Muitas subfiguras em uma figura

Gostaria de colocar 81 subfiguras em uma figura com uma legenda e cada subfigura rotulada por um número. Cada subfigura tem o mesmo tamanho (então provavelmente não preciso tabularxdisso). Eu gostaria de 4 subfiguras em uma linha, como segue,

SUBFIG1 e SUBFIG2 e SUBFIG3 e SUBFIG4

..

SUBFIG77 e SUBFIG78 e SUBFIG79 e SUBFIG80

SUFIG81

LEGENDA: XXX

Abaixo de cada subfigura eu gostaria de um número entre colchetes, por exemplo, abaixo de SUBFIG1 eu gostaria de (1) etc.

Qual é a melhor maneira de fazer isso no látex? Eu tentei o tabularambiente

\documentclass{report}
\usepackage{subcaption}
\begin{figure}
\begin{tabular}{cccc}
\subfloat[(1)]{\includegraphics[width=2cm]{SUBFIG1.eps}}
    & \subfloat[(2)]{\includegraphics[width=2cm]{SUBFIG2.eps}}
    &  \subfloat[(3)]{\includegraphics[width=2cm]{SUBFIG3.eps}}
    & \subfloat[(4)]{\includegraphics[width=2cm]{SUBFIG4.eps}} \\
\subfloat[(5)]{\includegraphics[width=2cm]{SUBFIG5.eps}}
    & \subfloat[(6)]{\includegraphics[width=2cm]{SUBFIG6.eps}}
 ...
\end{tabular}
\caption{XXX}
\label{xxx}
\end{figure}

mas aqui subfloattem az como delimitador de contagem e assim que atingi 24 subfiguras ele sai da página (ou seja, não inicia a subfigura 25 em uma nova página). Obrigado!

Responder1

Como todas as imagens têm a mesma largura, não há necessidade de uma abordagem do tipo tabular. Basta usar \subfloatdiretivas para colocá-los, quatro por linha.

Como você carrega a subcaptionlegenda (e, portanto, também o captionpacote), você pode usar \ContinuedFloatdiretivas no topo de cada figureambiente consecutivo.

A captura de tela a seguir mostra o último dos figureambientes produzidos pelo código abaixo.

insira a descrição da imagem aqui

\documentclass{report}
\usepackage[margin=2.5cm]{geometry} % set page parameters suitably
\usepackage[demo]{graphicx} % remove 'demo' option in real document

\usepackage{subcaption}
\renewcommand\thesubfigure{\arabic{subfigure}} % arabic numerals
\captionsetup[figure]{skip=0.5\baselineskip}
\captionsetup[subfigure]{skip=0.25\baselineskip,position=below}

\begin{document}

\begin{figure}[p]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\caption{XXX}\label{fig:xxx}

\subfloat[]{\includegraphics{SUBFIG01}}\hfill
\subfloat[]{\includegraphics{SUBFIG02}}\hfill
\subfloat[]{\includegraphics{SUBFIG03}}\hfill
\subfloat[]{\includegraphics{SUBFIG04}}

\medskip
\subfloat[]{\includegraphics{SUBFIG05}}\hfill
\subfloat[]{\includegraphics{SUBFIG06}}\hfill
\subfloat[]{\includegraphics{SUBFIG07}}\hfill
\subfloat[]{\includegraphics{SUBFIG08}}

\medskip
\subfloat[]{\includegraphics{SUBFIG09}}\hfill
\subfloat[]{\includegraphics{SUBFIG10}}\hfill
\subfloat[]{\includegraphics{SUBFIG11}}\hfill
\subfloat[]{\includegraphics{SUBFIG12}}

\medskip
\subfloat[]{\includegraphics{SUBFIG13}}\hfill
\subfloat[]{\includegraphics{SUBFIG14}}\hfill
\subfloat[]{\includegraphics{SUBFIG15}}\hfill
\subfloat[]{\includegraphics{SUBFIG16}}

\medskip
\subfloat[]{\includegraphics{SUBFIG17}}\hfill
\subfloat[]{\includegraphics{SUBFIG18}}\hfill
\subfloat[]{\includegraphics{SUBFIG19}}\hfill
\subfloat[]{\includegraphics{SUBFIG20}}

\medskip
\subfloat[]{\includegraphics{SUBFIG21}}\hfill
\subfloat[]{\includegraphics{SUBFIG22}}\hfill
\subfloat[]{\includegraphics{SUBFIG23}}\hfill
\subfloat[]{\includegraphics{SUBFIG24}}

\end{figure}

\begin{figure}[p]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\ContinuedFloat
\caption{XXX, continued}

\subfloat[]{\includegraphics{SUBFIG25}}\hfill
\subfloat[]{\includegraphics{SUBFIG26}}\hfill
\subfloat[]{\includegraphics{SUBFIG27}}\hfill
\subfloat[]{\includegraphics{SUBFIG28}}

