha tendo meia largura e depois ficando mais longa... Avisa bastante no log...

\documentclass{article}

\usepackage{shapepar}
\makeatletter

\def\zzshape#1{%
{0}%
{0}b{0}\\%
{0}t{0}{10}\\%
{#1}t{0}{20}\\%
{#1}e{20}%
}
\def\zzzshape{\zzshape\count@}

\def\zz#1{%
\count@=1 %
\loop
\setbox0\hbox{\Shapepar\zzzshape#1\par}%
\ifdim\wd0>\linewidth
\advance\count@\@ne
\repeat
\usebox0
\par}

\begin{document}

\raggedright
\setlength\parskip\bigskipamount

\zz{%
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.}

\zz{%
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.}

\zz{%
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.}

\zz{%
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.}

\end{document}

ou com

\def\zzshape#1{%
{0}%
{0}b{0}\\%
{0}t{0}{17}\\%
{#1}t{0}{20}\\%
{#1}e{20}%
}

você obtém um bloco mais retangular:

Answer 2

Isto tenta criar um triângulo para substituir o espaço extra na última linha. Não totalmente aperfeiçoado, pois gostaria de evitar a hifenização e sempre terminar com uma linha completa por último. É possível corrigir erros pelo uso cuidadoso de \rlap. Por exemplo, exam\rlap{ple}.

Provavelmente isso é incompatível com todos os pacotes que modificam o \@makecaption.

\documentclass[12pt]{article}

\makeatletter
\long\def\@makecaption#1#2{\bgroup
  \vskip\abovecaptionskip
  \sbox\@tempboxa{#1: #2}%
  \ifdim \wd\@tempboxa < \hsize
    \global \@minipagefalse
    \hb@xt@\hsize{\hfil\box\@tempboxa\hfil}%
  \else
    \ifdim \wd\@tempboxa < 2\hsize
      \dimen0=\dimexpr \wd\@tempboxa - \hsize\relax
      \parshape=2 0pt \dimen0 0pt \hsize
      #1: #2\par
    \else
      \count1=\numexpr \wd\@tempboxa/\hsize\relax% number lines
      \dimen0=\dimexpr \count1\hsize - \wd\@tempboxa\relax% extra space
      \ifdim \dimen0 < 0pt
        \advance \count1 by 1
        \advance \dimen0 by \hsize
      \fi
      \count2=\numexpr \count1-1\relax
      \dimen1=\dimexpr 2\dimen0/\count1/\count2\relax% increment
      \ifdim\dimen1 < 2em\relax
        \count2=\count1
        \advance\count1 by 1
        \advance\dimen0 by \hsize
        \dimen1=\dimexpr 2\dimen0/\count1/\count2\relax
      \fi
      \dimen2=\dimexpr \hsize - \count2\dimen1\relax
      \edef\@makecaptionparshapeargs{\the\count1}% \parshape arguments
      \loop\ifnum\count1>0\relax
        \edef\@makecaptionparshapeargs{\@makecaptionparshapeargs\space0pt \the\dimen2}%
        \advance\count1 by -1
        \advance\dimen2 by \dimen1
      \repeat
      \parshape=\@makecaptionparshapeargs
      #1: #2\par
    \fi
  \fi
  \vskip\belowcaptionskip
\egroup}
\makeatother

\begin{document}
\begin{figure}
\caption{Short cpation.}

\caption{This is an example of a very long caption of a figure which might be
too long to stay in one line.}

\caption{This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.}

\caption{This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.}

\caption{This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.
This is an example of a very long caption of a figure which might be
too long to stay in one line so that it will automatically jump to a
new line.}
\end{figure}
\end{document}
