O código a seguir envolve o corpo do texto em torno de uma imagem e do texto que a acompanha. Defina desta forma (com o \vfills) a imagem e o texto ficam centralizados verticalmente no recesso.
O que desejo alcançar é alinhar o texto abaixo da imagem com a grade da linha de base (abaixando ambos). Se eu omitir o último \vfilldentro do terceiro parâmetro \figflowo texto fica muito baixo.
Recursos: estou usando o XeTeX (para incluir a imagem),figflow.tex,caixa cinza.pnge grade de fundo retirada deesta resposta.
\newbox\gridbox
\setbox\gridbox\line{%
\special{color push rgb .8 .8 1}%
\vrule height\baselineskip width0pt \hrulefill
\special{color pop}}
\def\grid{\vtop to0pt{\hrule height0pt\kern-\dimexpr\baselineskip-\topskip\topskip=10pt\relax
\vbox to\dimexpr\vsize+2pt\relax{\leaders\copy\gridbox\vfil}\vss}}
\def\pagebody{\vbox to\vsize{\boxmaxdepth=\maxdepth \grid\pagecontents}}
\input figflow
\parskip=0pt \frenchspacing \raggedbottom
\font\smallrm=cmr8
\def\includegraphics#1#2#3#4{
{\parfillskip=0pt\par}\dimen0=#1
\dimen1=#2
\advance\dimen0 by 1pc
\setbox0=\vbox to #2{\hsize=#1
\XeTeXpicfile #3 width #1 height #2}
\setbox1=\vbox{\hsize=#1{\noindent\it #4\par}}
\advance\dimen1 by \ht1
\divide\dimen1 by \baselineskip
\multiply\dimen1 by \baselineskip
\advance\dimen1 by \baselineskip
\setbox2=\vbox to \dimen1{\vfil\box0\vskip2mm\box1}
\figflow{\dimen0}{\dimen1}{\vfill\box2\vfill}\noindent\ignorespaces}
\noindent
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more.%
\includegraphics{7cm}{7cm}{greybox.png}{Lorem ipsum dolor sit
amet, consectetur adipiscing elit. Donec a diam lectus.}
Especially pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
\bye
ATUALIZAR:
Emessecaso, onde \baselineskipo tamanho da fonte do texto abaixo da figura é igual ao do corpo do texto, consegui alinhar as linhas de base alterando a \figflowlinha para
\figflow{\dimen0}{\dimen1}{\vfill\box2\vskip0pt}\noindent\ignorespaces}
Por que inserir um \vskiptrabalho vazio? Observe que não funciona com outros tamanhos de fonte, nem com outros \baselineskips, nem mesmo ao inserir \struts dentro ou fora do grupo na caixa 1.
ATUALIZAÇÃO 2:
Graças à resposta do Wipet criei mais um MWE com um caso não tão incomum: quando a imagem e a legenda devem estar no canto inferior direito (ou esquerdo) de uma página:
\newbox\gridbox
\setbox\gridbox\line{%
\special{color push rgb .8 .8 1}%
\vrule height\baselineskip width0pt \hrulefill
\special{color pop}}
\def\grid{\vtop to0pt{\hrule height0pt\kern-\dimexpr\baselineskip-\topskip\topskip=10pt\relax
\vbox to\dimexpr\vsize+2pt\relax{\leaders\copy\gridbox\vfil}\vss}}
\def\pagebody{\vbox to\vsize{\boxmaxdepth=\maxdepth \grid\pagecontents}}
\input figflow
\parskip=0pt \frenchspacing \raggedbottom
\font\smallrm=cmr8
\def\includegraphics#1#2#3#4{%
{\parfillskip=0pt\par}
\dimen0=#1 \ifdim#1<0pt \dimen0=-\dimen0 \fi
\dimen1=#2
\dimen2=#1 \advance\dimen2 by \ifdim#1<0pt-\fi 1pc
\setbox0=\vbox {\XeTeXpicfile #3 width\dimen0 height #2}
\setbox1=\vbox{\hsize=\dimen0 \baselineskip=9.5pt\noindent\smallrm #4\par}
\advance\dimen1 by \ht1
\divide\dimen1 by \baselineskip
\multiply\dimen1 by \baselineskip
\advance\dimen1 by 1\baselineskip
\setbox2=\vbox to\dimen1{\vss\box0\vskip2mm\box1}
\figflow{\dimen2}{\dimen1}{}%
\line{\ifdim#1<0pt\hfill\fi\vtop to0pt{\kern0pt\box2\vss}\hfil}
\nobreak\vskip-\baselineskip
\noindent\ignorespaces}
\noindent
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more.
