Quero criar a seguinte imagem tikz:
O que tenho no momento é isto:
\documentclass{article}
\usepackage[showframe]{geometry}
\usepackage{tikz}
\usetikzlibrary{positioning,backgrounds}
\begin{document}
\noindent\begin{tikzpicture}[background rectangle/.style={fill=gray!25}, show background rectangle,every node/.style={inner sep=0pt,outer sep=0pt,draw}]
\begin{scope}[local bounding box=scope1]
\path[use as bounding box] (0,0) rectangle (.5\textwidth,0);
\filldraw (0,0) circle (2pt);
\node [text width=0.5\textwidth, align=left,anchor=north west](n1) {scope 1, node 1};
\node [below = 0pt of n1.south west,anchor=north west] (n2) {scope 1, node 2};
\node [below left = 0pt and 0pt of n2.north east,anchor=north west,align=left,text width=5.1cm] (n3) {scope 1, node 3 that includes longer text to be broken into lines};
\end{scope}
\begin{scope}[shift={(scope1.north east)},anchor=north west]
\node [text width=0.5\textwidth, align=left](n1) {scope 2, node 1};
\node [below = 0pt of n1.south west,anchor=north west] (n2) {scope 2, node 2};
\node [below left = 0pt and 0pt of n2.north east,anchor=north west,align=left,text width=5.1cm] (n3) {scope 2, node 3 which also includes longer text to be broken into lines};
\end{scope}
\end{tikzpicture}
\end{document}
Preciso de ajuda com duas coisas:
Como posso definir a largura do nó
n3
para que a largura total den2
en3
seja a den1
(que é.5\textwidth
)? No momento eu configurei para 5,1 cm porque parece bom, mas se eu alterar o conteúdo do nó 2, a dimensão do nó 3 também deverá mudar. Como posso usar a caixa delimitadora que criei para o primeiro escopo?Como posso inserir um separador entre os dois escopos (como o desenhado em amarelo na primeira foto)? Por que a largura dos dois escopos vai além
textwidth
? Há uma margem cinza à esquerda e à direita, emboraouter sep=0pt
.
Responder1
O retângulo de fundo tem um preenchimento (chamado ), portanto, mostra mais cinza do que o conteúdo real. Usarinner frame [xy]sep
tight background
para mudar isso.
Além disso, a largura da linha (de qualquer caminho, não apenas de nós, independentemente de quaisquer divisões externas) contribuirá para a caixa delimitadora final da imagem, o que também altera um pouco o posicionamento final da imagem (e levará a uma hbox excessiva).
Na sua configuração original, você pode substituir a medida horizontal da caixa delimitadora usando trim left=0pt, trim right=\textwidth
. No meu código abaixo, estou usando ±.5\textwidth
porque crio a imagem centrada na origem.
Para criar nós que possuem tamanhos relacionados a outros nós, eles são a fit
biblioteca que funciona definindo largura/altura/profundidade do texto, o que é ruim se você deseja que os nós realmente tenham texto.
Minha ext.positioning-plus
biblioteca faz coisas semelhantes usando a fit
biblioteca, mas controla o tamanho do novo nó usando minimum width
e minimum height
o que é melhor para ter texto no nó, mas precisa de um pouco de trabalho para texto que é mais longo do que caberia no nó.
Estou usando aqui uma text width between
chave muito básica que usa a calc
biblioteca para medir a distância entre dois pontos arbitrários noxdimensão e usa isso para definir a dimensão text width
do nó. Precisamos subtrair inner xsep
duas vezes aqui (para que o nó final realmente cubra a áreacomxsep interno). Esta é basicamente uma maneira de definir umLargura fixaem vez de uma largura mínima. (O fator 2 é diferente para outras formas.)
Para sincronizar tamanhos de nós, posso oferecer oext.node-families
bibliotecado meutikz-ext
pacote.
Cada nó que node family={height=row1}
definiu compartilha o mesmo arquivo minimum height
. Isso alinhará os textos em cada nó centralizado verticalmente.
Tanto os nós azuis quanto o separador amarelo (também um nó) abrangerão o mesmo espaço vertical.
Código (família de nós)
\documentclass{article}
\usepackage[showframe]{geometry}
\usepackage{tikz, amsmath}
\makeatletter % https://tex.stackexchange.com/a/656319/16595
\tikzset{parse let/.code={\def\tikz@cc@stop@let in{}\tikz@let@command et #1in}}
\makeatother
\usetikzlibrary{calc, positioning, backgrounds, ext.node-families}
\tikzset{
text width between/.style args={#1 and #2}{
parse let={\p@=($(#2)-(#1)$)},
text width/.expanded={abs(\x@)-2*(\noexpand\pgfkeysvalueof{/pgf/inner xsep}}}}
\begin{document}
\noindent
\begin{tikzpicture}[
background rectangle/.style={fill=gray!25},
show background rectangle, tight background,
trim left=-.5\textwidth, trim right=.5\textwidth,
every node/.style={outer sep=+0pt},
Yellow/.style={fill=yellow, node family={height=row1}},
Blue/.style ={fill=blue, node family={height=row1}, text=white},
Red/.style ={fill=red, align=center},
Green/.style ={fill=green, align=center},
node distance=+0pt
]
\node[Yellow] (sep) {};
\node[Blue, left=of sep, text width between={-.5\textwidth,0 and sep.west}]
(Blue-left) {scope 1, node 1 $\displaystyle e^x = \cfrac{1}{1 - \cfrac{x}{1 + x -
\cfrac{\frac{1}{2}x}{1 + \frac{1}{2}x - \ddots}}}$};
\node[Blue, right=of sep, text width between={ .5\textwidth,0 and sep.east}]
(Blue-right) {scope 1, node 1};
\node[Red, below right=of Blue-left.south west] (Red-left) {scope 1,\\ node 2};
\node[Red, below right=of Blue-right.south west] (Red-right) {scope 1,\\ node 2};
\node[Green, below left=of Blue-left.south east,
text width between=Red-left.east and Blue-left.east]
(Red-left) {scope 1, node 3 that includes longer text to be broken into lines};
\node[Green, below left=of Blue-right.south east,
text width between=Red-right.east and Blue-right.east]
(Red-left) {scope 2, node 3 which also includes longer text to be broken into lines
\dots\ and here's an extra linre};
\end{tikzpicture}
\end{document}
Código (sem família de nós)
\documentclass{article}
\usepackage[showframe]{geometry}
\usepackage{tikz, amsmath}
\makeatletter % https://tex.stackexchange.com/a/656319/16595
\tikzset{parse let/.code={\def\tikz@cc@stop@let in{}\tikz@let@command et #1in}}
\makeatother
\usetikzlibrary{calc, positioning, backgrounds}
\tikzset{
text width between/.style args={#1 and #2}{
parse let={\p@=($(#2)-(#1)$)},
text width/.expanded={abs(\x@)-2*(\noexpand\pgfkeysvalueof{/pgf/inner xsep}}},
minimum height of three nodes/.style n args={3}{
parse let={\p1=($(#1.north)-(#1.south)$),
\p2=($(#2.north)-(#2.south)$),
\p3=($(#3.north)-(#3.south)$),
\n@={max(\y1,\y2,\y3)}},
minimum height/.expanded={\n@}}}
\DeclareDocumentCommand{\tikzthreenodessameheight}{O{} m O{} m O{} m}{
\node[#1,alias=@1,overlay,path only,outer ysep=+0pt]{\phantom{#2}};
\node[#3,alias=@2,overlay,path only,outer ysep=+0pt]{\phantom{#4}};
\node[#5,alias=@3,overlay,path only,outer ysep=+0pt]{\phantom{#6}};
\node[#1,minimum height of three nodes={@1}{@2}{@3}] {#2};
\node[#3,minimum height of three nodes={@1}{@2}{@3}] {#4};
\node[#5,minimum height of three nodes={@1}{@2}{@3}] {#6};}
\begin{document}
\noindent
\begin{tikzpicture}[
background rectangle/.style={fill=gray!25},
show background rectangle, tight background,
trim left=-.5\textwidth, trim right=.5\textwidth,
every node/.style={outer sep=+0pt},
Yellow/.style={fill=yellow},
Blue/.style ={fill=blue, text=white},
Red/.style ={fill=red, align=center},
Green/.style ={fill=green, align=center},
node distance=+0pt
]
\tikzthreenodessameheight
[Yellow, name=sep]{}
[Blue, left=of sep, name=Blue-left,
text width between={-.5\textwidth,0 and sep.west}]
{scope 1, node 1 $\displaystyle e^x = \cfrac{1}{1 - \cfrac{x}{1 + x -
\cfrac{\frac{1}{2}x}{1 + \frac{1}{2}x - \ddots}}}$}
[Blue, right=of sep, text width between={ .5\textwidth,0 and sep.east}, name=Blue-right]
{scope 1, node 1};
\node[Red, below right=of Blue-left.south west] (Red-left) {scope 1,\\ node 2};
\node[Red, below right=of Blue-right.south west] (Red-right) {scope 1,\\ node 2};
\node[Green, below left=of Blue-left.south east,
text width between=Red-left.east and Blue-left.east]
(Red-left) {scope 1, node 3 that includes longer text to be broken into lines};
\node[Green, below left=of Blue-right.south east,
text width between=Red-right.east and Blue-right.east]
(Red-left) {scope 2, node 3 which also includes longer text to be broken into lines
\dots\ and here's an extra linre};
\end{tikzpicture}
\end{document}
Saída
Responder2
Com um raster tcbraster
(ou tcbitemize) from
tcolorbox \texwidth` por padrão, cada coluna raster tem largura igual, mas também é possível ajustá-las manualmente., we can leave the package to do all the work for us. The
use
\documentclass{article}
\usepackage[showframe]{geometry}
\usepackage[most]{tcolorbox}
\begin{document}
\begin{tcbitemize}[raster every box/.style={sharp corners,
fontupper=\sffamily, colupper=white, boxrule=0pt, halign=center},
raster left skip=0pt, raster right skip=0pt,
raster before skip=0pt, raster row skip=0pt,
raster after skip=0pt, raster valign=top]
\tcbitem[colback=blue!90!black] scope 1, node 1
\tcbitem[colback=blue!90!black] scope 2, node 1
\tcbitem[blankest, raster column skip=0pt]
\begin{tcbitemize}[raster force size=false]
\tcbitem[colback=red!90!black, width=.4\linewidth] scope 1, node 2
\tcbitem[colback=green!90!black, width=.6\linewidth] scope 1, node 3 that includes longer text to be broken into lines
\end{tcbitemize}
\tcbitem[blankest, raster column skip=0pt]
\begin{tcbitemize}[raster force size=false]
\tcbitem[colback=red!90!black, width=.4\linewidth] scope 2, node 2
\tcbitem[colback=green!90!black, width=.6\linewidth] scope 2, node 3 which also includes longer text to be broken into lines
\end{tcbitemize}
\end{tcbitemize}
\end{document}
Responder3
Tentei ficar próximo do seu código inicial. Porém, há uma questão não considerada: o que acontece se a altura do nó superior direito for maior que a altura do nó superior esquerdo. Uma solução poderia ser inverter a construção e o nó superior direito ser a referência.
