Estou usando o OpenVPN 2.1.1 com clientes Windows XP x86 SP3 e Windows 7 x64 em uma caixa Endian Community 2.4.0 que inclui OpenVPN 2.1-rc15.
A conexão de ambos funciona bem, mas o acesso aos recursos na LAN verde não funciona no Windows 7 e funciona no XP.
Então: posso fazer ping nos hosts nas redes enviadas por meio da VPN, mas com o windows7 só faço ping no endereço IP verde do firewall.
Editar: tentei o truque route-method exe/ route-delay 2, mas isso não resolve o problema.
Mais detalhes sobre a configuração Endian (tentei 2.2 e 2.4, ambos falharam):
vermelho=192.168.100.25;192.168.71.25
verde=176.16.41.1
laranja=176.16.141.1
Basicamente, ele funciona como um servidor OpenVPN, servindo no vermelho, fornecendo acesso ao verde.
No Windows XP, tenho o padrãoInstalação do OpenVPN 2.1.1, usando OpenVPN GUI (incluído na instalação) e tudo é elegante.
No Windows 7 x64, executo o mesmo, mas agora com OpenVPN GUI como administrador.
Ele só pode executar ping no gateway verde, mas em nenhuma outra máquina.
Registro do Windows 7:
Tue Aug 10 18:50:15 2010 OpenVPN 2.1.1 i686-pc-mingw32 [SSL] [LZO2] [PKCS11] built on Dec 11 2009
Tue Aug 10 18:50:23 2010 WARNING: No server certificate verification method has been enabled. See http://openvpn.net/howto.html#mitm for more info.
Tue Aug 10 18:50:23 2010 NOTE: OpenVPN 2.1 requires '--script-security 2' or higher to call user-defined scripts or executables
Tue Aug 10 18:50:24 2010 LZO compression initialized
Tue Aug 10 18:50:24 2010 Control Channel MTU parms [ L:1576 D:140 EF:40 EB:0 ET:0 EL:0 ]
Tue Aug 10 18:50:24 2010 Data Channel MTU parms [ L:1576 D:1450 EF:44 EB:135 ET:32 EL:0 AF:3/1 ]
Tue Aug 10 18:50:24 2010 Local Options hash (VER=V4): '31fdf004'
Tue Aug 10 18:50:24 2010 Expected Remote Options hash (VER=V4): '3e6d1056'
Tue Aug 10 18:50:24 2010 Attempting to establish TCP connection with 192.168.71.25:1194
Tue Aug 10 18:50:24 2010 TCP connection established with 192.168.71.25:1194
Tue Aug 10 18:50:24 2010 Socket Buffers: R=[8192->8192] S=[8192->8192]
Tue Aug 10 18:50:24 2010 TCPv4_CLIENT link local: [undef]
Tue Aug 10 18:50:24 2010 TCPv4_CLIENT link remote: 192.168.71.25:1194
Tue Aug 10 18:50:24 2010 TLS: Initial packet from 192.168.71.25:1194, sid=165d50de 52c0ecba
Tue Aug 10 18:50:24 2010 WARNING: this configuration may cache passwords in memory -- use the auth-nocache option to prevent this
Tue Aug 10 18:50:24 2010 VERIFY OK: depth=1, /C=IT/O=efw/CN=efw_CA
Tue Aug 10 18:50:24 2010 VERIFY OK: depth=0, /C=IT/O=efw/CN=127.0.0.1
Tue Aug 10 18:50:24 2010 Data Channel Encrypt: Cipher 'BF-CBC' initialized with 128 bit key
Tue Aug 10 18:50:24 2010 Data Channel Encrypt: Using 160 bit message hash 'SHA1' for HMAC authentication
Tue Aug 10 18:50:24 2010 Data Channel Decrypt: Cipher 'BF-CBC' initialized with 128 bit key
Tue Aug 10 18:50:24 2010 Data Channel Decrypt: Using 160 bit message hash 'SHA1' for HMAC authentication
Tue Aug 10 18:50:24 2010 Control Channel: TLSv1, cipher TLSv1/SSLv3 DHE-RSA-AES256-SHA, 1024 bit RSA
Tue Aug 10 18:50:24 2010 [127.0.0.1] Peer Connection Initiated with 192.168.71.25:1194
Tue Aug 10 18:50:26 2010 SENT CONTROL [127.0.0.1]: 'PUSH_REQUEST' (status=1)
Tue Aug 10 18:50:27 2010 PUSH: Received control message: 'PUSH_REPLY,ifconfig 172.16.41.209 255.255.255.0,dhcp-option DOMAIN pluimers.com,ping-restart 30,ping 8,route-gateway 172.16.41.1,route-gateway 172.16.41.1'
Tue Aug 10 18:50:27 2010 OPTIONS IMPORT: timers and/or timeouts modified
Tue Aug 10 18:50:27 2010 OPTIONS IMPORT: --ifconfig/up options modified
Tue Aug 10 18:50:27 2010 OPTIONS IMPORT: route-related options modified
Tue Aug 10 18:50:27 2010 OPTIONS IMPORT: --ip-win32 and/or --dhcp-option options modified
Tue Aug 10 18:50:27 2010 TAP-WIN32 device [Local Area Connection 2] opened: \\.\Global\{F3F5E8A1-1797-4FA8-902E-3895A2163148}.tap
Tue Aug 10 18:50:27 2010 TAP-Win32 Driver Version 9.6
Tue Aug 10 18:50:27 2010 TAP-Win32 MTU=1500
Tue Aug 10 18:50:27 2010 Notified TAP-Win32 driver to set a DHCP IP/netmask of 172.16.41.209/255.255.255.0 on interface {F3F5E8A1-1797-4FA8-902E-3895A2163148} [DHCP-serv: 172.16.41.0, lease-time: 31536000]
Tue Aug 10 18:50:27 2010 Successful ARP Flush on interface [34] {F3F5E8A1-1797-4FA8-902E-3895A2163148}
Tue Aug 10 18:50:32 2010 TEST ROUTES: 0/0 succeeded len=-1 ret=1 a=0 u/d=up
Tue Aug 10 18:50:32 2010 Initialization Sequence Completed[/code]
Tabela de roteamento do Windows 7:
IPv4 Route Table
===========================================================================
Active Routes:
Network Destination Netmask Gateway Interface Metric
0.0.0.0 0.0.0.0 192.168.71.1 192.168.71.160 20
127.0.0.0 255.0.0.0 On-link 127.0.0.1 306
127.0.0.1 255.255.255.255 On-link 127.0.0.1 306
127.255.255.255 255.255.255.255 On-link 127.0.0.1 306
169.254.0.0 255.255.0.0 On-link 169.254.100.145 276
169.254.100.145 255.255.255.255 On-link 169.254.100.145 276
169.254.255.255 255.255.255.255 On-link 169.254.100.145 276
172.16.41.0 255.255.255.0 On-link 172.16.41.209 286
172.16.41.209 255.255.255.255 On-link 172.16.41.209 286
172.16.41.255 255.255.255.255 On-link 172.16.41.209 286
192.168.71.0 255.255.255.0 On-link 192.168.71.160 276
192.168.71.160 255.255.255.255 On-link 192.168.71.160 276
192.168.71.255 255.255.255.255 On-link 192.168.71.160 276
192.168.237.0 255.255.255.0 On-link 192.168.237.1 276
192.168.237.1 255.255.255.255 On-link 192.168.237.1 276
192.168.237.255 255.255.255.255 On-link 192.168.237.1 276
224.0.0.0 240.0.0.0 On-link 127.0.0.1 306
224.0.0.0 240.0.0.0 On-link 192.168.71.160 276
224.0.0.0 240.0.0.0 On-link 169.254.100.145 276
224.0.0.0 240.0.0.0 On-link 192.168.237.1 276
224.0.0.0 240.0.0.0 On-link 172.16.41.209 286
255.255.255.255 255.255.255.255 On-link 127.0.0.1 306
255.255.255.255 255.255.255.255 On-link 192.168.71.160 276
255.255.255.255 255.255.255.255 On-link 169.254.100.145 276
255.255.255.255 255.255.255.255 On-link 192.168.237.1 276
255.255.255.255 255.255.255.255 On-link 172.16.41.209 286
===========================================================================
(você pode ignorar essas rotas, pois são da estação de trabalho VMware em execução na mesma máquina: - 192.168.237.0/24 - 169.254.0.0/16 )
Registro do Windows XP:
Tue Aug 10 19:01:04 2010 OpenVPN 2.1.1 i686-pc-mingw32 [SSL] [LZO2] [PKCS11] built on Dec 11 2009
Tue Aug 10 19:01:06 2010 WARNING: No server certificate verification method has been enabled. See http://openvpn.net/howto.html#mitm for more info.