\medskip
\subfloat[]{\includegraphics{SUBFIG29}}\hfill
\subfloat[]{\includegraphics{SUBFIG30}}\hfill
\subfloat[]{\includegraphics{SUBFIG31}}\hfill
\subfloat[]{\includegraphics{SUBFIG32}}

\medskip
\subfloat[]{\includegraphics{SUBFIG33}}\hfill
\subfloat[]{\includegraphics{SUBFIG34}}\hfill
\subfloat[]{\includegraphics{SUBFIG35}}\hfill
\subfloat[]{\includegraphics{SUBFIG36}}

\medskip
\subfloat[]{\includegraphics{SUBFIG37}}\hfill
\subfloat[]{\includegraphics{SUBFIG38}}\hfill
\subfloat[]{\includegraphics{SUBFIG39}}\hfill
\subfloat[]{\includegraphics{SUBFIG40}}

\medskip
\subfloat[]{\includegraphics{SUBFIG41}}\hfill
\subfloat[]{\includegraphics{SUBFIG42}}\hfill
\subfloat[]{\includegraphics{SUBFIG43}}\hfill
\subfloat[]{\includegraphics{SUBFIG44}}

\medskip
\subfloat[]{\includegraphics{SUBFIG45}}\hfill
\subfloat[]{\includegraphics{SUBFIG46}}\hfill
\subfloat[]{\includegraphics{SUBFIG47}}\hfill
\subfloat[]{\includegraphics{SUBFIG48}}

\end{figure}

\begin{figure}[p]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\ContinuedFloat
\caption{XXX, continued}

\subfloat[]{\includegraphics{SUBFIG49}}\hfill
\subfloat[]{\includegraphics{SUBFIG50}}\hfill
\subfloat[]{\includegraphics{SUBFIG51}}\hfill
\subfloat[]{\includegraphics{SUBFIG52}}

\medskip
\subfloat[]{\includegraphics{SUBFIG53}}\hfill
\subfloat[]{\includegraphics{SUBFIG54}}\hfill
\subfloat[]{\includegraphics{SUBFIG55}}\hfill
\subfloat[]{\includegraphics{SUBFIG56}}

\medskip
\subfloat[]{\includegraphics{SUBFIG57}}\hfill
\subfloat[]{\includegraphics{SUBFIG58}}\hfill
\subfloat[]{\includegraphics{SUBFIG59}}\hfill
\subfloat[]{\includegraphics{SUBFIG60}}

\medskip
\subfloat[]{\includegraphics{SUBFIG61}}\hfill
\subfloat[]{\includegraphics{SUBFIG62}}\hfill
\subfloat[]{\includegraphics{SUBFIG63}}\hfill
\subfloat[]{\includegraphics{SUBFIG64}}

\medskip
\subfloat[]{\includegraphics{SUBFIG65}}\hfill
\subfloat[]{\includegraphics{SUBFIG66}}\hfill
\subfloat[]{\includegraphics{SUBFIG67}}\hfill
\subfloat[]{\includegraphics{SUBFIG68}}

\medskip
\subfloat[]{\includegraphics{SUBFIG69}}\hfill
\subfloat[]{\includegraphics{SUBFIG70}}\hfill
\subfloat[]{\includegraphics{SUBFIG71}}\hfill
\subfloat[]{\includegraphics{SUBFIG72}}

\end{figure}

\begin{figure}[ht!]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\ContinuedFloat
\caption{XXX, continued}

\subfloat[]{\includegraphics{SUBFIG73}}\hfill
\subfloat[]{\includegraphics{SUBFIG74}}\hfill
\subfloat[]{\includegraphics{SUBFIG75}}\hfill
\subfloat[]{\includegraphics{SUBFIG76}}

\medskip
\subfloat[]{\includegraphics{SUBFIG77}}\hfill
\subfloat[]{\includegraphics{SUBFIG78}}\hfill
\subfloat[]{\includegraphics{SUBFIG79}}\hfill
\subfloat[]{\includegraphics{SUBFIG80}}

\medskip
\subfloat[]{\includegraphics{SUBFIG81}}\hfill

\end{figure}


\end{document}

Responder2

Talvez, se você colocar os números em uma tabela e depois dividi-los pelas páginas usando um arquivo \ContinuedFloat. Embora, nesta abordagem, você teria que dividir a figura manualmente, o que obviamente não é muito elegante.

\documentclass{scrreprt}
\usepackage{graphicx}
\usepackage{subcaption}

\DeclareCaptionSubType*{figure}\renewcommand\thesubfigure{\arabic{subfigure}}
\newcommand{\sub}[1]{\begin{minipage}{.2\linewidth}\includegraphics[width=\linewidth]{#1}\subcaption{}\end{minipage}}
\newcommand{\tabfig}[4]{\sub{#1} & \sub{#2} & \sub{#3} & \sub{#4}\\}

\begin{document}
\begin{figure}[ht]
   \begin{tabular}{cccc}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
   \end{tabular}
\end{figure}
\begin{figure}[ht]\ContinuedFloat
   \begin{tabular}{cccc}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
   \end{tabular}
\end{figure}
\end{document}
