Problema ao dimensionar cada foto (ângulos tikzlibrary)

Question

Olá a todos, preciso dimensionar uma imagem do tikz, então fiz isso, \begin{tikzpicture}[scale=<factor>]mas as fotos não são dimensionadas de acordo (é relatado no TikzManualseção 18.2 A sintaxe do Pic). Também quero fotos dimensionadas, então tentei a sintaxe, \begin{tikzpicture}[scale=0.4,every pic/.style={transform shape}]mas não funcionou. Usando transform shape como opção de cada foto, ou seja, \pic[angle radius=5.3cm,transform shape]está tudo bem, mas não quero usá-lo em todas as opções de \pics. Talvez seja um problema apenas com a biblioteca de ângulos (não tentei com outras fotos). Aqui estão meus MWEs, isso não funciona como esperado

    \documentclass[border=1cm]{standalone}
    \usepackage{tikz}
    \usetikzlibrary{calc,angles}
    \begin{document}
    %rotate vectors
\begin{tikzpicture}[vector/.style={thick,-stealth},scale=0.4,every pic/.style={transform shape}]
%drawing help lines
\newcommand*{\xmin}{-3}\newcommand*{\xmax}{4}
\newcommand*{\ymin}{-5}\newcommand*{\ymax}{1}
\draw[help lines](\xmin,\ymin)grid(\xmax,\ymax);
%vector coordinates and labels
\coordinate[label={above:$v$}] (O)at (0,0);
\coordinate (vec1)at (1,-2);
\coordinate (vec2)at(4,-1);
\draw[vector] (O)--(vec1)coordinate[label={[below]$u_1$}](u1);
%sum (vec1)+(vec2)
\draw[vector,very thick,blue](O)--($(vec1)+(vec2)$)coordinate(u1+u2);
%rotated sum (u1)+(u2) -> u'1+u'2
\draw[vector,very thick,orange](O)--([rotate=-90]u1+u2)coordinate(u'1+u'2);
%rotated vectors
\draw[red,vector] (0,0)--([rotate=-90]vec1)coordinate[label={[left]$u'_1$}](u'1);
%
\draw[red,vector] (0,0)--([rotate=-90]vec2)coordinate[label={[below]$u'_2$}](u'2);
%angles between vectors by angles library, issue with angle radius=
%default angle radius=1cm and it does not scale accordingly
\pic[draw=gray] {angle = u'1--O--u'2};
% rotation traces
\pic[draw=red,dashed,<-,angle radius=1.8cm]{angle=u'1--O--vec1};
\pic[draw=blue,dashed,<-,angle radius=5.3cm,]  {angle=u'1+u'2--O--u1+u2};
%vector sums labels
\coordinate[label={below:$w$}]() at(u1+u2);
\coordinate[label={below:$w'$}] ()at(u'1+u'2);
  % outgoing vector scaled accordingly but I'd rather prefer not
    \path[draw,fill=white] (O)circle[radius=2pt];
    \path[fill] (O)circle[radius=1pt];
    \end{tikzpicture}\end{document}

O seguinte funciona corretamente,

\documentclass[border=1cm]{standalone}
\usepackage{tikz}
\usetikzlibrary{calc,angles}
\begin{document}
%
%rotate vectors
\begin{tikzpicture}[vector/.style={thick,-stealth},scale=0.4 ] %every pic/.append style={transform shape}
%drawing help lines
\newcommand*{\xmin}{-3}\newcommand*{\xmax}{4}
\newcommand*{\ymin}{-5}\newcommand*{\ymax}{1}
\draw[help lines](\xmin,\ymin)grid(\xmax,\ymax);
%vector coordinates and labels
\coordinate[label={above:$v$}] (O)at (0,0);
\coordinate (vec1)at (1,-2);
\coordinate (vec2)at(4,-1);
\draw[vector] (O)--(vec1)coordinate[label={[below]$u_1$}](u1);
%sum (vec1)+(vec2)
\draw[vector,very thick,blue](O)--($(vec1)+(vec2)$)coordinate(u1+u2);
%rotated sum (u1)+(u2) -> u'1+u'2
\draw[vector,very thick,orange](O)--([rotate=-90]u1+u2)coordinate(u'1+u'2);
%rotated vectors
\draw[red,vector] (0,0)--([rotate=-90]vec1)coordinate[label={[left]$u'_1$}](u'1);
%
\draw[red,vector] (0,0)--([rotate=-90]vec2)coordinate[label={[below]$u'_2$}](u'2);
%angles between vectors by angles library, issue with angle radius=
%default angle radius=1cm and it does not scale accordingly
\pic[transform shape,draw=gray] {angle = u'1--O--u'2};
% rotation traces
\pic[draw=red,dashed,<-,angle radius=1.8cm,transform shape]{angle=u'1--O--vec1};
\pic[transform shape,draw=blue,dashed,<-,angle radius=5.3cm,]  {angle=u'1+u'2--O--u1+u2};
%vector sums labels
\coordinate[label={below:$w$}]() at(u1+u2);
\coordinate[label={below:$w'$}] ()at(u'1+u'2);

    % outgoing vector scaled accordingly but I'd rather prefer not
    \path[draw,fill=white] (O)circle[radius=2pt];
    \path[fill] (O)circle[radius=1pt];
\end{tikzpicture}
\end{document}

Talvez haja uma maneira melhor de conseguir isso, estou aberto a isso, mas não mudaria meu código do zero.

Tentei com every pic/.append style={transform shape}mas sem resultado aparente. Como efeito colateral, o raio devetor de saídanas últimas linhas do código é dimensionado, o que não quero.

