У меня есть инлайн-эквация внутри item-environment. Проблема в том, чтобы выровнять вторую линию по правой стороне. Как этого добиться?
\documentclass[a4paper,twocolumn]{scrbook}
\usepackage[T1]{fontenc}
\usepackage[utf8]{inputenc}
\usepackage{lmodern}
\usepackage{enumerate}
\usepackage{amsmath}
\begin{document}
\begin{enumerate}
\item Theoretically, the calculated voltage should be
correspond to the measured voltage. But in practice it is
often \emph{not} the case. There are small deviations. Calculate first
the absolute deviations according to the rule:\\
\medskip{}\\
$\left\langle\text{absolute deviation}\right\rangle = \\ \left\langle\text{calc. value}\right\rangle - \left\langle\text{measured value}\right\rangle$\\
\medskip{}\\
The ,,measured value`` here is of course the ,,measured voltage``.\\
Calculate all absolute deviations and enter the results in the
table.
\item Further steps
\end{enumerate}
\end{document}
решение1
LaTeX не является текстовым процессором. Использование \\
должно быть ограничено там, где необходимо явное завершение строк.
\documentclass[a4paper,twocolumn]{scrbook}
\usepackage[T1]{fontenc}
\usepackage[utf8]{inputenc}
\usepackage{lmodern}
\usepackage{enumerate}
\usepackage{amsmath}
\setlength{\multlinegap}{0pt}
\begin{document}
\begin{enumerate}
\item Theoretically, the calculated voltage should be
correspond to the measured voltage. But in practice it is
often \emph{not} the case. There are small deviations. Calculate first
the absolute deviations according to the rule:
\begin{multline*}
\langle\text{absolute deviation}\rangle = \\
\langle\text{calc.\ value}\rangle - \langle\text{measured value}\rangle
\end{multline*}
The ,,measured value`` here is of course the ,,measured voltage``.
Calculate all absolute deviations and enter the results in the
table.
\item Further steps
\end{enumerate}
\end{document}
Я также удалил \left
и \right
это не делает ничего полезного в этой формуле.
Примечание calc.\ value
, чтобы избежать точки в конце предложения. Это также может быть calc.\@ value
.
решение2
Хитрость заключается в том, чтобы использовать a \hfill
перед второй строкой, но с a \mbox{}
перед ней, потому что \hfill
в самом начале строки это не работает.
\documentclass[a4paper,twocolumn]{scrbook}
\usepackage[T1]{fontenc}
\usepackage[utf8]{inputenc}
\usepackage{lmodern}
\usepackage{enumerate}
\usepackage{amsmath}
\begin{document}
\begin{enumerate}
\item Theoretically, the calculated voltage should be
correspond to the measured voltage. But in practice it is
often \emph{not} the case. There are small deviations. Calculate first
the absolute deviations according to the rule:\\
\medskip{}\\
$\left\langle\text{absolute deviation}\right\rangle = \\ \mbox{}\hfill \left\langle\text{calc. value}\right\rangle - \left\langle\text{measured value}\right\rangle$\\
\medskip{}\\
The ,,measured value`` here is of course the ,,measured voltage``.\\
Calculate all absolute deviations and enter the results in the
table.
\item Further steps
\end{enumerate}
\end{document}