Especially pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages%
\includegraphics{-7cm}{7cm}{greybox.png}{Lorem ipsum dolor sit
amet, consectetur adipiscing elit. Donec a diam lectus.}
can optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
\bye
O problema é (eu acho) que em algum lugar \baselineskipestá inserido um que está sendo desfeito usando o \vskip-\baselineskipno final da macro. Isso \baselineskipfaz com que toda a imagem e o texto ao lado da imagem apareçam na próxima página. Ao mover a chamada para \includegraphicsuma linha acima (antes de Especially …), a imagem aparece na primeira página, mas com uma linha de corpo de texto abaixo da imagem e do texto da legenda.
ATUALIZAÇÃO 3:
A ejeção da página foi feita ao inserir a imagem no figflow.tex. Eu adicionei um \nobreakponto (marcado com ^^^) e a ejeção desapareceu:
% FIGFLOW: plain TEX macro by Ian Hutchinson, 21 Oct 95.
% Copyright 1995 Ian Hutchinson.
% You may freely use, modify, and/or distribute this file, without limitation.
% Make text flow round figure.
% Usage: \figflow{<width>}{<height>}{<[Figure+][Caption]>}
% at start of new paragraph. Figure top starts at insert.
% #1 figure width dimen. If negative, fig on right, else left.
% #2 figure height (including caption) dimen. (E.g.: 4 truein)
% #3 \special for figure if desired, then \vfill caption. (Both optional).
% Example: figflow{4 truein}{5 truein}{\epsfbox{figure.ps}\vfill Figure 1.}
% User is responsible for the figure fitting within the space defined.
% If figure won't fit on page, it is moved over the page break.
% If a new figflow starts before the old one is finished, a message is given
% and the second figure is skipped. Fix manually.
% Does not work for Latex.
\newdimen\pageremains\newdimen\pdepth
\newdimen\figwidth
\newdimen\figheight
\newcount\figlines
\newcount\flevel
\def\figflow#1#2#3{
\ifnum\flevel>0
\message{******Figure collision. Ignoring second figure.******}
\else
\figwidth=#1
\figheight=#2
\def\contents{#3}
% Put figure contents in an appropriate box.
\def\figure{\let\temp=\par \let\par=\plainpar
\line{\overfullrule=0pt% Avoid black box.
\ifdim \figwidth<0pt \hsize=-\figwidth \hss\else \hsize=\figwidth\fi
\advance \hsize by -10pt% Give a little extra hspace.
\vbox to \figheight{\vfil\noindent\contents}
\ifdim \figwidth>0pt \hss\fi
}\nobreak\vskip-\figheight
% ^^^^^^^^ inserted by MK
\let\par=\temp%
}
% […] remainder of file is the same
O único problema que existe agora é que as duas últimas linhas da página são movidas para a próxima (incluindo o encurtamento). Acho que tem algo a ver com \widowpenaltyand \clubpenalty, mas mexer nessas variáveis não resolveu o problema.
Quaisquer soluções melhores para os problemas acima mencionados também serão apreciadas.
ATUALIZAÇÃO 4:
Adicionar manualmente um \nobreak\̺após a última palavra no corpo do texto na primeira página (ou seja, depois de a variety of important) realmente resolve o problema mencionado na atualização 3, mas agora uma quebra de linha também é proibida neste ponto, resultando em uma linha (muito) estreita e hifenização desnecessária. Como resolver isso e, claro, como automatizar isso?
