我剛剛在樹莓派 v3 上安裝了以下設置，其 IP 192.168.1.2：
- 首先，我安裝了PiHole
- 然後我安裝了PiVPN
- 做了一項調整
/etc/openvpn/server.conf：我註解掉了現有的dhcp-options並添加了PiHole_IP 在push "dhcp-option DNS 192.168.1.2"哪裡192.168.1.2 - 我為我的手機創建了一個證書
我可以從手機連接到 VPN，但如果我嘗試打開任何網站，我不會收到任何回應。如果我嘗試在區域網路上找到任何客戶端，我也不會得到任何回應。
以下是日誌，取自我手機的開放 VPN 應用程式：
2018-02-10 14:02:41 1
2018-02-10 14:02:41 ----- OpenVPN Start -----
OpenVPN core 3.2 ios arm64 64-bit PT_PROXY built on Oct 3 2018 06:35:04
2018-02-10 14:02:41 Frame=512/2048/512 mssfix-ctrl=1250
2018-02-10 14:02:41 UNUSED OPTIONS
4 [resolv-retry] [infinite]
5 [nobind]
6 [persist-key]
7 [persist-tun]
10 [verify-x509-name] [server_HASH] [name]
14 [verb] [3]
2018-02-10 14:02:41 EVENT: RESOLVE
2018-02-10 14:02:41 Contacting [MY_EXTERNAL_IP]:1194/UDP via UDP
2018-02-10 14:02:41 EVENT: WAIT
2018-02-10 14:02:41 Connecting to [MY_DNS_NAME]:1194 (MY_EXTERNAL_IP) via UDPv4
2018-02-10 14:02:41 EVENT: CONNECTING
2018-02-10 14:02:41 Tunnel Options:V4,dev-type tun,link-mtu 1570,tun-mtu 1500,proto UDPv4,comp-lzo,cipher AES-256-CBC,auth SHA256,keysize 256,key-method 2,tls-client
2018-02-10 14:02:41 Creds: UsernameEmpty/PasswordEmpty
2018-02-10 14:02:41 Peer Info:
IV_GUI_VER=net.openvpn.connect.ios 3.0.2-894
IV_VER=3.2
IV_PLAT=ios
IV_NCP=2
IV_TCPNL=1
IV_PROTO=2
IV_LZO_STUB=1
IV_COMP_STUB=1
IV_COMP_STUBv2=1
IV_AUTO_SESS=1
2018-02-10 14:02:42 VERIFY OK : depth=1
cert. version : 3
serial number : A7:A9:F2:46:05:5B:BD:D8
issuer name : CN=ChangeMe
subject name : CN=ChangeMe
issued on : 2018-10-10 16:04:51
expires on : 2028-10-07 16:04:51
signed using : RSA with SHA-256
RSA key size : 4096 bits
basic constraints : CA=true
key usage : Key Cert Sign, CRL Sign
2018-02-10 14:02:42 VERIFY OK : depth=0
cert. version : 3
serial number : 01
issuer name : CN=ChangeMe
subject name : CN=server_HASH
issued on : 2018-10-10 16:05:10
expires on : 2028-10-07 16:05:10
signed using : RSA with SHA-256
RSA key size : 4096 bits
basic constraints : CA=false
key usage : Digital Signature, Key Encipherment
ext key usage : TLS Web Server Authentication
2018-02-10 14:02:42 SSL Handshake: TLSv1.2/TLS-ECDHE-RSA-WITH-AES-256-GCM-SHA384
2018-02-10 14:02:42 Session is ACTIVE
2018-02-10 14:02:42 EVENT: GET_CONFIG
2018-02-10 14:02:42 Sending PUSH_REQUEST to server...
