Glade Ubuntu - Botão transparente em uma imagem de fundo

Estou tentando fazer um aplicativo Ubuntu. Preciso colocar botões transparentes em locais específicos em uma imagem de fundo no Glade, de modo que a imagem mude ao clicar no botão.

Não consegui isso até agora. Meu botão simplesmente não pousa na imagem. Além disso, também não consegui tornar o botão completamente transparente (ou seja, fica visível quando pressionado).

Responder1

  1. Para posição fixa dos botões, é melhor usar GtkFixedou GtkLayout(com rolagem)
  2. Para transparência de botões, para mim funciona como deveria. Se não, tente:
    • Border Relief: Nonepara botão plano
    • Desmarque Focus on Clickpara evitar qualquer destaque de foco

Exemplo:

<?xml version="1.0" encoding="UTF-8"?>
<!-- Generated with glade 3.16.1 -->
<interface>
  <requires lib="gtk+" version="3.10"/>
  <object class="GtkWindow" id="window1">
    <property name="can_focus">False</property>
    <child>
      <object class="GtkLayout" id="layout1">
        <property name="visible">True</property>
        <property name="can_focus">False</property>
        <child>
          <object class="GtkButton" id="button1">
            <property name="label" translatable="yes">button</property>
            <property name="width_request">59</property>
            <property name="height_request">30</property>
            <property name="visible">True</property>
            <property name="can_focus">True</property>
            <property name="receives_default">True</property>
            <property name="opacity">0</property>
          </object>
          <packing>
            <property name="x">87</property>
            <property name="y">64</property>
          </packing>
        </child>
      </object>
    </child>
  </object>
</interface>

Pela primeira vez, pensei que você quisesse dizer Plano de fundo da área de trabalho. Então, deixo que pode ser útil para outras pessoas.

Não tenho certeza de qual versão do PyGTK é usada pelo Quickly no (Ubuntu 13.04). Melhor usar opacidade 0,1 para testar. Glade não oferece a opção de definir keep_belowpropriedades.

PyGTK3

Adicionar:

    <property name="opacity">0.0</property>
    <property name="decorated">False</property>

Para

builder_example.glade

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <!-- interface-requires gtk+ 3.0 -->
  <object class="GtkWindow" id="window1">
    <property name="can_focus">False</property>
    <!-- <property name="keep_below">True</property> -->
    <property name="opacity">0.0</property>
    <property name="decorated">False</property>
    <!-- <property name="position">gtk.WIN_POS_CENTER_ALWAYS</property> -->
    <signal name="delete-event" handler="onDeleteWindow" swapped="no"/>
    <child>
      <object class="GtkButton" id="button1">
        <property name="label" translatable="yes">button</property>
        <property name="use_action_appearance">False</property>
        <property name="visible">True</property>
        <property name="can_focus">True</property>
        <property name="receives_default">True</property>
        <property name="use_action_appearance">False</property>
        <signal name="pressed" handler="onButtonPressed" swapped="no"/>
      </object>
    </child>
  </object>
</interface>

Eu comentei isso, pois geraram erros (não tenho certeza se existe outra maneira no Glade)

    <!-- <property name="keep_below">True</property> -->
    <!-- <property name="position">gtk.WIN_POS_CENTER_ALWAYS</property> -->

Então, eu os adiciono ao arquivo .py para serem aplicados dinamicamente:

window.set_keep_below(True)
window.set_position(Gtk.WindowPosition.CENTER_ALWAYS)

builder_example.py

from gi.repository import Gtk

class Handler:
    def onDeleteWindow(self, *args):
        Gtk.main_quit(*args)

    def onButtonPressed(self, button):
        print("Hello World!")

builder = Gtk.Builder()
builder.add_from_file("builder_example.glade")
builder.connect_signals(Handler())

window = builder.get_object("window1")
window.set_keep_below(True)
window.set_position(Gtk.WindowPosition.CENTER_ALWAYS)
window.show_all()

Gtk.main()

PyGTK2

Adicionar:

        self.window.set_keep_below(True)
        self.window.set_opacity(0.0)
        self.window.set_decorated(False)
        self.window.set_position(gtk.WIN_POS_CENTER_ALWAYS)

parahelloworld.py

#!/usr/bin/env python

# example helloworld.py

import pygtk
pygtk.require('2.0')
import gtk

class HelloWorld:

    # This is a callback function. The data arguments are ignored
    # in this example. More on callbacks below.
    def hello(self, widget, data=None):
        print "Hello World"

    def delete_event(self, widget, event, data=None):
        # If you return FALSE in the "delete_event" signal handler,
        # GTK will emit the "destroy" signal. Returning TRUE means
        # you don't want the window to be destroyed.
        # This is useful for popping up 'are you sure you want to quit?'
        # type dialogs.
        print "delete event occurred"

        # Change FALSE to TRUE and the main window will not be destroyed
        # with a "delete_event".
        return False

    def destroy(self, widget, data=None):
        print "destroy signal occurred"
        gtk.main_quit()

    def __init__(self):
        # create a new window
        self.window = gtk.Window(gtk.WINDOW_TOPLEVEL)

        # Add these
        self.window.set_keep_below(True)
        self.window.set_opacity(0.0)
        self.window.set_decorated(False)
        self.window.set_position(gtk.WIN_POS_CENTER_ALWAYS)

        # When the window is given the "delete_event" signal (this is given
        # by the window manager, usually by the "close" option, or on the
        # titlebar), we ask it to call the delete_event () function
        # as defined above. The data passed to the callback
        # function is NULL and is ignored in the callback function.
        self.window.connect("delete_event", self.delete_event)

        # Here we connect the "destroy" event to a signal handler.
        # This event occurs when we call gtk_widget_destroy() on the window,
        # or if we return FALSE in the "delete_event" callback.
        self.window.connect("destroy", self.destroy)

        # Sets the border width of the window.
        self.window.set_border_width(10)

        # Creates a new button with the label "Hello World".
        self.button = gtk.Button("Hello World")

        # When the button receives the "clicked" signal, it will call the
        # function hello() passing it None as its argument.  The hello()
        # function is defined above.
        self.button.connect("clicked", self.hello, None)

        # This will cause the window to be destroyed by calling
        # gtk_widget_destroy(window) when "clicked".  Again, the destroy
        # signal could come from here, or the window manager.
        self.button.connect_object("clicked", gtk.Widget.destroy, self.window)

        # This packs the button into the window (a GTK container).
        self.window.add(self.button)

        # The final step is to display this newly created widget.
        self.button.show()

        # and the window
        self.window.show()

    def main(self):
        # All PyGTK applications must have a gtk.main(). Control ends here
        # and waits for an event to occur (like a key press or mouse event).
        gtk.main()

# If the program is run directly or passed as an argument to the python
# interpreter then create a HelloWorld instance and show it
if __name__ == "__main__":
    hello = HelloWorld()
    hello.main()

Referências:
