Estou executando o FreeBSD 11RC2 com o driver Nvidia atual versão 367.44 e usando o módulo do kernel nvidia-modeset que é carregado na inicialização em meu

/etc/rc.conf

arquivo adicionando

kld_list="nvidia-modeset"

Aqui estão as informações sobre minha GPU

vgapci0@pci0:1:0:0: class=0x030000 card=0x0130106b chip=0x0fe910de rev=0xa1 hdr=0x00
    vendor     = 'NVIDIA Corporation'
    device     = 'GK107M [GeForce GT 750M Mac Edition]'
    class      = display
    subclass   = VGA
    cap 01[60] = powerspec 3  supports D0 D3  current D0
    cap 05[68] = MSI supports 1 message, 64 bit enabled with 1 message
    cap 10[78] = PCI-Express 2 endpoint max data 256(256) RO NS
                 link x8(x16) speed 8.0(8.0) ASPM L0s/L1(L0s/L1)
    cap 09[b4] = vendor (length 20)
    ecap 0002[100] = VC 1 max VC0
    ecap 0004[128] = Power Budgeting 1
    ecap 0001[420] = AER 2 0 fatal 0 non-fatal 0 corrected
    ecap 000b[600] = Vendor 1 ID 1
    ecap 0019[900] = PCIe Sec 1 lane errors 0