ATUALIZAÇÃO 5:
Ao fazer algum tipo de teste de estresse, encontrei outro problema. Eu adicionei duas macros \toppicturee, \midpicturerespectivamente, adicionei um \ejectou um \parantes de começar \includegraphics(por favor, não se intimide com este código pelo seu comprimento, a maior parte dele é texto fictício):
\newbox\gridbox
\setbox\gridbox\line{%
\special{color push rgb .8 .8 1}%
\vrule height\baselineskip width0pt \hrulefill
\special{color pop}}
\def\grid{\vtop to0pt{\hrule height0pt\kern-\dimexpr\baselineskip-\topskip\topskip=10pt\relax
\vbox to\dimexpr\vsize+2pt\relax{\leaders\copy\gridbox\vfil}\vss}}
\def\pagebody{\vbox to\vsize{\boxmaxdepth=\maxdepth \grid\pagecontents}}
\input figflow
\parskip=0pt \frenchspacing \raggedbottom
\widowpenalty=10000 \clubpenalty=10000
\font\smallrm=cmr8
%\toppicture params:
% #1 <dimen> width of picture
% #2 <dimen> height of picture
% #3 <string> file name
% #4 <string> caption text
\def\toppicture#1#2#3#4{%
{\parfillskip=0pt\par}\eject%
\includegraphics{#1}{#2}{#3}{#4}
}
%\midpicture params:
% #1 <dimen> width of picture
% #2 <dimen> height of picture
% #3 <string> file name
% #4 <string> caption text
\def\midpicture#1#2#3#4{%
{\parfillskip=0pt\par}
\includegraphics{#1}{#2}{#3}{#4}
}
\def\includegraphics#1#2#3#4{%
\dimen0=#1 \ifdim#1<0pt \dimen0=-\dimen0 \fi
\dimen2=#2
\dimen4=#1 \advance\dimen4 by \ifdim#1<0pt-\fi 1pc
\setbox0=\vbox {\XeTeXpicfile #3 width\dimen0 height #2}
\setbox2=\vbox{\hsize=\dimen0 \baselineskip=9.5pt\noindent\smallrm #4\par}
\advance\dimen2 by \ht2
\divide\dimen2 by \baselineskip
\multiply\dimen2 by \baselineskip
\advance\dimen2 by \baselineskip
\setbox4=\vbox to\dimen2{\vss\box0\vskip2mm\box2}
\figflow{\dimen4}{\dimen2}{}
\line{\ifdim#1<0pt\hfill\fi\vtop to0pt{\kern0pt\box4\vss}\hfil}
\nobreak\vskip-\baselineskip
\noindent\ignorespaces}
\noindent
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more.
Especially pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more.
Especially pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages
\midpicture{-7cm}{7cm}{greybox.png}{Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec a diam lectus.}
can optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode,
%\midpicture{7cm}{7cm}{greybox.png}{Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec a diam lectus.}
namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more.
These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI
\midpicture{7cm}{7cm}{greybox.png}{Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec a diam lectus.}
or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
%\toppicture{7cm}{7cm}{greybox.png}{Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec a diam lectus.}
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important %\nobreak\
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
\bye
Primeiro, comente o segundo \midpicture(deve estar na linha 169) e execute o XeTeX. De uma forma ou de outra, agora posso deixar de fora as alterações que fiz na atualização 3 (adicionando \nobreakao figflow.tex) e na atualização 4 (adicionando \nobreak\à cópia de origem) e tudo está bem composto. Isso é muito estranho, pois não mudei mais nada, até onde eu sei. O texto flui corretamente ao redor da imagem e da legenda da imagem.
Por favor, agora descomente a \midpicturechamada que você acabou de comentar e execute o TeX novamente. Agora ele reclama da inserção de um }logo antes de um arquivo \endgroup. Isso parece estranho para mim. o que acontece aqui?
Terceiro, comente essa linha novamente e descomente a \midpicturelinha 149. Agora o figflow.tex reclamará de uma colisão de figuras, provavelmente porque não terminou o processamento das linhas ao lado da primeira imagem, embora eu tenha chamado a \midpicturemacro após a última palavra da linha . Isto implica que não se pode colocar duas imagens imediatamente uma abaixo da outra (elas não deveriam colidir). Como evitar essa colisão?
Quarto, comente a linha 149 novamente e remova o comentário do único \toppicture, na linha 178. Estranhamente, desta vez o TeX não engasga em uma segunda chamada para \figflowgostar de quando a linha 169 foi descomentada. O resultado são duas páginas digitadas corretamente e uma nova página com a imagem no canto superior esquerdo. Só que agora tudo (corpo do texto, imagem e legenda da imagem) está um pouco fora da grade. O que há de errado aqui?
Responder1
Sugiro usar o \figflowapenas para criar espaço apropriado para a foto e colocar a foto sob nosso controle.
\def\includegraphics#1#2#3#4{
{\parfillskip=0pt\par}\dimen0=#1
\dimen1=#2
\advance\dimen0 by 1pc
\setbox0=\vbox to #2{\hsize=#1
\XeTeXpicfile #3 width #1 height #2}
\setbox1=\vbox{\hsize=#1{\noindent\it #4\par}}
\advance\dimen1 by \ht1
\divide\dimen1 by \baselineskip
\multiply\dimen1 by \baselineskip
\advance\dimen1 by 1\baselineskip
\setbox2=\vbox to \dimen1{\vfil\box0\vskip2mm\box1}
% PO changes in OP's code:
\figflow{\dimen0}{\dimen1}{}%
\vtop to0pt{\kern0pt\box2\vss}\nobreak\vskip-\baselineskip
\noindent\ignorespaces}
Se você definir \kern-\baselineskipem vez de \kern0ptdentro \vtop, a imagem será colocada em uma linha.
Editar: considerando ao comentário adicionei a segunda versão do código, onde o \baselineskiptexto abaixo da imagem pode ser arbitrário e o primeiro parâmetro da \includegraphicsmacro pode ser negativo. Em seguida, o \dimen0valor absoluto deste parâmetro \dimen2é introduzido como #1mais ou menos 1pc (adiciona a margem na dependência do sinal de #1).
\def\includegraphics#1#2#3#4{%
{\parfillskip=0pt\par}
\dimen0=#1 \ifdim#1<0pt \dimen0=-\dimen0 \fi
\dimen1=#2
\dimen2=#1 \advance\dimen2 by \ifdim#1<0pt-\fi 1pc
\setbox0=\vbox {\XeTeXpicfile #3 width\dimen0 height #2}
\setbox1=\vbox{\hsize=\dimen0 \noindent\it #4\par}
\advance\dimen1 by \ht1
\divide\dimen1 by \baselineskip
\multiply\dimen1 by \baselineskip
\advance\dimen1 by 1\baselineskip
\setbox2=\vbox to\dimen1{\vss\box0\vskip2mm\box1}
\figflow{\dimen2}{\dimen1}{}%
\line{\ifdim#1<0pt\hfill\fi\vtop to0pt{\kern0pt\box2\vss}\hfil}
\nobreak\vskip-\baselineskip
\noindent\ignorespaces}
Editar2:Considerando as atualizações da sua pergunta, decidi que você pode tentar a macro \oblomdo meu livroTeXbook naruby(páginas 236 e 237). A versão completa em PDF deste livro está disponível, mas apenas em idioma tcheco.
O nome da macro \oblomé derivado da palavra tcheca "fazer composição em torno de algo". Esta macro cria um espaço retangular branco no próximo parágrafo (ou mais parágrafos). Meu próximo código aqui usa essa macro (mas renomeia as palavras separadoras). O uso desta macro é:
\oblom <width> from <linenum1> indent <linenum2>
onde <width>é a largura do espaço retangular, <linenum1>é o número da primeira linha recuada e <linenum2>é o número de linhas recuadas. Se <width>for negativo, o espaço retangular estará no lado direito. Por exemplo:
\oblom 5cm from 3 indent 5
significa que cinco linhas serão recuadas 5 cm da terceira linha (incluindo esta). As duas primeiras linhas não são recuadas e têm largura normal.
A macro \oblomdeve ser usada entre parágrafos e influencia a forma do próximo ou mais parágrafos. A principal vantagem é que você não precisa parar o parágrafo exatamente no local onde começa o recuo. Observe seus exemplos anteriores onde você deve fazer {\parfillskip=0pt\par}o que traz complicações.
Meu próximo código usa \oblome define a macro \flowpic:
\flowpic from <linenum> width <width> {<picfile>} {<caption>}
Por exemplo
\flowpic from 3 width -7cm {greybox.png}
{Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec a diam lectus.}
insere a imagem greybox.pngcom a legenda fornecida da terceira linha do próximo parágrafo no lado direito. A largura da imagem será de 7 cm menos 1 unidade porque 1 unidade é a margem entre a imagem e o texto. Você não precisa usar o pckage figflow.
