Configurei a VM Linux usando virsh/libvirt/kvm e estou tendo problemas com a rede bridge. A rede NAT padrão da libvirt estava funcionando bem, mas preciso de uma ponte para a interface pública. Removi a rede padrão usando virsh e alterei a configuração de rede da VM em virsh para:
<interface type='bridge'>
<mac address='02:00:00:c1:8f:95'/>
<source bridge='br0'/>
<model type='virtio'/>
<address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/>
</interface>
no sistema host eu configurei a ponte:
# brctl show br0
bridge name bridge id STP enabled interfaces
br0 8000.a0423f494574 yes enp97s0f0
vnet0
# brctl showstp br0
br0
bridge id 8000.a0423f494574
designated root 8000.a0423f494574
root port 0 path cost 0
max age 20.00 bridge max age 20.00
hello time 2.00 bridge hello time 2.00
forward delay 15.00 bridge forward delay 15.00
ageing time 300.00
hello timer 0.86 tcn timer 0.00
topology change timer 0.00 gc timer 240.41
flags
enp97s0f0 (1)
port id 8001 state forwarding
designated root 8000.a0423f494574 path cost 100
designated bridge 8000.a0423f494574 message age timer 0.00
designated port 8001 forward delay timer 0.00
designated cost 0 hold timer 0.00
flags
vnet0 (2)
port id 8002 state forwarding
designated root 8000.a0423f494574 path cost 100
designated bridge 8000.a0423f494574 message age timer 0.00
designated port 8002 forward delay timer 0.00
designated cost 0 hold timer 0.00
onde enp97s0f0 é uma NIC pública e vnet0 é uma NIC virtual usada pela libvirt.
Configurei IPs e gateways na VM, mas não obtive resposta aos pings. Eu fiz tcpdump na máquina Host durante pings de VM para 1.1.1.1 cloudflare dns, tanto em vnet0 quanto em br0. Aqui estão os resultados:
# tcpdump -i vnet0 -n host VM.VM.VM.VM
dropped privs to tcpdump
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on vnet0, link-type EN10MB (Ethernet), capture size 262144 bytes
15:13:50.863273 IP VM.VM.VM.VM > 1.1.1.1: ICMP echo request, id 2016, seq 80, length 64
15:13:51.887267 IP VM.VM.VM.VM > 1.1.1.1: ICMP echo request, id 2016, seq 81, length 64
15:13:52.911271 IP VM.VM.VM.VM > 1.1.1.1: ICMP echo request, id 2016, seq 82, length 64
15:13:53.935270 IP VM.VM.VM.VM > 1.1.1.1: ICMP echo request, id 2016, seq 83, length 64
# tcpdump -i br0 -n host VM.VM.VM.VM
dropped privs to tcpdump
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on br0, link-type EN10MB (Ethernet), capture size 262144 bytes
15:12:33.039228 IP VM.VM.VM.VM > 1.1.1.1: ICMP echo request, id 2016, seq 4, length 64
15:12:33.045522 IP 1.1.1.1 > VM.VM.VM.VM: ICMP echo reply, id 2016, seq 4, length 64
15:12:33.045532 IP 1.1.1.1 > VM.VM.VM.VM: ICMP echo reply, id 2016, seq 4, length 64
15:12:34.063111 IP VM.VM.VM.VM > 1.1.1.1: ICMP echo request, id 2016, seq 5, length 64
15:12:34.069501 IP 1.1.1.1 > VM.VM.VM.VM: ICMP echo reply, id 2016, seq 5, length 64
15:12:34.069510 IP 1.1.1.1 > VM.VM.VM.VM: ICMP echo reply, id 2016, seq 5, length 64
15:12:35.087281 IP VM.VM.VM.VM > 1.1.1.1: ICMP echo request, id 2016, seq 6, length 64
15:12:35.093640 IP 1.1.1.1 > VM.VM.VM.VM: ICMP echo reply, id 2016, seq 6, length 64
15:12:35.093649 IP 1.1.1.1 > VM.VM.VM.VM: ICMP echo reply, id 2016, seq 6, length 64
Então posso ver que a VM está enviando uma solicitação de ping via vnet0, a ponte br0 está encaminhando essa solicitação para 1.1.1.1 e 1.1.1.1 está enviando a resposta de volta para a ponte. Então o pacote desaparece e nunca alcança a interface da VM.
É por isso que acho que esse problema provavelmente está relacionado a algum tipo de filtragem de pacotes no host, mas verifiquei várias variáveis e tudo parece bem:
/proc/sys/net/ipv4/ip_forward : 1
/proc/sys/net/ipv4/conf/br0/forwarding : 1
/proc/sys/net/ipv4/conf/vnet0/forwarding : 1
/proc/sys/net/ipv4/conf/enp97s0f0/forwarding : 1
/proc/sys/net/bridge/bridge-nf-call-iptables: No such file or directory
# iptables -L
Chain INPUT (policy ACCEPT)
target prot opt source destination
Chain FORWARD (policy ACCEPT)
target prot opt source destination
Chain OUTPUT (policy ACCEPT)
target prot opt source destination
# ebtables -L
Bridge table: filter
Bridge chain: INPUT, entries: 0, policy: ACCEPT
Bridge chain: FORWARD, entries: 0, policy: ACCEPT
Bridge chain: OUTPUT, entries: 0, policy: ACCEPT
# nft list ruleset
table bridge filter {
chain INPUT {
type filter hook input priority filter; policy accept;
}
chain FORWARD {
type filter hook forward priority filter; policy accept;
}
chain OUTPUT {
type filter hook output priority filter; policy accept;
}
}
table ip filter {
chain INPUT {
type filter hook input priority filter; policy accept;
}
chain FORWARD {
type filter hook forward priority filter; policy accept;
}
chain OUTPUT {
type filter hook output priority filter; policy accept;
}
}
[root@HOST ~] # ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
inet6 ::1/128 scope host
valid_lft forever preferred_lft forever
2: enp97s0f0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq master br0 state UP group default qlen 1000
link/ether a0:42:3f:49:45:74 brd ff:ff:ff:ff:ff:ff
3: br0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default qlen 1000
link/ether a0:42:3f:49:45:74 brd ff:ff:ff:ff:ff:ff
inet xxx.xxx.xxx.xxx/24 scope global dynamic noprefixroute br0
valid_lft 71705sec preferred_lft 71705sec
inet6 fe80::6559:22b2:dccd:3b24/64 scope link noprefixroute
valid_lft forever preferred_lft forever
4: vnet0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc fq_codel master br0 state UNKNOWN group default qlen 1000
link/ether fe:00:00:c1:8f:95 brd ff:ff:ff:ff:ff:ff
inet6 fe80::fc00:ff:fec1:8f95/64 scope link
valid_lft forever preferred_lft forever
[root@VM ~]# ip addr show
1: lo: mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
inet6 ::1/128 scope host
valid_lft forever preferred_lft forever
2: enp1s0: mtu 1500 qdisc fq_codel state UP group default qlen 1000
link/ether 02:00:00:c1:8f:95 brd ff:ff:ff:ff:ff:ff
inet VM.VM.VM.VM/24 scope global enp1s0
valid_lft forever preferred_lft forever
[root@HOST ~]# bridge link
2: enp97s0f0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 master br0 state forwarding priority 32 cost 100
8: vnet0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 master br0 state forwarding priority 32 cost 100
[root@HOST ~]# bridge fdb show
fc:bd:67:ff:ec:6a dev enp97s0f0 master br0
fc:bd:67:ff:ec:31 dev enp97s0f0 master br0
2c:dd:e9:0d:9d:31 dev enp97s0f0 master br0
fe:ed:de:ad:be:ef dev enp97s0f0 master br0
a0:42:3f:49:45:74 dev enp97s0f0 vlan 1 master br0 permanent
a0:42:3f:49:45:74 dev enp97s0f0 master br0 permanent
01:00:5e:00:00:01 dev enp97s0f0 self permanent
33:33:00:00:00:01 dev enp97s0f0 self permanent
01:00:5e:00:00:01 dev br0 self permanent
33:33:00:00:00:01 dev br0 self permanent
33:33:ff:cd:3b:24 dev br0 self permanent
01:00:5e:00:00:6a dev br0 self permanent
33:33:00:00:00:6a dev br0 self permanent
02:00:00:c1:8f:95 dev vnet0 master br0
fe:00:00:c1:8f:95 dev vnet0 vlan 1 master br0 permanent
fe:00:00:c1:8f:95 dev vnet0 master br0 permanent
33:33:00:00:00:01 dev vnet0 self permanent
01:00:5e:00:00:01 dev vnet0 self permanent
33:33:ff:c1:8f:95 dev vnet0 self permanent
[root@HOST ~]# bridge vlan show
port vlan-id
enp97s0f0 1 PVID Egress Untagged
vnet0 1 PVID Egress Untagged
O sistema host é Centos8 com kernel 5.13.12-1.el8.elrepo.x86_64. O sistema VM é a instalação padrão do Centos8.
EDITAR:
Se eu configurar IPs de rede privada no host br0 e na interface VM enp1s0, a VM poderá executar ping no host e o host poderá executar ping na VM. Mas ainda não é possível executar ping em nada fora da rede local.
Responder1
Resolvido criando rota no endereço IP do host para VM:
route add -host VM.VM.VM.VM dev br0