Aqui estão as informações acpi para esta máquina:http://paste2.org/LUcIwtzn

device  acpi
debug.acpi.resume_beep: 0
debug.acpi.batt.batt_sleep_ms: 0
debug.acpi.ec.timeout: 750
debug.acpi.ec.polled: 0
debug.acpi.ec.burst: 0
debug.acpi.cpu_unordered: 0
debug.acpi.suspend_bounce: 0
debug.acpi.reset_clock: 1
debug.acpi.default_register_width: 1
debug.acpi.interpreter_slack: 1
debug.acpi.enable_debug_objects: 0
debug.acpi.acpi_ca_version: 20160527
debug.acpi.max_threads: 3
debug.acpi.tasks_hiwater: 40
debug.acpi.max_tasks: 1024
hw.acpi.acline: 1
hw.acpi.battery.info_expire: 5
hw.acpi.battery.units: 1
hw.acpi.battery.state: 0
hw.acpi.battery.time: -1
hw.acpi.battery.life: 97
hw.acpi.cpu.cx_lowest: C2
hw.acpi.reset_video: 0
hw.acpi.handle_reboot: 1
hw.acpi.disable_on_reboot: 0
hw.acpi.verbose: 0
hw.acpi.s4bios: 0
hw.acpi.sleep_delay: 1
hw.acpi.suspend_state: S3
hw.acpi.standby_state: NONE
hw.acpi.lid_switch_state: NONE
hw.acpi.sleep_button_state: S3
hw.acpi.power_button_state: S5
hw.acpi.supported_sleep_state: S3 S4 S5
machdep.idle: acpi
machdep.idle_available: spin, mwait, hlt, acpi
machdep.acpi_root: 2061033492
machdep.acpi_timer_freq: 3579545
dev.acpi_perf.7.%parent: cpu7
dev.acpi_perf.7.%pnpinfo:
dev.acpi_perf.7.%location:
dev.acpi_perf.7.%driver: acpi_perf
dev.acpi_perf.7.%desc:
dev.acpi_perf.6.%parent: cpu6
dev.acpi_perf.6.%pnpinfo:
dev.acpi_perf.6.%location:
dev.acpi_perf.6.%driver: acpi_perf
dev.acpi_perf.6.%desc:
dev.acpi_perf.5.%parent: cpu5
dev.acpi_perf.5.%pnpinfo:
dev.acpi_perf.5.%location:
dev.acpi_perf.5.%driver: acpi_perf
dev.acpi_perf.5.%desc:
dev.acpi_perf.4.%parent: cpu4
dev.acpi_perf.4.%pnpinfo:
dev.acpi_perf.4.%location:
dev.acpi_perf.4.%driver: acpi_perf
dev.acpi_perf.4.%desc:
dev.acpi_perf.3.%parent: cpu3
dev.acpi_perf.3.%pnpinfo:
dev.acpi_perf.3.%location:
dev.acpi_perf.3.%driver: acpi_perf
dev.acpi_perf.3.%desc:
dev.acpi_perf.2.%parent: cpu2
dev.acpi_perf.2.%pnpinfo:
dev.acpi_perf.2.%location:
dev.acpi_perf.2.%driver: acpi_perf
dev.acpi_perf.2.%desc:
dev.acpi_perf.1.%parent: cpu1
dev.acpi_perf.1.%pnpinfo:
dev.acpi_perf.1.%location:
dev.acpi_perf.1.%driver: acpi_perf
dev.acpi_perf.1.%desc:
dev.acpi_perf.0.%parent: cpu0
dev.acpi_perf.0.%pnpinfo:
dev.acpi_perf.0.%location:
dev.acpi_perf.0.%driver: acpi_perf
dev.acpi_perf.0.%desc:
dev.acpi_perf.%parent:
dev.fpupnp.0.%parent: acpi0
dev.atdma.0.%parent: acpi0
dev.acpi_button.1.%parent: acpi0
dev.acpi_button.1.%pnpinfo: _HID=PNP0C0E _UID=0
dev.acpi_button.1.%location: handle=\_SB_.SLPB
dev.acpi_button.1.%driver: acpi_button
dev.acpi_button.1.%desc: Sleep Button
dev.acpi_button.0.%parent: acpi0
dev.acpi_button.0.%pnpinfo: _HID=PNP0C0C _UID=0
dev.acpi_button.0.%location: handle=\_SB_.PWRB
dev.acpi_button.0.%driver: acpi_button
dev.acpi_button.0.%desc: Power Button
dev.acpi_button.%parent:
dev.acpi_lid.0.wake: 1
dev.acpi_lid.0.%parent: acpi0
dev.acpi_lid.0.%pnpinfo: _HID=PNP0C0D _UID=0
dev.acpi_lid.0.%location: handle=\_SB_.LID0
dev.acpi_lid.0.%driver: acpi_lid
dev.acpi_lid.0.%desc: Control Method Lid Switch
dev.acpi_lid.%parent:
dev.acpi_acad.0.wake: 0
dev.acpi_acad.0.%parent: acpi0
dev.acpi_acad.0.%pnpinfo: _HID=ACPI0003 _UID=0
dev.acpi_acad.0.%location: handle=\_SB_.ADP1
dev.acpi_acad.0.%driver: acpi_acad
dev.acpi_acad.0.%desc: AC Adapter
dev.acpi_acad.%parent:
dev.battery.0.%parent: acpi0
dev.pcib.0.%parent: acpi0
dev.pci_link.7.%parent: acpi0
dev.pci_link.6.%parent: acpi0
dev.pci_link.5.%parent: acpi0
dev.pci_link.4.%parent: acpi0
dev.pci_link.3.%parent: acpi0
dev.pci_link.2.%parent: acpi0
dev.pci_link.1.%parent: acpi0
dev.pci_link.0.%parent: acpi0
dev.acpi_timer.0.%parent: acpi0
dev.acpi_timer.0.%pnpinfo: unknown
dev.acpi_timer.0.%location: unknown
dev.acpi_timer.0.%driver: acpi_timer
dev.acpi_timer.0.%desc: 24-bit timer at 3.579545MHz
dev.acpi_timer.%parent:
dev.attimer.0.%parent: acpi0
dev.atrtc.0.%parent: acpi0
dev.cpu.7.%parent: acpi0
dev.cpu.6.%parent: acpi0
dev.cpu.5.%parent: acpi0
dev.cpu.4.%parent: acpi0
dev.cpu.3.%parent: acpi0
dev.cpu.2.%parent: acpi0
dev.cpu.1.%parent: acpi0
dev.cpu.0.%parent: acpi0
dev.acpi_sysresource.2.%parent: acpi0
dev.acpi_sysresource.2.%pnpinfo: _HID=PNP0C01 _UID=2
dev.acpi_sysresource.2.%location: handle=\_SB_.MEM2
dev.acpi_sysresource.2.%driver: acpi_sysresource
dev.acpi_sysresource.2.%desc: System Resource
dev.acpi_sysresource.1.%parent: acpi0
dev.acpi_sysresource.1.%pnpinfo: _HID=PNP0C02 _UID=1
dev.acpi_sysresource.1.%location: handle=\_SB_.PCI0.PDRC
dev.acpi_sysresource.1.%driver: acpi_sysresource
dev.acpi_sysresource.1.%desc: System Resource
dev.acpi_sysresource.0.%parent: acpi0
dev.acpi_sysresource.0.%pnpinfo: _HID=PNP0C02 _UID=2
dev.acpi_sysresource.0.%location: handle=\_SB_.PCI0.LPCB.LDRC
dev.acpi_sysresource.0.%driver: acpi_sysresource
dev.acpi_sysresource.0.%desc: System Resource
dev.acpi_sysresource.%parent:
dev.hpet.0.%parent: acpi0
dev.acpi_ec.0.wake: 0
dev.acpi_ec.0.%parent: acpi0
dev.acpi_ec.0.%pnpinfo: _HID=PNP0C09 _UID=0
dev.acpi_ec.0.%location: handle=\_SB_.PCI0.LPCB.EC__
dev.acpi_ec.0.%driver: acpi_ec
dev.acpi_ec.0.%desc: Embedded Controller: GPE 0x17, ECDT
dev.acpi_ec.%parent:
dev.acpi.0.%parent: nexus0
dev.acpi.0.%pnpinfo:
dev.acpi.0.%location:
dev.acpi.0.%driver: acpi
dev.acpi.0.%desc: APPLE Apple00
dev.acpi.%parent:

Eu vim rodando Linux e normalmente há um vídeo ou algumas configurações de acpi que controlam o brilho da tela, mas no FreeBSD, não parece haver nada parecido com isso, então meu monitor está constantemente com 100% de brilho. Não deveria haver alguma maneira de diminuir o brilho através da interface acpi?

Posso obter algum suporte para diminuir o brilho da tela?

[editar] Aqui está a saída do meu xorg.conf

# nvidia-xconfig: X configuration file generated by nvidia-xconfig
# nvidia-xconfig:  version 367.35  Wed Sep  7 17:03:49 CST 2016

Section "ServerLayout"
    Identifier     "Layout0"
    Screen      0  "Screen0"
    InputDevice    "Keyboard0" "CoreKeyboard"
    InputDevice    "Mouse0" "CorePointer"
EndSection

Section "Files"
EndSection

Section "InputDevice"
    # generated from default
    Identifier     "Mouse0"
    Driver         "mouse"
    Option         "Protocol" "auto"
    Option         "Device" "/dev/sysmouse"
    Option         "Emulate3Buttons" "no"
    Option         "ZAxisMapping" "4 5"
EndSection

Section "InputDevice"
    # generated from default
    Identifier     "Keyboard0"
    Driver         "keyboard"
EndSection

Section "Monitor"
    Identifier     "Monitor0"
    VendorName     "Unknown"
    ModelName      "Unknown"
    HorizSync       28.0 - 33.0
    VertRefresh     43.0 - 72.0
    Option         "DPMS"
EndSection

Section "Device"
    Identifier     "Device0"
    Driver         "nvidia"
    VendorName     "NVIDIA Corporation"
EndSection

Section "Screen"
    Identifier     "Screen0"
    Device         "Device0"
    Monitor        "Monitor0"
    DefaultDepth    24
    SubSection     "Display"
        Depth       24
    EndSubSection
EndSection

Responder1

Tive dificuldades com o brilho no Dell L702X com Nvidia GT550M. Você pode ver o que encontrei emeste tópico (link). Talvez algumas dessas coisas funcionem para você.

Não consegui usar xbacklight(1)(ou ativar as teclas de controle de brilho), mas encontrei algumas outras maneiras de alterar o brilho:

  • xrandr(1)

Graças aesta postagem (link)Consegui alterar o brilho do monitor externo usando o xrandr. O comando fica assim:

    xrandr --output HDMI-0 --brightness 0.9

O valor padrão parece ser 1.

  • redshift(1)

    Redshift é um software que permite alterar a temperatura da tela. Possui -bopções -tque -gpodem ser úteis (veja man redshiftpara mais detalhes).
