Eu tenho uma figura, contendo três subfiguras com legendas e uma legenda para a figura inteira, que juntas ocupam mais do que uma página inteira.
Posso alterar a geometria da página específica onde a figura aparece para ajustá-la, mas o LaTex deixa espaços em branco, pois a alteração da geometria parece criar uma quebra de página onde ela é inserida. Tentei colocar as alterações de geometria dentro do float, para que o LaTex pudesse tratá-lo como um float e apenas alterar o tamanho da página em que a figura aparecia, mas isso me deu vários erros.
Também tentei colocar a figura exatamente onde quero no documento, mas isso está dentro de um parágrafo, que está quebrado pela figura. Para fazer aparecer visualmente é se o parágrafo continuar depois da figura, tentei \newlineestender a última linha da página antes da figura e \noindentna próxima fazer aparecer se não houver novo parágrafo, mas aí acho que \newlinecomeça um nova linha que resulta em uma página inteira em branco antes da minha figura, o que não é o que eu quero.
Eu também tentei usar o \makeboxcomando. Isso funciona se eu inserir cada um subfiguredentro de uma caixa, mas não sei como diminuir a margem superior, necessária para caber. Também preciso deixar a legenda da figura inteira mais larga, mas ao criar uma caixa mais larga que \textwidthas coisas não ficam mais centralizadas, e quando tento colocar a figura inteira dentro do makebox, ela não compila.
Existe uma maneira de fazer um float maior que uma página para se comportar bem ou esticar uma linha para caber \textwidthsem iniciar uma nova linha, como \newlineparece acontecer?
Como parece que minha pergunta não está clara, acredito que devo fornecer um exemplo de código. Lamento a extensão, mas se você compilar, acho que será bastante fácil entender qual é o meu problema. Se não, diga-me e tentarei perguntar melhor. Não sei como adicionar o documento compilado à pergunta, ou saberia.
\documentclass[twocolumn]{article}
\usepackage[utf8]{inputenc}
\usepackage[english]{babel}
\usepackage{sectsty}
\usepackage[margin=1in]{geometry}
\usepackage{braket}
\usepackage{amsmath}
\usepackage[demo]{graphicx}
\usepackage{subcaption}
\usepackage{float}
\usepackage{tikz}
\usepackage{lipsum}
\begin{document}
\section{See last part of this section}
\lipsum[1-8]
\noindent\makebox[\linewidth]{\rule{0.5\textwidth}{1pt}}
\textbf{\large{And then there is some more text which I made large and bold here so you wont miss is. The important thing is that there is a paragraph right before the figure, and I don't what that to leave a pretty much empty page as it has here.}}
\onecolumn
\begin{figure}
\centering
\makebox[1\textwidth][c]{
\begin{subfigure}{1.2\textwidth}
\begin{tikzpicture}
\node at(0,0) {\includegraphics[width=0.5\textwidth]{x}};
\node at(0.5\textwidth,0) {\includegraphics[width=0.5\textwidth]{x}};
\end{tikzpicture}
\caption{\textbf{\large{All captions to this figure are really long, and at you can see they don't fit into the page.}} Readout spectra of the transitions from $\ket{\pm 5/2 g}$ to all three excited states and the transition $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz in the spectra. (left) The three peaks corresponding to the transitions $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$, $\ket{\pm 5/2 g} \rightarrow \ket{\pm 3/2 e}$ and $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$, positioned at 0, 2 and 6 MHz respectively, are present as expected. However, there is also a peak at $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz. This comes from some unwanted ion class, and must therefore be some other transition than $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$. (right) After burning at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ the two first peaks disappear. The last one, corresponding to $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$ is still there, although somewhat smaller. This means that also in this peak there are unwanted ions from some other ions class. The peak at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ is still there and has become bigger, as expected.}
\end{subfigure}}
\makebox[1\textwidth][c]{
\begin{subfigure}{1.2\textwidth}
\begin{tikzpicture}
\node at(0,0) {\includegraphics[width=0.5\textwidth]{x}};
\node at(0.5\textwidth,0) {\includegraphics[width=0.5\textwidth]{x}};
\end{tikzpicture}