Answer 1

Como você deseja anexar um estilo a cada \pic{angle}, você pode definir pics/angle/.append style={/tikz/transform shape}(você precisa indicar o caminho explicitamente, porque está dentro do \pic"diretório de caminho" aqui):

\documentclass[border=1cm]{standalone}
\usepackage{tikz}
\usetikzlibrary{calc, angles}

\begin{document}
%rotate vectors
\begin{tikzpicture}[
    vector/.style={thick,-stealth},
    scale=0.4,
    pics/angle/.append style={/tikz/transform shape}
]
    %drawing help lines
    \newcommand*{\xmin}{-3}\newcommand*{\xmax}{4}
    \newcommand*{\ymin}{-5}\newcommand*{\ymax}{1}
    \draw[help lines] (\xmin,\ymin) grid (\xmax,\ymax);
    %vector coordinates and labels
    \coordinate[label={above:$v$}] (O) at (0,0);
    \coordinate (vec1) at (1,-2);
    \coordinate (vec2) at (4,-1);
    \draw[vector] (O) -- (vec1)
        coordinate[label={[below]$u_1$}] (u1);
    %sum (vec1)+(vec2)
    \draw[vector,very thick,blue] (O)--($(vec1)+(vec2)$)
        coordinate (u1u2);
    %rotated sum (u1)+(u2) -> u'1+u'2
    \draw[vector,very thick,orange] (O)--([rotate=-90]u1u2)
        coordinate (u'1u'2);
    %rotated vectors
    \draw[red,vector] (0,0) -- ([rotate=-90]vec1)
        coordinate[label={[left]$u'_1$}] (u'1);
    %
    \draw[red,vector] (0,0) -- ([rotate=-90]vec2)
        coordinate[label={[below]$u'_2$}] (u'2);
    %angles between vectors by angles library, issue with angle radius=
    %default angle radius=1cm and it does not scale accordingly
    \pic[draw=gray] {angle={u'1--O--u'2}};
    % rotation traces
    \pic[draw=red, dashed, <-, angle radius=1.8cm] {angle={u'1--O--vec1}};
    \pic[draw=blue, dashed, <-, angle radius=5.3cm] {angle={u'1u'2--O--u1u2}};
    %vector sums labels
    \coordinate[label={below:$w$}] (w) at (u1u2);
    \coordinate[label={below:$w'$}] (w') at (u'1u'2);
    % outgoing vector scaled accordingly but I'd rather prefer not
    \path[draw, fill=white] (O) circle[radius=2pt];
    \path[fill] (O) circle[radius=1pt];
\end{tikzpicture}
\end{document}

Alterei alguns nomes das coordenadas porque não tenho certeza se um +nome é uma boa ideia. Sinta-se à vontade para aderir a isso ou não.

---

Se você não quiser que os círculos (O)sejam dimensionados, crie um \pica partir disso. Sabemos que \pics não são afetados pela escala e pics/angle/.append style={/tikz/transform shape}aplicamos transform shapeapenas ao \pic{angle}.

\documentclass[border=1cm]{standalone}
\usepackage{tikz}
\usetikzlibrary{calc, angles}

\begin{document}
%rotate vectors
\begin{tikzpicture}[
    vector/.style={thick,-stealth},
    scale=0.4,
    pics/angle/.append style={/tikz/transform shape},
    pics/origin/.style={
        code={
            \path[draw, fill=white] (0,0) circle[radius=2pt];
            \path[fill] (0,0) circle[radius=1pt];
        }
    }
]
    %drawing help lines
    \newcommand*{\xmin}{-3}\newcommand*{\xmax}{4}
    \newcommand*{\ymin}{-5}\newcommand*{\ymax}{1}
    \draw[help lines] (\xmin,\ymin) grid (\xmax,\ymax);
    %vector coordinates and labels
    \coordinate[label={above:$v$}] (O) at (0,0);
    \coordinate (vec1) at (1,-2);
    \coordinate (vec2) at (4,-1);
    \draw[vector] (O) -- (vec1)
        coordinate[label={[below]$u_1$}] (u1);
    %sum (vec1)+(vec2)
    \draw[vector,very thick,blue] (O)--($(vec1)+(vec2)$)
        coordinate (u1u2);
    %rotated sum (u1)+(u2) -> u'1+u'2
    \draw[vector,very thick,orange] (O)--([rotate=-90]u1u2)
        coordinate (u'1u'2);
    %rotated vectors
    \draw[red,vector] (0,0) -- ([rotate=-90]vec1)
        coordinate[label={[left]$u'_1$}] (u'1);
    %
    \draw[red,vector] (0,0) -- ([rotate=-90]vec2)
        coordinate[label={[below]$u'_2$}] (u'2);
    %angles between vectors by angles library, issue with angle radius=
    %default angle radius=1cm and it does not scale accordingly
    \pic[draw=gray] {angle={u'1--O--u'2}};
    % rotation traces
    \pic[draw=red, dashed, <-, angle radius=1.8cm] {angle={u'1--O--vec1}};
    \pic[draw=blue, dashed, <-, angle radius=5.3cm] {angle={u'1u'2--O--u1u2}};
    %vector sums labels
    \coordinate[label={below:$w$}] (w) at (u1u2);
    \coordinate[label={below:$w'$}] (w') at (u'1u'2);
    % outgoing vector scaled accordingly but I'd rather prefer not
    \pic at (O) {origin};
\end{tikzpicture}
\end{document}