2018-02-10 14:02:42 OPTIONS:
0 [dhcp-option] [DNS] [192.168.1.2]
1 [block-outside-dns]
2 [redirect-gateway] [def1]
3 [route-gateway] [10.8.0.1]
4 [topology] [subnet]
5 [ping] [1800]
6 [ping-restart] [3600]
7 [ifconfig] [10.8.0.2] [255.255.255.0]
8 [peer-id] [0]
9 [cipher] [AES-256-GCM]
2018-02-10 14:02:42 PROTOCOL OPTIONS:
cipher: AES-256-GCM
digest: SHA256
compress: COMP_STUB
peer ID: 0
2018-02-10 14:02:42 EVENT: ASSIGN_IP
2018-02-10 14:02:42 NIP: preparing TUN network settings
2018-02-10 14:02:42 NIP: init TUN network settings with endpoint: MY_EXTERNAL_IP
2018-02-10 14:02:42 NIP: adding IPv4 address to network settings 10.8.0.2/255.255.255.0
2018-02-10 14:02:42 NIP: adding (included) IPv4 route 10.8.0.0/24
2018-02-10 14:02:42 NIP: redirecting all IPv4 traffic to TUN interface
2018-02-10 14:02:42 NIP: adding DNS 192.168.1.2
2018-02-10 14:02:42 Connected via NetworkExtensionTUN
2018-02-10 14:02:42 LZO-ASYM init swap=0 asym=1
2018-02-10 14:02:42 Comp-stub init swap=1
2018-02-10 14:02:42 EVENT: CONNECTED MY_DNS_NAME.com:1194 (MY_EXTERNAL_IP) via /UDPv4 on NetworkExtensionTUN/10.8.0.2/ gw=[/]
這是server.conf我透過添加/刪除 dhcp-options 進行的稍微修改，如上所述：
dev tun
proto udp
port 1194
ca /etc/openvpn/easy-rsa/pki/ca.crt
cert /etc/openvpn/easy-rsa/pki/issued/server_HASH.crt
key /etc/openvpn/easy-rsa/pki/private/server_HASH.key
dh none
ecdh-curve secp384r1
topology subnet
server 10.8.0.0 255.255.255.0
# Set your primary domain name server address for clients
#push "dhcp-option DNS 1.1.1.1"
#push "dhcp-option DNS 1.0.0.1"
push "dhcp-option DNS 192.168.1.2"
# Prevent DNS leaks on Windows
push "block-outside-dns"
# Override the Client default gateway by using 0.0.0.0/1 and
# 128.0.0.0/1 rather than 0.0.0.0/0. This has the benefit of
# overriding but not wiping out the original default gateway.
push "redirect-gateway def1"
client-to-client
keepalive 1800 3600
remote-cert-tls client
tls-version-min 1.2
tls-crypt /etc/openvpn/easy-rsa/pki/ta.key
cipher AES-256-CBC
auth SHA256
compress lz4
user nobody
group nogroup
persist-key
persist-tun
crl-verify /etc/openvpn/crl.pem
status /var/log/openvpn-status.log 20
status-version 3
syslog
verb 3
#DuplicateCNs allow access control on a less-granular, per user basis.
#Remove # if you will manage access by user instead of device.
#duplicate-cn
# Generated for use by PiVPN.io
此外，我可以看到 PiHole 正在從 IP 10.0.8.2 取得請求，這些請求沒有被封鎖。我不知道從哪裡開始排除故障，並期待任何提示和指示:-)
答案1
除了刪除預設的 Google DNS 伺服器和推送“dhcp-選項 DNS 192.168.1.2”在伺服器設定檔，您已經完成了，請執行以下操作：
轉到
/etc/dnsmasq.d並建立一個新文件，例如自訂設定檔(sudo nano custom.conf)，內容如下：listen-address=127.0.0.1, 192.168.1.2, 10.8.0.1在哪裡192.168.1.2是您的 Pi-hole DNS 的位址，10.8.0.1是 PiVPN 網關。
這確保瞭如果 Pi-hole 更新，對其他 conf 檔案的更改不會被覆蓋。
透過執行重新啟動 OpenVPN 服務
sudo service openvpn restart
現在，當您從客戶端連接到 PiVPN 時，您應該能夠訪問互聯網，並且 Pi-hole 應該過濾所有廣告。
