Сделать longtable (в альбомной ориентации) шире textwidth

tag-icon • tag-icon tables longtable koma-script scaling landscape
Сделать longtable (в альбомной ориентации) шире textwidth

Предположим, у меня есть таблица, занимающая несколько страниц.

\documentclass[DIV=8]{scrartcl}
\usepackage[utf8]{inputenc}
\usepackage[english]{babel}
\usepackage{booktabs,array,ragged2e,longtable}
\newcolumntype{P}[1]{>{\RaggedRight\arraybackslash}p{#1\textwidth}}

\usepackage{enumitem}
%% Create a very compact itemized list environment
\newlist{mylist}{itemize}{1}
\setlist[mylist]{label=\textbullet, nosep, wide,
                 leftmargin=*, % hanging indentation
                 before=\vspace{-0.50\baselineskip},
                 after =\vspace{-0.8\baselineskip}}
\begin{document}

% keep scope of longtable-related instructions local to current TeX group
\begingroup
\setlength\tabcolsep{0pt} % <--- important
\setlength\LTleft{0pt}
\setlength\LTright{0pt}

\begin{longtable}{@{\extracolsep{\fill}}P{0.38}P{0.38}P{0.2}}

\caption{My caption} \label{my-label}\\
\toprule
Column 1 & Column 2 & Column 3 \\
\midrule
\endfirsthead

\multicolumn{3}{l}{(Table \ref{my-label}, cont'd)}\\ % re-state table number
\addlinespace
\toprule
Column 1 & Column 2 & Column 3 \\
\midrule
\endhead

\bottomrule
\addlinespace
\multicolumn{3}{r}{(cont'd on next page)}\\
\endfoot

\bottomrule
\endlastfoot

\begin{mylist}
     \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua. At vero eos et accusam et justo duo dolores et ea rebum. Stet clita
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\addlinespace

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\addlinespace

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\addlinespace

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

%\addlinespace % omit if at page break

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\end{longtable}
\endgroup % end of TeX group that encases the 'longtable' material

\end{document}

Код скопирован и вставлен изздесь, благодаряМико.

Я хочу ориентировать таблицу в альбомной ориентации. Когда я использую begin{landscape}с \documentclass[DIV=8]{scrartcl}, проблема, с которой я сталкиваюсь, заключается в том, что таблица имеет только такую ​​"длинную/глубокую" ширину, как ширина моего текста. Это приводит к тому, что на странице оказывается всего две или три строки... Есть ли способ заставить latex перекрыть ширину текста с таблицей?

решение1

Это использует \newgeometryи \restoregeometryдля увеличения текстовой области. Это \ruleпросто для демонстрации доступного пространства.

\documentclass[DIV=8]{scrartcl}
\usepackage{geometry}
\usepackage[utf8]{inputenc}
\usepackage[english]{babel}
\usepackage{pdflscape}
\usepackage{afterpage}
\usepackage{booktabs,array,ragged2e,longtable}
\newcolumntype{P}[1]{>{\RaggedRight\arraybackslash}p{#1\textwidth}}

\usepackage{enumitem}
%% Create a very compact itemized list environment
\newlist{mylist}{itemize}{1}
\setlist[mylist]{label=\textbullet, nosep, wide,
                 leftmargin=*, % hanging indentation
                 before=\vspace{-0.50\baselineskip},
                 after =\vspace{-0.8\baselineskip}}
\usepackage{lipsum}% mwe only
\begin{document}

% keep scope of longtable-related instructions local to current TeX group
\afterpage{%
\newgeometry{textwidth={\dimexpr \textwidth+2cm}}
\begin{landscape}
\noindent\rule{\linewidth}{\textheight}% show available space
\setlength\tabcolsep{0pt} % <--- important
\setlength\LTleft{0pt}
\setlength\LTright{0pt}

\begin{longtable}{@{\extracolsep{\fill}}P{0.38}P{0.38}P{0.2}}

\caption{My caption} \label{my-label}\\
\toprule
Column 1 & Column 2 & Column 3 \\
\midrule
\endfirsthead

\multicolumn{3}{l}{(Table \ref{my-label}, cont'd)}\\ % re-state table number
\addlinespace
\toprule
Column 1 & Column 2 & Column 3 \\
\midrule
\endhead

\bottomrule
\addlinespace
\multicolumn{3}{r}{(cont'd on next page)}\\
\endfoot

\bottomrule
\endlastfoot

\begin{mylist}
     \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua. At vero eos et accusam et justo duo dolores et ea rebum. Stet clita
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\addlinespace

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\addlinespace

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\addlinespace

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

%\addlinespace % omit if at page break

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\end{longtable}
\end{landscape}
\restoregeometry}

\lipsum[1-8]

\end{document}
