Escalonamento de colunas usando paracol

Escalonamento de colunas usando paracol

Estou tentando criar um texto "paralelo" de natureza temporal. Por exemplo, o segundo autor escreveu o início, o primeiro autor escreveu a segunda seção, o quarto autor escreveu a terceira seção, o terceiro autor escreveu a quarta seção, o quarto autor escreveu a quinta seção, o primeiro autor escreveu a sexta seção, etc... O texto não deve estar alinhado, mas deve permitir que o leitor se mova entre essas seções em ordem. Examinei a documentação do paracol e pesquisei o problema no Google. Peço desculpas se especifiquei incorretamente o problema ou ignorei um recurso. Eu incluí um MWE. TIA.

\documentclass{report}
\usepackage[english]{babel}
\usepackage{blindtext}
\usepackage{paracol}

\begin{document}
   \centering Introduction     \\
   \raggedright
   This is an introductory paragraph. \\
   The document should be able to ``bounce'' back and forth between columns. For example, columns 2, 1, 4, 3, 2, 1, 4, 3, \dots

   \begin{paracol}{4}

      \textbf{This is the second paragraph and should align with the bottom of the first paragraph (second column).}
      \switchcolumn*[1]

      \textbf{This is the first paragraph.}
      \blindtext
      \switchcolumn*[0]

      \textbf{This is the fourth paragraph and should align with the bottom of the third paragraph (fourth column).}
      \blindtext
      \switchcolumn*[3]

      \textbf{This is the third paragraph and should align with the bottom of the second paragraph (first column).}
      \blindtext
      \switchcolumn*[2]

   \end{paracol}
\end{document}

Responder1

Você pode fazer isso comparacole seu código está muito próximo do jeito que está.

Se você observar a compilação, os parágrafos serão escalonados em colunas separadas, mas basta pular uma coluna para a direita, em vez de ir para a coluna especificada, e os números das colunas especificadas serão, na verdade, digitados. Isso ocorre porque o uso pretendido é \switchcolumn[i]*(o que é indiscutivelmente incomum para a sintaxe LaTeX).

Além disso, \switchcolumnprecisa vir antes e não depois (o texto é composto imediatamente, portanto composto de acordo com a \switchcolumndiretiva anterior). Depois disso, o texto precisa vir na ordem vertical/temporal correta ou ser inserido (junto com algum argumento para indicar a ordem) em algumas macros que podem armazenar e classificar os parágrafos conforme necessário. O primeiro é naturalmente muito mais fácil.

\documentclass{report}
\usepackage[english]{babel}
\usepackage{blindtext}
\usepackage{paracol}

\begin{document}
   This is an introductory paragraph.

   The document should be able to ``bounce'' back and forth between columns. For example, columns 2, 1, 4, 3, 2, 1, 4, 3, \dots

   \begin{paracol}{4}
      \switchcolumn[1]*
      \textbf{This is the first paragraph.}
      \blindtext

      \switchcolumn[0]*
      \textbf{This is the second paragraph and should align with the bottom of the first paragraph (second column).}

      \switchcolumn[3]*
      \textbf{This is the third paragraph and should align with the bottom of the second paragraph (first column).}
      \blindtext

      \switchcolumn[2]*
      \textbf{This is the fourth paragraph and should align with the bottom of the third paragraph (fourth column).}
      \blindtext
   \end{paracol}
\end{document}

Primeira página do código compilado mostrando o primeiro parágrafo na segunda coluna, o segundo parágrafo na primeira coluna e o terceiro parágrafo na quarta coluna
