Tikzpicture não mostra vários preenchimentos entre

Question

Eu tenho o seguinte código dentro de uma apresentação do beamer:

\begin{frame}[c]{ }
\frametitle{Section 5.2: Definite Integral}


\begin{center}
\begin{tikzpicture}[scale =1]
  \begin{axis}[
    axis lines=center,
    grid=major,
    xmin=-12.5,
    xmax=12.5,
    ymin=-10.5,
    ymax=10.5,
    xtick = {-12,-10,...,12},
    ytick = {-10,-8,...,10},
    yticklabel style = {font=\tiny,xshift=0.5ex},
    xticklabel style = {font=\tiny,yshift=0.5ex},
    no marks,
    axis line style={thick, <->},
    ]
\addplot+[-, samples = 200, thin, black, domain = -12:12 , name path=A] {0};
\addplot+[<-, samples = 200, thick, blue, domain = -11:-4 , name path=B] {0.5*(x + 4) + 4};
\addplot+[-, samples = 200, thick, blue, domain = -4:-0 , name path=C] {4};
\addplot+[-, samples = 200, thick, blue, domain = 0:6, name path=D] {-2*x+4};
\addplot+[->, samples = 200, thick, blue, domain = 6:10.25, name path=E] {4*(x - 6)-8};
\addplot+[red, opacity = 0.3] fill between[of=A and B,soft clip={domain=-8:-4}]; % filling
\addplot+[red, opacity = 0.3] fill between[of=A and C,soft clip={domain=-4:-0}]; % filling
\addplot+[red, opacity = 0.3] fill between[of=A and D,soft clip={domain=0:6}]; % filling
\addplot+[red, opacity = 0.3] fill between[of=A and E,soft clip={domain=6:10}]; % filling
\node[blue] at (axis cs:7,7){{\tiny$y = g(t)$}};
\end{axis}
\end{tikzpicture}
\end{center}
\end{frame}

que produz a seguinte imagem:

Quero preencher toda a área sob a curva de t = -8 a t = 10, mas está preenchendo apenas a primeira parte. Como posso consertar isso?

Answer 1

Aconselho você a usar um único plotsempre que possível, repliquei o seu usando as mesmas coordenadas (para os caminhos imprecisos, sobrepus e combinam perfeitamente). Vou te dar também a solução com seu código, para você escolher.

Seu código

\documentclass[tikz, margin=10pt]{standalone}
\usepackage{pgfplots}

\pgfplotsset{compat=1.17}
\usepgfplotslibrary{fillbetween}

\begin{document}
\begin{tikzpicture}[scale =1]
    \begin{axis}[
      axis lines=center,
      grid=major,
      xmin=-12.5,
      xmax=12.5,
      ymin=-10.5,
      ymax=10.5,
      xtick = {-12,-10,...,12},
      ytick = {-10,-8,...,10},
      yticklabel style = {font=\tiny,xshift=0.5ex},
      xticklabel style = {font=\tiny,yshift=0.5ex},
      no marks,
      axis line style={thick, <->},
      ]
      \path[name path=axis] (axis cs:-10,0) -- (axis cs:12,0);
    \addplot+[-, samples = 200, thin, black, domain = -12:12 , name path=A] {0};
    \addplot+[<-, samples = 200, thick, blue, domain = -11:-4 , name path=B] {0.5*(x + 4) + 4};
    \addplot+[-, samples = 200, thick, blue, domain = -4:-0 , name path=C] {4};
    \addplot+[-, samples = 200, thick, blue, domain = 0:6, name path=D] {-2*x+4};
    \addplot+[->, samples = 200, thick, blue, domain = 6:10.25, name path=E] {4*(x - 6)-8};
    \addplot+[red, opacity = 0.3] fill between[of=A and B,soft clip={domain=-8:-4}]; % filling
    \addplot+[red, opacity = 0.3] fill between[of=A and C,soft clip={domain=-4:-0}]; % filling
    \addplot+[red, opacity = 0.3] fill between[of=A and D,soft clip={domain=0:6}]; % filling
    \addplot+[red, opacity = 0.3] fill between[of=A and E,soft clip={domain=6:10}]; % filling
  \node[blue] at (axis cs:7,7){{\tiny$y = g(t)$}};
  \end{axis}
  \end{tikzpicture}
\end{document}

Parcela única

\documentclass[tikz, margin=10pt]{standalone}
\usepackage{pgfplots}

\pgfplotsset{compat=1.17}
\usepgfplotslibrary{fillbetween}

\begin{document}
\begin{tikzpicture}
    \begin{axis}[
      axis lines=center,
      grid=major,
      xmin=-12.5,
      xmax=12.5,
      ymin=-10.5,
      ymax=10.5,
      xtick = {-12,-10,...,12},
      ytick = {-10,-8,...,10},
      yticklabel style = {font=\tiny,xshift=0.5ex},
      xticklabel style = {font=\tiny,yshift=0.5ex},
      no marks,
      axis line style={thick, <->},
      ]
    \addplot+[<->, samples=200, thick, blue, name path=myplot] coordinates {
        (-11,.5) (-4,4) (0,4) (6,-8) (10.25,9)
    };
    \path[name path=axis] (axis cs:-10,0) -- (axis cs:12,0);
    \addplot+[red, opacity = 0.3] fill between[of=myplot and axis,soft clip={domain=-8:10}]; % filling
\node[blue] at (axis cs:7,7){{\tiny$y = g(t)$}};
\end{axis}
\end{tikzpicture}
\end{document}

E o resultado em ambos os casos é:
