Tento visualizar a convolução 2D como uma imagem carregada.visualização de convolução 2D

$\begin{tabular}{|l|l|l|l|l|l|l|}
        \hline
        0 & 1 & 1 & 1 & 0 & 0 & 0 \\ \hline
        0 & 0 & 1 & 1 & 1 & 0 & 0 \\ \hline
        0 & 0 & 0 & 1 & 1 & 1 & 0 \\ \hline
        0 & 0 & 0 & 1 & 1 & 0 & 0 \\ \hline
        0 & 0 & 1 & 1 & 0 & 0 & 0 \\ \hline
        0 & 1 & 1 & 0 & 0 & 0 & 0 \\ \hline
        0 & 1 & 0 & 0 & 0 & 0 & 0 \\ \hline
    \end{tabular} \ast $
$
\begin{tabular}{|l|l|l|}
    \hline
    1 & 0 & 1 \\ \hline
    0 & 1 & 0 \\ \hline
    1 & 0 & 1 \\ \hline
\end{tabular} = $

\begin{tabular}{|l|l|l|l|l|}
    \hline
    1 & 4 & 3 & 4 & 1 \\ \hline
    1 & 2 & 4 & 3 & 3 \\ \hline
    1 & 2 & 3 & 4 & 1 \\ \hline
    1 & 3 & 3 & 1 & 1 \\ \hline
    3 & 3 & 1 & 1 & 0 \\ \hline
\end{tabular}

Como posso visualizar e desenhar linhas pontilhadas como na imagem acima.

Agradeço antecipadamente por sua ajuda

Responder1

Bem-vindo! Com TikMatrizes Z são fáceis.

\documentclass[tikz,border=3mm]{standalone}
\usetikzlibrary{matrix,positioning,fit,backgrounds}
\begin{document}
\begin{tikzpicture}[mmat/.style={matrix of math nodes,column sep=-\pgflinewidth/2,
   row sep=-\pgflinewidth/2,cells={nodes={draw,inner sep=2pt,thin}},draw=#1,thick,inner sep=0pt},
   mmat/.default=black,
   node distance=0.3em]
 \matrix[mmat](mat1){
         0 & 1 & 1 & 1 & 0 & 0 & 0 \\
         0 & 0 & 1 & 1 & 1 & 0 & 0 \\
         0 & 0 & 0 & 1 & 1 & 1 & 0 \\
         0 & 0 & 0 & 1 & 1 & 0 & 0 \\
         0 & 0 & 1 & 1 & 0 & 0 & 0 \\
         0 & 1 & 1 & 0 & 0 & 0 & 0 \\
         0 & 1 & 0 & 0 & 0 & 0 & 0 \\
         };
 \node[fit=(mat1-1-4)(mat1-3-6),inner sep=0pt,draw,red,thick](f1){};
 \node[right=of mat1] (mul) {$*$};
 \matrix[mmat=blue,fill=blue!20,right=of mul](mat2){
     1 & 0 & 1 \\
     0 & 1 & 0 \\
     1 & 0 & 1 \\ };
 \node[right=of mat2] (eq) {$=$};
 \matrix[mmat,right=of eq](mat3){
     1 & 4 & 3 & |[draw=green,thick,fill=green!20,alias=4]|4 & 1 \\
     1 & 2 & 4 & 3 & 3 \\
     1 & 2 & 3 & 4 & 1 \\
     1 & 3 & 3 & 1 & 1 \\
     3 & 3 & 1 & 1 & 0 \\
 };
 \foreach \Anchor in {south west,north west,south east,north east}
 {\draw[blue,densely dotted] (f1.\Anchor) -- (mat2.\Anchor);
 \draw[green,densely dotted] (4.\Anchor) -- (mat2.\Anchor);}
 \begin{scope}[on background layer]
  \fill[red!20] (f1.north west) rectangle (f1.south east);
 \end{scope}
\end{tikzpicture}
\end{document}

insira a descrição da imagem aqui

Ou com as pequenas entradas nos cantos inferiores direitos da submatriz vermelha. As bordas pontilhadas param na matriz esquerda para obter um efeito semelhante ao 3D.

\documentclass[tikz,border=3mm]{standalone}
\usetikzlibrary{matrix,positioning,fit,backgrounds,intersections}
\begin{document}
\begin{tikzpicture}[mmat/.style={matrix of math nodes,column sep=-\pgflinewidth/2,
   row sep=-\pgflinewidth/2,cells={nodes={draw,inner sep=3pt,thin}},draw=#1,thick,inner sep=0pt},
   mmat/.default=black,
   node distance=0.3em]
 \matrix[mmat](mat1){
         0 & 1 & 1 & 1 & 0 & 0 & 0 \\
         0 & 0 & 1 & 1 & 1 & 0 & 0 \\
         0 & 0 & 0 & 1 & 1 & 1 & 0 \\
         0 & 0 & 0 & 1 & 1 & 0 & 0 \\
         0 & 0 & 1 & 1 & 0 & 0 & 0 \\
         0 & 1 & 1 & 0 & 0 & 0 & 0 \\
         0 & 1 & 0 & 0 & 0 & 0 & 0 \\
         };
 \def\myarray{{1,0,1},{0,1,0},{1,0,1}}
 \foreach \X in {0,1,2}
 {\foreach \Y in {0,1,2}
  {\pgfmathsetmacro{\myentry}{{\myarray}[\Y][\X]}
  \path (mat1-\the\numexpr\Y+1\relax-\the\numexpr\X+4\relax.south east)
  node[anchor=south east,blue,scale=0.3,inner sep=1.2pt]{$\times\myentry$};
  }}
 \node[fit=(mat1-1-4)(mat1-3-6),inner sep=0pt,draw,red,thick,name path=fit](f1){};
 \node[right=of mat1] (mul) {$*$};
 \matrix[mmat=blue,fill=blue!20,right=of mul,name path=mat2](mat2){
     1 & 0 & 1 \\
     0 & 1 & 0 \\
     1 & 0 & 1 \\ };
 \node[right=of mat2] (eq) {$=$};
 \matrix[mmat,right=of eq](mat3){
     1 & 4 & 3 & |[draw=green,thick,fill=green!20,alias=4]|4 & 1 \\
     1 & 2 & 4 & 3 & 3 \\
     1 & 2 & 3 & 4 & 1 \\
     1 & 3 & 3 & 1 & 1 \\
     3 & 3 & 1 & 1 & 0 \\
 };
 \foreach \Anchor in {south west,north west,south east,north east}
 {\path[name path=test] (f1.\Anchor) -- (mat2.\Anchor);
 \draw[blue,densely dotted,name intersections={of=test and fit,total=\t}]
 \ifnum\t>0 (intersection-\t) -- (mat2.\Anchor) \else
  (f1.\Anchor) -- (mat2.\Anchor)\fi;
 \path[name path=test2]  (4.\Anchor) -- (mat2.\Anchor);
 \draw[green,densely dotted,name intersections={of=test2 and mat2,total=\tt}]
 \ifnum\tt>0 (intersection-1) -- (4.\Anchor) \else
    (mat2.\Anchor) --  (4.\Anchor)\fi;
    }
 \path (mat1.south) node[below] {$\mathbf{I}$}
  (mat2|-mat1.south) node[below] {$\mathbf{K}$}
  (mat3|-mat1.south) node[below] {$\mathbf{I}*\mathbf{K}$};
 \begin{scope}[on background layer]
  \fill[red!20] (f1.north west) rectangle (f1.south east);
 \end{scope}
\end{tikzpicture}
\end{document}

insira a descrição da imagem aqui