\caption{Another really long caption. Readout spectra of the transitions from $\ket{\pm 5/2 g}$ to all three excited states and the transition $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz in the spectra. (left) The three peaks corresponding to the transitions $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$, $\ket{\pm 5/2 g} \rightarrow \ket{\pm 3/2 e}$ and $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$, positioned at 0, 2 and 6 MHz respectively, are present as expected. However, there is also a peak at $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz. This comes from some unwanted ion class, and must therefore be some other transition than $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$. (right) After burning at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ the two first peaks disappear. The last one, corresponding to $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$ is still there, although somewhat smaller. This means that also in this peak there are unwanted ions from some other ions class. The peak at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ is still there and has become bigger, as expected.}
\end{subfigure}}
\makebox[1\textwidth][c]{
\begin{subfigure}{1.2\textwidth}
\begin{tikzpicture}
\node at(0,0) {\includegraphics[width=0.5\textwidth]{x}};
\node at(0.5\textwidth,0) {\includegraphics[width=0.5\textwidth]{x}};
\end{tikzpicture}
\caption{A this really long caption. Readout spectra of the transitions from $\ket{\pm 5/2 g}$ to all three excited states and the transition $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz in the spectra. (left) The three peaks corresponding to the transitions $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$, $\ket{\pm 5/2 g} \rightarrow \ket{\pm 3/2 e}$ and $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$, positioned at 0, 2 and 6 MHz respectively, are present as expected. However, there is also a peak at $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz. This comes from some unwanted ion class, and must therefore be some other transition than $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$. (right) After burning at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ the two first peaks disappear. The last one, corresponding to $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$ is still there, although somewhat smaller. This means that also in this peak there are unwanted ions from some other ions class. The peak at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ is still there and has become bigger, as expected.}
\end{subfigure}}
\onecolumn
\caption{And a caption for the whole figure. Readout spectra of the transitions from $\ket{\pm 5/2 g}$ to all three excited states and the transition $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz in the spectra. (left) The three peaks corresponding to the transitions $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$, $\ket{\pm 5/2 g} \rightarrow \ket{\pm 3/2 e}$ and $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$, positioned at 0, 2 and 6 MHz respectively, are present as expected. However, there is also a peak at $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz. This comes from some unwanted ion class, and must therefore be some other transition than $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$. (right) After burning at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ the two first peaks disappear. The last one, corresponding to $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$ is still there, although somewhat smaller. This means that also in this peak there are unwanted ions from some other ions class. The peak at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ is still there and has become bigger, as expected.}
\twocolumn
\end{figure}
\twocolumn
\section{Then I tried the geometry package, please read the last paragraph also here}
\lipsum[1-7]
\vspace{100pt}
\noindent\makebox[\linewidth]{\rule{0.5\textwidth}{1pt}}
\textbf{\large{The geometry package has worked best so far.}} Then I can make the figure fit by changing the top margin. However I still have the
\newgeometry{textwidth=19.5cm,textheight=29cm,top=1.5cm, bottom=3cm}
\begin{figure*}
\centering
\includegraphics[scale=1]{x}
\caption{Let's skip the figure as you now know why it is too big.}
\end{figure*}
\restoregeometry
problem that the figure does not fit nicely within the paragraph, but a lot of white space appears. I tried to avoid this by placing the figure exactly where I wanted it within the paragraph. As you can see, the paragraph is broken by the figure, which does not seem to be allowed to float and just change the geometry of the page it happens to appear on. Do you see my problem?
\section{Then I tried to avoid the breaking of the paragraph, at least visually}
\lipsum[1-6]
\vspace{120pt}
\noindent\makebox[\linewidth]{\rule{0.5\textwidth}{1pt}}
So I tried to visually make it seem as there was not break in the paragraph by using the \textbackslash newline and \textbackslash noindent commands, but as you can see, this gave me an entire blank page before the figure which I \newline
\newgeometry{textwidth=19.5cm,textheight=29cm,top=1.5cm, bottom=3cm}
\begin{figure*}
\centering
\includegraphics[scale=1]{x}
\caption{I've been using the starred figure because I want the figure to span the entire page, as I have a twocolumn environment otherwise.}
\end{figure*}
\restoregeometry
\noindent don't know how to get rid of!