Tue Aug 10 19:01:06 2010 NOTE: OpenVPN 2.1 requires '--script-security 2' or higher to call user-defined scripts or executables
Tue Aug 10 19:01:07 2010 LZO compression initialized
Tue Aug 10 19:01:07 2010 Control Channel MTU parms [ L:1576 D:140 EF:40 EB:0 ET:0 EL:0 ]
Tue Aug 10 19:01:07 2010 Data Channel MTU parms [ L:1576 D:1450 EF:44 EB:135 ET:32 EL:0 AF:3/1 ]
Tue Aug 10 19:01:07 2010 Local Options hash (VER=V4): '31fdf004'
Tue Aug 10 19:01:07 2010 Expected Remote Options hash (VER=V4): '3e6d1056'
Tue Aug 10 19:01:07 2010 Attempting to establish TCP connection with 192.168.71.25:1194
Tue Aug 10 19:01:07 2010 TCP connection established with 192.168.71.25:1194
Tue Aug 10 19:01:07 2010 Socket Buffers: R=[8192->8192] S=[8192->8192]
Tue Aug 10 19:01:07 2010 TCPv4_CLIENT link local: [undef]
Tue Aug 10 19:01:07 2010 TCPv4_CLIENT link remote: 192.168.71.25:1194
Tue Aug 10 19:01:07 2010 TLS: Initial packet from 192.168.71.25:1194, sid=983b94eb 87732d38
Tue Aug 10 19:01:07 2010 WARNING: this configuration may cache passwords in memory -- use the auth-nocache option to prevent this
Tue Aug 10 19:01:07 2010 VERIFY OK: depth=1, /C=IT/O=efw/CN=efw_CA
Tue Aug 10 19:01:07 2010 VERIFY OK: depth=0, /C=IT/O=efw/CN=127.0.0.1
Tue Aug 10 19:01:07 2010 Data Channel Encrypt: Cipher 'BF-CBC' initialized with 128 bit key
Tue Aug 10 19:01:07 2010 Data Channel Encrypt: Using 160 bit message hash 'SHA1' for HMAC authentication
Tue Aug 10 19:01:07 2010 Data Channel Decrypt: Cipher 'BF-CBC' initialized with 128 bit key
Tue Aug 10 19:01:07 2010 Data Channel Decrypt: Using 160 bit message hash 'SHA1' for HMAC authentication
Tue Aug 10 19:01:07 2010 Control Channel: TLSv1, cipher TLSv1/SSLv3 DHE-RSA-AES256-SHA, 1024 bit RSA
Tue Aug 10 19:01:07 2010 [127.0.0.1] Peer Connection Initiated with 192.168.71.25:1194
Tue Aug 10 19:01:09 2010 SENT CONTROL [127.0.0.1]: 'PUSH_REQUEST' (status=1)
Tue Aug 10 19:01:10 2010 PUSH: Received control message: 'PUSH_REPLY,ifconfig 172.16.41.201 255.255.255.0,dhcp-option DOMAIN pluimers.com,ping-restart 30,ping 8,route-gateway 172.16.41.1,route-gateway 172.16.41.1'
Tue Aug 10 19:01:10 2010 OPTIONS IMPORT: timers and/or timeouts modified
Tue Aug 10 19:01:10 2010 OPTIONS IMPORT: --ifconfig/up options modified
Tue Aug 10 19:01:10 2010 OPTIONS IMPORT: route-related options modified
Tue Aug 10 19:01:10 2010 OPTIONS IMPORT: --ip-win32 and/or --dhcp-option options modified
Tue Aug 10 19:01:10 2010 TAP-WIN32 device [Local Area Connection 3] opened: \\.\Global\{C4752F65-93BA-4DED-A1FE-2633F1481ABF}.tap
Tue Aug 10 19:01:10 2010 TAP-Win32 Driver Version 9.6
Tue Aug 10 19:01:10 2010 TAP-Win32 MTU=1500
Tue Aug 10 19:01:10 2010 Notified TAP-Win32 driver to set a DHCP IP/netmask of 172.16.41.201/255.255.255.0 on interface {C4752F65-93BA-4DED-A1FE-2633F1481ABF} [DHCP-serv: 172.16.41.0, lease-time: 31536000]
Tue Aug 10 19:01:10 2010 Successful ARP Flush on interface [2] {C4752F65-93BA-4DED-A1FE-2633F1481ABF}
Tue Aug 10 19:01:15 2010 TEST ROUTES: 0/0 succeeded len=-1 ret=0 a=0 u/d=down
Tue Aug 10 19:01:15 2010 Route: Waiting for TUN/TAP interface to come up...
