Gostaria de adicionar uma equação em uma célula com várias linhas, usando tabela e largura definida. Funcionou em todos os lugares da tabela, exceto em uma célula que é uma multilinha de duas outras multilinhas. Nesse caso, recebo um erro. (A célula está indicada AQUI na imagem anexa). Você tem alguma ideia de como resolver isso? Obrigado!
\RequirePackage[patch]{kvoptions}
\documentclass{DissOnlineLatex}
\usepackage{amsmath}
\usepackage{mathtools, eqparbox}
\usepackage[makeroom]{cancel}
\newcommand{\eqbox}[2][]{\eqmakebox[#1][l]{\mbox{#2~}}}
\usepackage{dsfont}
\usepackage{longtable}
\usepackage{supertabular}
\usepackage{tabu}
\usepackage{multirow, tabularx}
\usepackage{multicol}
\newcolumntype{T}{>{\centering\arraybackslash\hsize=0.4\hsize}X}
\newcolumntype{V}{>{\centering\arraybackslash\hsize=0.65\hsize}X}
\newcolumntype{s}{>{\hsize=0.2\hsize}X}
\newcolumntype{b}{>{\hsize=1.0\hsize}X}
\newcolumntype{d}{>{\hsize=0.5\hsize}X}
\usepackage{tabulary}
\usepackage{longtable}
\usepackage{array}
\newcolumntype{P}[1]{>{\centering\arraybackslash}p{#1}}
\newcolumntype{M}[1]{>{\centering\arraybackslash}m{#1}}
\newcolumntype{L}[1]{>{\raggedleft\arraybackslash}p{#1}}
\usepackage{lscape}
\usepackage{xcolor}
\usepackage{graphicx}
\usepackage{caption}
\usepackage{subcaption}
\usepackage[outdir=./]{epstopdf}
\usepackage{multirow}
\usepackage{booktabs}
\usepackage{float}
\usepackage{rotating}
\usepackage{SIunits}
\usepackage{blindtext}
\usepackage[latin1]{inputenc}
\usepackage[
backend=biber,
style=numeric,
sortcites,
sorting = anyvt,
isbn=false,
url=false,
doi=false,
eprint=false,
backref,
natbib,
hyperref
]{biblatex}
\begin{document}
\begin{table}[htb]
\renewcommand\tabularxcolumn[1]{m{#1}}
\caption{Necessary liquid-gas ratios for concave and convex equilibrium lines.}
\label{table:Nec_LG}
\setlength\abovedisplayskip{0pt}
\setlength\belowdisplayskip{0pt}
\centering
\begin{tabular}{|c|M{4.0cm}|M{2.0cm}|M{3.0cm}|M{4.0cm}|}
\hline
\textbf{LG} & \textbf{Description} &\textbf{Goal} & {\textbf{Case}} & {\textbf{LG=}}\\
\hline
\hline
\multirow{2}[4]{*}{$LG_a$} & \multirow{2}[4]{=}{Minimal LG for maximal (de)humidification} & \multirow{2}[4]{*}{$\omega_t=\omega_t^*$} & Convex & \begin{equation}
\frac{\partial \omega^*}{\partial \xi}\Bigr\rvert_{\xi = \xi_t}
\label{eq:ratio_a_pinch_convex}
\end{equation} \\
\cline{4-5} & & & Concave & \multirow{2}{*}{
HERE
} \\
\cline{1-4} \multirow{2}[4]{*}{$LG_d$} & \multirow{2}[4]{=}{Maximal LG for maximal dilution or regeneration} & \multirow{2}[4]{*}{$\xi_b=\xi_b^*$} & Concave & \\
\cline{4-5} & & & Convex & \begin{equation}
\frac{\partial \omega^*}{\partial \xi}\Bigr\rvert_{\xi = \xi_b^*}
\label{eq:ratio_d_pinch_convex} \end{equation} \\
\hline
\hline
\multirow{4}{*}{$LG_h$} & \multirow{4}{=}{Minimal LG for specified (de)-humidification} & \multirow{4}{*}{$\omega_t=\omega_{t,goal}$}& Straight, concave and convex $LG_h\le LG_d$& \begin{equation}
\frac{\omega_b-\omega_{t,goal}}{\xi_b^*-\xi_t}
\label{eq:ratio_h_pinch_concave}
\end{equation}\\
\cline{4-5}
& & & convex $LG_h\ge LG_d$ & \begin{equation}
\frac{\omega^*(\hat{\xi})-\omega_{t,goal}}{\hat{\xi}-\xi_t}
\label{eq:ratio_h_pinch_convex}
\end{equation} \\
\hline
\multirow{4}{*}{$LG_r$} & \multirow{4}{=}{Maximal LG for specified dilution or regeneration} & \multirow{4}{*}{$\xi_b=\xi_{b,goal}$}& Straight, concave and convex $LG_r\ge LG_a$& \begin{equation}
\frac{\omega_b-\omega_t^*}{\xi_{b,goal}-\xi_t}
\label{eq:ratio_r_pinch_concave}
\end{equation}\\
\cline{4-5}
& & & convex $LG_r<LG_a$ & \begin{equation}
\frac{\omega_{b}-\omega^*(\hat{\xi})}{\xi_{b,goal}-\hat{\xi}}
\label{eq:ratio_r_pinch_convex}
\end{equation} \\
\hline
\hline
\end{tabular}
\end{table}
\end{document}
Responder1
Como não tenho a DissOnlineLatexclasse document, usei o artigo a seguir.
