Estou tentando fazer uma tabela que continue na próxima página para que não haja espaços em branco criados no meio do documento.
No entanto, quando uso o ambiente de tabela longa, obtenho o seguinte;
\documentclass{article}
\usepackage[utf8]{inputenc}
\usepackage{longtable}
\begin{document}
\section{Introduction}
\section{Internal Functioning}
Magnetism is a property of matter that is a result of the orbiting electrons in atoms. The orbiting electrons cause the atoms to have a magnetic moment associated with an intrinsic angular momentum called spin. Spin will be discussed in more detail a little bit further down. It's convenient to imagine the electron spinning on its axis with the up and down orientations. However, in reality the electron is not physically spinning!
The following list gives a detailed description of each of this files.
\subsection{List of Program Components}
\subsubsection{alpha.py}
\textbf{Description:}
sndmbfjherhfiuewhiu
skdjfiejijfiejfiojowejqo
ksnjhewiufhiwef
ksdnfjnaiefhie
ajksdnfiefiuej
\textbf{Modules used:} 123
\textbf{Functional Specifications of the Functions:}\medskip
\begin{longtable}{ | p{3cm} | p{10cm}| }
\hline
\textbf{to} & kur\medskip
xmcnkdskjfakjfjkla;kslfk;lak;dslfklsd;k;alk;fekfoe \medskip
Magnetism is a property of matter that is a result of the orbiting electrons in atoms. The orbiting electrons cause the atoms to have a magnetic moment associated with an intrinsic angular momentum called spin. Spin will be discussed in more detail a little bit further down. It's convenient to imagine the electron spinning on its axis with the up and down orientations. However, in reality the electron is not physically spinning!
The body is largely composed of water molecules. Each water molecule has two hydrogen nuclei or protons. MRI takes advantage of the high prevalence of hydrogen in the body and the magnetic properties of the proton in a hydrogen atom. Hydrogen atoms induce a small magnetic field due to the spin of this atom's proton. When a person goes inside the powerful magnetic field of the scanner, the magnetic moments (the measure of its tendency to align with a magnetic field) of some of these protons changes, and aligns with the direction of the field.
The magnetic field in an magnetic resonance imaging (MRI) scanner is generated by surrounding a coil of wire with super cooling fluids (liquid helium and liquid nitrogen) lowering the temperature to about 10°K (-263°C or -441°F). Electrical current in the coil moves very fast creating the extremely large magnetic field.
kap(Integer, size -1)\medskip
\textbf{output}\par
theta\par
ppp\par
ooo\par
werwr\bigskip
kdkfjkrjeie\par
mdfmkerjoij\par
assad\\
\hline
\end{longtable}
\end{document}
Como posso fazer com que a tabela comece na primeira página e continue na segunda página?
Responder1
É um pouco complicado, mas você pode fazer isso com paracol. Observe o \struts na primeira e na última linha. A primeira e a última colunas são usadas apenas para criar linhas verticais nas \columnseplacunas resultantes.
\documentclass{article}
\usepackage[utf8]{inputenc}
\usepackage{paracol}
\begin{document}
\section{Introduction}
\section{Internal Functioning}
Magnetism is a property of matter that is a result of the orbiting electrons in atoms. The orbiting electrons cause the atoms to have a magnetic moment associated with an intrinsic angular momentum called spin. Spin will be discussed in more detail a little bit further down. It's convenient to imagine the electron spinning on its axis with the up and down orientations. However, in reality the electron is not physically spinning!
The following list gives a detailed description of each of this files.
\subsection{List of Program Components}
\subsubsection{alpha.py}
\textbf{Description:}
sndmbfjherhfiuewhiu
skdjfiejijfiejfiojowejqo
ksnjhewiufhiwef
ksdnfjnaiefhie
ajksdnfiefiuej
\textbf{Modules used:} 123
\textbf{Functional Specifications of the Functions:}\medskip
\columnseprule=0.4pt
\setcolumnwidth{\dimexpr 0.5\columnseprule-0.5\columnsep,3cm,8cm}
\begin{paracol}{4}
\parindent=0pt
\switchcolumn[1]*[\hrule width\dimexpr11cm+2\columnsep+\columnseprule]
\strut\textbf{to}
\switchcolumn[2]
\strut kur\medskip
xmcnkdskjfakjfjkla;kslfk;lak;dslfklsd;k;alk;fekfoe \medskip
Magnetism is a property of matter that is a result of the orbiting electrons in atoms. The orbiting electrons cause the atoms to have a magnetic moment associated with an intrinsic angular momentum called spin. Spin will be discussed in more detail a little bit further down. It's convenient to imagine the electron spinning on its axis with the up and down orientations. However, in reality the electron is not physically spinning!
