Minha configuração inclui ceph mimic (centos 7, configuração com ceph-ansible), combinação cinza/keystone no lançamento do pike e ovirt 4.2.5.1.
O provedor Cinder externo está configurado e posso criar discos.
Ao criar uma VM e iniciá-la, a VM aparece no painel do ovirt como "aguarde lançamento"
no nó ovirt, que deveria executar a VM que verifiquei libvirt:
# virsh --readonly list
Id Name State
----------------------------------------------------
14 testceph paused
verificar a configuração do domínio também parece ok ... O mais importante é que os ceph mons são fornecidos na configuração do disco.
# virsh --readonly dumpxml
<domain type='kvm' id='15'>
<name>testceph</name>
<uuid>036a2385-2b4f-48f9-bcf9-8f2882ecde36</uuid>
<metadata xmlns:ns0="http://ovirt.org/vm/tune/1.0" xmlns:ovirt-vm="http://ovirt.org/vm/1.0">
<ns0:qos/>
<ovirt-vm:vm xmlns:ovirt-vm="http://ovirt.org/vm/1.0">
<ovirt-vm:clusterVersion>4.2</ovirt-vm:clusterVersion>
<ovirt-vm:destroy_on_reboot type="bool">False</ovirt-vm:destroy_on_reboot>
<ovirt-vm:launchPaused>false</ovirt-vm:launchPaused>
<ovirt-vm:memGuaranteedSize type="int">2730</ovirt-vm:memGuaranteedSize>
<ovirt-vm:minGuaranteedMemoryMb type="int">2730</ovirt-vm:minGuaranteedMemoryMb>
<ovirt-vm:resumeBehavior>auto_resume</ovirt-vm:resumeBehavior>
<ovirt-vm:startTime type="float">1535016868.02</ovirt-vm:startTime>
<ovirt-vm:device mac_address="00:1a:4a:16:01:78">
<ovirt-vm:specParams/>
<ovirt-vm:vm_custom/>
</ovirt-vm:device>
</ovirt-vm:vm>
</metadata>
<maxMemory slots='16' unit='KiB'>16777216</maxMemory>
<memory unit='KiB'>4194304</memory>
<currentMemory unit='KiB'>4194304</currentMemory>
<vcpu placement='static' current='1'>16</vcpu>
<iothreads>1</iothreads>
<resource>
<partition>/machine</partition>
</resource>
<sysinfo type='smbios'>
<system>
<entry name='manufacturer'>oVirt</entry>
<entry name='product'>oVirt Node</entry>
<entry name='version'>7-5.1804.el7.centos.2</entry>
<entry name='serial'>49434D53-0200-9031-2500-31902500FB7F</entry>
<entry name='uuid'>036a2385-2b4f-48f9-bcf9-8f2882ecde36</entry>
</system>
</sysinfo>
<os>
<type arch='x86_64' machine='pc-i440fx-rhel7.3.0'>hvm</type>
<smbios mode='sysinfo'/>
</os>
<features>
<acpi/>
</features>
<cpu mode='custom' match='exact' check='partial'>
<model fallback='forbid'>Nehalem</model>
<topology sockets='16' cores='1' threads='1'/>
<numa>
<cell id='0' cpus='0' memory='4194304' unit='KiB'/>
</numa>
</cpu>
<clock offset='variable' adjustment='0' basis='utc'>
<timer name='rtc' tickpolicy='catchup'/>
<timer name='pit' tickpolicy='delay'/>
<timer name='hpet' present='no'/>
</clock>
<on_poweroff>destroy</on_poweroff>
<on_reboot>restart</on_reboot>
<on_crash>destroy</on_crash>
<pm>
<suspend-to-mem enabled='no'/>
<suspend-to-disk enabled='no'/>
</pm>
<devices>
<emulator>/usr/libexec/qemu-kvm</emulator>
<disk type='file' device='cdrom'>
<driver name='qemu' type='raw' error_policy='report'/>
<source file='/rhev/data-center/mnt/192.168.10.6:_media_ovirt-cd-images/c394242c-81ae-4d6a-a193-65157cc84702/images/11111111-1111-1111-1111-111111111111/ubuntu-server-18.04.iso' startupPolicy='optional'/>
<backingStore/>
<target dev='hdc' bus='ide'/>
<readonly/>
<boot order='2'/>
<alias name='ua-fcca0dff-d833-4f28-b782-78ce0b016afe'/>
<address type='drive' controller='0' bus='1' target='0' unit='0'/>
</disk>
<disk type='network' device='disk' snapshot='no'>
<driver name='qemu' type='raw' cache='none' error_policy='stop' io='threads'/>
<auth username='cinder'>
<secret type='ceph' uuid='c6020051-6cd3-4ddf-982e-3d94c080de9c'/>
</auth>
<source protocol='rbd' name='volumes/volume-9b95b28c-9eec-4110-9973-88c161d3503f'>
