Estou tentando conectar um iniciador a um respondedor usando ipv6
Ambos estão ativados Ubuntu 20.04e strongswan 5.9.0
o Iniciador está em uma máquina virtual (usando VMware) em um computador pessoal atrás de uma caixa conectada à minha rede ISP. A VM usa uma rede NAT com o computador host O respondente é um VPS online
O iniciador obteve um ipv6 (o de seu host) e pode executar ping no respondedor ipv6. É ipv6. <initiator_ipv6>
O respondedor ipv6 parece configurado corretamente, posso fazer ping e ssh usando-o. É ipv6 é<responder_ipv6>
O IPv6 foi ativado usando o seguinte conf (conforme fornecido pelo meu provedor VPS)
/etc/netplan/51-ipv6.yaml
network:
version: 2
ethernets:
<responder_interface>:
dhcp4: true
dhcp6: false
match:
name: <responder_interface>
addresses:
- <responder_ipv6>/128
gateway6: <responder_ipv6_gateway>
routes:
- to: <responder_ipv6_gateway>
scope: link
Ambos os Strongswan foram construídos no iniciador usando configure com os seguintes comandos:
./configure --prefix=<custom_dir> --with-piddir=<custom_dir>/var/run
make
make install
Eles têm o mesmo strongswan.conf, que é principalmente o padrão com uma opção de filelog para facilitar a depuração
charon {
load_modular = yes
plugins {
include strongswan.d/charon/*.conf
}
filelog {
logger {
path = <custom_dir>/swanctl.log
time_format = %b %e %T
ike_name = yes
default = 1
flush_line = yes
}
}
}
include strongswan.d/*.conf
O respondente tem o seguinte swanctl.conf
connections {
# Seems to change nothing
local_addrs = <responder_ipv6>
pubkey-vm {
pools = primary-pool-ipv4, primary-pool-ipv6
local {
auth = pubkey
certs = <responder_cert>
id = <responder_id>
}
remote {
auth = pubkey
id = <initiator_id>
}
children {
client {
}
}
}
}
pools {
primary-pool-ipv4 {
# Totally arbitrary value
addrs = 10.0.0.0/24
}
primary-pool-ipv6 {
# Totally arbitrary value
addrs = 2620:0:2d0:200::7/97
}
}
O iniciador tem a seguinte configuração
connections {
initiator-to-host {
remote_addrs = <responder_ip>
# Any value works, at long as vips got a value (but assigned ip will be in the respodner pool)
vips = 1.2.3.4
local {
auth = pubkey
certs = <initator_cert>
id = <initiator_id>
}
remote {
auth = pubkey
id = <responder_id>
}
children {
to-host {
start_action = none
}
}
}
}
Quando tento me conectar usando o respondedor ipv4, ele funciona e a inicialização foi concluída com sucesso. Quando mudo o ip para o ipv6, não funciona e recebo os seguintes logs no respondedor
<pubkey-vm|4> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (80 bytes)
<pubkey-vm|4> parsed INFORMATIONAL request 2 [ D ]
<pubkey-vm|4> received DELETE for IKE_SA pubkey-vm[4]
<pubkey-vm|4> deleting IKE_SA pubkey-vm[4] between <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|4> IKE_SA deleted
<pubkey-vm|4> generating INFORMATIONAL response 2 [ ]
<pubkey-vm|4> sending packet: from <responder_ipv6>[4500] to <initiator_ipv6>[53870] (80 bytes)
<pubkey-vm|4> lease 10.0.0.1 by '<initiator_id>' went offline
<5> received packet: from <initiator_ipv6>[1016] to <responder_ipv6>[500] (392 bytes)
<5> parsed IKE_SA_INIT request 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) N(FRAG_SUP) N(HASH_ALG) N(REDIR_SUP) ]
<5> <initiator_ipv6> is initiating an IKE_SA
<5> selected proposal: IKE:AES_CBC_128/HMAC_SHA2_256_128/PRF_AES128_XCBC/CURVE_25519
<5> remote host is behind NAT
<5> sending cert request for "C=FR, O=Test, CN=Test CA"
<5> generating IKE_SA_INIT response 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) CERTREQ N(FRAG_SUP) N(HASH_ALG) N(CHDLESS_SUP) N(MULT_AUTH) ]
<5> sending packet: from <responder_ipv6>[500] to <initiator_ipv6>[1016] (273 bytes)
<5> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (356 bytes)
<5> parsed IKE_AUTH request 1 [ EF(2/2) ]