O código
\documentclass{article}
\usepackage[showframe]{geometry}
\usepackage{lipsum}
\usepackage{tikz}
\usetikzlibrary{calc, positioning}
\begin{document}
\lipsum[1]
\bigskip
\tikzset{%
T/.style={blue!50!black, fill=blue!50!black, text=white,
minimum width=0.48\textwidth, text width=0.48\textwidth-1ex
},
BW/.style={green!50!black, fill=green!70!black, text=black,
minimum width=0.17\textwidth, text width=0.17\textwidth-1ex
},
BE/.style={red!75!black, fill=red!95!black, text=black,
minimum width=0.30\textwidth, text width=0.30\textwidth-1ex,
}
}
\noindent\begin{tikzpicture}[%
every node/.style={draw, inner sep=1ex, outer sep=0pt, align=center,
minimum height=7ex}
]
\node[T, anchor=north west] at (0, 0)
(nTW) {\bfseries \lipsum[2]};
\node[BW, below=0pt of nTW.south west, anchor=north west]
(n2) {scope 1, node 2};
\node[BE, below left=0pt and 0pt of n2.north east, anchor=north west]
(n3) {scope 1, node 3 that includes longer text to be broken into lines};
\path ($(nTW.south) -(nTW.north)$);
\pgfgetlastxy{\newW}{\newH}
\node[T, right=.02\textwidth of nTW.north east,
anchor=north west, minimum height={-\newH}]
(nTE) {\bfseries scope 2, node 1};
\node[BW, below=0pt of nTE.south west, anchor=north west]
(n2E) {scope 2, node 2};
\node[BE, below left=0pt and 0pt of n2E.north east, anchor=north west]
(n3E) {scope 2, node 3 that includes longer text to be broken
into lines; can be longer than the West corresponding node};
\fill[yellow!90!red] (nTW.north east) rectangle (nTE.south west);
\end{tikzpicture}
\end{document}
Responder4
Sugestão alternativa. Meu código é menos técnico (mas talvez também menos elegante?).
Você pode ajustar a largura do separador amarelo ( \yellowGap
no meu código), e a porcentagem da largura do nó 1 ( percentAmount
, um número inteiro entre 0 e 100, mas é melhor não escolher um valor muito próximo de 0 ou 100 para evitar muito colunas estreitas), para obter a largura do nó 2.
Por último, você pode ajustar o comprimento da separação interna nos nós \innerXSep
.
\documentclass[a4paper,10pt]{article}
\usepackage[showframe]{geometry}
\usepackage[x11names]{xcolor}
\usepackage{tikz}
\usetikzlibrary{calc}
\usepackage{calc}
\newlength{\yellowGap}
\setlength{\yellowGap}{3mm}
\newcounter{percentAmount}
\setcounter{percentAmount}{40}% =40% of the width of the first node. Value needs to be integer
\newlength{\innerXSep}
\setlength{\innerXSep}{.3333em}% default value
\newlength{\mainNodeWidth}
\setlength{\mainNodeWidth}{(\textwidth-\yellowGap)/2}
\newlength{\secondNodeWidth}
\setlength{\secondNodeWidth}{\mainNodeWidth*\value{percentAmount}/100}
\newlength{\thirdNodeWidth}
\setlength{\thirdNodeWidth}{\mainNodeWidth-\secondNodeWidth}
\begin{document}
\noindent\begin{tikzpicture}[outer sep=0pt,inner xsep=\innerXSep,text=white]
\node[text width=\mainNodeWidth-2\innerXSep,fill=DodgerBlue3,align=center] (mainLeft) {Scope 1, Node 1};
\node[text width=\secondNodeWidth-2\innerXSep,fill=Firebrick2,align=center,anchor=north west] (secondLeft) at (mainLeft.south west) {Scope 1,\\Node 2};
\node[text width=\thirdNodeWidth-2\innerXSep,fill=Green3,align=center,anchor=north west] (thirdLeft) at (secondLeft.north east) {Scope 1, Node 3\\ that includes longer text to be broken into lines};
\fill[DarkGoldenrod1] (mainLeft.north east) rectangle ($(mainLeft.south east)+(\yellowGap,0)$);
\node[text width=\mainNodeWidth-2\innerXSep,fill=DodgerBlue3,align=center,anchor=north west] (mainRight) at ($(mainLeft.north east)+(\yellowGap,0)$) {Scope 2, Node 1};
\node[text width=\secondNodeWidth-2\innerXSep,fill=Firebrick2,align=center,anchor=north west] (secondRight) at (mainRight.south west) {Scope 2,\\Node 2};
\node[text width=\thirdNodeWidth-2\innerXSep,fill=Green3,align=center,anchor=north west] at (secondRight.north east) {Scope 2, Node 3\\ which also includes longer text to be broken into lines};
\end{tikzpicture}
\end{document}