<host name='192.168.20.21' port='6789'/>
<host name='192.168.20.22' port='6789'/>
<host name='192.168.20.23' port='6789'/>
</source>
<target dev='sda' bus='scsi'/>
<serial>9b95b28c-9eec-4110-9973-88c161d3503f</serial>
<boot order='1'/>
<alias name='ua-9b95b28c-9eec-4110-9973-88c161d3503f'/>
<address type='drive' controller='0' bus='0' target='0' unit='0'/>
</disk>
<controller type='usb' index='0' model='piix3-uhci'>
<alias name='usb'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x2'/>
</controller>
<controller type='pci' index='0' model='pci-root'>
<alias name='pci.0'/>
</controller>
<controller type='scsi' index='0'>
<alias name='scsi0'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x04' function='0x0'/>
</controller>
<controller type='ide' index='0'>
<alias name='ide'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/>
</controller>
<controller type='virtio-serial' index='0'>
<alias name='virtio-serial0'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x05' function='0x0'/>
</controller>
<interface type='bridge'>
<mac address='00:1a:4a:16:01:78'/>
<source bridge='ovirtmgmt'/>
<target dev='vnet0'/>
<model type='virtio'/>
<filterref filter='vdsm-no-mac-spoofing'/>
<link state='up'/>
<mtu size='1500'/>
<alias name='ua-446090cf-6758-4b3d-bd87-eb8b61442a46'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x0'/>
</interface>
<channel type='unix'>
<source mode='bind' path='/var/lib/libvirt/qemu/channels/036a2385-2b4f-48f9-bcf9-8f2882ecde36.ovirt-guest-agent.0'/>
<target type='virtio' name='ovirt-guest-agent.0'/>
<alias name='channel0'/>
<address type='virtio-serial' controller='0' bus='0' port='1'/>
</channel>
<channel type='unix'>
<source mode='bind' path='/var/lib/libvirt/qemu/channels/036a2385-2b4f-48f9-bcf9-8f2882ecde36.org.qemu.guest_agent.0'/>
<target type='virtio' name='org.qemu.guest_agent.0'/>
<alias name='channel1'/>
<address type='virtio-serial' controller='0' bus='0' port='2'/>
</channel>
<channel type='spicevmc'>
<target type='virtio' name='com.redhat.spice.0'/>
<alias name='channel2'/>
<address type='virtio-serial' controller='0' bus='0' port='3'/>
</channel>
<input type='mouse' bus='ps2'>
<alias name='input0'/>
</input>
<input type='keyboard' bus='ps2'>
<alias name='input1'/>
</input>
<graphics type='spice' port='5900' tlsPort='5901' autoport='yes' listen='192.168.10.11' passwdValidTo='1970-01-01T00:00:01'>
<listen type='network' address='192.168.10.11' network='vdsm-ovirtmgmt'/>
<channel name='main' mode='secure'/>
<channel name='display' mode='secure'/>
<channel name='inputs' mode='secure'/>
<channel name='cursor' mode='secure'/>
<channel name='playback' mode='secure'/>
<channel name='record' mode='secure'/>
<channel name='smartcard' mode='secure'/>
<channel name='usbredir' mode='secure'/>
</graphics>
<graphics type='vnc' port='5902' autoport='yes' listen='192.168.10.11' keymap='en-us' passwdValidTo='1970-01-01T00:00:01'>
<listen type='network' address='192.168.10.11' network='vdsm-ovirtmgmt'/>
</graphics>
<video>
<model type='qxl' ram='65536' vram='32768' vgamem='16384' heads='1' primary='yes'/>
<alias name='ua-31537f3a-f1cf-4269-839c-bc82721ff7f3'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0'/>
</video>
<memballoon model='virtio'>
<stats period='5'/>
<alias name='ua-beeefd9c-c2bd-4836-83f0-a28657219b3e'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x06' function='0x0'/>
</memballoon>
<rng model='virtio'>
<backend model='random'>/dev/urandom</backend>
<alias name='ua-7d25e1b5-4d03-4bc3-80f6-83a80d69b391'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0'/>
</rng>
</devices>