Eu não colocaria equationambientes dentro de um tabularambiente e teria pensado que isso levaria a uma pilha de erros. Então, estou surpreso que você receba apenas um erro dentro das \multirowcélulas. Acho que isso funciona porque você está usando um Mtipo -column. Se você quiser colocar um equationambiente dentro da \multirowcélula, a coisa óbvia a fazer é colocar equationdentro de um minipageambiente. Usar isso parece fazer o que você deseja:
Definir a largura do minipageambiente \linbewidthdeveria, em teoria, fornecer a largura correta. Descobri por tentativa e erro que usar 0.97\linewidthfuncionou melhor porque fez com que o número da equação nesta célula se alinhasse corretamente com os outros números da equação. Aqui está o seu MWE modificado:
\RequirePackage[patch]{kvoptions}
\documentclass{article}
\usepackage{amsmath}
\usepackage{mathtools, eqparbox}
\usepackage[makeroom]{cancel}
\newcommand{\eqbox}[2][]{\eqmakebox[#1][l]{\mbox{#2~}}}
\usepackage{dsfont}
\usepackage{longtable}
\usepackage{supertabular}
\usepackage{tabu}
\usepackage{multirow, tabularx}
\usepackage{multicol}
\newcolumntype{T}{>{\centering\arraybackslash\hsize=0.4\hsize}X}
\newcolumntype{V}{>{\centering\arraybackslash\hsize=0.65\hsize}X}
\newcolumntype{s}{>{\hsize=0.2\hsize}X}
\newcolumntype{b}{>{\hsize=1.0\hsize}X}
\newcolumntype{d}{>{\hsize=0.5\hsize}X}
\usepackage{tabulary}
\usepackage{longtable}
\usepackage{array}
\newcolumntype{P}[1]{>{\centering\arraybackslash}p{#1}}
\newcolumntype{M}[1]{>{\centering\arraybackslash}m{#1}}
\newcolumntype{L}[1]{>{\raggedleft\arraybackslash}p{#1}}
\usepackage{lscape}
\usepackage{xcolor}
\usepackage{graphicx}
\usepackage{caption}
\usepackage{subcaption}
\usepackage[outdir=./]{epstopdf}
\usepackage{multirow}
\usepackage{booktabs}
\usepackage{float}
\usepackage{rotating}
\usepackage{SIunits}
\usepackage{blindtext}
\usepackage[latin1]{inputenc}
\usepackage[
backend=biber,
style=numeric,
sortcites,
sorting = anyvt,
isbn=false,
url=false,
doi=false,
eprint=false,
backref,
natbib,
hyperref
]{biblatex}
\begin{document}
\begin{table}[htb]
\renewcommand\tabularxcolumn[1]{m{#1}}
\caption{Necessary liquid-gas ratios for concave and convex equilibrium lines.}
\label{table:Nec_LG}
\setlength\abovedisplayskip{0pt}
\setlength\belowdisplayskip{0pt}
\centering
\begin{tabular}{|c|M{4.0cm}|M{2.0cm}|M{3.0cm}|M{4.0cm}|}
\hline
\textbf{LG} & \textbf{Description} &\textbf{Goal} & {\textbf{Case}} & {\textbf{LG=}}\\
\hline
\hline
\multirow{2}[4]{*}{$LG_a$} & \multirow{2}[4]{=}{Minimal LG for maximal (de)humidification} & \multirow{2}[4]{*}{$\omega_t=\omega_t^*$} & Convex & \begin{equation}
\frac{\partial \omega^*}{\partial \xi}\Bigr\rvert_{\xi = \xi_t}
\label{eq:ratio_a_pinch_convex}
\end{equation} \\
\cline{4-5} & & & Concave & \multirow{2}{*}{
\begin{minipage}{0.97\linewidth}
\begin{equation}\label{E:}
\frac{\partial \omega^*}{\partial \xi}\Bigr\rvert_{\xi = \xi_b^*}
\end{equation}
\end{minipage}
} \\
\cline{1-4} \multirow{2}[4]{*}{$LG_d$} & \multirow{2}[4]{=}{Maximal LG for maximal dilution or regeneration} & \multirow{2}[4]{*}{$\xi_b=\xi_b^*$} & Concave & \\
\cline{4-5} & & & Convex & \begin{equation}
\frac{\partial \omega^*}{\partial \xi}\Bigr\rvert_{\xi = \xi_b^*}
\label{eq:ratio_d_pinch_convex} \end{equation} \\
\hline
\hline
\multirow{4}{*}{$LG_h$} & \multirow{4}{=}{Minimal LG for specified (de)-humidification} & \multirow{4}{*}{$\omega_t=\omega_{t,goal}$}& Straight, concave and convex $LG_h\le LG_d$& \begin{equation}
\frac{\omega_b-\omega_{t,goal}}{\xi_b^*-\xi_t}
\label{eq:ratio_h_pinch_concave}
\end{equation}\\
\cline{4-5}
& & & convex $LG_h\ge LG_d$ & \begin{equation}
\frac{\omega^*(\hat{\xi})-\omega_{t,goal}}{\hat{\xi}-\xi_t}
\label{eq:ratio_h_pinch_convex}
\end{equation} \\
\hline
\multirow{4}{*}{$LG_r$} & \multirow{4}{=}{Maximal LG for specified dilution or regeneration} & \multirow{4}{*}{$\xi_b=\xi_{b,goal}$}& Straight, concave and convex $LG_r\ge LG_a$& \begin{equation}
\frac{\omega_b-\omega_t^*}{\xi_{b,goal}-\xi_t}
\label{eq:ratio_r_pinch_concave}
\end{equation}\\
\cline{4-5}
& & & convex $LG_r<LG_a$ & \begin{equation}
\frac{\omega_{b}-\omega^*(\hat{\xi})}{\xi_{b,goal}-\hat{\xi}}
\label{eq:ratio_r_pinch_convex}
\end{equation} \\
\hline
\hline
\end{tabular}
\end{table}
\end{document}