<5> received fragment #2 of 2, waiting for complete IKE message
<5> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (1220 bytes)
<5> parsed IKE_AUTH request 1 [ EF(1/2) ]
<5> received fragment #1 of 2, reassembled fragmented IKE message (1504 bytes)
<5> parsed IKE_AUTH request 1 [ IDi CERT N(INIT_CONTACT) CERTREQ IDr AUTH CPRQ(ADDR DNS) SA TSi TSr N(MOBIKE_SUP) N(ADD_4_ADDR) N(MULT_AUTH) N(EAP_ONLY) N(MSG_ID_SYN_SUP) ]
<5> received cert request for "C=FR, O=Test, CN=Test CA"
<5> received end entity cert "C=FR, O=Test, CN=<initiator_id>"
<5> looking for peer configs matching <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|5> selected peer config 'pubkey-vm'
<pubkey-vm|5> using trusted ca certificate "C=FR, O=Test, CN=Test CA"
<pubkey-vm|5> checking certificate status of "C=FR, O=Test, CN=<initiator_id>"
<pubkey-vm|5> certificate status is not available
<pubkey-vm|5> reached self-signed root ca with a path length of 0
<pubkey-vm|5> using trusted certificate "C=FR, O=Test, CN=<initiator_id>"
<pubkey-vm|5> authentication of '<initiator_id>' with RSA_EMSA_PKCS1_SHA2_256 successful
<pubkey-vm|5> peer supports MOBIKE
<pubkey-vm|5> authentication of '<responder_id>' (myself) with RSA_EMSA_PKCS1_SHA2_256 successful
<pubkey-vm|5> IKE_SA pubkey-vm[5] established between <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|5> scheduling rekeying in 14286s
<pubkey-vm|5> maximum IKE_SA lifetime 15726s
<pubkey-vm|5> sending end entity cert "C=FR, O=Test, CN=<responder_id>"
<pubkey-vm|5> peer requested virtual IP 1.2.3.4
<pubkey-vm|5> reassigning offline lease to '<initiator_id>'
<pubkey-vm|5> assigning virtual IP 10.0.0.1 to peer '<initiator_id>'
<pubkey-vm|5> selected proposal: ESP:AES_GCM_16_128
<pubkey-vm|5> received netlink error: Invalid argument (22)
<pubkey-vm|5> unable to add SAD entry with SPI cffdef3f (FAILED)
<pubkey-vm|5> received netlink error: Invalid argument (22)
<pubkey-vm|5> unable to add SAD entry with SPI c028512b (FAILED)
<pubkey-vm|5> unable to install inbound and outbound IPsec SA (SAD) in kernel
<pubkey-vm|5> failed to establish CHILD_SA, keeping IKE_SA
<pubkey-vm|5> generating IKE_AUTH response 1 [ IDr CERT AUTH CPRP(ADDR) N(MOBIKE_SUP) N(ADD_4_ADDR) N(NO_PROP) ]
<pubkey-vm|5> sending packet: from <responder_ipv6>[4500] to <initiator_ipv6>[53870] (1216 bytes)
Os logs do lado do cliente estão aqui
Starting IKE charon daemon (strongSwan 5.9.0, Linux 5.4.0-56-generic, x86_64)
loading ca certificates from '<custom_path>/etc/ipsec.d/cacerts'
loading aa certificates from '<custom_path>/etc/ipsec.d/aacerts'
loading ocsp signer certificates from '<custom_path>/etc/ipsec.d/ocspcerts'
loading attribute certificates from '<custom_path>/etc/ipsec.d/acerts'
loading crls from '<custom_path>/etc/ipsec.d/crls'
loading secrets from '<custom_path>/etc/ipsec.secrets'
loaded plugins: charon aes eap-aka eap-dynamic eap-identity eap-sim eap-tls des rc2 sha2 sha1 md5 mgf1 random nonce x509 revocation constraints pubkey pkcs1 pkcs7 pkcs8 pkcs12 pgp dnskey sshkey pem fips-prf gmp curve25519 xcbc cmac hmac drbg attr kernel-netlink resolve socket-default stroke vici updown xauth-generic counters
spawning 16 worker threads
loaded certificate 'C=FR, O=Test, CN=<responder_id>'
loaded certificate 'C=FR, O=Test, CN=<initiator_id>'
loaded certificate 'C=FR, O=Test, CN=Test CA'
loaded RSA private key
loaded RSA private key
added vici connection: host-host
vici initiate CHILD_SA 'to-host'
<host-host|1> initiating IKE_SA host-host[1] to <responder_ipv6>
<host-host|1> generating IKE_SA_INIT request 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) N(FRAG_SUP) N(HASH_ALG) N(REDIR_SUP) ]
<host-host|1> sending packet: from <initiator_ipv6>[500] to <responder_ipv6>[500] (392 bytes)
<host-host|1> received packet: from <responder_ipv6>[500] to <initiator_ipv6>[500] (273 bytes)
