lshw 工具和傳回的選項及其意義

該工具lshw報告有關所有連接硬體的資訊。

有些報告的選項和功能夠簡單易懂，而有些則不然。

找到的文檔頁面這裡和專案頁面不要定義所有這些功能及其描述。

一個例子：

sudo lshw -C net

  *-usb:1
       description: Wireless interface
       product: USB2.0 WLAN
       vendor: ATHEROS
       physical id: 3
       bus info: usb@1:1.3
       logical name: wlan2
       version: 1.08
       serial: 12345
       capabilities: usb-2.00 ethernet physical wireless
       configuration: broadcast=yes driver=ath9k_htc driverversion=4.9.35-v7+ firmware=1.3 ip=192.168.2.254 link=yes maxpower=500mA multicast=yes speed=480Mbit/s wireless=IEEE 802.11
  *-usb:2
       description: Wireless interface
       product: 802.11n NIC
       vendor: Realtek
       physical id: 4
       bus info: usb@1:1.4
       logical name: wlan1
       version: 0.00
       serial: 123456
       capabilities: usb-2.00 ethernet physical wireless
       configuration: broadcast=yes driver=rtl8812au ip=192.168.1.254 maxpower=500mA multicast=yes speed=480Mbit/s wireless=IEEE 802.11AC
  *-network:0
       description: Wireless interface
       physical id: 2
       logical name: wlan0
       serial: b8:27:eb:b0:32:ae
       capabilities: ethernet physical wireless
       configuration: broadcast=yes driver=brcmfmac driverversion=7.45.41.26 firmware=01-df77e4a7 ip=192.168.8.254 multicast=yes wireless=IEEE 802.11
  *-network:1
       description: Ethernet interface
       physical id: 3
       logical name: eth0
       serial: b8:27:eb:e5:67:fb
       size: 100Mbit/s
       capacity: 100Mbit/s
       capabilities: ethernet physical tp mii 10bt 10bt-fd 100bt 100bt-fd autonegotiation
       configuration: autonegotiation=on broadcast=yes driver=smsc95xx driverversion=22-Aug-2005 duplex=full firmware=smsc95xx USB 2.0 Ethernet ip=192.168.0.254 link=yes multicast=yes port=MII speed=100Mbit/s

透過查看每個 NIC，我們可以推斷出以下內容：

  1. 網路卡有4個，其中2個是USB網路卡

  2. 可以看到連結速度、實體位址、IP位址、邏輯名稱、驅動程式名稱等。

  3. 此外，如果適配器支援多播、廣播等。

問題：

然而，像（可能還有其他）這樣的選項link尚不清楚或無法理解，任何文件中也沒有給出任何定義或描述。

這些配置/功能的描述記錄在哪裡？

答案1

找到了“能力”

命令：lshw -class network -json

    "capabilities" : {
      "pm" : "Power Management",
      "msi" : "Message Signalled Interrupts",
      "msix" : "MSI-X",
      "pciexpress" : "PCI Express",
      "bus_master" : "bus mastering",
      "cap_list" : "PCI capabilities listing",
      "rom" : "extension ROM",
      "ethernet" : true,
      "physical" : "Physical interface",
      "tp" : "twisted pair",
      "10bt-fd" : "10Mbit/s (full duplex)",
      "100bt-fd" : "100Mbit/s (full duplex)",
      "1000bt-fd" : "1Gbit/s (full duplex)",
      "autonegotiation" : "Auto-negotiation"}