Tue Aug 10 19:01:18 2010 TEST ROUTES: 0/0 succeeded len=-1 ret=1 a=0 u/d=up
Tue Aug 10 19:01:18 2010 Initialization Sequence Completed
A tabela de roteamento XP:
===========================================================================
Active Routes:
Network Destination Netmask Gateway Interface Metric
0.0.0.0 0.0.0.0 192.168.237.2 192.168.237.128 10
127.0.0.0 255.0.0.0 127.0.0.1 127.0.0.1 1
172.16.41.0 255.255.255.0 172.16.41.201 172.16.41.201 30
172.16.41.201 255.255.255.255 127.0.0.1 127.0.0.1 30
172.16.255.255 255.255.255.255 172.16.41.201 172.16.41.201 30
192.168.237.0 255.255.255.0 192.168.237.128 192.168.237.128 10
192.168.237.128 255.255.255.255 127.0.0.1 127.0.0.1 10
192.168.237.255 255.255.255.255 192.168.237.128 192.168.237.128 10
224.0.0.0 240.0.0.0 172.16.41.201 172.16.41.201 30
224.0.0.0 240.0.0.0 192.168.237.128 192.168.237.128 10
255.255.255.255 255.255.255.255 172.16.41.201 172.16.41.201 1
255.255.255.255 255.255.255.255 192.168.237.128 192.168.237.128 1
Default Gateway: 192.168.237.2
===========================================================================
Alguém tem uma ideia do que está errado?
--jeroen
Responder1
Bem, eu enfrentei o mesmo problema. Tentei de tudo, como ativar o compartilhamento de arquivos, definir o mesmo grupo de trabalho, etc. Nada ajudou, exceto isso:
Percebi que há vários adaptadores de rede no Gerenciador de dispositivos. Todos estavam ocultos, então é preciso clicar em Exibir e ativar os dispositivos ocultos.
Todos eles foram nomeados como ... adaptador 4to6. Quando removi todos esses adaptadores, meu compartilhamento de arquivos/impressoras e rede com clientes XP começaram a funcionar após a reinicialização. Se houver um grande número desses adaptadores, você deverá removê-los todos. Isso pode ser feito usando a ferramenta DEVCON.EXE apropriada (versão de 32 ou 64 bits) (que faz parte do Windows Driver Kit - Detalhes do download: Windows Driver Kit versão 7.1.0). Mais informações podem ser encontradas aqui O utilitário de linha de comando DevCon funciona como uma alternativa ao Gerenciador de dispositivos.
Encontrei esta solução aqui:http://ryanvictory.com/posts/automating-6to4-adapter-removal-in-windows/
Responder2
Resolvi meu problema: foi um erro de testcase.
O Windows XP estava se conectando a uma caixa Endian física.
O Windows 7 x64 estava se conectando a uma caixa Endian virtual.
A caixa virtual está sendo executada em VMware ESX/ESXi, usando um switch de rede virtual.
esqueci de ativarmodo promíscuopara essa mudança.
Habilitar isso resolveu o problema.
--jeroen
