Как изменить логотипы на черный цвет с помощью bclogo.sty

Возможно ли изменить \bclampeцвет на черный? Мои теги следующие:

\documentclass{book}
\usepackage{environ} %fancy boxes
\usepackage{tikz}
\usetikzlibrary{patterns,shapes,arrows,calc,decorations.pathmorphing,backgrounds,graphs,positioning,fit,petri}
\tikzstyle{cuadricula}=[gray ,thick,dashed] %style for tike grids
\usetikzlibrary{decorations}
\usepackage{pgfplots} \pgfplotsset{compat=1.7}
\usepackage[tikz]{bclogo}

\NewEnviron{myidea}[1]
  {\par\medskip\noindent
  \begin{tikzpicture}
    \node[inner sep=0pt] (box) {\parbox[t]{.99\textwidth}{%
      \begin{minipage}{.3\textwidth}
      \centering\tikz[scale=5]\node[scale=2,rotate=30]{\bclampe};
      \end{minipage}%
      \begin{minipage}{.65\textwidth}
      \textbf{#1}\par\smallskip
      \BODY
      \end{minipage}\hfill}%
    };
    \draw[black,line width=3pt]
      ( $ (box.north east) + (-5pt,3pt) $ ) -- ( $ (box.north east) + (0,3pt) $ ) -- ( $ (box.south east) + (0,-3pt) $ ) -- + (-5pt,0);
    \draw[black,line width=3pt]
      ( $ (box.north west) + (5pt,3pt) $ ) -- ( $ (box.north west) + (0,3pt) $ ) -- ( $ (box.south west) + (0,-3pt) $ ) -- + (5pt,0);
  \end{tikzpicture}\par\medskip%
}

\begin{document}

\begin{myidea}{Title}
This is for test. This is for test. This is for test. This is for test. This is for test. This is for test.
This is for test. This is for test. This is for test. This is for test. This is for test. This is for test.
This is for test. This is for test. This is for test. This is for test. This is for test. This is for test.
This is for test. This is for test. This is for test. This is for test. This is for test. This is for test.
\end{myidea}

\end{document}

PS: Мне нужно, чтобы все логотипы были только черного цвета...

решение1

Логотипы bclogoнарисованы с помощью Metapost.

Найдите bc-lampe.mpв своей системе. Скопируйте его в свой рабочий каталог как bc-lampe-bw.mp.

Откройте файл и измените

drawoptions (withcolor (1.000000,1.000000,0.000000));

в

drawoptions (withcolor (1.000000,1.000000,1.000000));

Здесь используется желтый цвет, преобразованный в белый.

Запустите Metapost для файла.

В вашем документе добавьте

\newcommand{\bclampebw}{\includegraphics[width=\logowidth]{bc-lampe-bw}}

и в вашем коде измените \bclampeна \bclampebw.

введите описание изображения здесь

Это файл bc-lampe-bw.mp(уже с изменениями)

prologues:=1;
outputtemplate:="%j.mps";
beginfig(1);
linecap := butt;
fill (7.386720,3.144530)--(9.726560,3.144530)--(9.726560,5.484380)
    --(7.386720,5.484380)--cycle;
pickup pencircle scaled 0.600000bp;
draw (7.386720,3.144530)--(9.726560,3.144530)--(9.726560,5.484380)
    --(7.386720,5.484380)--cycle;
drawoptions (withcolor (1.000000,1.000000,1.000000));
pickup pencircle scaled 0.000000bp;
fill (9.726560,5.484380)--(9.726560,6.261720)..controls (9.726560,8.601560) and (10.894500,8.992190)..(11.675800,10.160200)
    ..controls (12.843800,12.109400) and (12.066400,15.621100)..(8.558590,15.621100)
    ..controls (5.046880,15.621100) and (4.269530,12.109400)..(5.437500,10.160200)
    ..controls (6.218750,8.992190) and (7.386720,8.601560)..(7.386720,6.261720)
    --(7.386720,5.484380)--cycle;
drawoptions (withcolor (0.000000,0.000000,0.000000));
pickup pencircle scaled 0.600000bp;
draw (9.726560,5.484380)--(9.726560,6.261720)..controls (9.726560,8.601560) and (10.894500,8.992190)..(11.675800,10.160200)
    ..controls (12.843800,12.109400) and (12.066400,15.621100)..(8.558590,15.621100)
    ..controls (5.046880,15.621100) and (4.269530,12.109400)..(5.437500,10.160200)
    ..controls (6.218750,8.992190) and (7.386720,8.601560)..(7.386720,6.261720)
    --(7.386720,5.484380);
draw (6.609380,4.312500)--(10.507800,4.312500);
pickup pencircle scaled 0.200000bp;
draw (8.558590,3.535160)..controls (8.945310,7.042970) and (8.167970,10.160200)..(10.117200,11.722700)
    ..controls (9.335940,12.890600) and (7.386720,12.500000)..(6.996090,11.722700)
    ..controls (8.945310,10.160200) and (8.167970,7.042970)..(8.558590,3.535160);
pickup pencircle scaled 0.600000bp;
draw (4.660160,16.007799)--(2.320310,18.347700);
draw (8.558590,17.570299)--(8.558590,20.296900);
draw (12.457000,15.621100)--(14.882800,17.660200);
draw (13.625000,12.890600)--(15.964800,12.890600);
draw (3.488280,12.890600)--(0.761719,12.890600);
r:=17pt/(xpart(urcorner(currentpicture))-xpart(ulcorner(currentpicture)));
picture pic;
pic:=currentpicture;
currentpicture:=nullpicture;
drawoptions();
draw pic scaled(r);
z0=.5*urcorner(currentpicture)+.5*ulcorner(currentpicture);
z1=.5*lrcorner(currentpicture)+.5*llcorner(currentpicture);
draw (z0+(10.5,2));
draw (z1-(10.5,2));
clip currentpicture to ((z0-(8.5pt,0))--(z0+(8.5pt,0))--(z1+(8.5pt,-2pt))--(z1-(8.5pt,2pt))--cycle);
endfig;
end

Насколько я могу судить, bclogoвыпущен под LLPL 1.3, поэтому изменение файла разрешено (также изменение имени, что не обязательно, но желательно).