<host-host|1> parsed IKE_SA_INIT response 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) CERTREQ N(FRAG_SUP) N(HASH_ALG) N(CHDLESS_SUP) N(MULT_AUTH) ]
<host-host|1> selected proposal: IKE:AES_CBC_128/HMAC_SHA2_256_128/PRF_AES128_XCBC/CURVE_25519
<host-host|1> local host is behind NAT, sending keep alives
<host-host|1> received cert request for "C=FR, O=Test, CN=Test CA"
<host-host|1> sending cert request for "C=FR, O=Test, CN=Test CA"
<host-host|1> authentication of '<initiator_id>' (myself) with RSA_EMSA_PKCS1_SHA2_256 successful
<host-host|1> sending end entity cert "C=FR, O=Test, CN=<initiator_id>"
<host-host|1> establishing CHILD_SA to-host{1}
<host-host|1> generating IKE_AUTH request 1 [ IDi CERT N(INIT_CONTACT) CERTREQ IDr AUTH CPRQ(ADDR DNS) SA TSi TSr N(MOBIKE_SUP) N(ADD_4_ADDR) N(MULT_AUTH) N(EAP_ONLY) N(MSG_ID_SYN_SUP) ]
<host-host|1> splitting IKE message (1504 bytes) into 2 fragments
<host-host|1> generating IKE_AUTH request 1 [ EF(1/2) ]
<host-host|1> generating IKE_AUTH request 1 [ EF(2/2) ]
<host-host|1> sending packet: from <initiator_ipv6>[4500] to <responder_ipv6>[4500] (1220 bytes)
<host-host|1> sending packet: from <initiator_ipv6>[4500] to <responder_ipv6>[4500] (356 bytes)
<host-host|1> received packet: from <responder_ipv6>[4500] to <initiator_ipv6>[4500] (1216 bytes)
<host-host|1> parsed IKE_AUTH response 1 [ IDr CERT AUTH CPRP(ADDR) N(MOBIKE_SUP) N(ADD_4_ADDR) N(NO_PROP) ]
<host-host|1> received end entity cert "C=FR, O=Test, CN=<responder_id>"
<host-host|1> using trusted ca certificate "C=FR, O=Test, CN=Test CA"
<host-host|1> checking certificate status of "C=FR, O=Test, CN=<responder_id>"
<host-host|1> certificate status is not available
<host-host|1> reached self-signed root ca with a path length of 0
<host-host|1> using trusted certificate "C=FR, O=Test, CN=<responder_id>"
<host-host|1> authentication of '<responder_id>' with RSA_EMSA_PKCS1_SHA2_256 successful
<host-host|1> IKE_SA host-host[1] established between <initiator_ipv6>[<initiator_id>]...<responder_ipv6>[<responder_id>]
<host-host|1> scheduling rekeying in 13877s
<host-host|1> maximum IKE_SA lifetime 15317s
<host-host|1> installing new virtual IP 10.0.0.1
<host-host|1> received NO_PROPOSAL_CHOSEN notify, no CHILD_SA built
<host-host|1> failed to establish CHILD_SA, keeping IKE_SA
<host-host|1> peer supports MOBIKE
Alguma idéia de como resolver isso?
Tentei uma solução usando --enable-kernel-libipseca opção de configuração. Então agora eu tenho
./configure --prefix=<custom_dir> --with-piddir=<custom_dir>/var/run --enable-kernel-libipsec
os logs do lado do iniciador permaneceram os mesmos, mas recebi novos logs do lado do respondedor abaixo
[CFG] <pubkey-vm|1> selected proposal: ESP:AES_GCM_16_128
[ESP] <pubkey-vm|1> failed to create ESP context: unsupported AEAD algorithm AES_GCM_16
[ESP] <pubkey-vm|1> failed to create SAD entry
[ESP] <pubkey-vm|1> failed to create ESP context: unsupported AEAD algorithm AES_GCM_16
[ESP] <pubkey-vm|1> failed to create SAD entry
[IKE] <pubkey-vm|1> unable to install inbound and outbound IPsec SA (SAD) in kernel
[IKE] <pubkey-vm|1> failed to establish CHILD_SA, keeping IKE_SA
Responder1
Se houver um NAT entre seus hosts, conforme detectado aqui pelos pares:
<5> remote host is behind NAT
e
<host-host|1> local host is behind NAT, sending keep alives
O encapsulamento UDP para ESP será habilitado para SAs IPsec (NAT-Traversal). No entanto, isso requer suporte da pilha IPsec, que o Linux fornece apenas desde 5.8 para IPv6. Portanto, com kernels mais antigos, isso não funcionará.
Você deve usar um kernel mais recente, remover o NAT, voltar a usar o IPv4 ou usar uma pilha IPsec alternativa (como a do próprio StrongSwan).libipsec).