<seclabel type='dynamic' model='selinux' relabel='yes'>
<label>system_u:system_r:svirt_t:s0:c565,c625</label>
<imagelabel>system_u:object_r:svirt_image_t:s0:c565,c625</imagelabel>
</seclabel>
<seclabel type='dynamic' model='dac' relabel='yes'>
<label>+107:+107</label>
<imagelabel>+107:+107</imagelabel>
</seclabel>
</domain>
E sim. Posso ver o nó ovirt e o nó ceph conversando entre si. Mas o nó ovirt está apenas conversando com o monitor ceph. Não há nenhum OSD envolvido. Ambos os nós podem se comunicar, os jumbo frames são permitidos e estão funcionando. Nesta saída, o monitor ceph é 192.168.20.21 e o nó ovirt é 192.168.20.11
[root@ceph1 ~]# tcpflow -c -i enp3s0 src or dst host 192.168.20.11
tcpflow: listening on enp3s0
192.168.020.021.06789-192.168.020.011.44734: ceph v027
192.168.020.011.44734-192.168.020.021.06789: ceph v027
192.168.020.011.44734-192.168.020.021.06789: *D
192.168.020.011.44734-192.168.020.021.06789:
192.168.020.021.06789-192.168.020.011.44734:
192.168.020.021.06789-192.168.020.011.44736: ceph v027
192.168.020.011.44736-192.168.020.021.06789: ceph v027
192.168.020.011.44736-192.168.020.021.06789: *D
192.168.020.021.06789-192.168.020.011.44736:
192.168.020.021.06789-192.168.020.011.44738: ceph v027
192.168.020.011.44738-192.168.020.021.06789: ceph v027
192.168.020.011.44738-192.168.020.021.06789: *D!
192.168.020.021.06789-192.168.020.011.44738:
192.168.020.021.06789-192.168.020.011.44740: ceph v027
192.168.020.011.44740-192.168.020.021.06789: ceph v027
192.168.020.011.44740-192.168.020.021.06789: *D"
192.168.020.021.06789-192.168.020.011.44740:
192.168.020.021.06789-192.168.020.011.44742: ceph v027
192.168.020.011.44742-192.168.020.021.06789: ceph v027
192.168.020.011.44742-192.168.020.021.06789: *D#
192.168.020.021.06789-192.168.020.011.44742:
192.168.020.021.06789-192.168.020.011.44754: ceph v027
192.168.020.011.44754-192.168.020.021.06789: ceph v027
192.168.020.011.44754-192.168.020.021.06789: *D)
192.168.020.021.06789-192.168.020.011.44754:
E isso continua até que o log do qemu nos nós ovirt mostre:
2018-08-23T09:34:31.233493Z qemu-kvm: -drive file=rbd:volumes/volume-9b95b28c-9eec-4110-9973-88c161d3503f:id=cinder:auth_supported=cephx\;none:mon_host=192.168.20.21\:6789\;192.168.20.22\:6789\;192.168.20.23\:6789,file.password-secret=ua-9b95b28c-9eec-4110-9973-88c161d3503f-secret0,format=raw,if=none,id=drive-ua-9b95b28c-9eec-4110-9973-88c161d3503f,serial=9b95b28c-9eec-4110-9973-88c161d3503f,cache=none,werror=stop,rerror=stop,aio=threads: 'serial' is deprecated, please use the corresponding option of '-device' instead
2018-08-23T09:39:31.281126Z qemu-kvm: -drive file=rbd:volumes/volume-9b95b28c-9eec-4110-9973-88c161d3503f:id=cinder:auth_supported=cephx\;none:mon_host=192.168.20.21\:6789\;192.168.20.22\:6789\;192.168.20.23\:6789,file.password-secret=ua-9b95b28c-9eec-4110-9973-88c161d3503f-secret0,format=raw,if=none,id=drive-ua-9b95b28c-9eec-4110-9973-88c161d3503f,serial=9b95b28c-9eec-4110-9973-88c161d3503f,cache=none,werror=stop,rerror=stop,aio=threads:
error connecting: Connection timed out
2018-08-23 09:39:31.291+0000: shutting down, reason=failed
Então, o que impede ovirt e ceph de falarem? A introdução da imagem via cinder foi feita, mas de alguma forma ovirt não está contatando o ceph osds...
Responder1
Parece haver um problema com a biblioteca librbd1 que vem junto com o centos 7 que é a base do oVirt 4.2.x. É muito antigo para brincar com o ceph V13.x, também conhecido como imitador e provavelmente também com o V12 luminoso.
Veresta postagemdos formulários oVirt para uma discussão sobre este problema.
Há uma maneirapara atualizar as bibliotecas.