I hope my question(s) are more clear now. And I am sorry for all the messy code, but I do think it is essential for understanding my problem. I hope you can help me. :)
\end{document}
Responder1
a página em branco após o parágrafo em negrito é simplesmente porque você forçou uma quebra de página com \onecolumn. Não tenho certeza do layout que você deseja, mas você deseja evitar quebras forçadas e usar o *formulário para permitir flutuações em toda a página, algo como
\documentclass[twocolumn]{article}
\usepackage[utf8]{inputenc}
\usepackage[english]{babel}
\usepackage{sectsty}
\usepackage[margin=1in]{geometry}
\usepackage{braket}
\usepackage{amsmath}
\usepackage[demo]{graphicx}
\usepackage{subcaption}
\usepackage{float}
\usepackage{tikz}
\usepackage{lipsum}
\newenvironment{outdent}
{\list{}{\leftmargin-1cm
\rightmargin\leftmargin}%
\item\relax}
{\endlist}
\begin{document}
\section{See last part of this section}
\lipsum[1-8]
\noindent\makebox[\linewidth]{\rule{0.5\textwidth}{1pt}}
\textbf{\large{And then there is some more text which I made large and bold here so you wont miss is. The important thing is that there is a paragraph right before the figure, and I don't what that to leave a pretty much empty page as it has here.}}
\begin{figure*}
\vspace*{-50pt}
\begin{outdent}
\centering
\makebox[1\textwidth][c]{
\begin{subfigure}{1.2\textwidth}
\begin{tikzpicture}
\node at(0,0) {\includegraphics[width=0.5\textwidth]{x}};
\node at(0.5\textwidth,0) {\includegraphics[width=0.5\textwidth]{x}};
\end{tikzpicture}
\caption{\textbf{\large{All captions to this figure are really long, and at you can see they don't fit into the page.}} Readout spectra of the transitions from $\ket{\pm 5/2 g}$ to all three excited states and the transition $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz in the spectra. (left) The three peaks corresponding to the transitions $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$, $\ket{\pm 5/2 g} \rightarrow \ket{\pm 3/2 e}$ and $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$, positioned at 0, 2 and 6 MHz respectively, are present as expected. However, there is also a peak at $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz. This comes from some unwanted ion class, and must therefore be some other transition than $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$. (right) After burning at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ the two first peaks disappear. The last one, corresponding to $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$ is still there, although somewhat smaller. This means that also in this peak there are unwanted ions from some other ions class. The peak at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ is still there and has become bigger, as expected.}
\end{subfigure}}
\makebox[1\textwidth][c]{
\begin{subfigure}{1.2\textwidth}
\begin{tikzpicture}
\node at(0,0) {\includegraphics[width=0.5\textwidth]{x}};
\node at(0.5\textwidth,0) {\includegraphics[width=0.5\textwidth]{x}};
\end{tikzpicture}
\caption{Another really long caption. Readout spectra of the transitions from $\ket{\pm 5/2 g}$ to all three excited states and the transition $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz in the spectra. (left) The three peaks corresponding to the transitions $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$, $\ket{\pm 5/2 g} \rightarrow \ket{\pm 3/2 e}$ and $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$, positioned at 0, 2 and 6 MHz respectively, are present as expected. However, there is also a peak at $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz. This comes from some unwanted ion class, and must therefore be some other transition than $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$. (right) After burning at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ the two first peaks disappear. The last one, corresponding to $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$ is still there, although somewhat smaller. This means that also in this peak there are unwanted ions from some other ions class. The peak at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ is still there and has become bigger, as expected.}
\end{subfigure}}
\makebox[1\textwidth][c]{
\begin{subfigure}{1.2\textwidth}
\begin{tikzpicture}
\node at(0,0) {\includegraphics[width=0.5\textwidth]{x}};
\node at(0.5\textwidth,0) {\includegraphics[width=0.5\textwidth]{x}};
\end{tikzpicture}
