Como posso fazer com que as legendas das tabelas e figuras estejam alinhadas na lista de tabelas ou lista de figuras, meu problema é que a lista de figuras e a lista de tabelas estão saindo das margens da página.

\documentclass[b5paper, 12pt]{report}
\begin{document}
\tableofcontents
\listoffigures
\listoftables
% the table caption is long when it added to the list of tables.
\begin{table}%[position specifier]
 \centering
   \caption{Comparison with "Indirect Ident." method with a white noise disturbance}
\begin{tabular}{| l | l | l | l |l |}\hline
 method& criterion& 25dB & 15dB & 10dB \\ \hline
      \end{tabular}
\end{table}
\end{document}

Responder1

Se você estiver usando um pacote hyperrefcom um driver que não suporta links que quebram linhas (por exemplo, dvips), então a opção linktocpageajuda. Ele transforma o número da página em um link e remove o link inquebrável do título.

Arquivo de exemplo com David Carlislecitando correção:

\documentclass[b5paper, 12pt]{report}
\usepackage[
  colorlinks,
  linktocpage,
]{hyperref}

\begin{document}
\tableofcontents
\listoffigures
\listoftables
\begin{table}%[position specifier]
 \centering
   \caption{Comparison with ``Indirect Ident.'' method with a white noise
 disturbance}
\begin{tabular}{| l | l | l | l |l |}\hline
 method& criterion& 25dB & 15dB & 10dB \\ \hline
      \end{tabular}
\end{table}
\end{document}

Resultado