O código consiste em três partes. A primeira parte é a definição da \oblommacro copiada deTeXbook naruby. Esta macro calcula \parshapeparâmetros e usa arquivos \parshape. A segunda parte define a macro \picpara inserção de imagens com determinada largura. As definições dependem do fato de o XeTeX ser ou não usado. A terceira parte declara \flowpicquais usos \oblome \pic. A macro flowpic insere a imagem na mesma página onde ela é usada se houver espaço suficiente. Caso contrário, o flowpic insere a imagem na próxima página, onde terminam os últimos parágrafos com formato modificado.
\newcount\shapenum \newcount\tempnum \newcount\globpar
\newdimen\ii \newdimen\ww
\newdimen\picwidth \newbox\picbox
\catcode`\@=11
\def\oblom #1 from #2 indent #3 {\par \ii=#1 \ww=\hsize
\ifdim\ii>\z@ \advance\ww by-\ii
\else \advance\ww by\ii \ii=\z@ \fi
\shapenum=1 \tempnum=0 \def\shapelist{}
\loop \ifnum\shapenum<#2 \edef\shapelist{\shapelist\z@\hsize}
\advance\shapenum by1 \repeat
\loop \edef\shapelist{\shapelist\ii\ww}
\advance\tempnum by1 \ifnum\tempnum<#3 \repeat
\advance\shapenum by#3 \edef\shapelist{\shapelist\z@\hsize}
\doshape}
\catcode`\@=12
\def\doshape{\globpar=0 \def\par{\ifhmode\shapepar\fi}}
\def\shapepar{\prevgraf=\globpar \parshape\shapenum\shapelist
\endgraf \globpar=\prevgraf
\ifnum \prevgraf<\shapenum\else \global\let\par=\endgraf \doshapeA \fi}
\ifx\XeTeXpicfile\undefined
\def\pic #1{\hbox{\pdfximage width\picwidth {#1}\pdfrefximage\pdflastximage}}
\else
\def\pic #1{\hbox{\XeTeXpicfile #1 width\picwidth}}
\fi
\def\flowpic from #1 width #2 #3#4{\par
\dimen0=#2 \ifdim\dimen0<0pt \dimen0=-\dimen0 \fi
\advance\dimen0 by -1pc %(margin around picture)
\picwidth=\dimen0
\setbox0=\vbox{\hsize\dimen0 \pic{#3}\kern 2mm
\emergencystretch=2em \noindent\it #4}
\dimen0=\ht0
\divide\dimen0 by\baselineskip \advance\dimen0 by1sp
\oblom #2 from #1 indent \dimen0
\multiply\dimen0 by\baselineskip
\setbox\picbox=\vbox to\dimen0{\vss\box0}
\dimen0=\pagegoal \ifdim\pagegoal=\maxdimen \dimen0=\vsize\fi
\advance\dimen0 by-\pagetotal \advance\dimen0 by-#1\baselineskip
\ifdim\dimen0<0pt
\def\doshapeA{\tempnum=\prevgraf \advance\tempnum by-#1 \advance\tempnum by2
\line{\ifdim#2<0pt \hfill\fi \vbox to0pt{\vss\vtop to0pt{\kern0pt\box\picbox\vss}%
\kern\the\tempnum\baselineskip}\hfil}
\nobreak\vskip-\baselineskip
}
\else \def\doshapeA{}
\line{\ifdim#2<0pt \hfill\fi
\vtop to0pt{\kern-2\baselineskip\kern#1\baselineskip\box\picbox\vss}\hfil}
\nobreak\vskip-\baselineskip
\fi
}
\parindent=0pt \raggedbottom % we need the grid
A limitação desta macro é: não é possível colocar a imagem na “borda” da página onde está a quebra de página. Somente antes ou depois dessa quebra de página. Você não pode inserir duas imagens em um parágrafo. O próximo uso de \flowpicé permitido somente antes do parágrafo onde não há linhas recuadas por previous \flowpic. Se você tem um parágrafo muito longo e precisa colocar dois \flowpics aqui, então você precisa usar o truque conhecido {\parfillskip=0pt\par}para fechar o parágrafo "invisível" anterior.