\caption{A this really long caption. Readout spectra of the transitions from $\ket{\pm 5/2 g}$ to all three excited states and the transition $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz in the spectra. (left) The three peaks corresponding to the transitions $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$, $\ket{\pm 5/2 g} \rightarrow \ket{\pm 3/2 e}$ and $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$, positioned at 0, 2 and 6 MHz respectively, are present as expected. However, there is also a peak at $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz. This comes from some unwanted ion class, and must therefore be some other transition than $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$. (right) After burning at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ the two first peaks disappear. The last one, corresponding to $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$ is still there, although somewhat smaller. This means that also in this peak there are unwanted ions from some other ions class. The peak at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ is still there and has become bigger, as expected.}
\end{subfigure}}
\caption{And a caption for the whole figure. Readout spectra of the transitions from $\ket{\pm 5/2 g}$ to all three excited states and the transition $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz in the spectra. (left) The three peaks corresponding to the transitions $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$, $\ket{\pm 5/2 g} \rightarrow \ket{\pm 3/2 e}$ and $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$, positioned at 0, 2 and 6 MHz respectively, are present as expected. However, there is also a peak at $\ket{\pm 1/2 g} \rightarrow \ket{\pm 5/2 e}$ at 4 MHz. This comes from some unwanted ion class, and must therefore be some other transition than $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$. (right) After burning at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ the two first peaks disappear. The last one, corresponding to $\ket{\pm 5/2 g} \rightarrow \ket{\pm 5/2 e}$ is still there, although somewhat smaller. This means that also in this peak there are unwanted ions from some other ions class. The peak at $\ket{\pm 5/2 g} \rightarrow \ket{\pm 1/2 e}$ is still there and has become bigger, as expected.}
\vspace*{-5pt}
\end{outdent}
\end{figure*}
\section{Then I tried the geometry package, please read the last paragraph also here}
\lipsum[1-7]
\vspace{100pt}
\noindent\makebox[\linewidth]{\rule{0.5\textwidth}{1pt}}
\textbf{\large{The geometry package has worked best so far.}} Then I can make the figure fit by changing the top margin. However I still have the
\begin{figure*}
\begin{outdent}
\centering
\includegraphics[scale=1]{x}
\caption{Let's skip the figure as you now know why it is too big.}
\end{outdent}
\end{figure*}
problem that the figure does not fit nicely within the paragraph, but a lot of white space appears. I tried to avoid this by placing the figure exactly where I wanted it within the paragraph. As you can see, the paragraph is broken by the figure, which does not seem to be allowed to float and just change the geometry of the page it happens to appear on. Do you see my problem?
\section{Then I tried to avoid the breaking of the paragraph, at least visually}
\lipsum[1-6]
\vspace{120pt}
\noindent\makebox[\linewidth]{\rule{0.5\textwidth}{1pt}}
So I tried to visually make it seem as there was not break in the paragraph by using the \textbackslash newline and \textbackslash noindent commands, but as you can see, this gave me an entire blank page before the figure which I \newline
\begin{figure*}
\centering
\includegraphics[scale=1]{x}
\caption{I've been using the starred figure because I want the figure to span the entire page, as I have a twocolumn environment otherwise.}
\end{figure*}
\noindent don't know how to get rid of!
I hope my question(s) are more clear now. And I am sorry for all the messy code, but I do think it is essential for understanding my problem. I hope you can help me. :)
\end{document}
Responder2
No MWE, o texto de \lipsum[4]pega na página 1, evitando assim o espaço vazio no final da página ao qual o OP fazia referência.
Usei um \makebox[\textwidth]{}para estender uma imagem extra larga além das margens horizontais. Usei a \smashpara reduzir a extensão vertical da imagem. Porém, apenas isso deixaria a legenda no meio da página verticalmente, então tive que adicionar um \ruleà imagem minipage, para empurrar a legenda para baixo, sendo a extensão da regra menor \textheighte regendo a localização final da legenda.
\documentclass[11pt]{report}
\usepackage[demo]{graphicx}
\usepackage{lipsum}
\begin{document}
\lipsum[1-3]
\begin{figure}[p]
\begin{minipage}{\textwidth}
\rule{0pt}{7.5in}%
\smash{\makebox[\textwidth]{\includegraphics[width=7in,height=8.5in]{x}}}
\end{minipage}
\caption{this is my figure caption}
\end{figure}
\lipsum[4-9]
\end{document}