The body is largely composed of water molecules. Each water molecule has two hydrogen nuclei or protons. MRI takes advantage of the high prevalence of hydrogen in the body and the magnetic properties of the proton in a hydrogen atom. Hydrogen atoms induce a small magnetic field due to the spin of this atom's proton. When a person goes inside the powerful magnetic field of the scanner, the magnetic moments (the measure of its tendency to align with a magnetic field) of some of these protons changes, and aligns with the direction of the field.
The magnetic field in an magnetic resonance imaging (MRI) scanner is generated by surrounding a coil of wire with super cooling fluids (liquid helium and liquid nitrogen) lowering the temperature to about 10°K (-263°C or -441°F). Electrical current in the coil moves very fast creating the extremely large magnetic field.
kap(Integer, size -1)\medskip
\textbf{output}\par
theta\par
ppp\par
ooo\par
werwr\bigskip
kdkfjkrjeie\par
mdfmkerjoij\par
assad\strut
\switchcolumn[1]*[\hrule width\dimexpr11cm+2\columnsep+\columnseprule]
\end{paracol}
\end{document}
Esta versão cria ambiente mytabularpara simplificar a aplicação. A largura da primeira coluna é ajustável e a segunda coluna preenche a área de texto.
\documentclass{article}
\usepackage[utf8]{inputenc}
\usepackage{paracol}
\newenvironment{mytabular}[1][3cm]% #1 = width of first column (optonal)
{\columnseprule=0.4pt
\setcolumnwidth{\dimexpr 0.5\columnseprule-0.5\columnsep\relax,
#1,
\dimexpr \textwidth-#1-2\columnsep-2\columnseprule\relax,
\dimexpr 0.5\columnseprule-0.5\columnsep\relax}%
\parindent=0pt
\def\hline{\switchcolumn[1]*[\hrule width\textwidth]}%
\begin{paracol}{4}}%
{\end{paracol}}
\begin{document}
\section{Introduction}
\section{Internal Functioning}
Magnetism is a property of matter that is a result of the orbiting electrons in atoms. The orbiting electrons cause the atoms to have a magnetic moment associated with an intrinsic angular momentum called spin. Spin will be discussed in more detail a little bit further down. It's convenient to imagine the electron spinning on its axis with the up and down orientations. However, in reality the electron is not physically spinning!
The following list gives a detailed description of each of this files.
\subsection{List of Program Components}
\subsubsection{alpha.py}
\textbf{Description:}
sndmbfjherhfiuewhiu
skdjfiejijfiejfiojowejqo
ksnjhewiufhiwef
ksdnfjnaiefhie
ajksdnfiefiuej
\textbf{Modules used:} 123
\textbf{Functional Specifications of the Functions:}\medskip
\begin{mytabular}
\hline
\strut\textbf{to}
\switchcolumn
\strut kur\medskip
xmcnkdskjfakjfjkla;kslfk;lak;dslfklsd;k;alk;fekfoe \medskip
Magnetism is a property of matter that is a result of the orbiting electrons in atoms. The orbiting electrons cause the atoms to have a magnetic moment associated with an intrinsic angular momentum called spin. Spin will be discussed in more detail a little bit further down. It's convenient to imagine the electron spinning on its axis with the up and down orientations. However, in reality the electron is not physically spinning!
The body is largely composed of water molecules. Each water molecule has two hydrogen nuclei or protons. MRI takes advantage of the high prevalence of hydrogen in the body and the magnetic properties of the proton in a hydrogen atom. Hydrogen atoms induce a small magnetic field due to the spin of this atom's proton. When a person goes inside the powerful magnetic field of the scanner, the magnetic moments (the measure of its tendency to align with a magnetic field) of some of these protons changes, and aligns with the direction of the field.
The magnetic field in an magnetic resonance imaging (MRI) scanner is generated by surrounding a coil of wire with super cooling fluids (liquid helium and liquid nitrogen) lowering the temperature to about 10°K (-263°C or -441°F). Electrical current in the coil moves very fast creating the extremely large magnetic field.
kap(Integer, size -1)\medskip
\textbf{output}\par
theta\par
ppp\par
ooo\par
werwr\bigskip
kdkfjkrjeie\par
mdfmkerjoij\par
assad\strut
\hline
\end{mytabular}
\end{document}
